DeRoyal WARRIOR User manual

IMPORTANT INFORMATION
Please read all instructions, warnings, and
precautions before use. Correct application is
essential for proper functioning of the product.
Use only on the person it was provided to by a
healthcare professional and only for the use it was
intended.
INTENDED USE
The DeRoyal® Warrior™ Spine, powered by The
Boa® Closure System, is intended for sagittal
alignment, hyperextension or flexion bracing used
for lower lumbar strains and sprains, proprioceptive
feedback, postural control and reinforcement of
proper body ergonomics.
CONTRAINDICATIONS
Patients with poor peripheral circulation, diabetes
or decreased skin sensitivity should not use this
product.
PRECAUTIONS
• This product is to be fitted initially by a physician
(or properly licensed practitioner) who is familiar
with the purpose for which it is intended. The
physician or practitioner is responsible for
providing wearing instructions and precautions
to other healthcare practitioners or healthcare
providers involved in the patient’s care as
well as the patient. Consult your physician (or
properly licensed practitioner) immediately if
you experience sensation changes, unusual
reactions, swelling or increased pain while
using this product. Follow the instructions of
your physician (or properly licensed practitioner)
for duration of use. These instructions do
not supersede hospital protocol and/or direct
orders of patient’s physician. Discontinue use
of the device and consult physician or properly
licensed practitioner if it becomes damaged
in any way, limiting its ability to perform as
intended.
• Use only as directed by your medical
professional.
• Discontinue use of the device and consult
physician or properly licensed practitioner if
pressure points or pressure ulcers develop.
• Inspect brace for damaged or missing
components prior to patient application.
• Inspect brace for proper fit immediately
following patient application.
INSTRUCTIONS FOR USE
SIZING
The DeRoyal Warrior Spine Universal Back Brace
features four (4) sizing zones:
NOTE: Measurement can be determined by
circumferential waist measurement or pant size.
1 2 3 4
WAIST MEAS. 24”-32” 32”-38” 38”-44” 44”-54”
MEN’S
PANT SIZE 26-32 32-38 38-44 44-46
WOMEN’S
PANT SIZE 0-6 8-10 12-16 18-24
NOTE: For best results and ease of adjustment,
brace sizing should be conducted on a large bed
or table.
WARRIOR™ SPINE
UNIVERSAL BACK BRACE
Single Patient Use
Non-Sterile
Not Made with Natural Rubber Latex
Rx Only
1. Prior to application, pull out both dials to release
lacing. Release front hook and loop closure to
open the brace belt completely.
2. Place the back of the brace flat
with the outside of the back
panel facing upward. Ensure
the left and right belt arms are
spread outward evenly and non-impinged.
3. Unfasten the back flap hook
closures (2) at the bottom of the
back panel, flip open the back
panel and flip over the belt arms.
4. Pull up on the two (2) plastic
hook flaps that secure the belt
in place until they reach a 45
degree angle upward from the
belt.
5. Place one hand in the middle of
the adjustment panel and under
the belt and use the other hand
to pull up on the belt pull strap
until the appropriate size zone is reached on the
left and right side of the belt. NOTE: Ensure that
the sizing zones are even on both sides. Reapply
the hook flaps to secure the belt.
6. Press down firmly on any excess
belt length, fold the flap over
and reattach the back flap hook
closures at the bottom of the
back panel.
APPLICATION
NOTE: Wear a shirt under this brace.
1. While in a standing or seated position, place
compression brace so the back panel is centered
in the low back area. Secure the front hook and
loop closure of the belt.
2. Next, the patient should lie in a supine position
with their knees comfortably bent (flexed) and
their hips parallel with their shoulders.
3. At each side of the brace, the
patient will find a dial. While
in the supine position, the
patient should push the dials
in to engage then turn knobs
clockwise to tighten laces. Turn dials at the
same time to ensure even compression. Turn
dials until a comfortable level of compression is
achieved. This compression is adjustable and
can be released or tightened using the dials to
accommodate different activity levels and degree
of comfort.
4. To remove the brace, pull out the dial to release
compression and remove the front hook and loop
closure of the belt.
LATERAL PANELS APPLICATION (159-03 ONLY):
The DeRoyal Warrior Spine Brace (159-03 series)
features lateral panels for increased stability,
motion restriction, and support.
1. Follow all application steps listed under
“APPLICATION.”
2. Once the sizing is determined, the brace is
applied and an appropriate fit is achieved,
remove the brace and place the lateral panels
on the inside of the brace’s belt using the two (2)
hook attachments.
3. Reapply the brace and ensure each panel
aligns directly with the patient’s frontal and
lateral plane. Readjust panel positioning to
accommodate different activity levels and degree
of comfort.
CUSTOM-FITTED POSTERIOR PANEL APPLICATION
(NOTE: 159-11, 159-12, 159-13 version ONLY):
The DeRoyal Warrior Spine Orthoses feature custom
formable panels that can be shaped to fit the
desired specifications of the prescribing clinician.
Once formed, these panels can be inserted into the
posterior pocket of the brace.
1. Follow all application steps listed under
“APPLICATION.”
2. Once the sizing is determined, the brace is
applied and an appropriate fit is achieved,
remove the brace by opening the hook and
loop closure in the center of the back panel and
unfasten the hook and loop closure at the top
of the back panel to open the posterior panel
pocket. Remove the existing black plastic panel.
3. Position the patient into a prone position (on
3
3
4
5
6
2

stomach) on a fitting table. Assist the patient into
a hyperextended position using a pillow. Patient
can also prop themselves up on their elbows if
they are capable and movement is pain free.
4. Remove the custom formable panel from the
silver package.
5. Place the panel on the patient’s back
with the bottom of the panel positioned just
above the top of the patient’s coccyx. Press to
form the panel to the patient’s spinal shape or
desired curvature.
6. Let panel and patient in desired form/position
for 10-15 minutes until panel is firm. Note: For
quicker forming, lightly spray or dampen panel
with water and let it sit for 5 minutes or until
firm.
7. Once panel is firm, insert the panel into the
posterior panel pocket and reapply the brace.
HOT/COLD PACKS:
The DeRoyal Warrior Spine Orthoses feature two (2)
hot/cold packs that can be utilized in conjunction
with the back brace for temperature therapy. NOTE:
Follow the instructions that are printed on each
hot/cold pack carefully before using with the back
brace.
NOTE: Wear a shirt under this brace.
1. Follow all application steps listed under
“APPLICATION.”
2. Once the sizing is determined,
the brace is applied and an
appropriate fit is achieved,
remove the brace, open the hook
and loop closure in the center of
the back panel and unfasten the hook and loop
closure at the top of the back panel to open the
posterior panel pocket.
3. Insert one or both cold packs and position as
desired. Use the hook and loop closure in the
center of the back panel to position hot/cold
packs.
CLEANING INSTRUCTIONS
Hand wash with mild detergent in lukewarm water. Air
dry.
WARRANTY
DEROYAL PRODUCTS ARE WARRANTED FOR
NINETY (90) DAYS FROM THE DATE OF SHIPMENT
FROM DEROYAL AS TO PRODUCT QUALITY
AND WORKMANSHIP. DEROYAL’S WRITTEN
WARRANTIES ARE GIVEN IN LIEU OF ANY
IMPLIED WARRANTIES, INCLUDING WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE.
DEROYAL INDUSTRIES, INC.
200 DeBusk Lane
Powell, TN 37849 U.S.A.
888.938.7828
865.938.7828
Part #0-1890
©2015 DeRoyal. All Rights Reserved.
Revised 1/15
Boa®is a registered trademark of Boa Technology, Inc.
