Behringer Miniamp AMP800 User manual

Technical Specications
MINIAMP AMP800
Ultra-Compact 4-Channel Stereo Headphone Amplier

2MINIAMP AMP800 Technical Specifications
MINIAMP AMP800
Ultra-Compact 4-Channel Stereo Headphone Amplier
Ultra-compact headphone amplier system for studio and stage applications
4 independent stereo high-power amplier sections
Highest audio quality with virtually all types of headphones even at maximum volume
Phones Level control plus accurate 6-segment LED output meter per channel for easy level monitoring
2 balanced stereo main inputs with independent Level and Balance controls for individual mixes, selectable for all 4 headphone ampliers
Accurate 6-segment LED main level meter for precise level indication of both line inputs
2 headphone outputs per channel (front and rear panel) allow a total of 8 headphones to be simultaneously connected
Parallel Link Output allows cascading of several headphone ampliers
High-quality potentiometers and illuminated switches for long-term reliability
All Mini Series models can be stacked on top of each other to create an ultra-compact signal processor solution
High-quality components and exceptionally rugged construction ensure long life
Conceived and designed by BEHRINGER Germany
Specications
INPUT
Type ¼" TRS connector, balanced
Impedance approx. 20 kΩ, balanced
approx. 10 kΩ, unbalanced
CMRR 40 dB typ. @ 1 kHz
PHONES OUT
Type ¼" TRS connector, stereo
Impedance min. 100 Ω
Max. output level +13 dBu @ 100 Ω load
LINK OUT A
Type ¼" TRS connector, balanced
SYSTEM SPECIFICATIONS
Frequency response 10 Hz to 120 kHz, -3 dB
Dynamic range 108 dB, 10 Hz to 22 kHz
(100 Ω load)
Distortion 0.007 % typ. (100 Ω load)
Crosstalk < 80 dBu @ 1 kHz
Signal-to-noise ratio 10 Hz to 22 kHz < 95 dB @
0 dBu, a-weighted
AMPLIFIER
Max. output level +21 dBm / 124 mW
(100 Ω load)
Min. output impedance 47 Ω

3MINIAMP AMP800 Technical Specifications
BEHRINGER constantly strives to maintain the highest quality standards. Modifications may be made, if necessary, without prior notice. The specifications and appearance of the equipment may therefore differ
from those listed or illustrated
Technical specifications and appearances are subject to change without notice and accuracy is not guaranteed. BEHRINGER is part of the MUSIC Group (music-group.com). All trademarks are the property
of their respective owners. MUSIC Group accepts no liability for any loss which may be suffered by any person who relies either wholly or in part upon any description, photograph or statement contained
herein. Colors and specifications may VARY FROM ACTUAL PRODUCT. MUSIC GROUP products are sold through authorized FULLFILLERS AND RESELLERS only. FULLFILLERS AND RESELLERS are not agents
of MUSIC Group and have absolutely no authority to bind MUSIC Group by any express or implied undertaking or representation. This manual is copyrighted. No part of this manual may be reproduced
or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for any purpose, without the express written permission of MUSIC Group IP Ltd.
ALL RIGHTS RESERVED. © 2012 MUSIC Group IP Ltd. Trident Chambers, Wickhams Cay, P.O. Box 146, Road Town, Tortola, British Virgin Islands
POWER SUPPLY
Mains connection external power supply,
9 V~ / 750 mA
Mains Voltage
USA/Canada 120 V~, 60 Hz
U.K./Australia 240 V~, 50 Hz
China 220 V~, 50 Hz
Europe 230 V~, 50 Hz
Japan 100 V~, 50 - 60 Hz
Power consumption 11 W
DIMENSIONS/WEIGHT
Dimensions (H x W x D) approx. 48 x 242.6 x 120 mm
(1.89 x 9.55 x 4.72")
Weight approx. 0.77 kg (1.7 lbs)
