1Mounting
Mounting instructions
General
Front cover
CleanSwitch
Seal
Surface-mounted box
IP seal (IP65)
EN 中文版
372494B
11/18
Secure surface-mounted box diagonally
with 2 screws
Attach the cover
at the top
Insert the seal as shown on the sur-
face-mounted box Dismantling
Press until
it clicks!
IP54IP65
Desired IP protection and cable routing
or IP54IP65 or
Pop out the window with pliers depend-
ing on the desired cable routing point
Pop out the cover
2Contact
CleanSwitch surface-mounted box
