Beko BP207C User manual

EN ES FR DE IT RO NL SQ
BP207C BP209C BP209H
Local ar-condtoner
User’s Manual
10M-8500183200-4520-01

2 / EN Air-Conditioner / User Manual
CONTENTS
ENGLISH 3-39
ESPAÑOL 40-78
FRANÇAIS 79-117
DEUTSCH 118-157
ITALIANO 158-195
ROMÂNĂ 196-234
NEDERLANDS 235-273
SHQIP 274-311

3 / EN
Local air-conditioner / User Manual
CONTENTS
1. Safety awareness 6
2. Instructons for reparng applances contanng R290 12
2.1 General instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2 Repairs to sealed components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.3 Repair to intrınsıcally safe components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.4 Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.5 Detection of flammable refrigerants. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.6 Leak detection methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.7 Removal and evacuation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.8 Charging procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.9 Decommissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.10 Labelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.11 Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3. Name of parts 20
4. Accessores 21
5. Appearance and functon of control panel 22
6. Appearance and functon of remote control 24
7. Operaton ntroducton 25
7.1 Before using . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7.2 Cooling operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7.3 Dehumidifying operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7.4 Fan operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7.5 Heating operation (this function is not available for a cold-single unit) . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.6 Timer operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.7 Speed function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.8 °C/°F function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.9 Water dainage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
1

4 / EN Local air-conditioner / User Manual
7.10 Sleep mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8. Installaton explanatons 28
8.1 Installation explanations: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
8.2 Introduction to exhaust hose Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
9. Mantenance explanatons 32
9.1 Air filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
9.2 Clean the air-conditioner surface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
10. Troubleshootng 33
11. European dsposal gudelnes 35
12. Installaton nstructons 36
13. Specfcatons 37
CONTENTS

Please read this user manual rst!
Dear Customer,
Thank you for preferrng a Beko product. We hope that you get the best results from
your product whch has been manufactured wth hgh qualty and state-of-the-art
technology. Therefore, please read ths entre user manual and all other accompanyng
documents carefully before usng the product and keep t as a reference for future
use. If you handover the product to someone else, gve the user manual as well.
Follow all warnngs and nformaton n the user manual.
Meanings of the symbols
Followng symbols are used n the varous secton of ths manual:
Ths product has been produced n envronmentally frendly, modern facltes
Comples wth the WEEE Regulaton. Does not contan PCB.
C
Important nformaton or useful
hnts about usage.
A
Warnng for hazardous
stuatons wth regard to lfe
and property.
Warnng to actons that must
never perform.
B
Warnng for electrc shock.
Warnng for hot surfaces.
Do not cover t.
Ths symbol shows that the
operaton manual should be
read carefully.
Ths symbol shows that a
servce personnel should be
handlng ths equpment wth
reference to the nstallaton
manual.
Ths symbol
shows that ths
applance used
a flammable
refrgerant. If
the refrgerant
s leaked and
exposed to an
external gnton
source, there s a
rsk of fre.

6 / EN Local air-conditioner / User Manual
1. Safety awareness
C
Very mportant!
Please do not nstall or use your portable ar
condtoner before you have carefully read ths
manual. Please keep ths nstructon manual for an
eventual product warranty and for future reference.
A
Warnng
Do not use means to accelerate the defrostng process
or to clean, other than those recommended by the
manufacturer.
The applance shall be stored n a room wthout
contnuously operatng gnton sources (for example:
open flames, an operatng gas applance or an
operatng electrc heater).
Do not perce or burn.
Be aware the refrgerants may not contan an odour.
Applance shall be nstalled, operated and stored n a
room wth a floor area larger than X m2.
Model X (m2)
5000Btu/h, 7000Btu/h,
8000Btu/h
4
9000Btu/h, 10000Btu/h,
10500Btu/h
12

7 / EN
Local air-conditioner / User Manual
1. Safety awareness
Warnng (for R290)
Specfc nformaton regardng
applances wth R290 refrgerant
gas.
• Thoroughly read all of the
warnngs.
• When defrostng and
cleanng the applance , do
not use any tools other than
those recommended by the
manufacturng company.
• The applance must be
placed n an area wthout
any contnuously sources of
gnton (for example: open
flames , gas or electrcal
applances n operaton).
• Do not puncture and do not
burn.
• Ths applance contans Y g
(see ratng label back of unt )
of R290 refrgerant gas.
• R290 s a refrgerant gas that
comples wth the European
drectves on the envronment.
Do not puncture any part of
the refrgerant crcut.
• If the applance s nstalled,
operated or stored n an
unventlated area, the room
must be desgned to prevent
to the accumulaton of
refrgerant leaks resultng n
a rsk of fre or exploson due
to gnton of the refrgerant
caused by electrc heaters,
stoves, or other sources of
gnton.
• The applance must be stored
n such a way as to prevent
mechancal falure.
• Indvduals who operate or
work on the refrgerant crcut
must have the approprate
certfcaton ssued by an
accredted organzaton
that ensures competence
n handlng refrgerants
accordng to a specfc
evaluaton recognzed by
assocatons n the ndustry.

8 / EN Local air-conditioner / User Manual
• Repars must be performed
based on the recommendaton
from the manufacturng
company. Mantenance and
repars that requre the
assstance of other qualfed
personnel must be performed
under the supervson of an
ndvdual specfed n the use
of flammable refrgerants.
• Ducts connected to an
applance shall not contan a
potental gnton source.
• A warmng that the non-fxed
applance shall be stored n
an area where the room sze
corresponds to the room area
as specfed for operaton.
• A warmng that the non-fxed
applance shall be stored n a
room wthout contnuously
operatng open flames (for
example an operatng gas
applance) or other potental
gnton sources (for example
an operatng electrc heater,
hot surfaces).
General safety
nstructon
1. The applance s for ndoor use
only.
2. Do not use the unt on a socket
under repars or not nstalled
properly
3. Do not use the unt, follow
these precautons:
A: Near to source of fre.
B: An area where ol s lkely to
splash.
C: An area exposed to drect
sunlght.
D: An area where water s
lkely to splash.
E: Near a bath, a laundry, a
shower or a swmmng pool.
4. Never nsert your fngers, rods
nto the ar outlet. Take specal
care to warn chldren of these
dangers.
5. Keep the unt upward whle
transport and storage, for the
compressor locates properly.
1. Safety awareness

9 / EN
Local air-conditioner / User Manual
6. Before cleanng the ar-
condtoner, always turn off or
dsconnect the power supply.
7. When movng the ar-
condtoner, always turn off
and dsconnect the power
supply, and move t slowly.
8. To avod the possblty of fre
dsaster, the ar-condtoner
shall not be covered.
9. All the ar-condtoner sockets
must comply wth the local
electrc safety requrements. If
necessary, please check t for
the requrements.
10.Chldren should be supervsed
to ensure that they do not
play wth the applance.
11. If the supply cord s damaged,
t must be replaced by the
manufacturer, ts servce
agent or smlarly qualfed
persons n order to avod a
hazard.
12. Ths applance can be used by
chldren aged from 8 years
and above and persons wth
reduced physcal, sensory
or mental capabltes or
lack of experence and
knowledge f they have
been gven supervson or
nstructon concernng use
of the applance n a safe
way and understand the
hazards nvolved. Chldren
shall not play wth the
applance. Cleanng and user
mantenance shall not be
made by chldren wthout
supervson.
13. The applance shall be nstalled
n accordance wth natonal
wrng regulatons.
14.Detals of type and ratng of
fuses: T, 250V AC,3.15A or
hgher.
15. Recyclng
1. Safety awareness

10 / EN Local air-conditioner / User Manual
Ths markng ndcates
that ths product should
not be dsposed wth
other household wastes
throughout the EU. To
prevent possble harm to
the envronment or human
health from uncontrolled
waste dsposal, recycle t
responsbly to promote the
sustanable reuse of materal
resources. To return your
used devce, please use the
return and collecton systems
or contact the retaler where
the product was purchased.
They can take ths product for
envronmental safe recyclng.
16.Contact authorzed servce
techncan for repar or
mantenance of ths unt.
17. Do not pull , deform . or modfy
the power supply cord , or
mmerse t n water . Pullng or
msuse of the power supply
cord can result n damage to the
unt and cause electrcal shock.
18.Complance wth natonal gas
regulatons shall be observed.
19.Keep ventlaton openngs
clear of obstructon.
20.Any person who s nvolved
wth workng on or breakng
nto a refrgerant crcut should
hold a current vald certfcate
from an ndustry-accredted
assessment authorty, whch
authorzes ther competence
to handle refrgerants safely
n accordance wth an ndustry
recognzed assessment
specfcaton.
21. Servcng shall only be
performed as recommended
by the equpment
manufacturer. Mantenance
and repar requrng the
assstance of other sklled
personnel shall be carred out
under the supervson of the
person competent n the use
of flammable refrgerants.
1. Safety awareness

11 / EN
Local air-conditioner / User Manual
22.Do not operate or stop the
unt by nsertng or pullng out
De power plug, t may cause
electrc shock or fre due to
heat generaton.
23.Unplug the unt f strange
sounds, smell, or smoke comes
from t.
C
Notes:
– If any parts damage, please contact the dealer or a
desgnated repar shop;
– In case of any damage, please turn off the ar swtch,
dsconnect the power supply, and contact the dealer or a
desgnated repar shop;
– In any case, the power cord shall be frmly grounded.
– To avod the possblty of danger, f power cord s
damaged, please turn off the ar swtch and dsconnect
the power supply. It must be replaced from the dealer or a
desgnated repar shop.
1. Safety awareness

12 / EN Local air-conditioner / User Manual
2.1 General nstructons
2.1.1 Checks to the area
Pror to begnnng work on systems contanng
flammable refrgerants, safety checks are
necessary to ensure that the rsk of gnton s
mnmzed. For repar to the refrgeratng system,
the followng precautons shall be compled wth
pror to conductng work on the system.
2.1.2 Work procedure
Work shall be undertaken under a controlled
procedure so as to mnmze the rsk of a
flammable gas or vapor beng present whle the
work s beng performed.
2.1.3 General work area
All mantenance staff and others workng n the
local area shall be nstructed on the nature of
work beng carred out. Work n confned spaces
shall be avod. The area around the workspace
shall be sectoned off. Ensure that the condtons
wthn the area have been made safe by control
of flammable materal.
2.1.4Checkng for presence of
refrgerant
The area shall be checked wth an approprate
refrgerant detector pror to and durng work,
to ensure the techncan s aware of potentally
flammable atmospheres. Ensure that the leak
detecton equpment beng used s sutable for
use wth flammable refrgerants, .e. nonsparkng,
adequately sealed or ntrnscally safe.
2.1.5 Presence of fre extngusher
If any hot work s to be conducted on the
refrgeraton equpment or any assocated parts,
proprate fre extngushng equpment shall be
avalable to hand. Have a dry powder or CO 2 fre
extngusher adjacent to the chargng area.
2.1.6 No gnton sources
No person carryng out work n relaton to a
refrgeraton system whch nvolves exposng
any ppe work that contans or has contaned
flammable refrgerant shall use any sources
of gnton n such a manner that t may lead to
the rsk of fre or exploson. All possble gnton
sources, ncludng cgarette smokng, should
be kept suffcently far away from the ste of
nstallaton, reparng, removng and dsposal,
durng whch flammable refrgerant can possbly
be released to the surroundng space. Pror to
work takng place, the area around the equpment
s to be surveyed to make sure that there are no
flammable hazards or gnton rsks. “No Smokng”
sgns shall be dsplayed.
2.1.7 Ventlated area
Ensure that the area s n the open or that t s
adequately ventlated before breakng nto the
system or conductng any hot work. A degree
of ventlaton shall contnue durng the perod
that the work s carred out. The ventlaton
should safely dsperse any released refrgerant
and preferably expel t externally nto the
atmosphere.
2.1.8Checks to the refrgeraton
equpment
Where electrcal components are beng changed,
they shall be ft for the purpose and to the correct
specfcaton. At all tmes the manufacturer’s
mantenance and servce gudelnes shall be
followed. If n doubt consult the manufacturer’s
techncal department for assstance. The
followng checks shall be appled to nstallatons
usng flammable refrgerants: the charge sze s
n accordance wth the room sze wthn whch
2. Instructons for reparng applances contanng
R290

13 / EN
Local air-conditioner / User Manual
2. Instructons for reparng applances contanng
R290
the refrgerant contanng parts are nstalled; the
ventlaton machnery and outlets are operatng
adequately and are not obstructed; f an ndrect
refrgeratng crcut s beng used, the secondary
crcut shall be checked for the presence of
refrgerant; markng to the equpment contnues
to be vsble and legble. Markngs and sgns that
are llegble shall be corrected; refrgeraton
ppe or components are nstalled n a poston
where they are unlkely to be exposed to any
substance whch may corrode refrgerant
contanng components, unless the components
are constructed of materals whch are nherently
resstant to beng corroded or are sutably
protected aganst beng so corroded.
2.1.9 Checks to electrcal devces
Repar and mantenance to electrcal components
shall nclude ntal safety checks and component
nspecton procedures. If a fault exsts that could
compromse safety, then no electrcal supply shall
be connected to the crcut untl t s satsfactorly
dealt wth. If the fault cannot be corrected
mmedately but t s necessary to contnue
operaton, an adequate temporary soluton shall
be used. Ths shall be reported to the owner of
the equpment so all partes are advsed.
Intal safety checks shall nclude: that capactors
are dscharged: ths shall be done n a safe manner
to avod possblty of sparkng; that there no lve
electrcal components and wrng are exposed
whle chargng, recoverng or purgng the system;
that there s contnuty of earth bondng.
2.2 Repars to sealed components
2.2.1 Durng repars to sealed components,
all electrcal supples shall be
dsconnected from the equpment
beng worked upon pror to any removal
of sealed covers, etc. If t s absolutely
necessary to have an electrcal supply
to equpment durng servcng, then
a permanently operatng form of leak
detecton shall be located at the most
crtcal pont to warn of a potentally
hazardous stuaton.
2.2.2 Partcular attenton shall be pad to the
followng to ensure that by workng
on electrcal components, the casng s
not altered n such a way that the level
of protecton s affected. Ths shall
nclude damage to cables, excessve
number of connectons, termnals
not made to orgnal specfcaton,
damage to seals, ncorrect fttng of
glands, etc. Ensure that apparatus s
mounted securely. Ensure that seals
or sealng materals have not degraded
such that they no longer serve the
purpose of preventng the ngress of
flammable atmospheres. Replacement
parts shall be n accordance wth the
manufacturer’s specfcatons.
C
Note: The use of slcon sealant
may nhbt the effectveness
of some types of leak detecton
equpment. Intrnscally safe
components do not have to be
solated pror to workng on
them.
2.3 Repar to ntrınsıcally safe
components
Do not apply any permanent nductve or
capactance loads to the crcut wthout ensurng

14 / EN Local air-conditioner / User Manual
that ths wll not exceed the permssble voltage
and current permtted for the equpment n use.
Intrnscally safe components are the only types
that can be worked on whle lve n the presence
of a flammable atmosphere. The test apparatus
shall be at the correct ratng. Replace components
only wth parts specfed by the manufacturer.
Other parts may result n the gnton of
refrgerant n the atmosphere from a leak.
2.4 Cablng
Check that cablng wll not be subject to wear,
corroson, excessve pressure, vbraton, sharp
edges or any other adverse envronmental
effects. The check shall also take nto account
the effects of agng or contnual vbraton from
sources such as compressors or fans.
2.5 Detecton of flammable
refrgerants
Under no crcumstances shall potental sources of
gnton be used n the searchng for or detecton
of refrgerant leaks. A halde torch (or any other
detector usng a naked flame) shall not be used.
2.6 Leak detecton methods
The followng leak detecton methods are
deemed acceptable for systems contanng
flammable refrgerants. Electronc leak detectors
shall be used to detect flammable refrgerants,
but the senstvty may not be adequate, or may
need recalbraton. (Detecton equpment shall
be calbrated n a refrgerant-free area.) Ensure
that the detector s not a potental source of
gnton and s sutable for the refrgerant used.
Leak detecton equpment shall be set at a
percentage of the LFL of the refrgerant and shall
be calbrated to the refrgerant employed and the
approprate percentage of gas (25 % maxmum)
s confrmed. Leak detecton fluds are sutable
for use wth most refrgerants but the use of
detergents contanng chlorne shall be avoded
as the chlorne may react wth the refrgerant
and corrode the copper ppe-work. If a leak s
suspected, all naked flames shall be removed/
extngushed. If a leakage of refrgerant s found
whch requres brazng, all of the refrgerant shall
be recovered from the system, or solated (by
means of shut off valves) n a part of the system
remote from the leak. Oxygen free ntrogen (OFN)
shall then be purged through the system both
before and durng the brazng process.
2.7 Removal and evacuaton
When breakng nto the refrgerant crcut to make
repars – or for any other purpose – con-ventonal
procedures shall be used.However, t s mportant
that best practce s followed snce flammablty
s a consderaton. The followng procedure shall
be adhered to: remove refrgerant; purge the
crcut wth nert gas; evacuate; purge agan wth
nert gas; open the crcut by cuttng or brazng.
The refrgerant charge shall be recovered nto
the correct recovery cylnders. The system shall
be “flushed” wth OFN to render the unt safe.
Ths process may need to be repeated several
tmes.Compressed ar or oxygen shall not be
used for ths task. Flushng shall be acheved by
breakng the vacuum n the system wth OFN and
contnung to fll untl the workng pressure s
acheved, then ventng to atmosphere, and fnally
pullng down to a vacuum. Ths process shall be
repeated untl no refrgerant s wthn the system.
When the fnal OFN charge s used, the system
shall be vented down to atmospherc pressure
to enable work to take place.Ths operaton s
absolutely vtal f brazng operatons on the
ppework are to take place.
2. Instructons for reparng applances contanng
R290

15 / EN
Local air-conditioner / User Manual
Ensure that the outlet for the vacuum pump s
not close to any gnton sources and there s
ventlaton avalable.
2.8 Chargng procedures
In addton to conventonal chargng
procedures,the followng requrements shall be
followed.
– Ensure that contamnaton of dfferent
refrgerants does not occur when usng
chargng equpment. Hoses or lnes shall
be as short as possble to mnmze the
amount of refrgerant contaned n them.
– Cylnders shall be kept uprght.
– Ensure that the refrgeraton system s
earthed pror to chargng the system wth
refrgerant.
– Label the system when chargng s
complete (f not already).
– Extreme care shall be taken not to overfll
the refrgeraton system.
Pror to rechargng the system t shall be
pressure tested wth OFN. The system shall be
leak tested on completon of chargng but pror
to commssonng. A follow up leak test shall be
carred out pror to leavng the ste.
2.9 Decommssonng
Before carryng out ths procedure, t s essental
that the techncan s completely famlar wth the
equpment and all ts detal. It s recommended
good practce that all refrgerants are recovered
safely. Pror to the task beng carred out, an ol
and refrgerant sample shall be taken n case
analyss s requred pror to re-use of reclamed
refrgerant. It s essental that electrcal power s
avalable before the task s commenced.
a) Become famlar wth the equpment and
ts operaton.
b) Isolate system electrcally.
c) Before attemptng the procedure ensure
that: mechancal handlng equpment
s avalable, f requred, for handlng
refrgerant cylnders; all personal
protectve equpment s avalable and
beng used correctly; the recovery process
s supervsed at all tmes by a competent
person; recovery equpment and cylnders
conform to the approprate standards.
d) Pump down refrgerant system f possble.
e) If a vacuum s not possble, make a manfold
so that refrgerant can be removed from
varous parts of the system.
f) Make sure that cylnder s stuated on the
scales before recovery takes place.
g) Start the recovery machne and operate
n accordance wth manufacturer’s
nstructons.
h) Do not overfll cylnders. (No more than 80 %
volume lqud charge).
) Do not exceed the maxmum workng
pressure of the cylnder,even temporarly.
j) When the cylnders have been flled
correctly and the process completed, make
sure that the cylnders and the equpment
are removed from ste promptly and all
solaton valves on the equpment are
closed off.
k) Recovered refrgerant shall not be charged
nto another refrgeraton system unless t
has been cleaned and checked.
2.10 Labellng
2. Instructons for reparng applances contanng
R290

16 / EN Local air-conditioner / User Manual
Equpment shall be labelled statng that t has
been de-commssoned and empted of refr-
gerant.The label shall be dated and sgned.
Ensure that there are labels on the equpment
statng the equpment contans flammable
refrgerant.
2.11 Recovery
When removng refrgerant from a system,
ether for servcng or decommssonng, t s
recommended good practce that all refrgerants
are removed safely. When transferrng refrgerant
nto cylnders, ensure that only approprate
refrgerant recovery cylnders are employed.
Ensure that the correct number of cylnders for
holdng the total system charge are avalable.
All cylnders to be used are desgnated for the
recovered refrgerant and labelled for that
refrgerant (.e. specal cylnders for the recovery
of refrgerant). Cylnders shall be complete wth
pressure relef valve and assocated shut-off
valves n good workng order. Empty recovery
cylnders are evacuated and, f possble, cooled
before recovery occurs.
The recovery equpment shall be n good workng
order wth a set of nstructons concernng the
equpment that s at hand and shall be sutable
for the recovery of flammable refrgerants.In
addton,a set of calbrated weghng scales shall
be avalable and n good workng order. Hoses
shall be complete wth leak-free dsconnect
couplngs and n good condton. Before usng the
recovery machne, check that t s n satsfactory
workng order, has been properly mantaned
and that any assocated electrcal components
are sealed to prevent gnton n the event of a
refrgerant release. Consult manufacturer f n
doubt.
The recovered refrgerant shall be returned to
the refrgerant suppler n the correct recovery
cylnder, and the relevant Waste Transfer Note
arranged. Do not mx refrgerants n recovery
unts and especally not n cylnders.
If compressors or compressor ols are to be
removed, ensure that they have been evacuated
to an acceptable level to make certan that
flammable refrgerant does not reman wthn the
lubrcant. The evacuaton process shall be carred
out pror to returnng the compressor to the
supplers. Only electrc heatng to the compressor
body shall be employed to accelerate ths process.
When ol s draned from a system, t shall be
carred out safely.
Competence of servce
personnel
General
Specal tranng addtonal to usual refrgeratng
equpment repar procedures s requred when
equpment wth flammable refrgerants s
affected.
In many countres, ths tranng s carred out by
natonal tranng organsatons that are accredted
to teach the relevant natonal competency
standards that may be set n legslaton.
The acheved competence should be documented
by a certfcate.
Tranng
The tranng should nclude the substance of the
followng:
Informaton about the exploson potental of
flammable refrgerants to show that flammables
may be dangerous when handled wthout care.
Informaton about potental gnton sources,
especally those that are not obvous, such as
lghters, lght swtches, vacuum cleaners, electrc
2. Instructons for reparng applances contanng
R290

17 / EN
Local air-conditioner / User Manual
heaters.
Informaton about the dfferent safety concepts:
Unventlated – (see Clause GG.2) Safety of the
applance does not depend on ventlaton of the
housng. Swtchng off the applance or openng
of the housng has no sgnfcant effect on the
safety. Nevertheless, t s possble that leakng
refrgerant may accumulate nsde the enclosure
and flammable atmosphere wll be released when
the enclosure s opened.
Ventlated enclosure – (see Clause GG.4) Safety
of the applance depends on ventlaton of the
housng. Swtchng off the applance or openng
of the enclosure has a sgnfcant effect on
the safety. Care should be taken to ensure a
suffcent ventlaton before.
Ventlated room – (see Clause GG.5) Safety of the
applance depends on the ventlaton of the room.
Swtchng off the applance or openng of the
housng has no sgnfcant effect on the safety.
The ventlaton of the room shall not be swtched
off durng repar procedures.
Informaton about the concept of sealed
components and sealed enclosures accordng to
IEC 60079-15:2010.
Informaton about the correct workng
procedures:
a) Commssonng
• Ensure that the floor area s suffcent
for the refrgerant charge or that the
ventlaton duct s assembled n a correct
manner.
• Connect the ppes and carry out a leak test
before chargng wth refrgerant.
• Check safety equpment before puttng
nto servce.
b) Mantenance
• Portable equpment shall be repared
outsde or n a workshop specally equpped
for servcng unts wth flammable
refrgerants.
• Ensure suffcent ventlaton at the repar
place.
• Be aware that malfuncton of the
equpment may be caused by refrgerant
loss and a refrgerant leak s possble.
• Dscharge capactors n a way that won’t
cause any spark. The standard procedure to
short crcut the capactor termnals usually
creates sparks.
• Reassemble sealed enclosures accurately.
If seals are worn, replace them.
• Check safety equpment before puttng
nto servce.
c) Repar
• Portable equpment shall be repared
outsde or n a workshop specally equpped
for servcng unts wth flammable
refrgerants.
• Ensure suffcent ventlaton at the repar
place.
• Be aware that malfuncton of the
equpment may be caused by refrgerant
loss and a refrgerant leak s possble.
• Dscharge capactors n a way that won’t
cause any spark.
• When brazng s requred, the followng
procedures shall be carred out n the rght
order:
– Remove the refrgerant. If the recovery s
not requred by natonal regulatons, dran
the refrgerant to the outsde. Take care
that the draned refrgerant wll not cause
2. Instructons for reparng applances contanng
R290

18 / EN Local air-conditioner / User Manual
any danger. In doubt, one person should
guard the outlet. Take specal care that
draned refrgerant wll not float back nto
the buldng.
– Evacuate the refrgerant crcut.
– Purge the refrgerant crcut wth ntrogen
for 5mn.
– Evacuate agan.
– Remove parts to be replaced by cuttng,
not by flame.
– Purge the braze pont wth ntrogen durng
the brazng procedure.
– Carry out a leak test before chargng wth
refrgerant.
• Reassemble sealed enclosures accurately.
If seals are worn, replace them.
• Check safety equpment before puttng
nto servce.
d) Decommssonng
• If the safety s affected when the
equpment s putted out of servce, the
refrgerant charge shall be removed before
decommssonng.
• Ensure suffcent ventlaton at the
equpment locaton.
• Be aware that malfuncton of the
equpment may be caused by refrgerant
loss and a refrgerant leak s possble.
• Dscharge capactors n a way that won’t
cause any spark.
• Remove the refrgerant. If the recovery s
not requred by natonal regulatons, dran
the refrgerant to the outsde. Take care
that the draned refrgerant wll not cause
any danger. In doubt, one person should
guard the outlet. Take specal care that
draned refrgerant wll not float back nto
the buldng.
• Evacuate the refrgerant crcut.
• Purge the refrgerant crcut wth ntrogen
for 5mn.
• Evacuate agan.
• Fll wth ntrogen up to atmospherc
pressure.
• Put a label on the equpment that the
refrgerant s removed.
e) Dsposal
• Ensure suffcent ventlaton at the workng
place.
• Remove the refrgerant. If the recovery s
not requred by natonal regulatons, dran
the refrgerant to the outsde. Take care
that the draned refrgerant wll not cause
any danger. In doubt, one person should
guard the outlet. Take specal care that
draned refrgerant wll not float back nto
the buldng.
• Evacuate the refrgerant crcut.
• Purge the refrgerant crcut wth ntrogen
for 5mn.
• Evacuate agan.
• Cut out the compressor and dran the ol.
Transportaton, markng and storage for
unts that employ flammable refrgerants
Transport of equpment contanng
flammable refrgerants
Attenton s drawn to the fact that addtonal
transportaton regulatons may exst wth respect
2. Instructons for reparng applances contanng
R290

19 / EN
Local air-conditioner / User Manual
to equpment contanng flammable gas. The
maxmum number of peces of equpment or
the confguraton of the equpment, permtted
to be transported together wll be determned
by the applcable transport regulatons.
Markng of equpment usng sgns
Sgns for smlar applances used n a work area
generally are addressed by local regulatons
and gve the mnmum requrements for the
provson of safety and/or health sgns for a
work locaton.
All requred sgns are to be mantaned and
employers should ensure that employees
receve sutable and suffcent nstructon and
tranng on the meanng of approprate safety
sgns and the actons that need to be taken n
connecton wth these sgns.
The effectveness of sgns should not be
dmnshed by too many sgns beng placed
together.
Any pctograms used should be as smple as
possble and contan only essental detals.
Dsposal of equpment usng flammable
refrgerants
See natonal regulatons.
Storage of equpment/applances
The storage of equpment should be
n accordance wth the manufacturer’s
nstructons.
Storage of packed (unsold) equpment
Storage package protecton should be
constructed such that mechancal damage to
the equpment nsde the package wll not cause
a leak of the refrgerant charge.
The maxmum number of peces of equpment
permtted to be stored together wll be
determned by local regulatons.
2. Instructons for reparng applances contanng
R290

20 / EN Local air-conditioner / User Manual
1
2
3
4
5
6
7
8
1 Control panel 5 Power cord
2 Front panel 6 Dranage outlet
3 Louver 7 Ar nlet
4 Castor 8 Ar outlet
3. Name of parts
