VINTAGER AC112
Version 1.2 September 2002
Technical Specifications
ENGLISH

2
VINTAGER AC112
AC112
VINTAGER
Ultra-flexible 60 Watt Guitar Workstation with Di ital Multi-Effects Processor
sPowerful 60 att RMS Guitar orkstation with a hand-selected 12AX7 vacuum tube
sAuthentic vintage design with ULTRATUBE circuitry for classic tube sound
sOriginal 70 att heavy duty 12" JENSEN guitar speaker model JCH12/70
sTwo independent channels with separate volume controls, EQ and effects
sCLEAN channel delivers clean and slightly distorted sounds with smooth tube compression
sOVERDRIVE channel offers a broad range, from modern crunch to high-gain sounds
sEach channel has its classic 3-band EQ with excellent sound characteristics
s24-bit stereo multi-effects processor with ultra-high resolution 24-bit AD/DA converters
s31 original VIRTUALIZER/MODULIZER presets with world-class effects such as Reverb, Delay, Phaser,
Chorus, Flanger, Pitch Shifter, Speaker Simulator, Rotary Speaker, Magic Drive, Compressor, Expander,
ah, Tube Emulator and various effect combinations
s99 outstanding and easy-to-edit user presets
sQuasi-analog operation: three FX parameters per preset can be edited with dedicated controls
sAdjustable AUX input for playback or other line-level signals (e.g. CD player, drum computer, etc.)
sFrequency-corrected stereo line output for recording and live applications
sInsert facility for external effects devices (stomp boxes, wah-wah pedals, etc.)
sChannel select and effect bypass footswitch FS112 included
sComplete MIDI implementation for channel and effect selection as well as real time control
sMaster volume control and frequency-corrected stereo headphones output
sExtremely rugged construction ensures long life, even under the most demanding conditions
sRobust power supply ensures excellent transient response
sManufactured under ISO9000 certified management system

3
VINTAGER AC112
SPECIFICATIONS
AUDIO INPUTS
Connector 1/4" mono jack
Type RF filtered input
Guitar input
impedance approx. 1 MΩ unbalanced
Insert return
impedance approx. 10 kΩ unbalanced
Aux input
impedance approx. 10 kΩ unbalanced
AUDIO OUTPUTS
Connector 1/4" mono jack
Type line level output
Insert send
Impedance approx. 100 Ω unbalanced
Line out
Impedance approx. 120 Ω unbalanced
Max. output level +12dBu unbalanced
SYSTEM SPECIFICATIONS (power amplifier)
Power amp output 60 atts RMS @ 5 % THD + N into 8 Ω; 230 V ~
MIDI INTERFACE
Type 5-pin-DIN-socket, MIDI IN
DIGITAL PROCESSING
Converters 24-bit sigma-delta, 64/128-times oversampling
Sampling rate 46.875 kHz
DISPLAY
Type 2-digit numeric LED-display
LOUDSPEAKER
Type 12" heavy duty loudspeaker, model JENSEN JCH12/70
Impedance 8 Ω
Power handling 70 atts
PO ER SUPPLY
Mains voltages USA/Canada 120 V ~, 60 Hz
U.K./Australia 240 V ~, 50 Hz
Europe 230 V ~, 50 Hz
general export model 100 - 120 V ~, 200 - 240 V ~, 50 - 60 Hz
Power consumption approx. 40 atts min. / approx. 130 atts max.
Fuse 100 - 120 V ~ : T 2 A H
200 - 240 V ~ : T 1 A H
Mains connection standard IEC receptacle
PHYSICAL
Dimensions (H * * D) approx. 18.8" (477.5 mm) * 20.3" (515.2 mm) * 10.5" / 12.5" (266 mm /317.5 mm)
eight approx. 18.5 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time
to time to e isting products without prior notice. Specifications and appearance may differ from those listed or illustrated.
