Behringer MULTICOM PRO-XL MDX4600 User manual

ENGLISH
Version 1.1 September 2002
Technical Specifications
ENGLISH
MULTICOM PRO-XL MDX4600
www.behringer.com
VERSION 1.2 September 2002

MDX4600
2
MULTICOM PRO-XL MDX4600
MULTICOM PRO-XL
INTERACTIVE REFERENCE-CLASS 4-CHANNEL EXPANDER/GATE/COMPRESSOR/ PEAK LIMITER WITH
DYNAMIC ENHANCER AND LOW CONTOUR FILTER
Switchable IKA (Interactive Knee Adaptation) program-adaptive compression circuitry combines the=
advantages of hard-knee and soft-knee characteristics
IRC (Interactive Ratio Control) expander/gate circuitry for virtually inaudible noise suppression=
Switchable dynamic Enhancer for brilliant, lively audio even with heavy compression=
IGC (Interactive Gain Control) peak limiting circuitry combines clipper and program limiter for reliable=
and inaudible protection against signal peaks
Switchable Low contour filter prevents “pumping” due to low-frequency dominated compression=
Stereo couple function selectable for channels 1/2 and 3/4=
Ultra low-noise 4580 operational amplifiers and state-of-the-art VCA’s=
Separate 8-segment LED meters for input/output levels and gain reduction=
Selectable operating level (+4 dBu/-10 dBV)=
Servo-balanced inputs and outputs with ¼” TRS and gold-plated XLR connectors=
High-quality components and exceptionally rugged construction ensure long life=
Conceived and designed by BEHRINGER Germany=

3
MULTICOM PRO-XL MDX4600
SPECIFICATIONS
AUDIO INPUTS
Type XLR and 1/4" TRS connectors,
HF-shielded, servo-balanced
I pedance
+4 dBu 90 kΩ bal., 45 kΩ unbal. @ 1 kHz
-10 dBV 180 kΩ bal., 90 kΩ unbal. @ 1 kHz
Operating level +4 dBu/-10 dBV (switchable)
Max. input level +22 dBu balanced and
unbalanced
CMRR typ. 40 dB, >60 dB @ 1 kHz
AUDIO OUTPUTS
Type XLR and 1/4" TRS connectors
Electronically controlled servo-
balanced output stage
I pedance 95 Ω bal., 50 Ω unbal. @ 1 kHz
Max. output level +21 dBu, +20 dB balanced
and unbalanced
SIDECHAIN INPUTS
Type 1/4" TS connector, unbalanced,
HF-shielded, DC-decoupled
I pedance 45 kΩ
Max. input level +24 dBu
SIDECHAIN OUTPUTS
Type 1/4" TS connector, unbalanced,
HF-shielded, DC-decoupled
I pedance 50 Ω
Max. output level +21 dBu
SYSTEM SPECIFICATIONS
Bandwidth 20 Hz to 20 kHz, +0/-0.5 dB
Frequency range 0.35 Hz to 200 kHz, +0/-3 dB
S/N ratio 115 dB, unweighted,
22 Hz - 22 kHz
THD 0.008 % typ. @ +4 dBu, 1 kHz,
gain 1
0.07 % typ. @ +20 dBu, 1 kHz,
gain 1
IMD 0.01 % typ. SMPTE
Crosstalk -110 dB @ 1 kHz
EXPANDER/GATE SECTION
Type IRC (Interactive Ratio Control)
expander
Threshold variable (OFF to +10 dB)
Ratio variable (1:1 to 1:8)
Attack <1 sec/50 dB, progra -
dependent
Release variable
SLOW: 100 sec/1 dB,
FAST: 100 sec/100 dB
COMPRESSOR SECTION
Type IKA (Interactive Knee
Adaptation) co pressor
Threshold variable (-40 to +20 dB)
Ratio variable (1:1 to oo :1)
Attack/release variable ( anual or auto atic)
Auto characteristic wave adaptive co pressor
Manual attack ti e variable (0.3 sec/20 dB to
300 sec/20 dB)
Manual release ti e variable (0.05 sec/20 dB to
5 sec/20 dB)
Auto attack ti e typ. 15 sec for 10 dB,
5 sec for 20 dB,
3 sec for 30 dB
Auto release ti e progra -dependent,
typ. 125 dB/sec
Output variable (-20 to +20 dB)
PEAK LIMITER SECTION
Type IGC (Interactive Gain Control)
peak li iter
Level variable (0 dB to OFF (+21 dBu))
Ratio oo :1
Level 1 li iter type clipper
Attack zero
Release zero
Level 2 li iter type progra li iter
Attack progra -dependent,
typ. <5 sec
Release progra -dependent,
typ. 20 dB/sec
DYNAMIC ENHANCER SECTION
Type IDE (Interactive Dyna ic
Enhancer)
Filter frequency 2.5 kHz (lower cut-off frequency)
Characteristic high-pass filter (6 dB/oct.)
Boost ax. 28 dB @ 7.5 kHz
POWER SUPPLY
Mains voltage USA/Canada 120 V ~, 60 Hz
U.K./Australia 240 V ~, 50 Hz
Europe 230 V ~, 50 Hz
General export odel 100 -120 V ~, 200 -240 V ~,
50 - 60 Hz
Power consu ption ax. 18 W
Fuse 100 -120 V ~: T 630 mA H
200 -240 V ~: T 315 mA H
Mains connection standard IEC receptacle
DIMENSIONS/WEIGHT
Di ensions approx. 1 ¾" (44.5 ) x 19"
(482.6 ) x 8 ½" (217 )
Weight approx. 2.25 kg (4.96 lbs)
Shipping weight approx. 3.45 kg (7.61 lbs)
BEHRINGER makes every effort to ensure the highest standard of quality. Necessary
modifications are carried out without notice. Thus the specifications and design of the
device may differ from the information given in this manual.
