Behringer EUROLIVE B115D User manual

EUROLIVE B115D and B112D active
loudspeakers are exactly what you’ve
come to expect from BEHRINGER—more
power, more features and absolutely
more aordable! Our engineers have
really outdone themselves, creating two
self-contained PA solutions that merge
state-of-the-art, 1,000-Watt Class-D
power amp technology, built-in wireless
microphone capability and exceptional
portability. These professional active
loudspeakers are destined to become
legends in its own right, alongside
the other EUROLIVE models that have
made BEHRINGER the world leader in
active loudspeakers.
Cut the Fat; Keep the Beef
We drew from our considerable
experience to build these performance-
grade loudspeakers and made them
lighter (B115D: 38.6 lbs./17.5 kg;
B112D: 32 lbs./14.5 kg) and more
powerful. We started with custom-
engineered Class-D power amps for the
ultimate in low-distortion power and
eciency. Backed by SMPS (Switch Mode
Power Supply) technology, the high-tech
alternative to heavy transformers and
massive heat sinks, these loudspeakers
can run cool all day and all night without
even breaking a sweat!
Active 1000-Watt 2-Way 15"/12"
PA Speaker System with Wireless
Option and Integrated Mixer
High-power 2-way PA sound
reinforcement speaker system for
live and playback applications
Ultra-compact and lightweight
system delivers excellent sound even
at extreme sound pressure levels
“Wireless-ready”for high-quality
BEHRINGER digital wireless system
(not included)
2-channel mixer with individual
Mic/Line inputs, Volume controls
and Clip LEDs
Dedicated 2-band EQ plus integrated
sound processor for ultimate system
control and speaker protection
Revolutionary Class-D amplier
technology: enormous power,
incredible sonic performance and
super-light weight
Extremely powerful 15''/12''
long-excursion driver provides
incredibly deep bass and
acoustic power
State-of-the-art 1.35'' aluminum-
diaphragm compression
driver for exceptional
high-frequency reproduction
Ultra-wide dispersion, large-format
exponential horn
Additional Line output allows linking
of additional speaker systems
Versatile trapezoidal enclosure
design allows dierent positioning:
• Stand mounting with 35-mm
pole socket
• Tilts on its side for use as a
oor monitor
Continued on next page
EUROLIVE
B115D/B112D
Professional Powered Speakers

Page 2 of 4
Ergonomically shaped handles for
easy carrying and setup
High-quality components and
exceptionally rugged construction
ensure long life
Conceived and designed by
BEHRINGER Germany
Wireless Wonderland
Until now, adding wireless
microphones to a PA system meant
either a mess of wires and dangling
receivers or worse, a built-in receiver
with dodgy performance and a hefty
price tag. Those days are ocially over
thanks to BEHRINGER ULTRALINK Series
wireless mics that feature our exclusive,
ultra-compact 2-channel receiver. Just
plug the receiver into the dedicated
wireless port on the rear panel and
you have full access to two channels
of supremely stable, natural-sounding
wireless connectivity. Sold separately and
available in hand-held or headset models,
BEHRINGER ULTRALINK Series wireless
mics will immediately (and inexpensively)
expand your B115D/B112D to handle
virtually any live sound application.
Built-in Mixing Capability
The integrated mixer features the
same ultra low-noise, high-headroom
mic preamps that have made BEHRINGER
mixers legendary, and the two inputs
accept virtually any mic/line level signal
you’re likely to run across. Variable Input
gain controls (with Clip LED) will have you
dialing in the perfect level every time.
And if you need more coverage, use the
convenient Link Output XLR connector to
add more active loudspeakers.
Power and Control
There is absolutely no substitute for
amplier power in high-performance
loudspeakers; the kind of power it takes
to deliver clean, in-your-face vocals
and chest-thumping bass day in and
day out. That’s why we gave these bad
boys 1000-Watts of bi-amplied, digitally
processed output power. But with great
LEVEL control
with CLIP LED
MIC/LINE
combo jack
MIX OUTPUT XLR
SIGNAL PRESENT LED
Indicators for optional
Wireless Microphones
EQ HIGH and
LOW
System CLIP LED
BEHRINGER Wireless
Microphone dongle
port (optional)
Power LED
Rear Panel
Front View
Large Format
Horn
12"/15" Long
Excursion
Transducer/
Rugged
Steel Grill
Integrated Pole
Mount Socket
1.35" Compression
Transducer
Bass Reex
Ports
Continued on next page
EUROLIVE
B115D/B112D

Page 3 of 4
power comes great responsibility, so our
engineers included a proprietary DSP
(DigitalSignal Processor) with high-end
features such as a dual-band EQ, an active
crossover, dual protection limiters and
transducer response correction, ensuring
these loudspeakers deliver incredible output
at the lowest possible distortion levels.
Custom-Engineered Transducers
Powerful, high-eciency Class-D
ampliers and Switch Mode Power Supply
technology coupled with state-of-the-art
DSP functionality sure sounds impressive—
but what about the part of the system you
actually hear? We never cut corners on
our transducers (woofers and tweeters),
and we never just pull what we have o
the shelf. Our LF (Low Frequency) and HF
(High Frequency) transducers are designed
specically for each application—it’s what
sets us apart from the competition. When
you buy a BEHRINGER active loudspeaker,
you can rest assured that the transducers
inside have been engineered to perform
awlessly in conjunction with every other
element for truly professional results.
B115D and B112D active speaker systems
crank out massive quantities of low
end, with articulate, detailed mids and
crystal-clear highs.
Extraordinarily Versatile
Thanks to its trapezoidal shape,
the B115D and B112D are suitable for a
wide variety of applications. They can be
mounted on standard speaker poles, placed
vertically atop subwoofers, or even laid on
their side for use as onstage monitor wedges.
Their extraordinary delity and frequency
response make them a favorite of vocalists
and instrumentalists alike. Hook up is simple,
requiring only a single XLR or ¼" cable from
your mixing console and power. Additional
monitors can be chained together via the
XLR Link Output jack on the rear panel.
Which Speaker Should I Buy?
Well, let's start with your application…
are you giving a speech in a hotel
ballroom—or rocking out at the local bar
or dance club? Whether to choose one
speaker cabinet over another depends on
your bass requirements. A 15" woofer has
about 40% more surface area with which
to move air than a 12" and that translates
into more bass. So if you're addressing a
small meeting, or jamming at the coee
house, the B112D might be all you'll ever
need. But if you're providing disco in a
busy nightclub, hosting Karaoke night
in your living room, or just need to crank
it up louder, then the B115D may be a
better choice.
Sound Value
EUROLIVE active PA loudspeakers
stand head and shoulders above the
rest of the pack and deliver exceptional
performance, even when pushed to
their limits. Lightweight and powerful,
with built-in mixers, custom-designed
transducers, and integrated wireless
functionality, B115D and B112D active
loudspeakers are ideal for both speech
and music applications—at a price that is
unheard of in this class.
Experience the B115D and B112D
at your local dealer today and nd out
why more and more professionals are
turning to BEHRINGER EUROLIVE Series
active loudspeakers for their superb
performance and extraordinary value.
Connecting a Microphone
XM8500 Mic
ULTRALINK
ULM200USB* *USB Wireless Connector
* optional, not included
Connecting Multiple Loudspeakers
XENYX XL1600
EUROLIVE
B115D/B112D

Page 4 of 4
For service, support or more information contact the BEHRINGER location nearest you:
Technical specifications and appearances are subject to change without notice and accuracy is not guaranteed. BEHRINGER, KLARKTEKNIK, MIDAS, BUGERA, and TURBOSOUND are part of the MUSIC Group (music-group.com). All trademarks are the property of their
respective owners. MUSIC Group accepts no liability for any loss which may be suffered by any person who relies either wholly or in part upon any description, photograph or statement contained herein. Colors and specifications may vary from actual product. MUSIC Group
products are sold through authorized fullfillers and resellers only. Fullfillers and resellers are not agents of MUSIC Group and have absolutely no authority to bind MUSIC Group by any express or implied undertaking or representation.This manual is copyrighted.
No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for any purpose, without the express written permission of MUSIC Group IP Ltd. ALL RIGHTS RESERVED.
© 2013 MUSIC Group IP Ltd.Trident Chambers,Wickhams Cay, P.O. Box 146, RoadTown,Tortola, British Virgin Islands.
Europe
MUSIC Group Services UK
Tel: [phone]
Email: [email protected]om
USA/Canada
MUSIC Group Services NV Inc.
Tel: [phone]
Email: [email protected]om
Japan
MUSIC Group Services JP K.K.
Tel.: [phone]
Email: [email protected]om
Specications
B115D/B112D
Ampliers
Low-Frequency Range
Max output power 700 W*
High-frequency range
Max output power 300 W*
Audio Inputs
XLR (Servo-Balanced)
Sensitivity -36 dBu to 0 dBu
Input impedance 14 kΩ
¼" TRS Jack (Servo-Balanced)
Sensitivity -36 dBu to 0 dBu
Input impedance 14 kΩ
Wireless System
Connector USB 3.0
Frequency band 2.4 GHz
Frequency response 20 Hz - 20 kHz (+0/-2.5 dB)
(Wireless Link)
Range Max. 80 m (line of sight)
Audio Outputs
Mix
Connector XLR, balanced
Level Control
Input trim -∞ to +36 dB
Max. input level 18 dBu
B115D
Loudspeaker System Data
Frequency response 45 Hz to 20 kHz
Crossover frequency 2.2 kHz
Limiter Optical
Dynamic equalizer Processor-controlled
B112D
Loudspeaker System Data
Frequency response 50 Hz to 20 kHz
Crossover frequency 2.8 kHz
Limiter Optical
Dynamic equalizer Processor-controlled
B115D/B112D
Equalizer
High +/-15 dB @ 12 kHz
Low +/-15 dB @ 80 Hz
Power Supply
Voltage (Fuses)
USA / Canada 120 V, 60 Hz (T 6.3 A H 250 V)
UK / Australia 240 V~, 50 Hz (T 3.15 A H 250 V)
Europe 230 V~, 50 Hz (T 3.15 A H 250 V)
Japan 100 V~, 50-60 Hz (T 6.3 A H 250 V)
Power consumption max. 110 W
Mains connection Standard IEC receptacle
B115D
Dimensions/Weight
Dimensions (H x W x D) 28.1 x 16.8 x 12.3"
713 x 427 x 313 mm
Weight 38.9 lbs / 17.7 kg
B112D
Dimensions/Weight
Dimensions (H x W x D) 22.4 x 13.4 x 10.6"
568 x 342 x 270 mm
Weight 27.1 lbs / 12.3 kg
*Independent of limiters and driver protection circuits
Please note these specifications are preliminary and conceptual in nature, and as such are subject
to change as product development progresses. This information is supplied for market research
purposes only and is not to be made public in any manner. This document is solely the property of
The MUSIC Group, or one of its subsidiaries, and must be surrendered upon request of the owner.
