Behringer Eurolive B207 MP3 User manual

EUROLIVE
B207
Professional Powered Speakers
Active 150-Watt 6.5"PA/Monitor
Speaker System with MP3 Player
Multi-purpose, 150-Watt,
active speaker for vocal and
keyboard monitoring, multi-media,
press conferences and home
recording studio, etc.
High-performance MP3 player
included to play audio les
via USB stick
Revolutionary Class-D amplier
technology: enormous power,
incredible sonic performance and
super-lightweight
6.5" premium-quality, full-range
driver for excellent sound
performance
Ultra-low noise 4-channel mixer
with 3-band EQ
3 “Invisible” Mic Preamps with
phantom power for condenser
microphones and 1 instrument-
ready input (no DI required)
Dedicated stereo input for
keyboards, MP3, CD, etc.
XLR “through” connector with
mic/line switch for linking more
B207MP3s
Mic stand integration system for use
with stand and boom
Integrated limiter for ultimate system
control and speaker protection
Internal switch-mode power supply
for noise-free audio, superior transient
response and very low
power consumption
Super-tough, impact-resistant
enclosure with integrated top
carry handle
High-quality components and
exceptionally rugged construction
ensure long life
Conceived and designed by
BEHRINGER Germany
We took the things people already
love about our best-selling B205D PA/
Monitor speaker system, and gave it an
extra channel, threw in a larger speaker
and added an onboard MP3 player, so you
can play your favorite tunes right from a
USB stick. Plus our new EUROLIVE B207MP3
system is so light you can mount it on a
mic stand and aim it right at your ears—
allowing you to hear yourself like never
before. But don’t let the small size fool
you—the B207MP3 cranks out truckloads
of high-quality sound; more than enough
to serve as a PA system for your more
intimate gigs and meetings—and it comes
packed with features that will simply blow
you away!
The Secret to B207MP3’s Amazing Sound
Thanks to our revolutionary Class-D
amplier technology and internal
switch-mode power supplies, not only
do B207MP3 loudspeakers sound great,
they weigh considerably less than most
competing active speakers. They pump
out 150 of the cleanest, punchiest Watts
you’ve ever heard from a compact
loudspeaker, and you can link additional
active loudspeaker systems via the handy
THRU socket. The built-in 4-channel
mixer accepts XLR, TRS and RCA inputs,
plus channel 2 features a switchable
instrument-ready input—no DI required!
A dedicated 3-band EQ (Low/Mid/High)
provides simple, yet eective tonal control.
Continued on next page

EUROLIVE
B207
Page 2 of 5
Put the Sound Where You Want It
Space limitations often make it impossible
to place full-sized monitor wedges where they
can do the most good—and passive monitors
require lots of external ampliers and processing
gear to function properly. All this adds up to even
more gear to move, and if you don’t know what
you’re doing, you can easily damage passive
monitors by applying too much power to them.
With the B207MP3 we’ve taken all the guesswork
out, giving each loudspeaker its own 150-Watt,
Class-D amplier specically designed as the
perfect mate for the custom-engineered 6.5"
neodymium driver.
Say Goodbye to Back-Breaking
Floor Wedges
By using an internal switch-mode
power supply, we reduced the weight of
the B207MP3 to a mere 7.0 lbs (3.2 kg).
This means that instead of bringing your
old passive oor wedges in one-at-a-time,
you can carry all of them in just one trip—
without even breaking a sweat! They are
small enough to mount on mic stands
(each speaker includes a special mic/boom
stand integration system), on a tabletop,
or they can be placed directly atop a piano
or electronic keyboard.
Custom-Engineered Drivers
Let’s face it; the drivers (otherwise
known as speakers) are the only part
of a sound system you actually hear.
So when it comes to ours, we don’t
cut any corners. While some of our
competitors outsource theirs, we
custom-design and build our speakers
from scratch. We wind our own voice coils,
process the paper pulp into cones and
even machine our own speaker back plates
and frames. This enables us to control
the quality, keep production costs down
and frankly, to make better components.
The premium-grade, full-range 6.5"
neodymium driver was designed
specically, and optimized solely,
for use in the B207MP3.
Continued on next page
MP3 transport
function switches
Power LED
6.5" premium-quality,
full-range neodymium driver
Impact-resistant,
molded enclosure
can stand up to
years of abuse
USB port for
connecting
thumb drive
with MP3 les
Built-in
MP3 player
status display
High EQ
12 kHz/
±15 dB
Mid EQ
2.5 kHz/
±15 dB
Low EQ
100 Hz/
±15 dB
Stereo
CD Inputs
Channels 1-4
Level controls
Channel 2
Instrument switch
+48 V Phantom Power
switch with LED
Main Level control
MP3 player Level control
Mic/Line combo inputs
accept ¼”or XLR connections

EUROLIVE
B207
Page 3 of 5
Ergonomic carry handle
Mic stand boom
integration socket
Power switch IEC power socket Thru XLR jack allows
connecting additional active
loudspeaker systems
Main In
combo jack
Mic/Line
Level switch
for Main in
combo jack
Mic stand socket
Value
The EUROLIVE B207MP3 provides
high-quality sound, tremendous functionality
and versatility for an amazingly low price.
Compare the B207MP3 to the competition
and you’ll own BEHRINGER with money
to spare. Stop by your authorized dealer,
or order yours online today!

EUROLIVE
B207
Page 4 of 5
B207MP3
XM8500 Mic
Guitar
B207MP3
USB Memory Stick
Personal Monitor Application
Piano/Guitar Bar Application
XM8500 Vocal Mic XM8500 Vocal Mic
USB Memory Stick
Acoustic Guitar
Keyboard

EUROLIVE
B207
Page 5 of 5
For service, support or more information contact the BEHRINGER location nearest you:
Europe
MUSIC Group Services UK
Tel: [phone]
Email: [email protected]om
USA/Canada
MUSIC Group Services NV Inc.
Tel: [phone]
Email: [email protected]om
Japan
MUSIC Group Services JP K.K.
Tel.: [phone]
Email: [email protected]om
Technical specifications and appearances are subject to change without notice and accuracy is not guaranteed. BEHRINGER, KLARKTEKNIK, MIDAS, BUGERA, and TURBOSOUND are part of the MUSIC Group (music-group.com). All trademarks are the property of their
respective owners. MUSIC Group accepts no liability for any loss which may be suffered by any person who relies either wholly or in part upon any description, photograph or statement contained herein. Colors and specifications may vary from actual product. MUSIC Group
products are sold through authorized fullfillers and resellers only. Fullfillers and resellers are not agents of MUSIC Group and have absolutely no authority to bind MUSIC Group by any express or implied undertaking or representation.This manual is copyrighted.
No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for any purpose, without the express written permission of MUSIC Group IP Ltd. ALL RIGHTS RESERVED.
© 2013 MUSIC Group IP Ltd.Trident Chambers,Wickhams Cay, P.O. Box 146, RoadTown,Tortola, BritishVirgin Islands.
Specication
Amplier
Maximum output power 150 W @ 6 Ω
Type Class-D
Limiter Optical
Dynamic equalizer Processor-controlled
Speaker Size
Size 6.5" / 156 mm
Audio Inputs
MP3 Playback: USB Type A
File system FAT16, FAT32
Format MP3
Bit rates 32 – 320 kbps, VBR
Channel 1: XLR / ¼" TRS Combo Jacks
Sensitivity -40 dBu to +4 dBu
Input impedance 20 kΩ
Channel 2: XLR / ¼" TRS Combo Jacks
Sensitivity -40 dBu to +4 dBu
Input impedance 20 kΩ / 1 MΩ switchable
Channel 3: XLR / ¼" TRS Combo Jacks
Sensitivity -40 dBu to +4 dBu
Input impedance 20 kΩ
Channel 4: RCA Jacks
Sensitivity -10 dBu to +4 dBu
Input impedance 10 kΩ
Phantom Power
Channels 1, 2 and 3 +48 Volts, switchable
Channel Level Controls
Input Trim -∞ to + 30 dB
Max. input level +22 dBu
Link
Thru XLR connector, mic/line switchable
Main in XLR / ¼" TRS combo jack
Loudspeaker System Data
Frequency response 60 Hz to 18 kHz (-10 dB)
90 Hz to 12 kHz (-3 dB)
Sound pressure level Max. 116 dB SPL @ 1 m
Equalizer
High >12 kHz / ±15 dB
Mid 2.5 kHz / ±15 dB
Low <100 Hz / ±15 dB
Power Supply, Voltage (Fuses)
USA / Canada 120 V~, 60 Hz
(T 3.15 A H 250 V)
UK / Australia / Europe 220-240 V~, 50/60 Hz
(T 3.15 A H 250 V)
Korea / China 220-240 V~, 50/60 Hz
(T 3.15 A H 250 V)
Japan 100 V~, 50/60 Hz
(T 3.15 A H 250 V)
Power consumption max. 180 W
Mains connection Standard IEC receptacle
Dimensions/Weight
Dimensions (H x W x D) Appr. 8.58 x 14 x 10"
Appr. 218 x 356 x 254 mm
Weight Appr. 11.24 lbs / 5.1 kg
Please note these specifications are preliminary and conceptual in nature, and as such are subject
to change as product development progresses. This information is supplied for market research
purposes only and is not to be made public in any manner. This document is solely the property of
The MUSIC Group, or one of its subsidiaries, and must be surrendered upon request of the owner.
