Bedrooms Plus M4TEC space-pro Tower Storage Unit DIY Shelf User manual

SPR_INSTRUC_TU_DR_05.2016www.spacepro.co.uk/instructions-2/
tower unit shelves only
Assembly Instructions
Page 1 of 4
V1
CONTENTS:
A1x Top panel
B 1x Side panel (left)
C 1x Side panel (right)
D6x Shelves
E 1x Plinth panel
32x
Cams
32x
Dowels
2x
Wall mounting
brackets
We recommend you use the Wall Mounting
Brackets provided to fix the Tower Unit to a
wall (where possible). This will prevent the
unit being pulled over. Use suitable fixings.
•TOOLS: Screwdriver
•TWO PERSON BUILD
RECOMMENDED:
(400 & 600mm wide)
Tower Storage Unit DIY Shelf Assembly Guide M4TEC by Bedrooms Plus, 2 Murray Court, Hamilton ML3 9SL • Tel: [phone]
Email: [email protected].uk • Web: www.m4tec.com

SPR_INSTRUC_TU_DR_05.2016www.spacepro.co.uk/instructions-2/
12
34
Apply to all panels.
Note: B panel shown
Page 2 of 4
x4
x4
x14
x4
x2
5
Lay panels (B &C) on a flat surface. Fit cams & dowels to both panels.
Tower Storage Unit DIY Shelf Assembly Guide M4TEC by Bedrooms Plus, 2 Murray Court, Hamilton ML3 9SL • Tel: [phone]
Email: [email protected].uk • Web: www.m4tec.com

SPR_INSTRUC_TU_DR_05.2016www.spacepro.co.uk/instructions-2/
6
7
Page 3 of 4
8
Ensure cams are facing inwards.
Tower Storage Unit DIY Shelf Assembly Guide M4TEC by Bedrooms Plus, 2 Murray Court, Hamilton ML3 9SL • Tel: [phone]
Email: [email protected].uk • Web: www.m4tec.com

SPR_INSTRUC_TU_DR_05.2016www.spacepro.co.uk/instructions-2/Page 4 of 4
Use two people to stand up straight.
We recommend you use
the Wall Mounting
Brackets provided to fix
the Tower Unit to a wall
(where possible). This
will prevent the unit
being pulled over.
Use suitable fixings.
WALL MOUNTING
BRACKETS
Fix the Wall Mounting Bracket to both sides of the Tower
Unit. (Use suitable fixings when attaching to the wall).
USE SUITABLE
WALL FIXINGS
x2
