BCM MX266 User manual

COM Ports Settings
COM3 / 4 Pin 9 Signal Select (JP9, JP8)
MX266 COM3 / 4 pin 9 signal can be selected as +12V, +5V, or Ring by setting JP9 / JP8 /
JP4.
COM3 / COM4 / COM2 Select (JP9, JP8, JP4)
RI* +5V +12V
COM2 RS232/422/485 Select (JP5, JP6, JP7)
Mx266 COM2 serial port can be selected as RS-232, RS-422, or RS-485 by setting JP5, JP6,
JP7.
COM2 Select (JP5, JP6, JP7)
RS232* RS422 RS485
Serial Port Header CN26, CN27
Front Panel Connector CN1
Audio Header CN29
Line Out R 1 2 NC
GND 3 4 Mic VRef
Line In R 5 6 Line In L
Mic In 7 8 GND
NC 9 10 Line Out L
VCC5 1 2 VCC5
HD LED 3 4 GND
GND 5 6 PWRBTN
RST SW 7 8 GND
Reserved 9 10 NC
NC 10 5 GND
RI 9 4 TxD
CTS 8 3 SOUT
RTS 7 2 RxD
DSR 6 1 DCD
Clear CMOS JP1
ATX
Pow
er Connector Block
Normal (Default 1-2
Clear CMOS 2-3
3.3V 11 1 3.3V
-12V 12 2 3.3V
GND 13 3 GND
PS-ON 14 4 +5V
GND 15 5 GND
GND 16 6 +5V
GND 17 7 GND
+5V 18 8 PWROK
+5V 19 9 5VSB
+5V 20 10 +12V
JP5
1 3 5
2 4 6
2
4
6
1
3
5
JP6
JP7
1 3 5
2 4 6
1 3 5
2 4 6
1 3 5
2 4 6
1 3 5
2 4 6
1 3 5
2 4 6
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
MX266
MX266
With 1 GHz VIA Eden ESP10000 Processors
4 COM Port, Dual 10/100 LAN, PCI Riser up to 3 PCI Slots, Mini PCI
and 24/48bit LVDS DFP Support
User’s Quick Start Card Version 1.0 http://www.bcmcom.com
Inspect the Package:
One MX266 Motherboard
One IDE Cable (80 Pins)
One SATA Cable
Two COM port Cable (DB9)
One I/O Shield
One User’s Quick Start Card
One Driver CD (Manual/Drivers)
Responsibility:
This manual is provided “As-Is” with no warranties of any kind, it will neither expressed or
implied, including, but not limited to the implied warranties or conditions of this product’s fitness
for any particular purpose. In no event shall we be liable for any loss of profits, loss of business,
loss of data, interruption of business, or indirect, special, incidental, or consequential damages
of any kind, even the possibility of such damages arising from any defect or error in this manual
or product. We reserve the right to modify and update the user manual without prior notice.
WARNING: CMOS Battery Damage
Replace your system’s CMOS RAM battery only with the identical CR-2032 3V Lithium-Ion coin
cell (or equivalent) battery type to avoid risk of personal injury or physical damage to your
equipment. Always dispose of used batteries according to the manufacturer’s instructions, or
as required by the local ordinance (where applicable). The damage due to not following this
warning will void your motherboard’s manufacturer warranty.
ATTENTION: Incorrect BIOS Setup
If you do not know how to handle BIOS setup or how to set it up properly, it is strongly
advisable that you do not modify any of the settings than otherwise instructed in the User’s
Quick Start Card. Even a seemingly small incorrect adjustment or modification in the BIOS
setup can render your system unstable or unusable. The incorrect BIOS setup is not covered
by your motherboard’s manufacturer warranty.
Additional Information:
Additional information on setting this board up can be found in the User’s Manual in the
provided CD-ROM. The Online User’s Manual and FAQ/Knowledge Base can be found on our
website by visiting our website: http://www.bcmcom.com. If your question is not answered in
our FAQ/Knowledge Base, visit our forums and post your messages or submit a new FAQ
through FAQ Submittal form for us to add your question in our FAQ with our answer.

Motherboard Layout:
WARNING: Electrostatic Sensitive Device (ESD)
Static electricity can easily damage your motherboard and will void your motherboard warranty.
Keep the motherboard and other system components in their anti-static packaging until you are
ready to install them. Touch a grounded surface before you remove any system component
from its protective anti-static packaging. Unpacking and installation should be done on a
grounded, anti-static mat. The operator should be wearing an anti-static wristband, grounded
at the same points as the anti-static mat. During configuration and installation touch a
grounded surface frequently to discharge any static electrical charge that may have built up in
your body. Avoid touching the components when handling the motherboard or a peripheral
card. Handle the motherboard and peripheral cards either by the edges or by the peripheral
card case-mounting bracket.
WARNING: Misplaced Jumper Damage
Incorrect setting jumpers and connectors may lead to damage to your motherboard and will
void your motherboard warranty. Please pay special attention not to connect these headers in
wrong directions. DO NOT change ANY jumpers while the motherboard has the power!
System Front Panel Connector
HDLED
RESET
VCC5
GND
VCC5
PWR LED
PWRBT
PWRBTN
GND HDDLED
RSTSW
Reserve
GND
CN1
Pin 1
Connectors
Jumpers
Jumper Name Description Page
JP1 Clear CMOS 3-pin Block
JP2 Power Mode 3-pin Block
JP3 CF MA/SL Select 3-pin Block
JP4 COM2 P9 Select 6-pin Block
JP5 COM2 Mode Select 6-pin Block
JP6 COM2 Mode Select 6-pin Block
JP7 COM2 Mode Select 6-pin Block
JP8 COM3 P9 Select 6-pin Block
JP9 COM4 P9 Select 6-pin Block
JP10 DFP Clock/Data Select 6-pin Block
Socket/Slot Name Description Page
CN1 Front Panel 8-pin Block
CN2 SATA2 SATA Connector
CN3 Secondary IDE 40-pin Block
CN4 SATA1 SATA Connector
CN5 SMBUS Header 4-pin Block
CN6 CPU Fan Header 3-pin Block
CN10 Primary IDE 40-pin Block
CN13 ATX Power 20-pin Block
CN15 Mini PCI 144-pin Slot
CN16 AT/ATX Power 3-pin Block
CN17 Reserved 10-pin Block
CN18 USB 5/6 Header 10-pin Block
CN19 USB 7/8 Header 10-pin Block
CN20 Chassis Intrusion 2-pin Block
CN21 Floppy Header 34-pin Block
CN22 LPC 20-pin Block
CN23 Brightness Adjust 5-pin Block
CN24 PCI (Riser) PCI Slot
CN25 IRDA 5-pin Block
CN26 COM3 9-pin Block
CN27 COM4 9-pin Block
CN28 LCD Panel Connector 40-pin Hirose DF-13A-40DP-1.25
CN29 Audio Header 10-piin Block
CN30 LCD Inverter Connector 5-pin Block
CN31 CD-IN 4-pin Block
CN36 LAN LED Header 10-pin Block
