BCR Premium MSTU 100 User manual

Änderungen vorbehalten – Stand 08.05.2019
1
MANUAL
BCR PREMIUM MSTU 100
VERSION 3.1 – 02.07.2019
!!!CONFIDENTIAL!!!

Änderungen vorbehalten – Stand 08.05.2019
2
Copyright
© Copyright 2019, Dr. Schwab Gesellschaft für Technologieberatung mbH, All rights reserved. This manual or any portion thereof may not be
reproduced or used in any manner whatsoever without the express written permission of the author except for the use in brief quotations in a
review. Dr. Schwab Gesellschaft für Technologieberatung mbH shall not be liable for any damages, losses, costs or expenses, direct, indirect or
incidental, consequential or special, arising out of, or related to the use of this material or the products described herein. The information in this
document is subject to change without notice. The manufacturer makes no representations or warranties with respect to the contents hereof and
specifically disclaims any implied warranties of merchantability or fitness for any particular purpose. The manufacturer reserves the right to revise
this publication and to make changes from time to time in the content hereof without obligation of the manufacturer to notify any person of such
revision or changes.
General Information
Special not for this instruction manual
Carefully read this instruction manual and follow all instructions.
This will insure the reliable operation and longevity of your device.
List of warning symbols and key words in this instruction manual
DANGER!
Warning of immediate life-threatening consequences!
WARNING!
Warning of possible life-threatening consequences and/or serious,
irreversible injuries!
WARNING!
Warning of danger of electric shock!
CAUTION!
Follow instructions to avoid injury and damage!
ATTENTION!
Follow instructions to avoid damage!
NOTICE!
Further reading on use of device!

Änderungen vorbehalten – Stand 08.05.2019
3
NOTICE!
Follow instructions from the manual!
Brief Description
The device BCR Premium MSTU 100 is a home device for the generation of micro currents
and LED-light and belongs in the category of “electrotherapy devices“ and “LED light therapy
devices“ personal wellness and beauty.
The microcurrent and light parameters are determined by programs, which are loaded into
the device via a USB data storage medium.
A main area of use for the device is in the field of Preventive Health/Wellness, Rehabilitation
of pain/physical disabilities and Beauty.
The device is used at homes, offices, traditional & alternative therapy practitioners,
physiotherapy centres, doctor’s clinics and hospitals.
Please refer to the section „Further Information on Treatment“ of this
manual for more detailed information.
Designated Use
Area of application / indications:
The designated use lies in the use for Preventive Health/Wellness, Rehabilitation of
pain/physical disabilities and Beauty.
Intended user group:
•Personal and family use,
•Traditional & Alternative therapy Practitioners,
•Physical Therapists,
•Doctors,
•Hospitals

Änderungen vorbehalten – Stand 08.05.2019
4
Please refer to the section “Further Information on Treatment” of
this manual for more detailed information.
Responsibility of the user
This product is designed in a way that it works according to the description contained in this
manual, when it is installed, used, serviced, and repaired in accordance with the provided
instruction. A defective product may not be used. Parts that are damaged, obviously worn,
incomplete, or contaminated have to be replaced immediately. When a repair or replacement
becomes necessary, it is recommended that all work be done by the manufacturer of the
device. The user of the product carries the sole responsibility for any malfunction resulting
from the improper use, deficient service, faulty repair, damage or modification by anyone
other than Dr. Schwab Gesellschaft für Technologieberatung mbH, or the authorized service
personnel of this company.
Indications and Contraindications of the System
Indications:
•Preventive Health/Wellness
•Rehabilitation of Pain/Physical disabilities
• Beauty
General contraindications:
•Pacemaker
•Small children under the age of 6
•Pregnancy
•Malignant tumors
•Malignant blood diseases
•Epilepsy
•Morbus Paget
•Brittle bone disease

Änderungen vorbehalten – Stand 08.05.2019
5
Adverse Side Effects
Adverse side effects in connection with the BCR Premium MSTU 100 can be:
•Increased secretion of wounds in the early postoperative phase
•A feeling of pins and needles on the skin under the pad electrodes (in case of high
sensitivity to electricity)
•Redness and itching of skin under the pad electrodes (in case of high sensitivity to
electricity)
•Increased urge to urinate
•Temporary worsening of symptoms
•Flashes of light in the eyes when treating the head.
•Use of the electrodes close to the chest can increase the risk of ventricular fibrillation
• The material of the gel pads and of the light hand piece was tested for
biocompatibility according to EN 10993-1, however an allergic reaction to these
materials can’t be excluded under all circumstances. In case of symptoms, abort the
treatment immediately and remove the gel pads, respectively the light hand piece
from your body.
Please refer to the section „Further Information on Treatment“ of
this manual for more detailed information.

Änderungen vorbehalten – Stand 08.05.2019
6
Mode of Operation of the Treatment
The BCR Premium MSTU 100 is a treatment system of the category of “electrotherapy
devices“ and “LED light therapy devices“ and is used for Preventive Health/Wellness,
Rehabilitation of pain/physical disabilities and Beauty.
In the biological therapy through microcurrent, currents between 10 and 999 microamps [µA],
with frequencies between 0.1 and 10,000 Hertz [Hz] are applied to the affected region using
electrodes. With this low current, a stimulation of physical activity takes place, which is the
basis of the healing process.
Verifiably, microcurrent is effective in the painless therapy of acute and chronic pain,
especially of the joints. Studies show a reduction in pain through microcurrent e.g. in cases
of Arthrosis, Arthralgia, Epicondylitis (tennis elbow), Fibromyalgia, etc.
A blood circulation promoting effect has also been proven, which is beneficial for the
rehabilitation of physical disabilities and wound healing.
BCR Premium MTSU 100 is controlled by a central microprocessor. All user in- and outputs
are performed via a capacitive touch display. The hardware for the generation of the
microcurrents allows for the independent generation of current pulses with frequencies of up
to 1 kHz for two channels, with currents up to 999 µA.
Additionally, a constant measurement of the skin resistance takes place. The generation of
an initial voltage of 60V for each channel is galvanically isolated from all other electric
potential, and allows for both the simultaneous treatment of one area or region with different
currents, or the independent treatment of different regions.
Through the use of a flash-processor, the installation of firmware updates by the user is
possible at any time.
The following parameters can be set for the channels:
•Currents from 10 to 999 µA in 1 µA steps
•Pulse frequencies of 0,1 Hz to 1 kHz in 0,1 Hz steps
•Rise time of the preset current from 0,1 to 1,0 sec (Amplitude modulation of the current
output from 10 to 100% within the selected time in 10% steps)
From the output of current-controlled impulses, the maximum strength of which can be
selected, the amplitude of the voltage output is derived, depending on the connected load,
the body through which the current flows. The maximum Amplitude of the voltage is limited to
60 Volts, so that the following relationship is valid for maximum current output (Ohm’s law):
R = U / I
Rx = 60V / 990µA
Rx = 60.6 kΩ

Änderungen vorbehalten – Stand 08.05.2019
7
This means that in cases where the resistance of the connected body is lower than 60 kΩ,
linearly lower voltages can be expected. Current regulation provides for an absolute short
circuit resistance, and thereby the safety of the system.
The period of a master unit for current output is 2.5 seconds, so that the channels are
restarted after 2.5 seconds while a program is running. The purpose of this sequence is as
follows:
•A change, respectively restart every 2.5 seconds
•Channel A and/or B can output current impulses unidirectional (+ or -) or bidirectional,
meaning that the polarity changes from + to – and vice versa after 2.5 seconds.
Simultaneously with the start of a cycle, the rise of the current is reactivated, so that an
amplitude-modulated current flow follows.
Here is an example of a measured output signal:
The voltage was measured on a load of 10 kΩwith the following parameters:
Polarity: +/- , Current: 500µA , Rise time: 1 sec , Frequency: 3 Hz
At the beginning of a period, the amplitude of the pulses is zero, then it rises to its maximum
value of 5 Volts within 1 second. It maintains this amplitude until the end of the period.
(U=R x I, so 10kΩx 500µA = 5V)

Änderungen vorbehalten – Stand 08.05.2019
8
The device contains an automatic diagnosis mode. At the start of each program segment,
the conductivity of the connected body is measured on channel A, and the value is scaled on
a logarithmic scale from 0 to 100. A value of 50 on this scale corresponds to a resistance of
95 kΩ. This is based on Dr Voll’s theory where the values 0 to 100 equates to 0 to 800 kΩ
resistance over the organ or tissue where 95 kΩ, the baseline value of balanced energy,
equals to 50 in the scale.
Please refer to the section „Further Information on Treatment“ of
this manual for more detailed information.
Warnings!
Read the following warnings before using the device.

Änderungen vorbehalten – Stand 08.05.2019
9
Doctor/Therapist/User
•The BCR Premium MSTU 100 is a microcurrent therapy device that is primarily used
for Preventive Health/Wellness, Rehabilitation of pain/physical disabilities and
Beauty.
Adequate Environment
•The device is designed for home use and for the use in professional institutions.
Inadequate Environment
• In close proximity to high frequency surgical devices, close to short wave or
microwave therapeutic devices, within the shielded cages of MRI equipment.
Ambient conditions
• The device may not be used in a humid environment, or in places where it may come
in contact with liquids.
• Don’t expose the device to direct or indirect sources of heat.
The device has to be used and stored in a safe environment.
• The device can be used in temperatures from +5°C to +40°C, and up to an altitude of
2000m above sea level.
• Don’t use the device in presence of free oxygen, anesthetics, or flammable
substances. The device has to be used and stored in a safe environment.
• The device may cause radio frequency interference or interfere with the use of other
devices in the area. If this happens, the interference should be eliminated by
changing the orientation of the device or by shielding the immediate vicinity. The
electromagnetic emissions emitted by the BCR Premium MSTU 100 are below the
limits set forth in the currently valid regulations (IEC 60601-1-2:2014, EN 60601-1-
2:2015).
• The use of the device in the vicinity of, or on top of other devices should be avoided,
as this might interfere with proper operation. If use in this manner is necessary, both
devices should be monitored for proper operation.
• The device requires special precautions with respect to electromagnetic compatibility
(EMC) and has to be installed and used in strict accordance with EMC guidelines.
Don’t use the device in close proximity to fluorescent lighting, radio transmitters,
remote controls, or portable HF communication devices, even if these fulfill the
requirements of CISPR-11.
• The use of accessories, converters or cables other than the ones indicated or
delivered by the manufacturer of this device can lead to increased electromagnetic
emissions or reduced interference immunity of the product, and affect its usability
(See chapter “Scope of delivery” -> “Conforming cables and accessories).

Änderungen vorbehalten – Stand 08.05.2019
10
• Portable HF communication devices (including peripheral devices like antenna cables
and external antennas) should be kept at least 30cm from all parts of the BCR
Premium MSTU 100, including the cables and accessories indicated by the
manufacturer. Otherwise, the usability of the device may be affected.
•In order to avoid damage through electrostatic discharge, avoid charges by e.g.
inadequate clothing, carpets, insufficient humidity, etc.
•The device may not be used on the patient in connection with other medical devices
(e.g. high frequency surgical devices, ECG, defibrillator, etc.).
• It can’t be ruled out that the BCR Premium MSTU 100 may affect the operation of
implantable devices. Patients with implantable devices should not use the BCR
Premium MSTU 100.
•Don’t insert any objects into openings of the device.
•Clean the device regularly and disinfect the accessories, should this become
necessary. Disinfectant wipes are available as accessories.
•The integrated USB port may under no circumstances be used to connect the device
to another device. This port is intended solely for the insertion of a USB drive.
•Set up the device so it is in a stable position, and place the cables so they will not be
damaged or may cause danger.
•When not in use, the device is to be placed in its transport case, to protect it from lint,
dust, and sunlight.
•The device may only be stored in a dry place at temperatures ranging from -20°C to
+70°C.
• The device is to be stored in its case out of reach of pets, pests and children.
During Treatment
• In case irregularities of the device occur during treatment, turn it off and contact the
manufacturer or authorized service provider.
•The power of the light emitted by the hand piece was determined according to the
rules of IEC 62471 and DIN EN 60601-2-57. The hand piece falls into the „free
group“, which precludes a photobiological danger to the eyes. However, it is
recommended not to look directly into the source of light, as this may trigger epileptic
seizures in vulnerable patients. Should this not be possible in certain treatments, the
eyes should be covered accordingly.

Änderungen vorbehalten – Stand 08.05.2019
11
Accessories
• Only use components/accessories that are designed for the use with the BCR
Premium MSTU 100.
•Only connect the patient cables and the cable for the light hand piece to the
corresponding socket on the device – don’t insert the connectors into any other
devices.
•Place the cables so no one can step on, or trip over them.
•Don’t place any objects on the cables, as this may damage them.
•Don’t exert excessive force on the connectors, e.g. from the side. This may lead to
damages.
•Don’t use excessive force when plugging in connectors and make sure of the correct
orientation.
•Avoid short circuits of breaking of cables by not pinching or flexing excessively.
Power Supply
•Only use the supplied power converter ATM036T-A050 and the supplied power cord
to connect the device to the mains.
•Please observe the power ratings (see Technical Data)
•The power converter can be used with a supply voltage of 100 - 240V. If you want to
use the device abroad, inform yourself about the local mains voltage and which type
of power cord will be needed.
•A damaged power cord may not be used under any circumstances. Please contact
the manufacturer or an authorized service partner if you need a new power cord or a
power cord with a country-specific plug.
•The power adapter should always be connected directly to an easily accessible wall
outlet, do not use extension cords.
•In order to disconnect the device from the mains, pull the power plug from the wall
outlet.
Repairs and Damages (also see section „Troubleshooting)
•Do not use the device if you suspect damages or a defect.
•Should liquid have entered the device or its accessories by accident, further use is
prohibited. Please send the device and accessories to the manufacturer for
inspection/repair.

Änderungen vorbehalten – Stand 08.05.2019
12
•Repairs, alterations and modifications of the device without prior consent of the
manufacturer are prohibited. Dr. Schwab GfT cannot be held accountable if the
device has been altered or modified. If a defect appears, contact Dr. Schwab GfT or
your authorized service provider.
•The device is designed in a way that it can only be opened with the use of tools. It
may only be opened by the manufacturer. There is a risk of death, if you open the
device or the power converter while connected to mains!
• The device contains an internal Li-Ion battery. Should the battery become weak or
defective, it can be replaced by the manufacturer.
Transport
•Always use the supplied carrying case and transport packaging when transporting the
device.
If you have questions or are unsure about the safety precautions,
contact the manufacturer - he will be happy to provide information
and help you ensure a safe and effective use of the device.

Änderungen vorbehalten – Stand 08.05.2019
13
Informations about Treatment
General Information
The skin of the patient/client should be free from oils and without wounds before the
treatment. Potentially applied make up or similar must be removed.
It is very important to make sure that a good adhesive effect is found on the entire surface of
the pad electrodes.
The pad electrodes have to be in contact with the skin with their entire surface during the
treatment and can‘t fall off.
Should the pad electrodes not fulfill the requirements mentioned above, they have to be
replaced with new electrodes.
•the patient should be in a safe and relaxed position throughout the entire treatment
•except for cases where it is desired, the body of the patient should not be wet
•please abort the treatment in case something unusual happens
•don’t place the electrodes over fresh surgery scars or open wounds
•avoid contact of the electrodes with metals like necklaces or belt buckles
•don’t use knotted or defective cables
•the device may not be opened, don’t drop it or expose it to heavy impacts or
vibrations
•if you have doubts about the treatment, you should seek medical/professional help
Additional Information for Medical Applications
For the treatment with BCR Premium MSTU 100, a calm and relaxing atmosphere should be
created. The patient should be treated sitting down or lying down, according to his ailment.
Corresponding to the anamnesis, diagnosis or diagnostic findings, the progression of
treatments should be planned and coordinated with the patient.
For the treatment of acute ailments, a daily treatment is recommended. When treating
chronic symptoms, a rhythm of 2 to 3 treatments per week is appropriate.

Änderungen vorbehalten – Stand 08.05.2019
14
Accessories
Overview
Pos. Description: Article
No.: Quantity:
1 Transport case 9205 1
2 Patient cable 9029 2
3 Pad electrode
adapter 2.0 mm,
black
4151 2
4 Pad electrode
adapter 2.0 mm,
red
4152 2
5 Pad electrode
Type PG470 4416 4

Änderungen vorbehalten – Stand 08.05.2019
15
6 Pad electrode
Type PG473 5371 4
7 Pad electrode
Type PG470W 5154 4
8 Pad electrode
Type PG473W 9074 4
9 Light hand piece
with cable 9275 1
10 Power supply
ATM036Z-A050 8366 1
11 Power cable with
EURO
connector, 1.50
m
8002 1

Änderungen vorbehalten – Stand 08.05.2019
16
Transport Case (Optional)
The transport case protects the device from environmental influences. It is recommended to
store the BCR Premium MSTU 100 in this case when not in use. The case is available as an
optional accessory.
Light Hand Piece
The light hand piece CELLIGHT is a non-invasive and non-burdensome accessory for the
BCR Premium MSTU 100.
Its mode of operation is based on the stimulation of afflicted cells by microcurrent and light.
The stimulation by light takes place in parallel to the stimulation by current and supports the
effects of the current.
The electronics of the BCR Premium MSTU 100 allow for the modulation of the red and blue
LEDs, integrated into the hand piece. The light source is modulated according to the
frequency that it output by the microcurrent channel A. The brightness of the light source is
dependent on the amplitude of the current.
The light hand piece is to be connected to socket “L” of the BCR Premium MSTU 100.
INFORMATION about Treatment with Light
The selective treatment with light is used to support the treatment with microcurrent. From
practical experience, a positive effect of the light treatment can be derived. However, there
are currently no clinical studies available that prove the effectiveness of light treatment.
Pad Electrodes
General Description
For pad electrodes, the types „Gel-Pad PG470“ and „Gel-Pad PG473“ are available. The
“Gel-Pads“ PG470W and PG473W can also be used. For an optimal success of the
treatment, only these types of pad electrodes may be used.
Dimensions
PG470/PG470W: 35 x 45mm
PG473/PG473W: 45 x 80mm

Änderungen vorbehalten – Stand 08.05.2019
17
Please observe the following information when using pad
electrodes.
The skin of the patient/client should be free from oils and without wounds before the
treatment. Potentially applied make up or similar must be removed.
It is very important to make sure that a good adhesive effect is found on the entire
surface of the pad electrodes.
The pad electrodes have to be in contact with the skin with their entire surface during
the treatment and can‘t fall off.
Should the pad electrodes not fulfill the requirements mentioned above, they have to
be replaced with new electrodes.
When using the device on different patients, the pad electrodes have to be replaced
after each use.
Further information can be found in the chapter „Initial Operation“
of this manual.
Patient Cables
The patient cables provide an electrical connection between the microcurrent device BCR
Premium MSTU 100 and the patient.
2 patient cables are provided as accessories with the device.
These cables are to be connected to sockets „A“ and „B“ on the device.
The other end of the patient cable is connected to the pad electrodes or hand electrodes,
which provide a conductive connection to the patient. Depending on the pad electrodes, the
red and black pad electrode adapters are to be used.
The patient cables do not need to be serviced, they should only be cleaned with a damp rag
when necessary.

Änderungen vorbehalten – Stand 08.05.2019
18
ATTENTION Important Safety Information!
Connecting or inserting the patient leads into other devices or to a patient who is
connected to another medical device, when connected to the body, poses a risk of
death for the user.
Only connect the patient leads of the BCR Premium MSTU 100 to the respective
sockets on the BCR Premium MSTU 100 and never insert the connectors into any
other devices/sockets or create a connection to another patient.
Only USB drives may be connected to the device’s USB port!
Under no circumstances may the USB port be used to create a connection with
another device, e.g. a PC or laptop, as this may lead to dangerously high touch
currents/leakage currents on the BCR Premium MSTU 100!
Don’t use any knotted, twisted or damaged patient leads.
The electrode
pad adapters of
the patient cables are small parts that
can be swollowed by children and might cause suffocation. The
wrapping of patient cables around one’s neck may also lead to
strangulation. Therefore, always store the device and its
accessories out of the reach of children. Only use the device on
children in the presence of adults.

Änderungen vorbehalten – Stand 08.05.2019
19
Further information can be found in the chapter „Initial Operation“
of this manual.
Storage/Transport
Always store the device in the provided transport case in a dry location out of the reach of
children, and don’t use it in an environment, where it is exposed to the following influences:
•Magnetic fields and / or electromagnetic radiation
•Very high or very low temperatures (above 70°C or below -20°C storage / transport
temperature). After the device has been exposed to very low temperatures and is
supposed to be used in a warm room, please wait one tot wo hours before turning the
device on, so condensation can evaporate.
•High humidity
•Direct sunlight
•Impact and vibrations
•Fully charge the internal battery if you intend to store the device for an extended
period of time (more than 1 month)
Don’t place any containers with liquids on the device!
Place the device on an even surface for use and storage!
Always use the supplied transport case and transport packaging
when transporting the device in oder to avoid damaging it.

Änderungen vorbehalten – Stand 08.05.2019
20
Cleaning and Care
Before cleaning the device, please disconnect the device from the power converter. The
cleaning/disinfection of the device, the light hand piece and the cables should be performed
using the disinfectant wipes “acryl-des” by Schülke, available as accessories. If disinfection is
not necessary, the device can also be cleaned using a mild detergent and a no more than
damp, soft cloth. Please make sure that no liquid enters the openings of the device and don’t
use any sprays. Especially when cleaning the display and the light opening of the light hand
piece, make sure you are not using any harsh chemicals or abrasive cleaning agents.
The pad electrodes are single use products that have to be replaced after each use.
Check the power cord and its plug for damage before each use. Damaged cables may no
longer be used!
CAUTION!
The device may only be opened by trained personnel.
ATTENTION!
There are no user serviceable parts inside the device.
ATTENTION Important Safety Information!
The housing of the power adapter may not be opened!
Touching parts inside the power adapter poses the risk of death
