BCP SKY5297 User manual

SKY5297
Ver. 1
INSTRUCTION
MANUAL
2-in-1 Cordless Vacuum Cleaner

2|
SPECIFICATIONS
BATTERY WARNINGS
Voltage
Battery Capacity
120V, 60Hz
2500 mAh
•Do not allow children to operate this appliance. Keep appliance out of reach of children.
•This item is intended for indoor, household use only.
•Ensure that your voltage is consistent with specifications.
•Using an extension cord is not recommended as it may overheat and cause a risk of fire.
•This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
•If any parts are missing, broken, damaged, or worn, stop using this product until repairs are made
and/or factory replacement parts are installed.
•Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void the
product warranty.
•Keep appliance away from direct sunlight and other sources of heat (stove, heater, etc.).
•Do not run power cord over sharp edges/corners or a hot surface.
•Do not pull or carry wall bracket by the power cord.
•Do not obstruct the ventilation openings or filters as this may overheat the vacuum.
•Do not handle power cord/plug or touch wall outlet with wet hands.
•Do not charge or use appliance outdoors or in a damp, humid environment like a bathroom or spa.
•Do not immerse the appliance or power cord in water or any other liquid.
•Do not spill water on the electrical components or connectors.
•Do not unplug by pulling on the power cord. Always grasp the plug firmly and pull straight out from the outlet.
•Do not use if the plug, power cord, or any components are damaged.
•Do not use any accessory or fitting other than original accessories and fittings.
•Do not use the power adapter for a dierent product.
•Do not attempt to charge this appliance with a dierent power adapter. Only use the supplied power adaptor.
•The batteries in this this appliance cannot be removed or replaced.
•Appliance contains rechargeable batteries.
•Do not throw batteries into a fire or subject them to high temperatures.
•Under extreme conditions, the battery cells may leak. Do not allow battery fluid to come in contact with skin.
If this happens, wash immediately and contact a physician.
WARNING
Please retain these instructions for future reference.
NOTICE

USE TO CLEAN CARPET AND SMOOTH FLOORING
DIAGRAM
VACUUM HEAD
BATTERY
INDICATOR
RELEASE
BUTTON
POLE
RELEASE
BUTTON
ROLLING BRUSH
RELEASE BUTTON
ROLLING BRUSH
VACUUM UNIT
VACUUM HEAD
CHARGING PORT
| 3

•Crevice tool: Clean narrow, hard-to-reach areas and grooves in furniture
•Large round brush: Gently clean upholstery, window sills, and uneven
objects such as furniture, lamps, etc.
•Small round brush: Clean smaller objects such as computer keyboards
and electronics
VACUUM UNIT / DUST BIN
ACCESSORIES & ATTACHMENTS
BATTERY-SAVING MODE
ECO MODE
ON/OFF
CREVICE TOOL LARGE ROUND
BRUSH SMALL ROUND BRUSH ACCESSORY HOLDERS WALL BRACKET
CHARGING PORT
HEPA FILTER
(1 EXTRA)
LID
LID
RELEASE
DUST BIN
FILTER
FRAME
RELEASE
BUTTON
DUST FILTERS (2)
BATTERY
4|

| 5
USAGE TIPS
•Always switch o appliance and unplug before emptying dust bin, cleaning nozzles, or changing attachments.
•Do not use appliance without the filters inserted.
•Do not vacuum sharp objects or broken glass.
•Do not vacuum liquids.
•Do not vacuum burning matches, embers, or cigarette butts.
•Do not vacuum chemicals, stone dust, gypsum, cement, or similar particles.
•Do not vacuum inflammable and explosive substances/chemicals or similar aggressive liquids.
•Do not vacuum cables, fringed materials, etc. as they may get caught in the rolling brush and be damaged.
•Take special care when using appliance on the stairs.
•Never hold nozzle to body parts or animals during use. Switch o vacuum immediately if it is stuck to a
body part or object.
•Do not insert fingers into nozzles.
•Keep hair, loose clothing, fingers, and other body parts away from suction opening or moving parts
(e.g. the rolling brush).
•Do not spray filters with fragrances or perfumed products; the chemicals may be flammable.
PARTS
HARDWARE
1
2 PCS
M4x25mm
SCREW
TOOLS REQUIRED
APPROXIMATELY
30 MIN.
ASSEMBLY
1 PERSON
ASSEMBLY
2
2 PCS
WALL ANCHOR
1 PC
DUST BIN
AD
1 PC
VACUUM HEAD
1 PC
VACUUM UNIT
B
1 PC
POLE
C
PHILLIPS
SCREWDRIVER
PENCIL
& RULER LEVELER
(OPTIONAL)
DRILL WITH
DRILL BIT
HAMMER

6|
PARTS
1 PC
WALL BRACKET
E
3 PCS
ACCESSORY
HOLDERS
F
1 PC
POWER
ADAPTER
G
PRODUCT ASSEMBLY
1Insert the part A dust bin into the bottom of the part B vacuum unit until it locks in place.
-To remove the dust bin, hold open the lock and remove.
NOTE: Make sure the
HEPA filter and filter frame
are inserted completely
into the dust bin.
B
A

| 7
PRODUCT ASSEMBLY
Insert the part C pole into the vacuum unit until it locks in place.
Insert the part D vacuum head into the pole until it locks in place.
2
D
C

8|
WALL MOUNTING INSTRUCTIONS
1Line up the part E wall bracket on the wall; make sure it is mounted high enough for the vacuum
to hang on it comfortably.
Use the pencil and ruler to mark the desired mounting location.
Measure twice to produce the
most accurate measurement.
Use a level to ensure that holes
are drilled at an even height.
BACK VIEW
2Use an electric drill to drill two screw holes. Use a hammer to insert two part 2 wall anchors
into the holes.
Screw two part 1 screws into the wall anchors.
NOTE: Screws are designed to have space
between the screwhead and wall.
2
x2
MOUNTING
BRACKETS
1
x2
E

| 9
WALL MOUNTING INSTRUCTIONS
3Press three part F accessories holders into the sides of the wall bracket.
4Slide the wall bracket onto the
screw heads.
Insert one end of the part G power
adapter into the charging port and
the other end into a wall outlet.
Slide the vacuum onto the wall
bracket to charge.
- The battery indicator lights will
flash to display the current charge.
CHARGING PORT
F
x3

10 |
CHARGING BATTERIES
•There are two ways to charge the vacuum:
- Hang the vacuum on the wall bracket (which is plugged into a wall outlet).
- Insert one end of the power adapter directly into the changing port on the vacuum unit and the other
end into a wall outlet.
•The battery indicator lights will flash and display the current charge.
- Each bar represents 25% full.
•Do not operate appliance during charging.
ECO MODE
•Use ECO mode to save battery and vacuum with reduced noise.
•Press the ECO button to turn ECO mode on/o.
-The button will illuminate to indicate it is in ECO mode.
CLEANING DUST BIN/FILTERS
1. Lift vacuum o the wall bracket or disconnect from the power adapter. Hold open the lock to remove
the dust bin.
2. Hold the dust bin over a waste basket. Press the lid release button and empty the dust bin.
3. Pull the HEPA filter from the filter frame on the dust bin. Unclip the two removable dust filters from the
sides of the vacuum unit.
4. Tap the dust out from the filters over a waste basket.
5. If necessary, rinse the filters with warm water and allow to dry. Make sure filters are completely dry
before reinserting.
6. Insert the HEPA filter back into the filter frame and reinstall the dust filters on the sides.
OPERATING INSTRUCTIONS
1. Lift vacuum o the wall bracket or disconnect from the power adapter.
2. Fit the desired attachments to the vacuum unit.
NOTE: All attachments, including the vacuum head and pole, are interchangeable. Select the appropriate
attachment for your cleaning job.
3. Press the power button to operate the vacuum. The battery indicator will illuminate to show the
current charge.
4. When finished, turn o vacuum and return it to the wall bracket to charge.

| 11
TROUBLESHOOTING
REASON
Battery empty
Suction opening is
obstructed or blocked
PROBLEM
Suction weak
Not Working
SOLUTION
Charge appliance
Remove obstructions
Battery almost empty Charge appliance
Filter too dirty Clean filter
Dust bin not fitted properly
Dust escaping from dust bin Make sure dust bin is installed
correctly and lid is closed
CLEANING AND STORAGE
NOTE: Do not immerse or soak the appliance in water or any other liquid.
•Wipe the exterior of the unit and attachments with a damp cloth. If necessary, use a mild detergent and
warm water.
•Do not clean with steel wool, abrasive detergents, or corrosive liquids like gasoline or acetone.
•Place unit and attachments in a cool, well-ventilated place to dry.
•Make sure unit and parts are completely dry before storage.
•Store in a cool, dry place away from direct sunlight.
CLEANING ROLLING BRUSH
• Regularly inspect the vacuum head for blockages and obstructions.
• If the vacuum head is blocked and the rolling brush cannot rotate, the appliance will switch o and the
battery indicator lights will flash. Immediately clean the rolling brush.
1. Remove the vacuum head from the pole or vacuum unit.
2. Hold open the release button and remove the rolling brush.
3. Clean the rolling brush of hair, dirt, and obstructions.
4. Reinsert the rolling brush into the vacuum head. Insert the side opposite from the release button into
the slot, then insert the other side and lock it in place.
-Make sure rolling brush is correctly installed before using the vacuum head.

All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long
as the item is returned in its original product packaging and all accessories from its original shipment are
included. All returned items will receive a full refund back to the original payment method. All returned
items will not be charged a re-stocking fee.
All returned items require an RA (Return Authorization) number, which can only be provided by a Best
Choice Products Customer Service Representative when the return request is submitted. Items received
without an RA may not be accepted or may increase your return processing time. Once an item has been
received by Best Choice Products, refunds or replacements will be processed within 5 business days.
All returns must be shipped back to the Best Choice Products Return Center at the customer’s expense. If
the reason for return is a result of an error by Best Choice Products then Best Choice Products will provide
a pre-paid shipping label via email. Boxes for return shipping will not be provided by Best Choice Products,
and is the customer’s responsibility to either use the original shipping boxes or purchase new boxes.
Pictures may be required for some returns to ensure an item is not damaged prior to its return. Items
returned are not considered undamaged until they are received by Best Choice Products and verified as
such. All damages to items are the customer’s responsibility until the item has been received by and
acknowledge by Best Choice Products as undamaged.
PRODUCT WARRANTY INFORMATION
Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage or
loss, whether direct, indirect, or incidental, resulting from the incorrect attachment, improper use,
inadequate maintenance, or neglect of this product.
