Beckett CG10(A) User manual

COMMERCIAL PRODUCTS
Models: CG10(A) • CG15 • CG25 • CG50
COMMERCIAL
COMMERCIAL
GAS BURNERS
GAS BURNERS
OEM Setup Guide
Specifications for commercial and industrial gas-fired heating appliances.

Commercial Gas Burner OEM Setup Guide
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Armstrong LG-14
280 LP CG10 On/Off 282 1.9 10.1S / 10.1 -1.5 / 0 2.25"
280 Nat CG10 On/Off 284 2.2 10.1S / 10.1 -1.5 / 0 2.25"
350 LP CG10 On/Off 350 2.9 10.1S / 10.1 -2.5 / 0 2.25"
350 Nat CG10 On/Off 351 3.4 10.1S / 10.1 -3 / 0 2.25"
420 LP CG10 On/Off 422 1.3 10.3S / 10.3 -4 / 0 2.25"
420 Nat CG10 On/Off 419 1.2 10.3S / 10.3 -3.5 / 0 2.25"
500 LP CG10 On/Off 498 1.8 10.3S / 10.3 -6.5 / 0 2.25"
500 Nat CG10 On/Off 499 1.7 10.3S / 10.3 -5.5 / 0 2.25"

Commercial Gas Burner OEM Setup Guide
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Buderus G315
5CG10 Low Fire Start 437 1.0 / 1.8 10.2S / 10.2 -4.5 / 0 4.50"
6CG10 Low Fire Start 551 1.0 / 2.1 10.3S / 10.3 -6.5 / 0 4.50"
7CG10 Low Fire Start 678 1.0 / 3.6 10.4S / 10.4 -8 / 0 4.50"
8CG10 Low Fire Start 800 1.0 / 3.9 10.5S / 10.5 -10 / 0 4.50"
9CG10 Low Fire Start 906 1.0 / 3.8 10.6S / 10.5 -10 / 3 4.50"
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Buderus SB615
145 CG10 Low Fire Start 497 0.9 / 1.8 10.3S / 10.3 -8 / 0 6.50"
185 CG10 Low Fire Start 644 0.9 / 1.7 10.4S / 10.4 -8 / 0 7.00"
240 CG10 Low Fire Start 835 1.0 / 2.0 10.5S / 10.5 -10 / 2 7.00"
240 CG15 Mod 468 / 835 1.2 / 3.9 15.1S / 15.1 22 / 46 -7.00"
310 CG10 Low Fire Start 1080 1.2 / 2.4 10.6S / 10.6 -10 / 8 7.00"
310 CG15 Mod 641 / 1080 1.2 / 3.4 15.3S / 15.3 28 / 60 -7.00"
400 CG25 Mod 669 / 1393 0.95 / 4.1 25.1S / 25.1 15 / 45 -7.00"
510 CG25 Mod 896 / 1776 1.0 / 4.1 25.3S / 25.3 27 / 58 -7.00"
640 CG50 Low/High 1101 / 2214 0.95 / 4.1 50.1S / 50.1 21 / 35 -7.00"
640 CG50 Mod 892 / 2214 0.6 / 4.1 50.1S / 50.1 18 / 35 -7.00"
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Buderus SB735
1200 CG50 Mod 1719 / 4162 0.7 / 5.0 50.5S / 50.5 26 / 86 -9.00"
790 CG50 Mod 1245 / 2802 0.65 / 3.9 50.3S / 50.3 21 / 48 9.00"
970 CG50 Mod 1443 / 3378 0.78 / 4.3 50.4S / 50.4 23 / 65 -9.00"

Commercial Gas Burner OEM Setup Guide
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Burnham MPC
MPC 4 CG10 Low Fire Start 500 1.0 / 1.8 10.3 / 10.3 -6/0 4.25"
MPC 5 CG10 Low Fire Start 773 1.6 / 3.2 10.5S / 10.4 -10/0 4.25"
MPC 6 CG15 Mod 540 / 995 1.15 / 3.15 15.2S / 15.2 26 / 45 -4.25"
MPC 7 CG15 Mod 628 / 1216 1.1 / 3.6 15.3S / 15.3 29 / 60 -4.25"
MPC 8 CG15 Mod 668 / 1438 1.1 / 3.6 25.1S / 25.1 16 / 45 -4.25"
MPC 9 CG25 Mod 772 / 1660 0.8 / 3.57 25.2S / 25.2 22 / 48 -4.25"
MPC10 CG25 Mod 878 / 1881 0.75 / 3.4 25.3S / 25.3 25 / 54 -4.25"
MPC11 CG25 Mod 1052 / 2103 0.9 / 3.6 25.4S / 25.4 27 / 62 -4.25"
MPC12 CG25 Mod 1048 / 2325 0.9 / 4.2 25.4S / 25.4 29 / 83 -4.25"
MPC13 CG50 Mod 1048 / 2325 0.8 / 3.6 50.2S / 50.2 20 / 39 -4.25"
MPC14 CG50 Mod 1247 / 2769 0.7 / 3.4 50.3S / 50.3 22 / 43 -4.25"
MPC15 CG50 Mod 1216 / 2991 0.7 / 4.0 50.3S / 50.3 22 / 50 -4.25"
MPC16 CG50 Mod 1214 / 3213 0.7 / 4.3 50.3S / 50.3 21 / 70 -4.25"
MPC17 CG50 Mod 1471 / 3435 0.7 / 4.0 50.4S / 50.4 24 / 60 -4.25"
MPC18 CG50 Mod 1389 / 3657 0.7 / 4.9 50.4S / 50.4 25 / 72 -4.25"
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Burnham V11
V1104 CG10 Low Fire Start 843 1.0 / 3.3 10.6S / 10.6 -10 / 0 4.00"
V1104 CG15 Mod 478 / 845 1.1 / 3.45 15.1S / 15.1 22 / 42 4.00"
V1105 CG10 Low Fire Start 1070 1.0 / 4.75 10.6S / 10.6 -10 / 5 4.00"
V1105 CG15 Mod 554 / 1078 0.9 / 3.8 15.2S / 15.2 25 / 50 -4.00"
V1106 CG15 Mod 757 / 1343 1.15 / 3.3 15.4S / 15.4 33 / 67 -4.00"
V1106 CG25 Mod 670 / 1340 0.8 / 3.1 25.1S / 25.1 15 / 40 -4.00"
V1107 CG25 Mod 782 / 1588 0.75 / 3.1 25.2S / 25.2 21 / 46 -4.00"
V1108 CG25 Mod 896 / 1876 0.77 / 3.36 25.3S / 25.3 27 / 55 -4.00"
V1109 CG25 Mod 1037 / 2136 0.78 / 3.32 25.4S / 25.4 28 / 62 -4.00"
V1110 CG25 Mod 1200 / 2396 0.74 / 2.94 25.5S / 25.5 32 / 95 -4.00"
V1111 CG50 Mod 1052 / 2710 0.55 / 3.55 50.2S / 50.2 20 / 42 -4.00"
V1112 CG50 Mod 1238 / 2915 0.55 / 2.9 50.3S / 50.3 21 / 42 -4.00"
V1113 CG50 Mod 1228 / 3103 0.53 / 3.4 50.3S / 50.3 21 / 50 -4.00"
V1114 CG50 Mod 1443 / 3392 0.54 / 2.97 50.4S / 50.4 23 / 50 -4.00"
V1115 CG50 Mod 1443 / 3680 0.54 / 3.4 50.4S / 50.4 23 / 70 -4.00"
V1116 CG50 Mod 1700 / 3897 0.57 / 3.0 50.5S / 50.5 26 / 65 -4.00"
V1117 CG50 Mod 1700 / 4186 0.57 / 3.44 50.5S / 50.5 26 / 75 -4.00"
V1118 CG50 Mod 1700 / 4474 0.56 / 3.85 50.5S / 50.5 26 / 85 -4.00"
V1119 CG50 Mod 1703 / 4713 0.57 / 4.15 50.5S / 50.5 26 / 95 -4.00"

Commercial Gas Burner OEM Setup Guide
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Burnham V9A
V903A CG10 Low Fire Start 442 1.1 / 2.5 10.1S / 10.1 -10 / 1 4.125"
V904A CG10 Low Fire Start 618 1.1 / 2.6 10.4S / 10.4 -5 / 2 4.125"
V905A CG10 Low Fire Start 811 1.2 / 3.3 10.5S / 10.5 -7 / 1 4.125"
V906A CG10 Low Fire Start 1010 1.2 / 4.0 10.6S / 10.6 -10 / 6 4.125"
V907A CG15 Mod 641 / 1192 0.9 / 3.6 15.3S / 15.3 28 / 64 -4.125"
V908A CG15 Mod 736 / 1381 0.95 / 3.4 15.4S / 15.4 33 / 75 -4.125"
V908A CG25 Mod 752 / 1378 0.9 / 3.2 25.1S / 21.1 16 / 41 -4.125"
V909A CG25 Mod 774 / 1674 0.9 / 3.4 25.2S / 25.2 23 / 47 -4.125"
V910A CG25 Mod 896 / 1905 0.76 / 3.44 25.3S / 25.3 26 / 52 -4.125"
V911A CG25 Mod 1041 / 2108 0.8 / 3.2 25.4S / 25.4 28 / 62 -4.125"
V912A CG50 Mod 1027 / 2360 0.55 / 2.6 50.2S / 50.2 20 / 38 -4.125"
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Crown 24
03 CG10 Low Fire Start 442 1.1 / 2.5 10.1S / 10.1 -10 / 1 4.125"
04 CG10 Low Fire Start 618 1.1 / 2.6 10.4S / 10.4 -5 / 2 4.125"
05 CG10 Low Fire Start 811 1.2 / 3.3 10.5S / 10.5 -7 / 1 4.125"
06 CG10 Low Fire Start 1010 1.2 / 4.0 10.6S / 10.6 -10 / 6 4.125"
07 CG15 Mod 641 / 1192 0.9 / 3.6 15.3S / 15.3 28 / 64 -4.125"
08 CG15 Mod 736 / 1381 0.95 / 3.4 15.4S / 15.4 33 / 75 -4.125"
08 CG25 Mod 752 / 1378 0.9 / 3.2 25.1S / 25.1 16 / 41 -4.125"
09 CG25 Mod 774 / 1674 0.9 / 3.4 25.2S / 25.2 23 / 47 -4.125"
10 CG25 Mod 896 / 1905 0.76 / 3.44 25.3S / 25.3 26 / 52 -4.125"
11 CG25 Mod 1041 / 2108 0.8 / 3.2 25.4S / 25.4 28 / 62 -4.125"
12 CG50 Mod 1027 / 2360 0.55 / 2.6 50.2S / 50.2 20 / 38 -4.125"

Commercial Gas Burner OEM Setup Guide
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
H. B. Smith 19A
19A- 3 CG10 Low Fire Start 369 0.7 / 2.2 10.1 / 10.1 -4.5 / 0 4.00"
19A- 4 CG10 Low Fire Start 523 0.8 / 2.3 10.3 / 10.3 -5.5 / 0 4.00"
19A- 5 CG10 Low Fire Start 728 1.5 / 3.7 10.4S / 10.4 -10 / 2 4.00"
19A- 6 CG10 Low Fire Start 942 1.7 / 4.7 10.5S / 10.5 -10 / 4 4.00"
19A- 6 CG15 Mod 467 / 940 1.0 / 4.1 15.1S / 15.1 22 / 47 -4.50"
19A- 7 CG15 Mod 551 / 1160 0.9 / 4.25 15.2S / 15.2 25 / 55 -4.50"
19A- 8 CG15 Mod 647 / 1328 0.95 / 4.2 15.3S / 15.3 28 / 70 -4.50"
19A- 9 CG25 Mod 667 / 1558 0.7 / 4.2 25.1S / 25.1 17 / 52 -4.50"
19A-10 CG25 Mod 762 / 1762 0.7 / 3.8 25.2S / 25.2 22 / 56 -4.50"
19A-11 CG25 Mod 882 / 2006 0.7 / 3.9 25.3S / 25.3 26 / 71 -4.50"
19A-12 CG25 Mod 1044 / 2157 0.75 / 3.5 25.4S / 25.4 28 / 68 -4.50"
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
H. B. Smith 28A
28A- 4 CG15 Mod 581 / 1156 1.05 / 4.4 15.2S / 15.2 25 / 50 -4.875"
28A- 5 CG25 Mod 758 / 1506 0.7 / 2.95 25.2S / 25.2 21 / 43 -4.875"
28A- 6 CG25 Mod 899 / 1833 0.7 / 3.15 25.3S / 25.3 25 / 50 -4.875"
28A- 7 CG25 Mod 1051 / 2179 0.75 / 3.45 25.4S / 25.4 28 / 60 -4.875"
28A- 7 CG50 Low/High 1085 / 2182 0.85 / 3.5 50.1S / 50.1 20 / 35 -4.875"
28A- 7 CG50 Mod 890 / 2182 0.6 / 3.5 50.1S / 50.1 17 / 35 -4.875"
28A- 8 CG25 Mod 1201 / 2527 0.7 / 3.3 25.5S / 25.5 32 / 105 -4.875"
28A- 8 CG50 Low/High 1259 / 2507 0.8 / 3.2 50.2S / 50.2 23 / 40 -4.875"
28A- 8 CG50 Mod 1047 / 2507 0.6 / 3.2 50.2S / 50.2 20 / 40 -4.875"
28A- 9 CG50 Mod 1235 / 2862 0.6 / 3.1 50.3S / 50.3 21 / 42 -4.875"
28A- 9 CG50 Low/High 1420 / 2862 0.8 / 3.1 50.3S / 50.3 24 / 42 -4.875"
28A-10 CG50 Low/High 1599 / 3222 0.9 / 3.8 50.3S / 50.3 26 / 65 -4.875"
28A-10 CG50 Mod 1234 / 3222 0.6 / 3.8 50.3S / 50.3 21 / 65 -4.875"
28A-11 CG50 Low/High 1683 / 3521 0.8 / 3.3 50.4S / 50.4 26 / 52 -4.875"
28A-11 CG50 Mod 1452 / 3521 0.55 / 3.3 50.4S / 50.4 23 / 52 -4.875"
28A-12 CG50 Low/High 1931 / 3918 0.8 / 3.1 50.5S / 50.5 29 / 65 -4.875"
28A-12 CG50 Mod 1707 / 3918 0.55 / 3.1 50.5S / 50.5 27 / 65 -4.875"
28A-13 CG50 Mod 1712 / 4199 0.55 / 3.5 50.5S / 50.5 27 / 85 -4.875"
28A-13 CG50 Low/High 2108 / 4199 0.9 / 3.5 50.5S / 50.5 31 / 85 -4.875"
28A-14 CG50 Low/High 2262 / 4538 1.0 / 4.0 50.5S / 50.5 32 / 95 -4.875"
28A-14 CG50 Mod 1732 / 4538 0.55 / 4.0 50.5S / 50.5 27 / 95 -4.875"

Commercial Gas Burner OEM Setup Guide
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
H. B. Smith HE28
HE28- 4 CG15 Mod 580 / 1146 1.15 / 4.55 15.2S / 15.2 25 / 58 -4.875"
HE28- 5 CG25 Mod 730 / 1467 0.65 / 2.9 25.2S / 25.2 21 / 42 -4.875"
HE28- 6 CG25 Mod 899 / 1794 0.75 / 3.15 25.3S / 25.3 25 / 50 -4.875"
HE28- 7 CG25 Mod 1048 / 2097 0.8 / 3.35 25.4S / 25.4 28 / 60 -4.875"
HE28- 7 CG50 Low/High 1058 / 2103 0.8 / 3.2 50.1S / 50.1 19 / 34 -4.875"
HE28- 7 CG50 Mod 889 / 2103 0.55 / 3.2 50.1S / 50.1 17 / 34 -4.875"
HE28- 8 CG25 Mod 1221 / 2411 0.8 / 3.25 25.5S /25.5 32 / 105 -4.875"
HE28- 8 CG50 Mod 1047 / 2435 0.55 / 3.1 50.2S / 50.2 20 / 38 -4.875"
HE28- 9 CG50 Mod 1053 / 2724 0.55 / 3.8 50.2S / 50.2 21 / 43 -4.875"
HE28- 9 CG50 Low/High 1367 / 2724 0.85 / 3.8 50.2S / 50.2 23 / 43 -4.875"
HE28-10 CG50 Mod 1241 / 3081 0.55 / 3.5 50.3S / 50.3 21 / 50 -4.875"
HE28-10 CG50 Low/High 1520 / 3081 0.8 / 3.5 50.3S / 50.3 25 / 50 -4.875"
HE28-11 CG50 Mod 1463 / 3396 0.55 / 3.2 50.4S / 50.4 23 / 50 -4.875"
HE28-11 CG50 Low/High 1676 / 3396 0.8 / 3.2 50.4S / 50.4 26 / 50 -4.875"
HE28-12 CG50 Mod 1449 / 3679 0.55 / 3.7 50.4S / 50.4 26 / 60 -4.875"
HE28-12 CG50 Low/High 1849 / 3679 0.85 / 3.7 50.4S / 50.4 30 / 60 -4.875"
HE28-13 CG50 Mod 1711 / 3982 0.55 / 3.2 50.5S / 50.5 26 / 70 -4.875"
HE28-13 CG50 Low/High 2009 / 3982 0.8 / 3.2 50.5S / 50.5 30 / 70 -4.875"
HE28-14 CG50 Mod 1709 / 4299 0.55 / 3.7 50.5S / 50.5 26 / 90 -4.875"
HE28-14 CG50 Low/High 2149 / 4299 0.85 / 3.7 50.5S / 50.5 31 / 90 -4.875"

Commercial Gas Burner OEM Setup Guide
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Peerless LC/LCE
LC04 CG10 Low Fire Start 691 1.4 / 3.2 10.5S / 10.4 -7.5 / 0 3.00"
LC05 CG15 Low/High 468 / 881 0.8 / 2.9 15.2S / 15.1 25 / 40 -3.00"
LC05R CG15 Low/High 476 / 806 0.9 / 2.35 15.2S / 15.1 25 / 37 -3.00"
LC06 CG15 Low/High 550 / 1086 0.9 / 3.9 15.2S / 15.2 25 / 52 -3.00"
LC07 CG15 Low/High 641 / 1270 0.8 / 3.65 15.3S / 15.4 33 / 59 -3.00"
LC07 CG25 Mod 659 / 1280 0.7 / 3.0 25.1S / 25.1 16 / 38 -3.00"
LC08 CG25 Mod 669 / 1469 0.7 / 3.4 25.1S / 25.1 16 / 43 -3.00"
LC09 CG25 Mod 774 / 1664 0.7 / 3.4 25.2S / 25.2 21 / 49 -3.00"
LC10 CG25 Mod 896 / 1860 0.8 / 3.1 25.3S / 25.3 25 / 52 -3.00"
LC11 CG25 Mod 1037 / 2059 0.7 / 3.1 25.4S / 25.4 28 / 60 -3.00"
LC12 CG25 Mod 1184 / 2278 0.7 / 2.9 25.5S / 25.5 32 / 68 -3.00"
LCE13 CG50 Mod 1060 / 2460 0.55 / 2.7 50.2S / 50.2 20 / 40 -3.00"
LCE14 CG50 Mod 1044 / 2657 0.5 / 3.5 50.2S / 50.2 20 / 42 -3.00"
LCE15 CG50 Mod 1228 / 2850 0.5 / 2.9 50.3S / 50.3 21 / 42 -3.00"
LCE16 CG50 Mod 1228 / 3043 0.5 / 3.2 50.3S / 50.3 21 / 49 -3.00"
LCE17 CG50 Mod 1228 / 3236 0.5 / 3.5 50.3S / 50.3 21 / 70 -3.00"
LCE18 CG50 Mod 1439 / 3451 0.55 / 3.05 50.4S / 50.4 23 / 50 -3.00"
LCE19 CG50 Mod 1443 / 3622 0.5 / 3.2 50.4S / 50.4 23 / 60 -3.00"
LCE20 CG50 Mod 1443 / 3815 0.5 / 3.7 50.4S / 50.4 23 / 75 -3.00"
LCE21 CG50 Mod 1700 / 4027 0.5 / 3.1 50.5S / 50.5 26 / 75 -3.00"
LCE22 CG50 Mod 1700 / 4239 0.5 / 3.3 50.5S / 50.5 26 / 78 -3.00"
LCE23 CG50 Low/High 2197 / 4450 0.75 / 3.8 50.5S /50.5 33 / 82 -3.00"
LCE23 CG50 Mod 1707 / 4450 0.55 / 3.8 50.5S / 50.5 26 / 82 -3.00"
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Peerless SC/SCT
SC05 CG10 Low Fire Start 444 1.0 / 3.0 10.1 / 10.1 -10 / 2 2.50"
SC06 CG10 On/Off 491 2.0 10.3 / 10.3 -5 / 0 2.50"
SC07 CG10 On/Off 569 2.7 10.3 / 10.3 -8 / 0 2.50"
SC08 CG10 Low Fire Start 656 1.5 / 3.4 10.4S / 10.4 -6.5 / 0 2.50"
SC09 CG10 Low Fire Start 741 2.0 / 4.2 10.4S / 10.4 -8.5 / 0 2.50"
SC10 CG10 Low Fire Start 802 2.0 / 3.9 10.5S /10.5 -10 / 3 2.50"

Commercial Gas Burner OEM Setup Guide
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Peerless TC
TC-04 CG15 Mod 581 / 1156 1.05 / 4.4 15.2S / 15.2 25 / 50 -4.875"
TC-05 CG25 Mod 758 / 1506 0.7 / 2.95 25.2S / 25.2 21 / 43 -4.875"
TC-06 CG25 Mod 899 / 1833 0.7 / 3.15 25.3S / 25.3 25 / 50 -4.875"
TC-07 CG25 Mod 1051 / 2179 0.75 / 3.45 25.4S / 25.4 28 / 60 -4.875"
TC-07 CG50 Low/High 1085 / 2182 0.85 / 3.5 50.1S / 50.1 20 / 35 -4.875"
TC-07 CG50 Mod 890 / 2182 0.6 / 3.5 50.1S / 50.1 17 / 35 -4.875"
TC-08 CG25 Mod 1201 / 2527 0.7 / 3.3 25.5S / 25.5 32 / 105 -4.875"
TC-08 CG50 Mod 1047 / 2507 0.6 / 3.2 50.2S / 50.2 20 / 40 -4.875"
TC-08 CG50 Low/High 1259 / 2507 0.8 / 3.2 50.2S / 50.2 23 / 40 -4.875"
TC-09 CG50 Low/High 1420 / 2862 0.8 / 3.1 50.3S / 50.3 24 / 42 -4.875"
TC-09 CG50 Mod 1235 / 2862 0.6 / 3.1 50.3S / 50.3 21 / 42 -4.875"
TC-10 CG50 Low/High 1599 / 3222 0.9 / 3.8 50.3S / 50.3 26 / 65 -4.875"
TC-10 CG50 Mod 1234 / 3222 0.6 / 3.8 50.3S / 50.3 21 / 65 -4.875"
TC-11 CG50 Mod 1452 / 3521 0.55 / 3.3 50.4S / 50.4 23 / 52 -4.875"
TC-11 CG50 Low/High 1683 / 3521 0.8 / 3.3 50.4S / 50.4 26 / 52 -4.875"
TC-12 CG50 Mod 1707 / 3918 0.55 / 3.1 50.5S / 50.5 27 / 65 -4.875"
TC-12 CG50 Low/High 1931 / 3918 0.8 / 3.1 50.5S / 50.5 29 / 65 -4.875"
TC-13 CG50 Low/High 2108 / 4199 0.9 / 3.5 50.5S / 50.5 31 / 85 -4.875"
TC-13 CG50 Mod 1712 / 4199 0.55 / 3.5 50.5S / 50.5 27 / 85 -4.875"
TC-14 CG50 Low/High 2262 / 4538 1.0 / 4.0 50.5S / 50.5 32 / 95 -4.875"
TC-14 CG50 Mod 1732 / 4538 0.55 / 4.0 50.5S / 50.5 27 / 95 -4.875"
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Scotch Marine
100HP CG50 Mod 1700 / 4200 0.55 / 3.6 50.5S / 50.5 26 / 90 -4.00"
20HP CG15 Mod 468 / 840 0.9 / 3.44 15.1S / 15.1 23 / 43 -4.12"
30HP CG15 Mod 641 / 1260 0.9 / 3.86 15.3S / 15.3 24 / 80 -4.12"
40HP CG25 Mod 774 / 1680 0.75 / 3.58 25.2S / 25.2 22 /48 -4.12"
50HP CG25 Mod 1037 / 2100 0.75 / 3.3 25.4S / 25.4 28 / 63 -4.12"
60HP CG50 Mod 1044 / 2520 0.55 / 3.32 50.2S / 50.2 21 / 41 -4.00"
70HP CG50 Mod 1228 / 2940 0.55 / 3.2 50.3S / 50.3 22 / 46 -4.00"
80HP CG50 Mod 1443 / 3360 0.55 / 3.26 50.4S / 50.4 23 / 48 -4.00"
90HP CG50 Mod 1443 / 3780 0.55 / 3.88 50.4S / 50.4 23 / 80 -4.00"

Commercial Gas Burner OEM Setup Guide
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Weil McLain 80
380 CG10 Low Fire Start 336 0.7 / 1.8 10.1S / 10.1 -3 / 0 3.00"
480 CG10 Low Fire Start 491 0.8 / 1.45 10.3S / 10.3 -6 / 0 3.00"
580 CG10 Low Fire Start 639 1.6 / 3.11 10.4S / 10.4 -8 / 0 3.00"
680 CG10 Low Fire Start 787 1.7 / 3.3 10.5S / 10.5 -8 / 1 3.00"
780 CG10 Low Fire Start 943 1.0 / 3.2 10.6S / 10.6 -10 / 3 3.00"
780 CG15 Mod 461 / 945 1.0 / 4.2 15.1S / 15.1 22 / 50 -4.00"
880 CG10 Low Fire Start 1067 1.0 / 4.1 10.6S / 10.6 -10 / 4 4.00"
880 CG15 Mod 542 / 1072 0.9 / 3.5 15.2S / 15.2 25 / 47 -4.00"
980 CG15 Mod 641 / 1230 0.95 / 3.49 15.3S / 15.3 28 / 65 -4.00"
1080 CG15 Mod 742 / 1392 0.8 / 3.0 15.4S / 15.4 28 / 62 -4.00"
1080 CG25 Mod 682 / 1378 0.75 / 3.0 25.1S / 25.1 15 / 42 -4.00"
1180 CG25 Mod 774 / 1526 0.73 / 2.83 25.2S / 25.2 21 / 43 -4.00"
1280 CG25 Mod 787 / 1670 0.75 / 3.1 25.2S / 25.2 21 / 48 -4.00"
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Weil McLain 88
488 / 488R CG10 Low Fire Start 995 1.0 / 3.8 10.6S / 10.6 -10 / 4 4.00"
488 / 488R CG15 Mod 550 / 991 0.9 / 3.2 15.2S / 15.2 25 / 45 -4.00"
588 CG25 Mod 656 / 1382 0.75 / 3.1 25.1S / 25.1 17 / 40 -4.00"
688 CG25 Mod 774 / 1703 0.76 / 3.62 25.2S / 25.2 21 / 51 -4.00"
788 CG50 Mod 888 / 2053 0.55 / 2.5 50.1S / 50.1 17 / 32 -4.00"
888 CG50 Mod 1040 / 2350 0.55 / 2.2 50.2S / 50.2 20 / 37 -4.00"
988 CG50 Mod 1044 / 2713 0.54 / 3.77 50.2S / 50.2 20 / 42 -4.00"
988R CG50 Mod 1044 / 2482 0.55 / 3.12 50.2S / 50.2 20 / 39 -4.00"
1088 CG50 Mod 1228 / 3103 0.55 / 3.52 50.3S / 50.3 21 / 53 -4.00"
1088R CG50 Mod 1228 / 2887 0.56 / 3.1 50.3S / 50.3 21 / 42 -4.00"
1188 CG50 Mod 1443 / 3392 0.57 / 3.14 50.4S / 50.4 23 / 50 -4.00"
1288 CG50 Mod 1443 / 3753 0.55 / 3.73 50.4S / 50.4 23 / 75 -4.00"
1388 CG50 Mod 1700 / 4113 0.59 / 3.45 50.5S / 50.5 26 / 70 -4.00"
1488 CG50 Mod 1762 / 4488 0.6 / 3.2 50.5S / 50.5 26 / 90 -4.00"

Commercial Gas Burner OEM Setup Guide
Boiler Burner Firing Mode Rate
MBH
Manifold
Pressure
in. water
Damper
Setting
Blue / Red
Head Type
/ Head
Setting
Shutter
Band
Settings
Air Tube
Insertion
Inches
Weil McLain 88 Series 2
488 CG10 Low Fire Start 986 1.5 / 4.5 10.6S / 10.6 -10/4 4.00"
588 CG25 Mod 676 / 1357 0.8 / 3.5 25.1S / 25.1 16 / 41 -4.00"
688 CG25 Mod 784 / 1729 0.8 / 3.7 25.2S / 25.2 22 / 53 -4.00"
788 CG50 Mod 904 / 2017 0.6 / 3.1 50.1S / 50.1 19 / 32 -4.00"
888 CG50 Mod 1030 / 2396 0.5 / 3.05 50.2S / 50.2 20 / 39 -4.00"
988 CG50 Mod 1055 / 2666 0.6 / 3.75 50.2S / 50.2 20 / 43 -4.00"
1088 CG50 Mod 1228 / 3089 0.55 / 3.65 50.3S / 50.3 21 / 48 -4.00"
1188 CG50 Mod 1458 / 3403 0.6 / 3.6 50.4S / 50.4 23 / 53 -4.00"
1288 CG50 Mod 1462 / 3762 0.6 / 4.15 50.4S / 50.4 23 / 75 -4.00"
1388 CG50 Mod 1719 / 4171 0.65 / 4.0 50.5S / 50.5 26 / 70 -4.00"

COMMERCIAL PRODUCTS
R.W. Beckett Corporation ● P.O. Box 1289, Elyria, Ohio 44036-1289 ● 1-800-645-2876 ● Fax: [phone]
R.W. Beckett Canada, Ltd. ●430 Laird Road, Unit 3, Guelph, Ontario N1G 3X7 ●1-800-665-6972 ●Fax: [phone]
www.beckettcorp.com
Form No. 61640 R04, Printed in the USA 01/10
