BEA EAS RF User manual

1/2
EAS RF
USER’S GUIDE
EASY ACCESS SYSTEM BASED ON RADIO FREQUENCY
EAS RF RECEIVER EAS RF KEY FOBS EAS RF TRANSMITTER
FOR PUSH PLATES
To open the receiver, expand the two
sides of the box and lift up the cover.
In its standard position, the antenna has a
maximum range of 10 m (open field).
To obtain a range of max 2 m, you can change the
position of the antenna as shown above.
LED Receiver
YELLOW
The record LED flashes when the system receives information coming from any key fob/transmitter
(recorded or not). During a ‘record’ sequence, the LED switches on until the system receives the data
coming from the new key fob/transmitter.
RED
The output LED switches on when the output is activated.
LED
Ke Fob/Transmitter
RED
The check LED switches on when the key fob/transmitter sends data to the EAS receiver.
Dip Switch Settings
1 2
ON
▲
Output
Toggle mode
Hold time
10s
OFF
▼
Output
Impulse mode
Hold time
0. s
Toggle mode
When you press the button of the key fob/transmitter, the output is
activated until you press the same button again.
Impulse mode
When you press the button of the key fob/transmitter, the output is
activated during 0. or 10 s (depending on dip switch 2).
Add one Ke Fob/ Transmitter 1. Press the record button on the EAS receiver once. The yellow LED will switch on.
2. Press the button of the new EAS ke fob/ transmitter twice.
When the LED stops flashing the key fob/transmitter is recorded in the system.
Remove all
Ke Fobs/ Transmitters
1. Press the record button on the EAS receiver until the ellow LED switches off (about 8 s).
2. The memory of the receiver is cleared now and you can re-activate your EAS key
fob(s)/transmitter(s) by using the above mentioned procedure.
1 Available from this ra ge (sold seperately)
2 Ge eral i formatio
L
arge
Butto
S
mall
Butto

2/2
1
11
1
Mounting and wiring the receiver
Fix the receiver in the door operator using
the double sided tape.
Connect the receiver to the door operator as shown.
Note: You can choose between NO (normally open) or NC (normally closed)
2
22
2
Mounting and wiring the transmitter for push plates
Connect the transmitter to the battery and to the push plate.
Note: You can choose between NO (normally open) or NC (normally closed)
To fix the transmitter and the battery in the push
plate mounting box, you can use the round
VELCRO stickers.
Technolog : radio frequency
Transmitter frequenc : 433.92 MHz
Max. detection distance : 2 m (open field)
Suppl voltage : 12V to 24V AC ±1 %; 12V to 30V DC ±10%
Standard output : relay; COM, NO, NC; 42 V AC/DC; 1A; 30 W (DC) / 60 VA (AC)
Holdtime : 0. s or 10s
Dimensions of receiver : 94mm (W) x 2mm (H) x 28mm (D)
Temperature range : -20°C to + °C (indoor use only!)
Length of cable : 2. m
Max. number of ke fobs/transmitters : 10
Power consumption Receiver: standby 10 mA, active 0 mA
Key Fob SB/Transmitter: standby 1 µA, active 10 mA
Key Fob LB: standby 1 µA, active 14 mA
LED-indicator Receiver: 1 yellow LED: record; 1 red LED: output
Key Fob/Transmitter: 1 red LED: emission
Batter Key Fob: 12V alkaline type A23 – 33 mAh; Transmitter: 9 V alkaline – 00 mAh
SYMPTOMS
POSSIBLE CAUSES
CORRECTIVE ACTI
ON
The door does not react to the EAS
key fob/ transmitter and the yellow
LED is OFF.
The key fob/transmitter battery is down. Check the key fob/transmitter LED and change the battery if
necessary.
Check the position of the antenna.
The EAS receiver power is off. Check the supply.
Check the supply voltage.
The door does not react to the EAS
key fob/ transmitter and the yellow
LED is flashing.
The key fob/transmitter is not recognized by
the EAS receiver.
Push the button on the key fob/transmitter twice.
Execute the recording procedure described under point 2 with
that key fob/transmitter.
The door does not react to the EAS
key fob/ transmitter and the red LED is
switched on.
The EAS receiver is not correctly wired. Check the connection to the door operator.
It is impossible to add or remove a key
fob/transmitter.
The maximum number of recordable key
fobs/transmitters in the system is reached.
Try to reduce the number of key fobs/transmitters.
Connect a second EAS receiver.
The key fob/transmitter battery is down. Check the key fob/transmitter LED and change the battery if
necessary.
4 Troubleshooti g
5 Tech ical specificatio s
3 I stallatio
42.0104 / V3 – 01.0
7
BROWN/GREEN
WHITE
YELLOW
NO
NC
COM
12V
-
24V AC/DC
NO
NC
COM
