Beijer Electronics IFC PBDP User manual

IFC PBDP
Manual
MA00062E 2002-03 English Svenska

Foreword
Beijer Electronics
Manual IFC PBDP
Foreword
This manual describes the installation and function of the PROFIBUS DP
expansion card, IFC PBDP.
The expansion card is connectable to operator terminals with expansion slots.
Besides this manual, the manual for the operator terminals and the
programming tool for the operator terminals is also available.
 Beijer Electronics AB, MA00062E 2002-03
All examples in this manual are used solely to promote understanding of how the equipment works and its
operation. Beijer Electronics AB takes no responsibility if these examples are used in real applications.
Because of the great many areas for this equipment, the user himself must acquire the appropriate knowl-
edge needed to use the equipment correctly for particular applications.
Beijer Electronics AB absolves itself of all responsibilities for damage and injuries that may occur during
installation or use of this equipment.
Beijer Electronics AB absolves itself of all responsibilities for any type of modification made to the
equipment.
Beijer Electronics AB absolves itself of all responsibilities for damage caused to its products by other brands
of equipment linked to them.

Foreword
Beijer Electronics
Please fill this form out with any suggestions regarding the manual.
This page, or a copy of it, can be sent to us at the addresses below.
Name ............................................................................
Company............................................................................
Address ............................................................................
City, Zip code.....................................................................
Country ............................................................................
Telephone...............................Fax.......................................
E-mail ............................................................................
Please fax this page to the Marketing Department,
Beijer lectronics AB at [phone],
or send it by conventional mail to
The Marketing Department, Beijer lectronics AB
Box 426, S -201 24 MALMÖ, Sweden.
Comments can also be sent to [e-mail].
Comments regarding MA00062E Page

Safety precautions
Beijer Electronics
Safet precautions
General
– Check the delivery for transport damage. If damage is found, advise the
supplier.
– The product fulfils the requirements of article 4 of EMC directive
89/336/EEC.
– Do not use the product in an explosive environment.
– Modifications, changes and additions to the product are forbidden.
– Use only spare parts approved by Beijer Electronics AB.
– Read the user instructions carefully before use.
– The equipment should be operated by qualified personnel only.
At installation
– The product is constructed for stationary installation.
– Install the product according to the accompanying installation instructions.
– The product must be grounded according to the accompanying installation
instructions.
– The equipment must be installed by qualified personnel.
– Separate cables for high voltage, signals and supply.
In use
– Keep the equipment clean.
– Emergency stop and other safety functions should not be controlled from the
operator terminal.
Service and maintenance
– The agreed guarantee applies.
– Repairs should be made by qualified personnel.

Safety precautions
Beijer Electronics
At disassembl and scrapping
–Local regulations apply concerning recycling of products or parts.

Contents
Beijer Electronics
Contents
1Introduction.............................................................................................7
2Installation................................................................................................8
2.1 Installation of one expansion card................................................8
2.2 Installation of two expansion cards.............................................10
3 Settings in the programming tool...........................................................11
3.1 Define slot .................................................................................11
4 Description of the expansion card IFC PBDP .......................................15
4.1 Components on the expansion card ...........................................15
4.2 Cable for connection via PROFIBUS DP ..................................16
4.3 Technical data............................................................................16

Contents
Beijer Electronics

Introduction
Beijer Electronics 7
1Introduction
PROFIBUS DP is a vendor-independent, open industrial field bus which can be
used in a very wide range of applications. It is an established technology with a
large installed base.
Process automation equipment such as sensors, actuators, transmitters, drives
and programmable logic controllers, increasingly use digital microelectronics.
PROFIBUS DP ensures that devices from different vendors can communicate
efficiently in a network.
PROFIBUS is standardized as European Standard EN 50170.
The PROFIBUS DP expansion card, IFC PBDP, is delivered with a type
diskette containing PLC programs for communication between the terminal
and the PLC system. We refer to the current driver manual for further
information.

Installation
8Beijer Electronics
2 Installation
This chapter describes how to mount the expansion card in the operator
terminal.
2.1 Installation of one expansion card
Perform the following steps to mount an IFC PBDP expansion card:
1. Switch the terminal power off.
2. Make sure that the ESD protection is good.
3. Remove the cover plate on the rear of the terminal, and the two expansion
plates on the short side. In terminals equipped with two expansion slots, the
slots are called Slot 1 and Slot 2. In terminals with only one expansion slot,
it is called Slot 1.
Slot 1
Slot 2

Installation
Beijer Electronics 9
4. Put the jumper J1 on the expansion card in the position SLOT 1 if the
expansion card is mounted in Slot 1, and in position SLOT 2 if the card is
mounted in Slot 2.
5. Mount the expansion cables with the components of the expansion card
placed upwards. One of the expansion cables is mounted between X1 on the
CPU card and X1 on the expansion card, and the other cable between X2
on the CPU card and X2 on the expansion card.
6. Fasten the card with the spacers or the screws. Use the screws if the
expansion card is mounted in Slot 1, and the spacers if the card is mounted
in Slot 2.
7. Check that the expansion cable is correctly mounted.
8. Mount the cover plates.
J1
X1
X1
X2
X2

Installation
10 Beijer Electronics
2.2 Installation of two expansion cards
Two expansion cards can be mounted in some terminals. They are mounted in
parallel to the connector on the CPU card in the terminal. Two expansion cards
can be connected via one expansion cable since there is a parallel contact on the
cable. The connector in the middle is used for the expansion card placed in Slot
1, and the end connector is used for the expansion card placed in Slot 2. If only
one card is used either connector can be used.
The connector X1 on the expansion card in Slot 2 is connected to the connector
X1 and the CPU card in the terminal via the X1 connector on the expansion
card in Slot 1. If the X2 connector on the CPU card in the terminal is used by
any or both cards, this connector is connected to the X2 connector on the
expansion card.
When two expansion cards are mounted in the same terminal you mount the
card in Slot 1 with the distances and the card in Slot 2 with the screws in the
distances.
X1
X2
X1
Card in
Slot 2
Card in
Slot 1
X2
X1

Settings in the programming tool
Beijer Electronics 11
3 Settings in the programming tool
Install the IFC PBDP card in the terminal according to chapter 2, and then
perform the following steps to configure the operator terminal as a slave in the
PROFIBUS DP network.
3.1 Define slot
1. Select Setup/Peripherals.

Settings in the programming tool
12 Beijer Electronics
2. Select the slot defined with jumper J1 on the expansion card and click Edit.
3. Select type of expansion card; in this case IFC PBDP.
4. Select Settings to state the settings for the MMI profile. State the size of the
input and output area. The default setting is 32 bytes. If the setting is
changed, the terminal has to be restarted after transfer of the project. This is
made by turning the power to the terminal off and on again. After that the
new setting is enabled.

Settings in the programming tool
Beijer Electronics 13
5. Click OK.
6. Click OK once more to confirm settings.
7. Drag the controller that is PROFIBUS DP master (Controller 1 or
Controller 2) from Unused functions and drop at the slot where the
expansion card is installed.
8. Finish the configuration of the expansion card IFC PBDP by clicking Exit.

Settings in the programming tool
14 Beijer Electronics

Description of the expansion card IFC PBDP
Beijer Electronics 15
4 Description of the expansion card
IFC PBDP
4.1 Components on the expansion card
1. Connector for the communication cable.
2. Bus termination. Set to ON for the first and last units in the network. The
first unit in the network often is the master unit in the PLC system.
3. The LEDs on the expansion card have the following functions:
1: ERR, red, indicates configuration or communication error. The LED is
red until the unit is configured, and then indicates time-out.
2: PWR, green, indicates that 5 V DC power id supplied.
3: DIA, green, indicates diagnostic error on the PROFIBUS network, not
used by the terminal.
4. Rotary switches for stating of the station number.
00
11
2
2
3
3
4
5
6
4
5
6
7
7
8
8
9
9
Term. Stn. no.
MSB
MSB
LSB
ON
1
1234
1
2
3

Description of the expansion card IFC PBDP
16 Beijer Electronics
4.2 Cable for connection via PROFIBUS DP
4.3 Technical data
The cable Unitronic-Bus L2/F.I.P is tested and has the following performance:
Description Specification
I/O area size 32 - 200 bytes
Baud rate 9.6 kbit/s - 12 Mbit/s
Identity code 1002
Maximum number of nodes without repeater 32
Maximum number of nodes with repeater 96
Maximum cable length and baud rate (with repeater) 3 000 m, 9.6 kbit/s
Maximum cable length and baud rate (without repeater) 200 m, 12 Mbit/s
Description Specification
Capacitance 30 nF/km
Impedance 150 ohm (3 - 20 MHz)
Resistance 115 ohm/km
(3) RxD/TxD-P
(5) DGND
(8) RxD/TxD-N
RxD/TxD-N (8)
DGND (5)
RxD/TxD-P (3)
Protective earth
Shield
Protective earth
Station 2Station 1

Förord
Beijer Electronics
Manual IFC PBDP
Förord
Denna manual är en installations- och funktionsbeskrivning för PROFIBUS
DP-expansionskortet IFC PBDP.
Expansionskortet kan användas till operatörsterminaler med expansionskorts-
platser.
Förutom denna manual finns också manualen för operatörsterminalerna och
programmeringsverktyget för operatörsterminalerna att tillgå.
 Beijer Electronics AB, MA00062E, 2002-03
Alla exempel i denna manual är enbart ämnade för att öka förståelsen av utrustningens funktionalitet och
handhavande. Beijer Electronics AB tar inget ansvar om dessa exempel används i verkliga applikationer.
På grund av det stora antalet användningsområden för denna utrustning, måste användaren själv inhämta
tillräckligt med kunskap för att rätt använda denna i sin speciella applikation.
Beijer Electronics AB fråntager sig allt ansvar för skador som kan uppståvid installation eller användning
av denna utrustning.
Beijer Electronics AB förbjuder all modifiering, ändring eller ombyggnad av utrustningen.
Beijer Electronics AB fråntager sig allt ansvar för skador påprodukterna orsakade av anslutna produkter
från andra leverantörer.

Förord
Beijer Electronics
Synpunkter på manualen kan noteras i formuläret. Denna sida, eller
en kopia av den, kan skickas till oss enligt nedanstående adresser.
Namn ............................................................................
Företag ............................................................................
Adress ............................................................................
Postadress............................................................................
Land ............................................................................
Telefon ...............................Telefax..................................
E-post ............................................................................
Faxa till Marknadsavdelningen, Beijer lectronics AB
040-93 23 01 eller skicka med post till Marknadsavdelningen,
Beijer lectronics AB, Box 426, 201 24 MALMÖ.
Det går också bra att skicka kommentarer till [e-mail].
Synpunkter på MA0006 E Sida

Säkerhetsföreskrifter
Beijer Electronics
Säkerhetsföreskrifter
Allmänt
–Kontrollera de levererade produkterna för att upptäcka eventuella
transportskador. Meddela leverantören om skador upptäcks.
–Produkten uppfyller kraven enligt artikel 4 i EMC-direktivet 89/336/EEC.
–Produkten får ej användas i explosiv miljö.
–All modifiering, ändring och ombyggnad av produkten är förbjuden.
–Endast reservdelar godkända av Beijer Electronics AB får användas.
– Läs användarbeskrivningen noga innan produkten används.
–Utrustningen måste hanteras av personal med adekvat utbildning.
Vid installation
–Produkten är konstruerad för fasta installationer.
–Installera produkten enligt medföljande installationsbeskrivning.
–Jordning skall ske enligt medföljande installationsbeskrivning.
–Installation skall göras av personal med adekvat utbildning.
– Högspännings-, signal- och spänningskablar måste separeras.
Vid användning
– Håll utrustningen ren.
– Nödstoppsfunktioner eller andra säkerhetsfunktioner får ej styras från
operatörsterminalen.
Service och underhåll
–Garanti gäller enligt avtal.
–Reparationer ska utföras av auktoriserad personal.
