3 Tuning Velocity Controller (Ziegler&Nichols)
3.1 General Information
The main velocity controller parameters are the proportional gain Kp (S-0-0100) and the integral action time
Tn (S-0-0101).
On selection of the motor default values are set,
which enable the motor to be operated safely without
load.
During commissioning the two parameters should be
adjusted in order to find a good compromise between
drive responsiveness (controller bandwidth) and
noise generation.
The method described below initially determines the
stability limit of the control loop. The value
determined for the gain is then multiplied with a field-
proven factor, based on the rules of Ziegler and
Nichols, in order to obtain a stable control loop.
If the bandwidth of the control loop turns out to be inadequate for the application, other methods should be
used. A description of these methods would be beyond the scope of this documentation.
Attention
Nature and source of the danger
This does not apply to vertical axes that are subjected to a continuous force, since it would
cause the axis to drop. In order to minimize the influence of the integral controller, Tn
should be set to a large value, e.g. 100 ms. Be sure to test carefully!
3.2 Preparation
For the tuning process the axis must be able to move in both directions, without reaching the mechanical end
stops. For example, it should be pushed manually to the center of the travel path.
In most cases the AX5000 operates in mode "11:
Position control feedback 1". In order to eliminate the
influence of the position controller, Kv should be 0 for
the tuning process in the position controller. In
addition, Tn is set to 0 in the velocity controller.
Following-error monitoring should be disabled for the
NC axis or set to a large value so that it is not
triggered in the following tests.

Tuning Velocity Controller (Ziegler&Nichols)
AX5000 Tuning - Guide8 Version: 1.0
3.3 Determining the stability limit for Kp
To determine the stability limit, while the axis is active, Kp is increased in the velocity controller in small steps
until the axis starts to oscillate. Depending on the axis type and the environment in which the axis is
operated, it may be sufficient to determine the stability limit based on the noise generation. When Kp
reaches a critical value, many axes start "squeaking" audibly. In noisy environments and for axes for which
oscillation must be avoided, the TwinCAT "Scope View" oscilloscope should be used. The next chapter
describes the setup. If the oscilloscope is not used, you can skip the next chapter and continue reading at
"Starting the test movement [}9]".
3.4 Setting up TwinCAT Scope View
Use the function:
• File → Add → New project
to add a "TwinCAT Measurement" project of type
"Scope YT NC Project".
Right-click on the chart to add two axes, so that a
total of three axes are available.
Notice!
If you have a sufficiently large monitor, right-click on
the chart again and select "Stacked Axes" for a better
overview.
The axes are then shown one below the other. Add
the "Torque feedback value" (S-0-0084), the velocity
command value and the actual velocity value
(P-0-0504 and S-0-0040) to the AX5000 process
data.
In the process image of the EtherCAT master activate
the ADS server and the symbol generation facility.

Tuning Velocity Controller (Ziegler&Nichols)
AX5000 Tuning - Guide 9
Version: 1.0
Now reactivate the configuration.
Right-click on an axis in the oscilloscope and open the target
browser.
Select:
• the controller,
• the ADS port,
• the drive and the channel.
Use “drag and drop” to assign the signals to the oscilloscope
axes, as shown (picture below).
The signal scaling is not important for determining the stability
limit. To establish the relationship with the drive axis it may be
useful to enter the scaling factors in the property window of
the axis. The values can be taken from the "Scaling and NC
Parameters" window in the TC DriveManager.
If you start the recording now, the oscilloscope should not
issue an error message.
Nature and source of the danger!
If a German keyboard is used, the decimal symbol must be comma!
3.5 Starting the test movement
From "NC Functions" select the function "Velo Step
Sequence". To make the axis reverse, you have to
specify two velocities with different sign. Enter 1
second as "Idle time", for example, and a number of
cycles.
Attention
Nature and source of the danger
Since the position controller and the integral component of the velocity controller are not
active, the axis may drift into another positioning range during reversing.

Tuning Velocity Controller (Ziegler&Nichols)
AX5000 Tuning - Guide10 Version: 1.0
3.6 Evaluating the oscilloscope pattern
While the axis reverses, observe the behavior with the
oscilloscope. The following oscilloscope pattern shows the
velocity command value and actual velocity value in the upper
diagram and the current or torque ("torque feedback value") in
the lower diagram.
The red line is based on an increased value for Kp. The next
motion shows that an oscillation occurs, which continues for
the whole motion.
Depending on the mechanical system, the value that was
reached can be regarded as Kpcrit, or Kp can be increased
further, until the oscillation also shows up in the velocity
value. It will then also be more audible.
In the sample application with a ball screw, the oscillation in
the current signal starts at Kp = 0.22. Only a soft "squeaking"
can be heard, which is inaudible in a noisy environment.
At Kp = 0.25 the oscillation also shows up in the speed signal.
3.7 Reducing Kp
Based on the rules of Ziegler and Nichols, the correct value for Kp should be determined using the following
formula.
Kp = 0.45 x Kpcrit
In the example,
• Kp = 0.45 x 0.22 = 0.10 or
• Kp = 0.45 x 0.25 = 0.11
is the correct value.
3.8 Determining Tn
Tn determines the integral action time of the integral controller. The smaller Tn, the larger the gain of the
Integral controllers. The correct value for Tn is mainly dependent on the type of coupling between motor and
load. Many applications run satisfactorily with the default value Tn = 8 ms. At the Rigid coupling and if the
tracking error appears to be too large, Tn can e.g. up to 5 ms.
Attention
Value ranges from Tn!
Do not reduce Tn any further without using the TC ScopeView to ensure that the current or
speed actual value does not start to oscillate! Values ≤ 5 ms are not required in most appli-
cations. With elastic coupling between engine and load or even with long straps it may be
useful for Tn Values> 10 ms. Swinging of the axis is thereby prevented.

Support and Service
AX5000 Tuning - Guide 11
Version: 1.0
4 Support and Service
Beckhoff and their partners around the world offer comprehensive support and service, making available fast
and competent assistance with all questions related to Beckhoff products and system solutions.
Beckhoff's branch offices and representatives
Please contact your Beckhoff branch office or representative for local support and service on Beckhoff
products!
The addresses of Beckhoff's branch offices and representatives round the world can be found on her internet
pages:
http://www.beckhoff.com
You will also find further documentation for Beckhoff components there.
Beckhoff Headquarters
Beckhoff Automation GmbH & Co. KG
Huelshorstweg 20
33415 Verl
Germany
Phone: [phone]
Fax: [phone]
e-mail: [email protected]
Beckhoff Support
Support offers you comprehensive technical assistance, helping you not only with the application of
individual Beckhoff products, but also with other, wide-ranging services:
• support
• design, programming and commissioning of complex automation systems
• and extensive training program for Beckhoff system components
Hotline: [phone]
Fax: [phone]
e-mail: [email protected]
Beckhoff Service
The Beckhoff Service Center supports you in all matters of after-sales service:
• on-site service
• repair service
• spare parts service
• hotline service
Hotline: [phone]
Fax: [phone]
e-mail: [email protected]
