Beckett CF1000 User manual

COMMERCIAL PRODUCTS
Models: CF375 • CF500 • CF800 • CF1000 • CF1400 • CF2300A • CF2500A • CF3500A
COMMERCIAL
COMMERCIAL
OIL BURNERS
OIL BURNERS
OEM Setup Guide
Specifications for commercial and industrial oil-fired heating appliances.

Bryan Steam DR Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
250 CF375 BCF3907 CF56KZ 1.79 1.50x60ES 1 10 1/2 N/A 140 51311 5.00"
350 CF375 BCF3907 C100KZ 2.50 2.00x60P 3 10 2 N/A 190 51311 5.00"
450 CF500 BCF809 CF100KK 3.21 2.50x45P 4 4 0 N/A 150 51311 5.00"
650 CF800 BCF403 CF100KH 4.64 4.00x60B (D) 3 7 0 N/A 140 51311 5.50"
850 CF800 BCF403 CF100KJ 6.07 5.00x45B (D) 2 8 8 N/A 150 51311 5.50"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 1

Buderus G215 Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
3 AFG B2007 AFG50ML 1.10 0.90x45ES 0 8 1 N/A 170 51311 3.50"
4 AFG B2007 AFG50ML 1.40 1.10x45ES 2 8 2 N/A 175 51311 3.50"
5 CF375 BCF3907 CF56KY 1.75 1.35x45ES 2 5 1 N/A 170 51311 3.50"
6 CF375 BCF3907 CF56KZ 2.10 1.75x45ES 1 7 2 N/A 140 51311 3.50"
7 CF375 BCF3907 CF56KZ 2.50 2.00x45P 1 9 3 N/A 150 51311 3.50"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Buderus G315 Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
5 CF500 BCF809 CF80KK 3.00 2.50x45P 3 7 0 N/A 140 51311 4.75"
6 CF800 BCF403 CF80KH 3.85 3.25x45P 1 7 0 N/A 140 51311 4.75"
7 CF800 BCF403 CF80KH 4.70 4.00x45P 2 10 0 N/A 140 51311 4.50"
8 CF1400 BCF205 CF66KD 5.50 3.25x45P 1 20 35 150 275 51312 4.50"
9 CF1400 BCF205 CF66KD 6.40 3.75x45P 3 25 40 150 275 51312 4.50"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Buderus G515 Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
7 CF1400 BCF205 CF102KD 6.90 4.00x60P 5 20 30 150 300 51312 6.00"
8 CF1400 BCF205 CF102KD 8.40 5.00x60P 9 30 43 150 275 51312 6.00"
9 CF2300A BCF304 CF102KG 10.00 5.50x45P 0 20 33 150 300 51312 6.00"
10 CF2300A BCF304 CF102KG 11.60 6.50x45P 2 25 40 150 300 51312 6.00"
11 CF2300A BCF304 CF102KG 13.00 7.50x45P 6 25 40 150 300 51312 6.00"
12 CF2300A BCF304 CF102KG 14.60 8.50x45P 8-1/2 30 70 150 300 51312 6.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 2

Buderus G615 Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
9 CF2300A BCF304 CF102KG 16.00 9.00x45P 5 30 60 150 300 51630 6.25"
10 CF2500 BCF1801 CF102KP 18.50 5.00x45P (2) 2 23 25 300 300 51630 6.25"
11 CF2500 BCF1801 CF102KP 21.00 6.00x45P (2) 5 27 40 300 300 51630 6.25"
12 CF3500A BCF1301 CF114KM 23.50 6.50x45P (2) 4-1/2 20 35 300 300 51630 6.25"
13 CF3500A BCF1301 CF114KM 26.00 7.50x45P (2) 5 25 40 300 300 51630 6.25"
14 CF3500 BCF1301 CF114KR 28.50 8.50x60P (2) 6 30 60 300 300 51631 6.25"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Flange requires an additional adapter plate.
Page 3

Burnham Corporation ESeries Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
E20 CF800 BCF403 CF80KJ 6.00 5.00x60SS 2 10 5 N/A 140 51628 5.50"
E20 CF1400 BCF205 CF66KE 6.00 3.50x60SS 1/2 20 40 125 300 51629 5.50"
E30 CF1400 BCF205 CF66KE 9.00 5.00x60SS 3 30 60 125 300 51629 5.50"
E40 CF2300A BCF304 CF66KG 12.00 7.00x60SS 1 30 40 125 300 51630 5.50"
E50 CF2300A BCF304 CF66KG 15.00 9.00x60SS 4 25 30 125 300 51630 5.50"
E60 CF2300A BCF304 CF66KG 18.00 11.00x60SS 6 35 90 125 300 51630 5.50"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Burnham Corporation FD Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
FD-9 CF500 BCF809 CF60KK 2.75 2.00x45P 2 4 0 N/A 150 51311 3.375"
FD-10 CF500 BCF809 CF60KK 3.00 2.50x45P 2 4 0 N/A 150 51311 3.375"
FD-12 CF800 BCF403 CF60KH 4.00 3.25x45P 1-1/2 5-1/2 0 N/A 150 51311 3.375"
FD-14 CF800 BCF403 CF60KH 4.50 3.75x45P 2 7 0 N/A 150 51311 3.375"
FD-15 CF800 BCF403 CF60KH 5.00 4.00x45P 2 8 0 N/A 150 51311 3.375"
FD-19 CF800 BCF403 CF60KH 6.00 4.50x60B 4 10 2 N/A 150 51628 3.375"
FD-24 CF1400 BCF205 CF66KD 7.50 4.50x45P 3 30 55 150 300 51629 3.375"
FD-30 CF1400 BCF205 CF66KE 9.50 5.50x45P 1-1/2 30 75 150 300 51629 3.375"
FD-38 CF2300A BCF304 CF66KG 12.00 7.00x45P 1 25 45 150 300 51313 3.375"
FD-45 CF2300A BCF304 CF66KG 13.80 8.00x45P 1-1/2 25 60 150 300 51313 3.375"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 4

Burnham Corporation FDO Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
FDO-7 CF500 BCF809 CF60KK 2.25 2.00x45P 1 3-1/2 0 N/A 140 51311 4.375"
FDO-9 CF500 BCF809 CF60KK 2.75 2.25x45P 2 4 0 N/A 140 51311 4.375"
FDO-10 CF500 BCF809 CF60KK 3.00 2.75x45P 2 4 0 N/A 140 51311 4.375"
FDO-12 CF800 BCF403 CF60KH 4.00 3.50x45P 2 6 0 N/A 140 51311 4.375"
FDO-14 CF800 BCF403 CF60KH 4.50 4.00x45P 2 7 0 N/A 140 51311 4.375"
FDO-15 CF800 BCF403 CF60KH 5.00 4.50x45P 2 8 0 N/A 140 51311 4.375"
FDO-19 CF800 BCF403 CF60KJ 6.00 5.00x45P 3 10 3 N/A 140 51628 4.375"
FDO-24 CF1400 BCF205 CF66KD 7.50 4.50x45P 3 30 55 150 300 51629 4.375"
FDO-30 CF1400 BCF205 CF66KE 9.00 5.50x45P 1-1/2 45 75 150 300 51629 4.375"
FDO-38 CF2300A BCF304 CF66KG 12.00 7.00x45P 1 25 45 150 300 51313 4.375"
FDO-45 CF2300A BCF304 CF66KG 13.80 8.00x45P 1-1/2 25 60 150 300 51313 4.375"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 5

Burnham Corporation MPC Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
MPC-4 CF500 BCF809 CF66KK 3.55 02.75x70B D 3 10 2 N/A 150 0 4.25"
MPC-5 CF800 BCF403 CF60KH 5.50 04.50x70B D 3 8.5 0 N/A 150 0 4.25"
MPC- 6 CF1400 BCF205 CF66KD 7.10 04.25x60B D 4 43 48 150 250 0 4.25"
MPC-7 CF1400 BCB8302 CF66KE 7.80 05.00x45B D 6 45 51 150 300 0 4.25'
MPC-8 CF2300A BCF304 CF66KG 10.20 06.00x45B D 1 37 47 150 300 0 4.25"
MPC-9 CF2500A BCF304 CF66KG 11.20 07.00x45B D 7 39 47 150 300 0 4.25"
MPC-10 CF2300A BCF304 CG66KG 13.40 08.00x45B D 9 43 54 150 280 0 4.25"
MPC-11 CF2500A BCF3001 CF66KP 15.00 04.50x45P H 0 22 35 275 275 0 4.25"
MPC-12 CF2500A BCF3001 CF66KP 16.60 05.00x45P H 2 23 41 300 300 0 4.25"
MPC-13 CF2500A BCF3001 CF66KP 18.20 05.50x45P H 5 24 38 300 300 0 4.25"
MPC-14 CF2500A BCF3001 CF66KP 19.20 06.00x45P D 6 26 43 275 275 0 4.25"
MPC-15 CF2500 BCF1801 CF66KP 21.50 06.50x45P H 9 25 40 275 275 0 4.25"
MPC-16 CF3500A BCF1301 CF144KR 23.00 07.00x45P H 7 29 42 275 275 0 5.125"
MPC-17 CF3500A BCF1301 CF114KR 24.50 07.50x45P H 8 30 51 275 300 0 5.125"
MPC-18 CF3500A BCF1301 CF114KR 26.00 07.00x45P H 7 29 42 275 275 0 5.125"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 6

Burnham Corporation PF-5 Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
504 CF800 BCF403 CF60KH 5.45 4.50x45P 2-1/2 5 10 N/A 140 51628 3.00"
505 CF1400 BCF205 CF66KD 6.80 3.50x45P 3 25 50 150 300 51629 3.375"
506 CF1400 BCF205 CF66KD 8.30 4.50x45P 4 30 60 150 300 51629 3.375"
507 CF1400 BCF205 CF66KD 9.80 5.50x45P 5 35 70 150 300 51629 3.375"
508 CF2300A BCF304 CF66KG 11.20 6.00x45P 2 20 70 150 300 51630 3.375"
509 CF2300A BCF304 CF66KG 12.60 7.00x45P 2-1/2 20 85 150 300 51630 3.375"
510 CF2300A BCF304 CF66KG 14.00 8.00x45P 3 25 95 150 300 51630 3.375"
511 CF2300A BCF304 CF66KG 15.50 8.50x45P 4 25 100 150 300 51630 3.375"
512 CF2300A BCF304 CF66KG 17.00 9.50x45P 4 30 105 150 300 51630 3.375"
513 CF2500A BCF1801 CF66KP 18.40 5.00x60P (2) 3 23 35 300 300 51630 3.375"
514 CF2500A BCF1801 CF66KP 19.50 5.50x60P (2) 4 25 40 300 300 51630 3.375"
515 CF2500 BCF1801 CF66KP 21.00 6.00x60P (2) 4-1/2 25 50 300 300 51630 3.375"
516 CF2500 BCF1801 CF66KP 22.50 6.50x60P (2) 5 25 50 300 300 51630 3.375"
517 CF3500A BCF1301 CF80KM 24.00 7.00x60PLP (2) 2 30 80 300 300 51630 4.25"
518 CF3500A BCF1301 CF80KM 25.50 7.50x60PLP (2) 3 32 95 280 280 51630 4.25"
519 CF3500A BCF1301 CF80KM 27.00 7.50x60PLP (2) 3-1/2 35 105 300 300 51630 4.25"
520 CF3500A BCF1301 CF114KR 28.50 8.00x60P (2) 4 37 95 300 300 51631 5.00"
521 CF3500A BCF1301 CF114KR 29.90 8.50x60P (2) 4 40 103 300 300 51631 5.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 7

Burnham Corporation V11 Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
V1104 CF1400 BCF205 CF66KD 5.80 3.50x45P 0 25 50 150 300 51629 4.12"
V1105 CF1400 BCF205 CF66KE 7.40 4.50x45P 0 30 50 150 300 51629 4.12"
V1106 CF1400 BCF205 CF66KE 9.20 5.50x45P 2 30 60 150 300 51629 4.12"
V1107 CF2300A BCF304 CF66KG 11.00 6.50x45P 2 30 60 150 300 51630 4.00"
V1108 CF2300A BCF304 CF66KG 13.00 7.50x45P 4 35 60 150 300 51630 4.12"
V1109 CF2300A BCF304 CF66KG 14.80 8.50x45P 4 35 75 150 300 51630 4.12"
V1110 CF2300A BCF304 CF66KS 16.60 9.50x45P 4 30 55 150 300 51630 4.12"
V1111 CF2300A BCF304 CF66KS 18.40 10.50x45P 6 40 60 150 300 51630 4.12"
V1112 CF2500A BCF1801 CF66KP 20.00 5.50x45P (2) 4 20 45 300 300 51630 4.12"
V1113 CF2500A BCF1801 CF66KP 21.50 6.00x45P (2) 5 22 55 300 300 51630 4.12"
V1114 CF3500 BCF1301 CF80KM 23.50 6.50x45P (2) 2 25 80 300 300 51630 4.12"
V1115 CF3500A BCF1301 CF80KM 25.50 7.00x45P (2) 3 30 90 300 300 51630 4.12"
V1116 CF3500A BCF1301 CF114KR 27.00 7.50x45P (2) 6 32 85 300 300 51631 5.50"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 8

Burnham Corporation V9 Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
V-903 CF500 BCF809 CF80KK 2.75 2.25x60P 2 10 5-1/2 N/A 140 51628 4.00"
V-904 CF500 BCF809 CF80KK 3.50 3.00x45P 3-1/2 10 5-1/2 N/A 140 51628 4.00"
V-905 CF800 BCF403 CF80KH 4.60 4.00x60P 4 10 5 N/A 140 51628 4.00"
V-906 CF800 BCF403 CF80KJ 5.80 5.00x60P 3 10 6 N/A 140 51628 4.00"
V-907 CF1400 BCF205 CF66KD 6.90 4.00x45P 3 35 60 125 300 51629 4.00"
V-908 CF1400 BCF205 CF66KE 8.00 4.50x45P 3 25 50 125 300 51629 4.00"
V-909 CF1400 BCF205 CF66KE 9.10 5.00x45P 3 30 55 125 300 51629 4.00"
V-910 CF1400 BCF205 CF66KE 10.20 5.50x45P 5-3/4 40 75 125 300 51629 4.00"
V-911 CF2300A BCF304 CF66KG 11.40 6.50x45P 1-1/2 38 45 125 300 51630 4.00"
V-912 CF2300A BCF304 CF66KG 12.60 7.00x45P 4 40 50 125 300 51630 4.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Burnham Corporation V9A Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
V-903A CF500 BCF809 CF60KK 3.10 2.50x45P 2 10 3 N/A 150 51628 4.12"
V-904A CF800 BCF403 CF80KH 4.20 3.50x45P 1 8 0 N/A 150 51628 4.12"
V-905A CF800 BCF403 CF80KH 5.60 4.50x45P 2 10 6 N/A 150 51628 4.12"
V-906A CF1400 BCF205 CF66KD 7.00 4.00x60P 3 28 40 150 300 51629 4.12"
V-907A CF1400 BCF205 CF66KD 8.30 5.00x45P 4 30 65 150 275 51629 4.12"
V-908A CF1400 BCF205 CF66KEE 9.60 5.50x45P 1 35 85 150 300 51629 4.12"
V-909A CF2300A BCF304 CF66KG 11.60 7.00x45P 0 20 40 150 275 51630 4.12"
V-910A CF2300A BCF304 CF66KG 13.20 8.00x45P 1 20 60 150 275 51630 4.12"
V-911A CF2500A BCF1801 CF66KP 14.80 4.50x45P (2) 0 17 30 275 275 51630 4.12"
V-912A CF2500A BCF1801 CF66KP 16.40 5.00x45P (2) 0 20 40 275 275 51630 4.12"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 9

Columbia Boiler CT Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
CT-20 CF800 BCF403 CF100KJ 6.00 5.00x60P 3 7 0 N/A 150 51628 4.75"
CT-25 CF1000 BCF101 CF66KD 7.50 4.50x60P 3 5 N/A N/A 275 51629 4.75"
CT-25 CF1400 BCF205 CF66KD 9.00 5.50x60P 3 30 50 150 300 51629 4.75"
CT-35 CF2300A BCF304 CF66KG 10.50 6.00x45P 3 30 50 150 300 51630 4.75"
CT-50 CF2300A BCF304 CF66KG 15.00 9.00x60P 3 30 50 150 300 51630 4.75"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Columbia Boiler CWH Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
CWH-780 CF800 BCF403 CF100KJ 6.00 5.00x60P 3 7 0 N/A 150 51628 4.75"
CWH-1200 CF1000 BCF101 CF66KD 9.00 5.50x60P 3 5 N/A N/A 275 51629 4.75"
CWH-1200 CF1400 BCF205 CF66KD 9.00 5.50x60P 3 30 50 150 300 51629 4.75"
CWH-1510 CF2300A BCF304 CF66KG 12.00 7.00x45SS 3 30 50 150 300 51630 4.75"
CWH-1810 CF2300A BCF304 CF66KG 14.00 8.00x60P 3 30 50 150 300 51630 4.75"
CWH-2460 CF2300A BCF304 CF66KG 18.00 10.00x60P 3 30 50 150 300 51630 4.75"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 10

Columbia Boiler HRT Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
HRT-20 CF800 BCF403 CF100KJ 6.00 5.00x60P 3 7 0 N/A 150 51628 4.75"
HRT-30 CF1000 BCF101 CF66KD 9.00 5.50x60P 3 5 N/A N/A 275 51629 4.75"
HRT-30 CF1400 BCF205 CF66KD 9.00 5.50x60P 3 30 50 150 300 51629 4.75"
HRT-40 CF1400 BCF205 CF66KE 12.00 7.00x60P 3 30 50 150 300 51629 4.75"
HRT-50 CF2300A BCF304 CF66KG 15.00 10.00x60P 3 30 50 125 225 51630 4.75"
HRT-60 CF2300A BCF304 CF66KG 18.00 10.00x60P 3 30 50 150 300 51630 4.75"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Columbia Boiler WL Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
WL-60 CF800 BCF403 CF100KJ 6.00 5.00x60P 3 7 0 N/A 150 51628 4.75"
WL-90 CF1000 BCF101 CF66KD 9.00 5.50x60P 3 5 N/A N/A 275 51629 4.75"
WL-90 CF1400 BCF205 CF66KD 9.00 5.50x60P 3 30 50 150 300 51629 4.75"
WL-120 CF2300A BCF304 CF66KG 12.00 7.00x45SS 3 30 50 150 300 51630 4.75"
WL-140 CF2300A BCF304 CF66KG 14.00 8.00x60P 3 30 50 150 300 51630 4.75"
WL-180 CF2300A BCF304 CF66KG 18.00 10.00x60P 3 30 50 150 300 51630 4.75"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 11

Crown Boiler CT Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
CT6 SMG B1403 SMG45NR 1.65 1.35x45ES 0 7 1 N/A 150 51311 1.75"
CT6 CF375 BCF3907 CF56KY 1.65 1.35x60ES 1 6 0 N/A 150 51311 1.75"
CT7 CF500 BCF809 CF60KK 2.00 1.75x60ES 1 3-1/2 0 N/A 140 51311 2.25"
CT8 CF500 BCF809 CF60KK 2.50 2.00x45B 2 4-1/2 0 N/A 140 51311 2.25"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Crown Boiler FSeries Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
F4 CF800 BCF403 CF80KHS 3.00 2.50x60B 0 4 0 N/A 140 51311 7.00"
F5 CF800 BCF403 CF80KHS 4.00 3.25x45P 1 5 0 N/A 140 51311 7.00"
F6 CF800 BCF403 CF80KHS 5.00 4.00x45P 3 7 0 N/A 140 51311 7.00"
F7 CF1400 BCF205 CF102KD 6.00 3.50x45P 2 25 38 125 275 51312 7.00"
F8 CF1400 BCF205 CF102KD 7.50 4.50x45P 4 35 60 125 275 51312 7.00"
F9 CF2300A BCF304 CF102KG 9.00 5.00x45P 0 20 33 150 275 51630 7.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Flange requires an additional adapter plate.
Crown Boiler FW Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
FW4 CF500 BCF809 CF80KK 3.00 2.50x60B 2-1/2 4-1/2 0 N/A 140 51311 4.75"
FW5 CF800 BCF403 CF80KHS 4.00 3.25x45P 1 5 0 N/A 140 51311 4.75"
FW6 CF800 BCF403 CF80KHS 5.00 4.00x45P 3 7 0 N/A 140 51311 4.75"
FW7 CF1400 BCF205 CF102KE 6.00 3.50x45P 2 25 38 125 275 51312 4.75"
FW8 CF1400 BCF205 CF102KE 7.50 4.50x45B 4 35 60 125 275 51312 4.75"
FW9 CF2300A BCF304 CF102KG 9.00 5.50x45P 0 20 33 150 275 51313 4.75"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Flange requires an additional adapter plate.
Page 12

Crown Boiler VH Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
VH8 CF2300A BCF304 CF66KG 10.20 6.00x45P 0 16 30 125 300 51630 5.75"
VH9 CF2300A BCF304 CF66KG 12.00 7.00x45P 0 20 40 125 300 51630 5.75"
VH10 CF2300A BCF304 CF66KG 14.00 8.00x45P 1-1/2 20 50 125 300 51630 5.75"
VH11 CF2300A BCF304 CF66KG 15.80 9.00x45P 2-1/2 30 60 125 300 51630 5.75"
VH12 CF2300A BCF304 CF66KG 17.60 10.00x45P 3 40 70 125 300 51630 5.75"
VH13 CF2500A BCF3001 CF66KP 19.60 5.00x45P (2) 1 20 40 300 300 51630 5.75"
VH14 CF2500 BCF1801 CF66KP 21.50 6.00x45P (2) 2 20 40 300 300 51630 5.75"
VH15 CF2500 BCF1801 CF66KP 23.50 6.50x45P (2) 4 20 40 300 300 51630 5.75"
VH16 CF3500A BCF1301 CF80KM 25.00 7.50x45P (2) 7 30 70 300 300 51630 5.75"
VH17 CF3500A BCF1301 CF80KM 27.00 8.00x45P (2) 7 30 60 300 300 51630 5.75"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 13

DeDietrich GT210 Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
214A AFG B2007 AFG50MLSS 1.20 1.00x60B 1 10 1 N/A 150 51311 4.50"
215A AFG B2007 AFG50MLSS 1.55 1.25x45B 2 10 3 N/A 150 51311 4.50"
216A CF375 BCF3907 CF56KY 1.90 1.35x45ES 1 7-1/2 0 N/A 200 51311 4.50"
217A CF500 BCF809 CF60KK 2.25 1.75x45B 2 4 0 N/A 150 51311 3.75"
218A CF500 BCF809 CF60KK 2.50 2.00x45B (D) 2 5 0 N/A 150 51311 3.75"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
DeDietrich GT300 Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
304 CF500 BCF809 CF60KK 2.82 2.25x45P 1 4 1 N/A 150 51628 5.50"
305 CF800 BCF403 CF80KH 4.10 3.50x45P 1 6-1/2 0 N/A 140 51628 5.00"
306 CF800 BCF403 CF80KH 5.60 4.50x45P 4 10 2-1/2 N/A 150 51628 5.00"
307 CF1400 BCF205 CF66KD 7.10 4.25x45P 3 28 40 150 300 51312 5.00"
308 CF1400 BCF205 CF66KD 8.50 5.00x45P 6 35 45 150 300 51312 5.00"
309 CF2300A BCF304 CF102KG 10.00 6.00x45P 0 28 30 125 275 51313 5.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Dunkirk DPFO Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
6 CF375 BCF3907 CF56KZ 2.10 1.75x60B (D) 2 10 0 N/A 140 51311 4.00"
7 CF375 BCF3907 CF56KZ 2.35 2.00x60B (D) 2 10 2-1/2 N/A 140 51311 4.00"
8 CF375 BCF3907 CF56KZ 2.75 2.25x60B (D) 3 10 3 N/A 140 51311 4.00"
9 CF375 BCF3907 CF56KZ 3.00 2.50x60P 5 10 4 N/A 140 51311 4.00"
9 CF375 BCF3907 CF56KZ 3.33 3.00x45B (D) 5 10 10 N/A 140 51311 4.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 14

Easco Boiler ESP Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
70 CF2500 BCF1801 CF102KP 21.00 6.00x45P (2) 5 10 50 300 300 51630 5.00"
80 CF3500 BCF1301 CF80KM 24.00 6.50x45P (2) 2 20 80 300 300 51630 5.00"
90 CF3500 BCF1301 CF114KR 27.00 7.50x45P (2) 6 25 85 300 300 51631 5.00"
100 CF3500 BCF1301 CF114KR 30.00 8.50x45P (2) 7 35 95 300 300 51631 5.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Flange requires an additional adapter plate.
Easco Boiler FST Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
20 CF800 BCF403 CF100KH 6.00 4.50x45P 3 10 3 N/A 150 51628 5.00"
20 CF1400 BCF205 CF102KE 6.10 3.50x45P 1/2 20 40 150 300 51629 5.00"
32 CF1400 BCF205 CF102KE 9.60 5.50x45P 4 35 70 150 300 51629 5.00"
40 CF2300A BCF304 CF102KG 12.00 6.50x45P 1 17 30 150 300 51630 5.00"
50 CF2300A BCF304 CF102KG 15.60 8.50x45P 4 35 75 150 300 51630 5.00"
60 CF2300A BCF304 CF102KG 18.00 10.00x45P 5 30 60 150 300 51630 5.00"
70 CF2500 BCF1801 CF102KP 21.00 6.00x45P (2) 5 20 50 300 300 51630 5.00"
80 CF3500 BCF1301 CF80KM 24.00 6.50x45P (2) 2 20 80 300 300 51630 5.00"
90 CF3500 BCF1301 CF114KR 27.00 7.50x45P (2) 6 25 85 300 300 51631 5.00"
100 CF3500 BCF1301 CF114KR 30.00 8.50x45P (2) 7 35 95 300 300 51631 5.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Flange requires an additional adapter plate.
Page 15

Easco Boiler PLW Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
53 CF2300A BCF304 CF102KG 16.00 9.50x45P 5 30 60 150 275 51630 5.00"
60 CF2300A BCF304 CF102KG 18.00 10.00x45P 7 35 70 150 300 51630 5.00"
66 CF2300A BCF304 CF102KS 19.90 11.00x45P 9 50 100 150 300 51630 5.00"
79 CF3500 BCF1301 CF80KM 24.00 7.00x45P (2) 7 35 85 275 275 51630 5.00"
93 CF3500 BCF1301 CF114KR 28.00 8.00x45P (2) 8 45 95 300 300 51631 5.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Flange requires an additional adapter plate.
Easco Boiler SM4 Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
20 CF800 BCF403 CF100KH 6.00 4.50x45P 3 10 3 150 N/A 51628 5.00"
32 CF1400 BCF205 CF102KE 9.60 5.50x45P 4 35 70 150 300 51629 5.00"
40 CF2300A BCF304 CF102KG 12.00 6.50x45P 1 16 30 150 300 51630 5.00"
50 CF2300A BCF304 CF102KG 15.00 8.50x45P 4 35 75 150 300 51630 5.00"
60 CF2300A BCF304 CF102KG 18.00 10.00x45P 5 30 60 150 300 51630 5.00"
70 CF2500 BCF1801 CF102KP 21.00 6.00x45P (2) 5 20 50 300 300 51630 5.00"
80 CF3500 BCF1301 CF80KM 24.00 6.50x45P (2) 2 20 80 300 300 51630 5.00"
90 CF3500 BCF1301 CF114KR 27.00 7.50x45P (2) 6 25 85 300 300 51631 5.00"
100 CF3500 BCF1301 CF114KR 30.00 8.50x45P (2) 7 35 95 300 300 51631 5.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Flange requires an additional adapter plate.
Page 16

Easco Boiler SM5 Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
20 CF800 BCF403 CF100KH 5.80 4.50x45P 3 10 3 150 N/A 51628 5.00"
25 CF1000 BCF101 CF102KD 7.30 4.00x45P 4 20 N/A 300 N/A 51629 5.00"
30 CF1400 BCF205 CF102KE 8.70 5.00x45P 7 20 40 150 300 51629 5.00"
35 CF1400 BCF205 CF102KE 10.20 5.50x45P 9 30 70 150 300 51629 5.00"
40 CF2300A BCF304 CF102KG 11.70 7.00x45P 0 16 30 150 275 51630 5.00"
50 CF2300A BCF304 CF102KG 14.60 8.50x45P 3 20 40 150 275 51630 5.00"
60 CF2300A BCF304 CF102KG 17.50 10.00x45P 6 20 70 150 300 51630 5.00"
60S CF2300A BCF304 CF102KG 17.50 10.00x45P 6 20 70 150 300 51630 5.00"
70 CF2500 BCF1801 CF102KP 20.40 6.00x45P (2) 8 40 90 275 275 51630 5.00"
80 CF3500 BCF1301 CF80KM 23.30 6.50x45P (2) 7 30 80 300 300 51630 5.00"
90 CF3500 BCF1301 CF114KR 26.20 7.50x45P (2) 7-1/2 40 90 300 300 51631 5.00"
100 CF3500 BCF1301 CF114KR 29.20 8.50x45P (2) 8 50 100 280 280 51631 5.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Flange requires an additional adapter plate.
Page 17

Hurst Cyclone Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
6HP CF500 BCF809 CF100KK 2.00 1.75x60B (D) 0 2 0 N/A 140 51311 N/A
10HP CF500 BCF809 CF100KK 3.50 3.00x60B 3 10 2 N/A 140 51311 N/A
15HP CF800 BCF403 CF140KH 4.50 4.00x60B 4-1/2 10 3 N/A 140 51312 N/A
20HP CF1400 BCF205 CF136KD 6.00 3.50x45P 1/2 20 40 150 300 51312 N/A
25HP CF1400 BCF205 CF136KD 7.50 4.50x45P 3 35 60 150 300 51312 N/A
30HP CF2300A BCF304 CF136KG 9.00 5.00x45P 1-1/2 30 40 150 300 51313 N/A
40HP CF2300A BCF304 CF136KG 12.00 7.00x45P 2 30 60 150 300 51313 N/A
50HP CF2300A BCF304 CF136KG 15.00 8.50x45P 3 35 75 150 300 51313 N/A
60HP CF2500 BCF1801 CF176KP 18.00 5.00x60P (2) 3 19 40 300 300 51313 N/A
70HP CF2500 BCF1801 CF176KP 21.00 6.00x60P (2) 4 26 50 300 300 51313 N/A
80HP CF3500A BCF1301 CF150KM 24.00 7.00x60P (2) 3 32 90 300 300 51630 N/A
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 18

National Combustion CO-XC Series Boiler
Boiler Burner
Chassis
Spec.
Air Tube
Combination
High
Fire
Rate Nozzle
Head
Setting
Blue -
Low Fire
Air or
Shutter
Red -
High Fire
Air or
Band
Low Fire
Pump
Press.
High Fire
Pump
Press.
Pressure
Firing
Flange Insertion
58 CF800 BCF403 CF60KH 4.50 4.00x45P 3 10 0 N/A 140 51311 3.00"
72 CF800 BCF403 CF60KH 5.25 4.50x45P 4 10 5 N/A 140 51311 3.00"
82 CF1400 BCF205 CF66KE 6.00 3.50x45P 1/2 20 40 150 300 51629 3.00"
105 CF1400 BCF205 CF66KE 8.00 4.50x45P 2-1/2 30 60 150 300 51629 3.00"
130 CF2300A BCF304 CF66KG 10.00 5.50x45p 0 15 30 150 300 51630 3.00"
165 CF2300A BCF304 CF66KG 12.00 7.00x45P 1 30 40 150 300 51630 3.00"
200 CF2300A BCF304 CF66KG 15.00 9.00x45P 4 25 40 150 300 51630 3.00"
250 CF2300A BCF304 CF102KS 19.00 11.00x45P 5 35 55 150 300 51630 6.00"
290 CF2500A BCF1801 CF66KP 22.00 6.50x45P (2) 5 25 50 300 300 51630 3.00"
400 CF3500A BCF1301 CF114KR 29.90 8.50x45P (2) 5 30 80 300 300 51631 6.00"
Shutter and band settings refer to the AFG, CF375, CF500 and CF800 only.
Page 19
