BBQ Grillware GSF2616 Instruction Manual

GSF2616 owner’s manual 0
WARNING
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property
damage.
Read the installation, operation
and maintenance instructions
thoroughly before installing or
servicing this equipment.
DANDER
Failure to follow these
instructions could result in fire or
explosion which could cause
property damage, personal injury
or death.
DANGER!
DO NOT use gas grill for indoor
cooking or heating. TOXIC fumes
can accumulate and cause
asphyxiation. NOT to be used in
or on boats or recreational
vehicles.
3-Burner LP Gas Grill
PROP 65 WARNING
Chemicals known to the state of
California to cause cancer, birth
defects or other reproductive
harm are created by the
combustion of propane.
WARNING
FOR YOUR SAFETY :
For Outdoor Use Only
(outside any enclosure)
Printed in China
ITEM # 41590
SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. IF YOU ARE ASSEMBLING THIS UNIT FOR
SOMEONE ELSE, GIVE THIS MANUAL TO HIM OR HER
TO SAVE FOR FUTURE REFERENCE.
FOR CUSTOMER SERVICE, CALL 1-877-885-8227,
6 A.M. – 5 P.M. PST, MONDAY-FRIDAY.

GSF2616 owner’s manual 1
Table of Contents
For Your Safety...................................................................................................2
Illustrated Parts List ...........................................................................................4
Assembly Instructions........................................................................................6
Operating Your Grill Connecting Gas Cylinder....................................14
Check for Leaks....................................................14
Lighting Your Grill................................................14
Cleaning and Care................................................15
Award- Winning Barbecue Recipes..................................................................16
Gas Grill Troubleshooting.................................................................................17
Warranty Program..............................................................................................29
WARNING
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open Lid.
4. If odor continues, immediately
call your gas supplier or fire
department.
WARNING
FOR YOUR SAFETY
1. DO NOT store or use gasoline or
other flammable vapors and liquids
within 25 feet (8m) of this or any
other appliance.
2. When cooking with oil/grease, do
not allow the oil/grease to exceed
350° F (177°C). Do not store or use
extra cooking oil in the vicinity of
this or any other appliance.
3. An LP Cylinder not connected for
use shall NOT be stored within 10
feet (3m) of this or any other
appliance.

GSF2616 owner’s manual 2
Dear Valued Customer,
Congratulations on your new barbecue grill! You’ve made the right choice. In this manual, you will find assembly
instructions, suggestions for grilling and helpful hints, as well as guidelines for the safe operation, proper care and
use of your grill. Our expert staff strives to provide you with an easy to assemble product. Should you have any
questions, problems or missing parts with this product, please call our customer service department at 1-877-885-
8227 6:00am - 5:00pm (PST). Monday through Friday.
Safety First!
Read and understand all warnings and precautions prior to operating your grill.
DANGER
To prevent fire or explosion hazard when testing for a leak:
1. Always perform the “leak test” on page 14 before lighting the grill and each time the cylinder is connected for use.
2. Do not smoke or allow other sources of ignition in the area while conducting a leak test.
3. Conduct the leak test outdoors in a well-ventilated area.
4. Do not use matches, lighters or a flame to check for leaks.
5. Do not use grill until any and all leaks are corrected. If you are unable to stop a leak, disconnect the propane supply. Call a gas
appliance serviceman or your local propane gas supplier.
6. This grill is for use with propane gas only (propane gas cylinder not included).
7. Never attempt to attach this grill to the self-contained propane system of a camper trailer, motor home or house.
8. Never use charcoal or lighter fluid.
9. Do not use gasoline, kerosene or alcohol for lighting! The LP-gas supply cylinder must be constructed and marked in accordance
with the specifications for propane gas cylinders of the U.S. Department of Transportation (DOT) CFR 49. This outdoor cooking
appliance is not intended to be installed in or on recreation vehicles and/ or boats.
10. Do not attempt to move the grill while it is lit.
11. Do not use the grill unless it is COMPLETELY assembled and all parts are securely fastened and tightened.
12. Keep all combustible items and surfaces at least 20 inches (50.8 cm) away from the grill at all times. DO NOT use this gas grill or
any gas product under any overhead or near any unprotected combustible constructions.
13. Do not use in an explosive atmosphere. Keep grill area clear and free from combustible materials, gasoline and other flammable
vapors and liquids.
WARNING
1. This grill is for outside use only, and shall not be used in a building, garage or any other enclosed area.
2. The use of alcohol or prescription or non-prescription drugs may impair the consumer's ability to properly assemble or safely operate
the appliance.
3. Always open grill lid carefully and slowly as heat and steam trapped within grill can severely burn you.
4. Always place your grill on a hard, level surface far away from combustibles. An asphalt or blacktop surface may not be acceptable
for this purpose.
5. Do not leave a lit grill unattended, especially keep children and pets away from grill at all times.
6. This is not a table top grill. Therefore, do not place this grill on any type of tabletop surface.
7. Do not use grill in high winds.
CAUTION
1. Do not touch metal parts of grill until it has completely cooled (about 45 minutes.) to avoid burns, unless
you are wearing protective gear (pot holders, gloves, BBQ mittens, etc.).
2. Do not alter grill in any manner.
3. Clean and inspect the hose before each use of the appliance. If there is evidence of abrasion, wear, cuts, or leaks, the hose must
be replaced prior to the appliance being put into operation. The replacement hose assembly shall be that specified by the
manufacturer.
4. Move gas hoses as far away as possible from hot surfaces and dripping hot grease.
5. Never keep a filled container in a hot car or car trunk. Heat will cause the gas pressure to increase, which may open the relief valve
and allow gas to escape.
IMPORTANT NOTICE: READ ALL INSTRUCTIONS PRIOR TO ASSEMBLY AND USE!
NOTE: The use and installation of this product must conform to local codes. In absence of local codes, use the National Fuel Gas
Code
,
ANSI Z223.1
/
NFPA54.

GSF2616 owner’s manual 3
DANGER
Liquid propane (LP) gas is flammable and hazardous if handled improperly. Become aware of the characteristics before using any propane
product.
• Propane Characteristics: Flammable, explosive under pressure, heavier than air and settles in pools in low areas.
• In its natural state propane has no odor. For your safety, an odorant has been added.
• Contact with propane can cause freeze burns to skin.
• This grill is shipped from the factory for propane gas use only.
• Never use propane cylinder with a damaged body, valve, collar or footing.
• Dented or rusted propane cylinders may be hazardous and should be checked by your propane gas supplier.
• It maybe hazardous to attempt to fit other types of gas cylinder.
CAUTION
It is essential to keep the grill’s valve compartment, burners and circulating air passages clean.
Inspect grill before each use.
GENERAL INFORMATION
1. Propane gas cylinder required for operation.
2. This gas grill is NOT for commercial use!

GSF2616 owner’s manual 4
Illustrated parts list
1. Leg L-F ----------------------------1pc
2. Leg R-F ----------------------------1pc
3．Leg R-B --------------------------1pc
4．Leg L-B ---------------------------1pc
5. Left foot-----------------------------1pc 6. Right foot---------------------------1pc
7. Hub cap---------------------------2pcs
8. Wheel-----------------------------2pcs
9. Axle----------------------------------1pc
10. Cart front panel-down---------1pc
11. Cart front panel-top------------1pc
12. Top cart R-F-------------------1pc
13. Top cart L-F -------------------1pc
14. Top cart L-B ------------------1pc
15. Top cart R-B -------------------1pc
16. Control panel--------------------1pc
17. Cart beam----------------------2pcs
18. Cart back beam----------------1pc
19. Gas cylinder support----------1pc
20. Grill head assembly------------1pc
21. Left side shelf-------------------1pc
22. Right side shelf ----------------1pc
23. Side burner grate---------------1pc
24. Heating plate-------------------3pcs

GSF2616 owner’s manual 5
25. Cooking grids------------------2pcs
26. Warming rack- body-----------1pc
27. Warming rack-lid---------------1pc
28. Grease cup support------------1pc
29. Grease cup----------------------1pc
Hardware ( A screwdriver is also included for your convenience.)
A
M6 X 16mm
Bolt
27pcs B 2pcs
C
Side burner knob
1pc D
M10 mm
Axle Nut
2pcs
E
Phillips head
screwdriver
1pc F
Wrench
2pcs
M4 X 8 mm
Bolt

GSF2616 owner’s manual 6
Assembly Instructions
For best results
Remove all contents from packaging, and make sure all parts are present before attempting to assemble! Tighten all bolt connections by hand first, then
when the grill is fully assembled, go back and tighten.
It will take about 30 to 40 minutes to assemble this grill.

GSF2616 owner’s manual 7
Step 1
Connect the cart front panel-top with cart front
panel-down and install a let L-F and leg R-F at
the both side as shown.

GSF2616 owner’s manual 8
Step 2
Install the step 1 assembly and leg R-B and
leg L-B onto the right and left foot as shown.

GSF2616 owner’s manual 9
Step 3
Install the top cart R-F, L-F, L-B, R-B
onto the step 2 assembly as shown.

GSF2616 owner’s manual 10
Step 4
Install the control panel in the front of the
cart as shown.

GSF2616 owner’s manual 11
Step 5
Install the cart back beam at the
behind of the cart as shown.

GSF2616 owner’s manual 12
Step 6
Install the right and left side shelves as
shown.

GSF2616 owner’s manual 13
Step 7
Install the axle at the left foot and install
wheels and hub caps as shown.

GSF2616 owner’s manual 14
Step 8
Install the grill head assembly with
regulator onto the cart and as shown.

GSF2616 owner’s manual 15
Step 9
Install the cart beams at the both side
of the cart as shown.

GSF2616 owner’s manual 16
Step 10
Install the gas cylinder support on the left
cart beam as shown.

GSF2616 owner’s manual 17
Step 11
Install the side burner knob at the left
side shelf as shown.
Step 12
Install the side burner grate inside the left
side shelf and place heating plates into the
grill head assembly and then place cooking
grids upon them as shown.

GSF2616 owner’s manual 18

GSF2616 owner’s manual 19
Step 13
Install the warming rack-lid on the lid and
install the warming rack-body on the body
as shown.
