Behringer Micropower PS400 User manual

BEHRINGER MICROPOWER PS400
WELCOMETOBEHRINGER
Thank you for showing your confidence in us by purchasing the
BEHRINGER MICROPOWER PS400. Use this ultra-compact phantom
power supply with mixers and microphone preamplifiers that do not
include phantom power sources. The PS400:
Vsupplies phantom power (+12 V or +48 V) to any type of
condenser microphone
Vroutes the microphone signal to a mixer or
a microphone preamplifier
Please read the safety instructions that appear at the
end of this document.
CONNECTORSANDCONTROLELEMENTS
This section illustrates and describes each PS400 connector and
control element.
13 45
2
Fig. 1: PS400 connectors and control elements
12 V connector:
To connect the power supply unit to the PS400, use the
12 V connector. Connecting the power supply unit to the
mains automatically switches the PS400 on. To disconnect
the unit from the mains, pull out the main cord plug.
ON LED:
As soon as the unit is connected to the mains, the ON LED is
illuminated.
MIC INPUT connector:
To send a microphone signal to the PS400, you need an
audio cable that includes XLR connectors. Plug:
Vone XLR connector into the MIC INPUT connector
Vthe other XLR connector into the condenser microphone
MIC THRU connector:
To route the microphone signal from the PS400 to a mixer
or a microphone preamplifier, you need an audio cable that
includes XLR connectors.
Plug:
Vone XLR connector into the MIC THRU connector
Vthe other XLR connector into the mic input of a mixer or,
alternatively a microphone preamplifier
+12 V / +48 V PHANTOM VOLTAGE switch:
To select the voltage that you need, push this switch toward
+12 V or, alternatively +48 V. For details about what value
to use, refer to instructions from the microphone
manufacturer.
SERIAL NUMBER: To register the unit, use the serial number that is
located on the bottom of the PS400.
SETUPEXAMPLE
The following is an example of how to set up the PS400:
PROMIXER DJX700
MICROPOWER PS400
STUDIO CONDENSER
MICROPHONE C-1
MIC INPUT MIC THRU
Fig. 2: PS400 setup example
WARRANTY
For our current warranty terms, please refer to our website at
http://www.behringer.com.
Other language versions of this documentation...
Die deutsche Anleitung ist erhältlich @ www.behringer.com
Manuel francophone en téléchargement sur www.behringer.com
Manual en español disponible en www.behringer.com
Manuali italiani disponibili @ www.behringer.com
Русскоязычное руководство @ www.behringer.com
Polska instrukcja dostępna jest pod adresem @ www.behringer.com
Nederlandse handleiding beschikbaar @ www.behringer.com
Suomenkielinen käyttöohje saatavilla osoitteesta www.behringer.com
Svensk manual finns tillgänglig på www.behringer.com
Dansk vejledning findes på @ www.behringer.com
Manual português disponível @ www.behringer.com
Åëëçíéêü åã÷åéñßäéï õðÜñ÷åé äéáèÝóéìï óôç äéåýèõíóç www.behringer.com

BEHRINGER MICROPOWER PS400
SPECIFICATIONS
MIC INPUT and MIC THRU
Type XLR connector, balanced
PHANTOM POWER SUPPLY
Voltage (switchable) +12 V or +48 V
POWER SUPPLY
Mains connector external power supply, 12 V /150 mA
Mains voltage
USA/Canada 120 V~, 60 Hz
China/Korea 220 V~, 50 Hz
U.K./Australia 240 V~, 50 Hz
Europe 230 V~, 50 Hz
Japan 100 V~, 50 - 60 Hz
Power consumption approx. 2 W
DIMENSIONS/WEIGHT
Dimensions (H x D x W) approx. 1 ¼" x 4" x 2 ¼"
(approx. 32 mm x 103 mm x 58 mm)
Weight approx. 0.40 lbs (0.180 kg)
BEHRINGER is constantly striving to maintain the highest professional
standards. As a result of these efforts, modifications may be made
from time to time to existing products without prior notice.
Specifications and appearance may differ from those listed or
illustrated.
SAFETYINSTRUCTIONS
1) Readtheseinstructions.
2) Keeptheseinstructions.
3) Heedallwarnings.
4) Followallinstructions.
5) Donotusethisapparatusnearwater.
6) Cleanonlywith drycloth.
7) Donotblockanyventilationopenings.Installinaccordancewiththemanufacturer’sinstructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus(including amplifiers) that produceheat.
9) Donotdefeat the safety purposeofthe polarized or grounding-typeplug.Apolarized plug
hastwoblades withonewiderthantheother.A groundingtypeplughastwobladesandathird
groundingprong.Thewideblade orthethirdprongareprovidedforyoursafety.Iftheprovided
plugdoes notfitintoyouroutlet, consultanelectrician forreplacement oftheobsolete outlet.
10) Protectthepowercord from beingwalkedon or pinchedparticularlyat plugs, convenience
receptacles,and thepointwhere theyexit fromtheapparatus.
11) Onlyuseattachments/accessoriesspecified bythemanufacturer.
12) Useonlywiththe cart, stand,tripod,bracket, ortablespecified bythemanufacturer,or sold
with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combinationto avoidinjuryfrom tip-over.
13) Unplugthisapparatusduringlightningstorms or when unused for long periodsoftime.
14) Referallservicingto qualified servicepersonnel.Servicing is requiredwhenthe apparatus
hasbeendamagedinanyway,suchaspowersupplycordor plugisdamaged,liquidhasbeen
spilledor objectshavefalleninto theapparatus,the apparatushasbeenexposed torainor
moisture,does notoperatenormally,orhasbeendropped.
Technicalspecificationsandappearancesubjecttochangewithoutnotice.Theinformationcontainedhereiniscorrectatthetime ofprinting.Thenamesofcompanies,institutions orpublications pictured
ormentioned andtheirrespective logosareregistered trademarks oftheirrespective owners.Theiruse neitherconstitutesa claimofthe trademarksbyBEHRINGER®nor affiliationofthe trademark
ownerswithBEHRINGER®.BEHRINGER®acceptsnoliabilityforanylosswhichmay besufferedbyanypersonwhorelies eitherwhollyorinpartuponany description,photographorstatementcontained
herein.Colours andspecificationmay varyslightlyfrom product.Productsaresoldthrough ourauthoriseddealers only.Distributors anddealersare notagentsof BEHRINGER®andhave absolutely
noauthoritytobindBEHRINGER®byanyexpressorimpliedundertaking orrepresentation.Nopartofthismanual maybereproducedortransmittedinanyformorbyanymeans,electronicormechanical,
includingphotocopying andrecordingof any kind,forany purpose,withoutthe expresswrittenpermission of BEHRINGERSpezielleStudiotechnik GmbH.BEHRINGER®isaregisteredtrademark.
ALLRIGHTS RESERVED © 2006 BEHRINGERSpezielleStudiotechnikGmbH,
Hanns-Martin-Schleyer-Str.36-38, 47877Willich-MünchheideII, Germany.
