BEA 10TD900INDHH1 User manual

75.5858.02 900 MHZ INDUSTRIAL 20160419 Page 1 of 4
2
3
4 5 10
1
6
7
8 9
11
4 BUTTON
(10TD900INDHH4)
3 BUTTON
(10TD900INDHH3)
2 BUTTON
(10TD900INDHH2)
1 BUTTON
(10TD900INDHH1)
75.5858.02 900 MHZ INDUSTRIAL 20160419 Page 1 of 4
900 MHZ RECEIVER & INDUSTRIAL TRANSMITTERS
Digital receiver and industrial transmitter
with frequency hopping, sequencing and
extended hold functionality
(US version)
ENGLISH
1. receiver (10RD900)
2. antenna wire
3. blue activation LED
4. red learn LED
5. tri-color signal strength LED
6. DIP switches
7. no-delay learn button
8. delay learn button
9. delay learn potentiometer
10. NEMA 4 1-button transmitter
11. belt clip (10BELTCLIP)
NEMA 4 HAND HELD TRANSMITTERS
DESCRIPTION
IMPORTANT:
This product is NOT intended for use directly with Magnetic Locks or Electric Strikes.
Contact BEA Technical Support for further information.

Page 2 of 4 75.5858.02 900 MHZ INDUSTRIAL 20160419
1 2 3
ON
1 2 3
Page 2 of 4 75.5858.02 900 MHZ INDUSTRIAL 20160419
• The device should not be used for purposes other than its intended use. All other uses cannot be guaranteed by
the manufacturer of this device.
• The installer of the door system is responsible for carrying out a risk assessment and installing this device and the
door system in compliance with applicable national and international regulations and standards on door safety.
• The manufacturer of this device cannot be held responsible for incorrect installations or inappropriate adjustments
of this device.
PRECAUTIONS
qShut off all power going to header before attempting any wiring procedures.
qMaintain a clean & safe environment when working in public areas.
qConstantly be aware of pedestrian traffic around the door area.
qAlways stop pedestrian traffic through the doorway when performing tests that may result in unexpected reactions
by the door.
qESD (electrostatic discharge): Circuit boards are vulnerable to damage by electrostatic discharge. Before handling
any board ensure you dissipate your body’s ESD charge.
qAlways check placement of all wiring before powering up to ensure that moving door parts will not catch any wires
and cause damage to equipment.
qEnsure compliance with all applicable safety standards (i.e. ANSI A156.10) upon completion of installation.
qDO NOT attempt any internal repair of the components. All repairs and/or component replacements must be
performed by BEA, Inc. Unauthorized disassembly or repair:
1. May jeopardize personal safety and may expose one to the risk of electrical shock.
2. May adversely affect the safe and reliable performance of the product resulting in a voided warranty.
Hand Held Configuration
INSTALLATION
Wiring
SETUP
DIP Switches
DIP STATUS FUNCTION DESCRIPTION
1
PUL Pulse Relay pressing transmitter activates and holds relay according to DIP 2 and 3
TOG Toggle
Relay pressing transmitter once activates and holds relay indefinitely pressing transmitter again deactivates relay immediately (no hold)
2
(PUL only)
0.5s 0.5 second
hold time relay remains active for 0.5 seconds after transmitter is... pressed [STD] released [EH]
10s 10 second
hold time relay remains active for 10 seconds after transmitter is... pressed [STD] released [EH]
3
STD standard
hold
relay acts according to DIP 1 and 2
(does not matter if transmitter is pressed/released or pressed/held)
EH extended
hold
relay remains active as long as transmitter is pressed and held
once released, relay acts according to DIP 1 and 2
Set DIP switches as desired. Press transmitter twice (blue LED
on receiver will illuminate).
Press and release desired learn button
(red LED on receiver will illuminate)1.
NOTES: 1If Learn w/ Delay button is used, adjust potentiometer (1 s to 30 s).
COM
NO
NC
12-24 V
AC-DC
RED
BLACK
WHITE
GREEN
YELLOW

75.5858.02 900 MHZ INDUSTRIAL 20160419 Page 3 of 4
1 2 1
1 2
3 V
3 V
x2
75.5858.02 900 MHZ INDUSTRIAL 20160419 Page 3 of 4
All Transmitters
Removing Transmitters
Single Transmitter
Press BOTH learn buttons until
red LED flashes once (~2 s). Press BOTH learn buttons until blue LED illuminates (~10 s).
Press transmiter TWICE within
10 seconds.
Battery Replacement
Handheld (TD900INDHHx)
Remove back three (3) screws
and disassemble. Replace two (2) 3V (CR2032) batteries observing polarity and reassemble.
Low Battery Indicator - After transmitter button is pressed, low battery is indicated by three (3) transmitter LED blinks.
NOTE: All transmitters must ONLY be powered with provided batteries or equivalent.
SIGNAL STRENGTH INDICATION
red LED on receiver
fickering; unable to
program
stuck push plate disconnect push plates to determine which is
stuck (LED should go out)
faulty transmitter
if LED does not go out, remove transmitter
batteries to determine which is faulty, replace
transmitter
weak signal receiver antenna positioned
poorly position antenna outside of door header
TROUBLESHOOTING
Pressing and hold transmitter button for
at least 5 seconds activates singal strength
tri-color LED on receiver
Green LED on
Red LED on
Strong signal
Weak signal
Yellow LED on Medium signal

Page 4 of 4 75.5858.02 900 MHZ INDUSTRIAL 20160419
©BEA|OriginalInstructions|75.5858.02900MHZINDUSTRIAL20160419
FCC ID: 2ABWS-10RD900 IC: 4680A-10RD900 MODEL: 10RD900
FCC ID: 2ABWS-10TD9001HH4 IC: 4680A-10TD9001HH4 MODEL: 10TD900INDHH1
FCC ID: 2ABWS-10TD9001HH4 IC: 4680A-10TD9001HH4 MODEL: 10TD900INDHH2
FCC ID: 2ABWS-10TD9001HH4 IC: 4680A-10TD9001HH4 MODEL: 10TD900INDHH3
FCC ID: 2ABWS-10TD9001HH4 IC: 4680A-10TD9001HH4 MODEL: 10TD900INDHH4
Page 4 of 4 75.5858.02 900 MHZ INDUSTRIAL 20160419
Upon completion of the installation or service work, at a minimum, perform a daily safety check in accordance with the minimum
inspection guidelines provided by AAADM. Provide each equipment owner with an owner’s manual that includes a daily safety
checklist and contains, at a minimum, the information recommended by AAADM. Offer an information session with the equipment
owner explaining how to perform daily inspections and point out the location of power/operation switches to disable the equipment if
a compliance issue is noted. The equipment should be inspected annually in accordance with the minimum inspection guidelines. A
safety check that includes, at a minimum, the items listed on the safety information label must be performed during each service call.
If you are not an AAADM certifi ed inspector, BEA strongly recommends you have an AAADM certifi ed inspector perform an AAADM
inspection and place a valid inspection sticker below the safety information label prior to putting the equipment into operation.
ANSI / AAADM Compliance
PLEASE KEEP FOR FURTHER USE – DESIGNED FOR COLOR PRINTING
24/7 Tech Support: 1-800-407-4545 | Customer Service: 1-800-523-2462 | General Tech Questions: T[email protected] | Tech Docs: www.beasensors.com
TECHNICAL SPECIFICATIONS
Frequency: 908-918 MHz (frequency hopping)
Emitted radio power: -25 dBm (TX)
Power consumption: 13 mA (Transmitter)
40mA (Receiver)
Supply voltage: 12-24 VAC/DC
Contact rating: 1.0 A @ 30 VDC
0.5 A @ 125 VAC
0.3 A @ 60 VDC
Temperature range: 14°F to 131°F (-10°C to 55°C)
Programmable units per receiver: 75
LEDs: red (receiver learn)
blue (relay activation)
tri-color (signal strength)
Dimensions: 2.5” (W) x 2.0” (D) x 0.75” (H) [RD900]
1.5” (W) x 3.0” (D) x 0.5” (H) [Transmitter]
Transmitter Protection Rate NEMA4 / IP65
Certification: FCC, IC
Specifications are subject to changes without prior notice.
All values measured in specific conditions
