Behringer CL106 Installation and operation manual

Ultra-Compact 100-Watt, 2-Way, 8 Ω Loudspeaker System and 70.7 V / 100 V Loudspeaker System
CL106/CL106T
Features
• 120-Watt6"low-frequencytransducerprovidesdeep
bassforsmalltomediumsizedrooms
• Constantdirectivity90°Hx70°Vrotatablewaveguide
with1"high-frequencytransducer
• Passivecrossoverwithoverloadcircuitryensures
optimaldriverprotection
• 5-positionterminalstripprovidesamplier
connectiontointernal100-Watt70/100Vtransformer
(CL106T/CL106T-WH)
• Internallybracedandacousticallyinert15°trapezoidal
birchplywoodenclosureidealfor
clusterapplications
• Multiplethreadedinsertsforexibleinstallation
includingOmnimount™products;includesmatching
yokebracket
• Powdercoatedsteelgrillewrappedwithacoustically
transparentfabricandfoammatchingblack
cabinetcolor
• Availableineitherblack(CL106/CL106T)orwhite
(CL106-WH/CL106T-WH)
bracket included bracket included

2
Ultra-Compact 100-Watt, 2-Way, 8 Ω Loudspeaker System and 70.7 V / 100 V Loudspeaker System
CL106/CL106T
Product Overview Technical Specications
• Frequency range (-10 dB) 62 Hz - 20 kHz
• Frequency responsev 69 Hz - 15 kHz
(±3 dB)
• Nominal dispersion 90º H x 70º V
• Directivity factor (Q) 7.5
• Directivity index (DI) 8.8 dB
• Sensitivity 90 dB
(1 W @ 1 m passive)
(half space)
• Crossover modes Passive
• Crossover frequency 2.5 kHz
• Power handling 100 W RMS @ 28.3 V
(long term, IEC passive)
Transducers
• Nominal impedance 8 Ω
• Low frequency driver 6" @ 120 W
• High frequency driver 1" @ 20 W
• Horn waveguide 90º H x 70º V, rotatable
• Maximum continuous 110 dB
SPL (passive)
• Maximum peak 116 dB
SPL (passive)
• Overload protection Full range power limiting to protect drivers
andcrossovers
CL106 CL106T
• Transformer 70 V: 12.5 W, 25 W, 100 V: 25 W, 50 W,
50 W, 100 W 100 W
• Enclosure Trapezoidal 15° side angle, laminated
birchplywood
• Grille Steel
• Rigging points 14 x M6 threaded points; 4 x M6 threaded
inserts for OmniMount™ 30 series.
• Termination NL4 and 4-position 5-position terminal
terminal strip strip connection
• Dimensions (H x W x D) 17.7 x 10.2 x 11.3" / 450 x 260 x 286 mm
• Weight 20.7 lbs / 9.4 kg 23.3 lbs / 10.6 kg
• Included accessories Yoke and bracket
* Optional accessories Model CLFK array bracket
TheEUROCOMCL106/CL106Tisanultra-compact
professionaltwo-wayloudspeakersystemthatisideal
forawidevarietyofxedinstallationapplications.
Featuringcleanlinesandauniquefabric-nished
wrap-aroundgrille,theCL106/CL106Tisfullyathomein
eventhemostelegantsettings,includingtheatersand
auditoria,housesofworship,themedentertainment,
andsportingvenues.Perfectformainsinsmallvenues,
theCL106/CL106Talsoexcelsforllanddelaysystemsin
largerrooms.
Builtofhigh-qualitylaminatedBalticbirchplywood,
theCL106/CL106T’slightweightcabinetcombinesnatural
rigidityandacousticinertnesswiththeadditionalstrength
ofinternalsteelbracing.Threadedmounting-pointinserts
intheinternalbracketsprovidearatedloadfactorofat
least10timesoverallcabinetweight,makingtheCL106/
CL106Texceptionallysafeforowninstallation,either
singlyorinarrays.
TheCL106/CL106Tachievesfully-professionalperformance
andreliabilitywithnewly-designedcomponentswhose
frequencyresponse,sensitivity,andpowerhandlingare
allcustom-tailoredforCLSeriesloudspeakers.BEHRINGER
maintainscompletecontroloverqualityandsonic
characterbymanufacturingallCLSeriescomponents—
startingwiththepulpusedforconefabrication—inour
ownfactories.
Dual6"(150mm)lowfrequencydriversprovidingfull,
richlowsarematchedtoa1"(25mm)highfrequency
driverviaaninternalpassivecrossoverat2kHztodeliver
clear,smoothsoundacrosstheentireaudiblespectrum.
Arotatablewaveguideallowsoptimalapplicationof
the90°x70°coveragepatternregardlessofspeaker
orientation,whichmaybeeitherverticalorhorizontal.
EveryaspectoftheCL106/CL106Thasbeenthought
throughtomaximizevalueandconvenienceforboth
theinstallerandtheenduser.Theresultisanattractive,
durable,installation-readyloudspeakersystemthatwill
delivertop-notchsoundday-after-dayforyearstocome.

3
Ultra-Compact 100-Watt, 2-Way, 8 Ω Loudspeaker System and 70.7 V / 100 V Loudspeaker System
CL106/CL106T
Summary description:Theloudspeakershallbeaprofessional2-wayxed-installationloudspeakersysteminasteel-braced
plywoodenclosureusingabypassableinternalcrossovernetworkwitha6"/150mmlow-frequencyconetransduceranda
waveguide-mounted1"/25mmhigh-frequencydomedriver.
Drivers:Theloudspeakersystemshallusetwotransducers:
• Low-frequencydrivershallbea6"/150mmdirect-radiatingconetransducer
• High-frequencydrivershallbea1"/25mmphenolicdometransducermountedonarotatable90°x70°waveguide
constructedofpolypropylene
Enclosure:Theloudspeakersystemshallbehousedinanenclosureconstructedoflaminatedbirchplywoodthatisinternally
bracedwithsteel.Theenclosureshallbenishedwithdurable,scu-freeblackorwhitepaint.Thefrontoftheenclosureshall
beprotectedwithaperforatedgrilleofpowder-coatedstructuralsteelbehindfabric-wrappedacousticallytransparentfoam.
Thebackoftheenclosureshallhavearecessedsteelinputplateforconnectors.
Rigging and mounting:Theexterioroftheenclosureshallbettedwith14M6threadedriggingpoints.Therearofthe
enclosureshallhave4M6threadedinsertsforOmniMount™30series.Theenclosureshallprovideattachmentpointsforan
optionalyokebracket.
I/O and connectors:Theloudspeakershallhavethefollowingconnectors:
• OneNL4connector,wiredinparallelasafull-rangeinputtothepassivecrossover(CL106)
• One4-positionterminalstripwithcaptivewireclampsandremovableplasticcover,withINterminalswiredinparallelto
OUTterminalsandtotheNL4connectors(CL106)
• One5-positionterminalstripwithcaptivewireclampsandremovableplasticcover,with70Vand100Vterminalswired
totheprimarysideofthematchingtransformer(CL106T)
Performance criteria:Theloudspeakersystemshallmeetthefollowingperformancecriteria:
• Nominalimpedanceshallbe8ΩformodelsCL106/CL106-WH
• CL106T/CL106T-WHTransformertapsshallbe12.5W,25W,50W,100W(70.7V),25W,50W,100W(100V)
• Sensitivity(1W/1mpassive)shallbe90dB
• Usablefrequencyrange(-10dB)shallbe62Hz-20kHz
• Frequencyresponse(±3dB)shallbe69Hz-15kHz
• Powerhandling(IEC268-5,passive)shallbe100WRMS@28.3V(CL106)/100WRMS(CL106T)
• Nominaldispersionshallbe90°x70°(axisdependentonhornorientation)
• MaximumSPL(1m,passive)shallbe110dBcontinuousand116dBpeak
Dimensions and weight:Theloudspeakersystemshallhavethefollowingcharacteristics:
• Heightshallbe17.7"/450mm
• Widthshallbe10.2"/260mm
• Depthshallbe11.3"/286mm
NetWeightforCL106shallbenomorethan20.7lbs/9.4kg
NetWeightforCL106Tshallbenomorethan22.3lbs/10.6kg
Model:TheloudspeakershallbetheBEHRINGEREUROCOMCL106/CL106-WH/CL106T/CL106T-WH.
Architect’s and Engineer’s Specications

4
Ultra-Compact 100-Watt, 2-Way, 8 Ω Loudspeaker System and 70.7 V / 100 V Loudspeaker System
CL106/CL106T
Horizontal Off-Axis Frequency Response
Vercal Up Off-Axis Frequency Response
Vercal Down Off-Axis Frequency Response
Impedance VS. Frequency
Horizontal Off-Axis Frequency Response
Vercal Up Off-Axis Frequency Response
Vercal Down Off-Axis Frequency Response
Impedance VS. Frequency
Horizontal Off-Axis Frequency Response
Vercal Up Off-Axis Frequency Response
Vercal Down Off-Axis Frequency Response
Impedance VS. Frequency
Beamwidth VS. Frequency
Directivity Index, Q
Frequency Response, 1 W @ 1 M
Horizontal Off-Axis Frequency Response
Vercal Up Off-Axis Frequency Response
Vercal Down Off-Axis Frequency Response
Impedance VS. Frequency
Horizontal Off-Axis Frequency Response
Vertical Up Off-Axis Frequency Response
Vertical Down Off-Axis Frequency Response
Impedance VS. Frequency

5
Ultra-Compact 100-Watt, 2-Way, 8 Ω Loudspeaker System and 70.7 V / 100 V Loudspeaker System
CL106/CL106T
Horizontal 1/3 Octave Polars
Vercal 1/3 Octave Polars
Horizontal 1/3 Octave Polars
Vertical 1/3 Octave Polars

6
Ultra-Compact 100-Watt, 2-Way, 8 Ω Loudspeaker System and 70.7 V / 100 V Loudspeaker System
CL106/CL106T
Vercal 1/3 Octave Polars
Horizontal 1/3 Octave Polars

Ultra-Compact 100-Watt, 2-Way, 8 Ω Loudspeaker System and 70.7 V / 100 V Loudspeaker System
CL106/CL106T
Dimensional Drawings
