Bebob ML-120V/V-HL User manual

bebob factory GmbH – Höglwörtherstr. 350 – D-81379 München – Tel.: [phone]
www.bebob.de
April 2016
ML-120V/V-HL Hot Swap Adapter
User Manual
WE STRONGLY RECOMMEND THAT YOU
READ THIS INSTRUCTION BEFORE USING
YOUR BEBOB ML-120V/V-HL HOT SWAP
ADAPTER! PLEASE KEEP THIS MANUAL
FOR FUTURE REFERENCE
Features
•Automatic switching by empty batteries to allow continuous powering of the Camera for
120s
•For Power hungry cameras: maximum Load 20.0A
•High-End aluminium V-Mount plate
•2 Step empty battery-alarm
•20Wh built-in power-buffer
•12V (unreg.) D-Tap Port with self-resetting 5A Fuse
•Zero maintenance required
•works only with V-Mount Lithium-Ion Battery ( nominal voltage between 14.4V and
14.8V)
Charging
•The ML-120V/V-HL charges itself from the V-Mount battery
•At first charge or If completely empty, the ML-120V/V-HL will be ready to use after 60
minutes
•While Charging the yellow "Charging" LED turns on
•When fully charged the green „Ready“ LED turns on
•The ML-120V/V-HL charges itself automatically when needed.
•During charging The ML-120V/V-HL keep monitoring the voltage of the battery and is
ready to switch if needed

bebob factory GmbH – Höglwörtherstr. 350 – D-81379 München – Tel.: [phone]
www.bebob.de
April 2016
Battery Swap
•The ML-120V/V-HL detects a battery as empty when the voltage drops below 12,5V
•The ML-120V/V-HL instantly takes over powering the Camera and the D-Tap port for a
maximum of 2 minutes and displays a red LED alarm
•The LED Alarm flashes for 90s, turns to solid for the last 30s.
•After the empty battery has been replaced by a charged one (voltage under load of over
14,5V), powering of the Camera instantly reverts to the V-Mount battery.
•The ML-120V/V-HL switches up to 6 Times before running empty
•If the empty battery is not replaced within 2 minutes the ML-120V/V-HL and the Camera
will switch off.
Alarm LED´s brightness
•To allow the Alarm LED to be visible in bright environments (sunlight etc.) but not
disturbingly over bright in darker environments (studio etc.), the ML-120 has automatic
brightness adjust.
•The brighter the environment the brighter the alarm LED will show.
•The environment light detector is located at the top – middle of the ML-120 housing.
•Covering the housing (with tape for instance) will switch off the automatic brightness adjust
and the alarm LED will flash with minimum brightness
Safety instructions
•Only for professional use! Keep Charger out of reach of children and personnel that has
not been instructed in the use!
•Use only with recommended batteries.
•Keep the ML-120V/V-HL dry and do not immerse in water.
•Do not attempt to open or repair the ML-120V7V. Contact your dealer for help if it becomes
defective.
•Handle with care! Do not throw! Do not drop!
Warranty
•The ML-120V/V-HL is covered by a 2 years unconditional warranty on all parts, except the
cells.
•The cells are covered by a 2 year warranty, 80% of the original capacity.
•For warranty issues or if you have any additional questions, please contact the appropriate
bebob distributor listed at www.bebob.de.

bebob factory GmbH – Höglwörtherstr. 350 – D-81379 München – Tel.: [phone]
www.bebob.de
April 2016
Specifications
Model
ML-120V/V-HL
Connection (camera)
V-Mount(m)
Batteries
Li-ion 14,4V or 14,8V
Battery Mount
V-Mount
Running Time
2 Minutes
Voltage
14,4V
Cells
Li-Ion Trimix HL made in Japan
Maximum Load
15.0A
D-Tap
1(max 5.0A) Self-reset Fuse
Charging Mode
Automatic
Charging Time
Max 60 Minutes
Display
Charge/ready
Dimensions (WXHXD)
140 x 76 x 45mm
Weight
0,52 Kg
