Behringer Digital Multi-FX FX100 User manual

DIGITAL MULTI-FX FX100
Thank you for showing your confidence in us by purchasing the BEHRINGER DIGITAL ULTI-FX FX100.
This ultimate digital multi-effects pedal delivers 24-bit high-resolution stereo effects including Flanger,
Chorus, Phaser, Delay, Tremolo and Pitch Shifter. Thanks to its extensive tone control plus additional multi-
functional parameter adjustment youll have plenty of cool sounds at your disposal to handle every situation.
1. CONTROLS
Top view
The LEVEL control adjusts the output level.
and The PAR 1 and 2 controls have different functions depending on the chosen effect.
); )XQFWLRQ3$5FRQWURO )XQFWLRQ3$5FRQWURO
Chorus
Effects speed
Effects depth
Flanger
Effects speed
Effects depth
Phaser
Effects speed
Effects depth
Delay
Delay time
Delay feedback
Tremolo
Effects speed
Shape (LFO waveform)
Pitch Shifter
Detune (slight shifting for fatter sound)
Semi tone (pitch interval)
The FX control lets you chose between six different modulation effects:
CHORUS: This effect slightly detunes the original signal. A very pleasant detune effect is created
in connection with the pitch variation.
FLANGER: Originally, the flanger effect was generated with two tape recorders running synchronously.
The same audio signal was recorded on both machines. If you put a finger on the left spool of one of
the machines, the spool and the playback speed are slowed down. The generated delay results in
phase shifting of the signals.
PHASER: With the phaser, a second, phase-shifted signal is added to the original audio signal. The
resulting sound is thicker and above all livelier.
PITCH SHIFTER: The pitch shifter slightly detunes the audio signal.
TREMOLO: The tremolo effect is achieved by periodic modulation of the input signal level. This
results in a continuous change from low to high level that lends a quivering, tremulous sound character.
DELAY: A delay of the input signal with various repetitions.
The ON/BATT LED illuminates when the effect is activated. It also serves as a battery level indicator.
Use the footswitch to activate/deactivate the effect.
Use the two 1/4" TS connectors IN A and IN B to plug in a stereo input signal. For mono use
just plug in IN A.
The two 1/4" TS connectors OUT A and OUT B send the signal to your amp. Use both connectors
if you want to achieve full stereo effect. For mono use just plug in OUT A.
Use the DC IN connection to plug in a 9 V power supply (not included).
The BATTERY COMPARTMENT is located underneath the pedal cover. To install or replace the 9 V
battery, press the hinges with a ballpen and remove the pedal cover. Be careful not to scratch the unit.

DIGITAL MULTI-FX FX100
+The FX100 has no on/off switch. As soon as you insert the jack into the IN connector, the
FX100 begins running. When not using the FX100, re ove the jack fro the IN connector.
This extends the life of the battery.
The ERIAL NUMBER is located at the bottom.
2. WARRANTY
For our current warranty terms, please refer to our website at http://www.behringer.com.
3. SPECIFICATIONS
In A
Connector 1/4" TS
Impedance 500 kW
Impedance mono 250 kW
In B
Connector 1/4" TS
Impedance 500 kW
Out A
Connector 1/4" TS
Impedance 1 kW
Out B
Connector 1/4" TS
Impedance 1 kW
Power supply 9 V, 100 mA DC regulated
PSU-SB-CN BEHRINGER 220 VAC adaptor China
PSU-SB-EU BEHRINGER 230 VAC adaptor Europe
PSU-SB-JP BEHRINGER 100 VAC adaptor Japan
PSU-SB-SAA BEHRINGER 240 VAC adaptor Australia
PSU-SB-UK BEHRINGER 240 VAC adaptor UK
PSU-SB-UL BEHRINGER115 VAC adaptor USA
Power connector 2 mm DC jack, negative center
Battery 9 V type 6LR61
Power consumption 90 mA
Dimensions (H x W x D) approx. 54 mm (2 1/8") x 70 mm (2 3/4") x 123 mm (4 4/5")
Weight approx. 0.33 kg (0.73 lbs)
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made
from time to time to e isting products without prior notice. Specifications and appearance may therefore differ from those listed or shown.
