Behringer Noice Reducer NR100 User manual

NOISE REDUCER NR100
Thank you for showing your confidence in us by purchasing the BEHRINGER NOISE
RED CER NR100. This ultimate effects pedal is specifically designed to eliminate unwanted
noise and hum without altering your tone. Thanks to its high-performance features it
preserves the original attack and envelope while leaving your playing and dynamics intact.
1. CONTROLS
Top view
This MODE switch allows you to chose between MUTE and REDUCTION mode.
Pressing the pedal in M TE mode results in muting the whole input signal, to reduce
noises in during pauses for example. In RED CTION mode, quiet passages (when
noise or hum would get obvious to the listener) are effectively reduced. Adjustments
to threshold and decay settings are necessary in this case (see below).
se the THRESH(old) control to define a level threshold in RED CTION mode.
When the input signal falls below this value, the unit starts reducing the signal.
The DECAY control determines how fast the signal reduction is released when the
input signal exceeds the threshold value again.
The MUTE/BATT LED illuminates when the effect is activated. It also serves as a
battery level indicator.
The REDUCTION LED illuminates when the input level falls below the threshold
and starts getting reduced.
se the footswitch to activate/deactivate the effect.
se this 1/4" TS IN connector to plug in the instrument cable.
The 1/4" TS OUT connector sends the signal to your amp.
se this 1/4" TS SEND connector to connect it to the input of an external effect unit. This
way you can feed in an effect signal while simultaneously eliminating noises from the unit.
The 1/4" TS RETURN connector is used to feed in the external effect signal.
se the DC IN connection to plug in a 9 V power supply (not included).
The BATTERY COMPARTMENT is located underneath the pedal cover. To install or
replace the 9 V battery, press the hinges with a ballpen and remove the pedal cover. Be
careful not to scratch the unit.
+The NR100 has no on/off switch. As soon as you insert the jack into the IN
connector, the NR100 begins running. When not using the NR100, remo e
the jack from the IN connector. This extends the life of the battery.
The SERIAL NUMBER is located at the bottom.

NOISE REDUCER NR100
2. WARRANTY
For our current warranty terms, please refer to our website at http://www.behringer.com.
3. SPECIFICATIONS
In
Connector 1/4" TS
Impedance 500 kW
Out
Connector 1/4" TS
Impedance 1 kW
Send
Connector 1/4" TS
Impedance 1 kW
Return
Connector 1/4" TS
Impedance 50 kW
Power supply 9 V, 100 mA DC regulated
PS -SB-CN BEHRINGER 220 VAC adaptor China
PS -SB-E BEHRINGER 230 VAC adaptor Europe
PS -SB-JP BEHRINGER 100 VAC adaptor Japan
PS -SB-SAA BEHRINGER 240 VAC adaptor Australia
PS -SB- K BEHRINGER 240 VAC adaptor K
PS -SB- L BEHRINGER 115 VAC adaptor SA
Power connector 2 mm DC jack, negative center
Battery 9 V type 6LR61
Power consumption 30 mA
Dimensions (H x W x D) approx. 54 mm (2 1/8") x 70 mm (2 3/4") x 123 mm (4 4/5")
Weight approx. 0.33 kg (0.73 lbs)
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made
from time to time to e isting products without prior notice. Specifications and appearance may therefore differ from those listed or shown.
4. SAFETY INSTRUCTIONS
Do not use near water, or install near heat sources. Use only authorized attachments/accessories. Do not service product yourself.
Contact our qualified servicing personnel for servicing or repairs, especially when power supply cord or plug is damaged.
No utilizar cerca de agua o instalar cerca de fuentes de calor. Utilice sólo accesorios y aditamentos autorizados. No intenté reparar
el producto usted mismo. Contacte a nuestro personal técnico cualificado para servicio y reparaciones, especialmente cuando la
fuente o el cable de alimentación estén dañados.
