Beko BEEPG 090 User manual

10M-8504153200-4922-02
Split type air conditioner
User Manual
EN - PL - BG
BEHPGH 090/BEHPGH 091
BEHPGH 120/BEHPGH 121
BEHPGH 180/BEHPGH 181
BEHPGH 240/BEHPGH 241
BEEPGH 090/BEEPGH 091
BEEPGH 120/BEEPGH 121
BEHPG 090/BEHPG 091
BEHPG 120/BEHPG 121
BEHPG 180/BEHPG 181
BEHPG 240/BEHPG 241
BEEPG 090/BEEPG 091
BEEPG 120/BEEPG 121

CONTENTS
ENGLISH 3-64
POLSKI 65-131
БЪЛГАРСКИ 132-200
V2211013
AG UM

Please read this user manual rst!
Dear Customer,
Thank you for preferring a Beko product. We hope that you get the best results from
your product which has been manufactured with high quality and state-of-the-art
technology. Therefore, please read this entire user manual and all other accompanying
documents carefully before using the product and keep it as a reference for future use.
If you handover the product to someone else, give the user manual as well. Follow all
warnings and information in the user manual.
Meanings of the symbols
Following symbols are used in the various section of this manual:
C
Important information or
useful hints about usage.
A
Warning for hazardous
situations with regard to life
and property.
Warning to actions that
must never perform.
B
Warning for electric shock.
This symbol shows that
information is available such
as the operating manual or
installation manual.
Do not cover it.
This symbol shows that the
operation manual should be
read carefully.
This symbol shows that a
service personnel should be
handling this equipment with
reference to the installation
manual.
(For R32/R290 gas type)
This symbol
shows that this
appliance used
a flammable
refrigerant. If
the refrigerant
is leaked and
exposed to an
external ignition
source, there is a
risk of fire.
RECYCLED &
RECYCLABLE
PAPER

CONTENTS
1 Safety precautions 6
2 Unit specifications and features 15
2.1 Indoor unit display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.2 Operating temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.3 Inverter split type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.4 Fixed-speed type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.5 Other features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.6 Manual operation (without remote) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.7 Install the HomeWhiz kit (wireless module) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3 Care and maintenance 21
3.1 Cleaning your indoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.2 Cleaning your air filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.3 Maintenance — long periods of non-use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.4 Maintenance – pre-season inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4 Troubleshooting 24
4.1 Common issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5 Accessories 28
6 Installation summary - indoor unit 30
7 Unit parts 31
8 Indoor unit installation 32
8.1 Installation instructions - Indoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
9 Outdoor unit installation 41
9.1 Installation instructions — outdoor unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4 / 200 EN Split type air conditioner / User Manual

CONTENTS
10 Refrigerant piping connection 46
10.1 Connection instructions – refrigerant piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
10.2 Instructions for connecting piping to outdoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
11 Air evacuation 50
11.1 Preparations and precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
11.2 Evacuation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
11.3 Note on adding refrigerant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
12 Electrical and gas leak checks 52
12.1 Before test run . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
12.2 Electrical safety checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
12.3 Gas leak checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
13 Test Run 54
13.1 Test run instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
14 European disposal guideline 55
15 Installation instructions 56
15.1 F-Gas instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
16 Specifications 57
Split type air conditioner / User Manual 5 / 200 EN

6 / 200 EN Split type air conditioner / User Manual
Warning
This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved. Children
shall not play with the appliance.
Cleaning and user maintenance
shall not be made by children
without supervision (European
Union countries).
This appliance is not intended
for use by persons (including
children) with reduced physical,
sensory or mental capabilities,
or lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
Children should be supervised to
ensure that they do not play with
the appliance.
Warnings for product use
•If an abnormal situation
arises (like a burning smell),
immediately turn off the unit
and disconnect the power.
Call your dealer for instructions
to avoid electric shock, fire or
injury.
•Do not insert fingers, rods or
other objects into the air inlet
or outlet. This may cause injury,
since the fan may be rotating at
high speeds.
•Do not use flammable sprays
such as hair spray, lacquer or
paint near the unit. This may
cause fire or combustion.
•Do not operate the air
conditioner in places near or
around combustible gases.
Emitted gas may collect around
the unit and cause explosion.
1 Safety precautions

Split type air conditioner / User Manual 7 / 200 EN
•Do not operate your air
conditioner in a wet room
such as a bathroom or laundry
room. Too much exposure
to water can cause electrical
components to short circuit.
•Do not expose your body
directly to cool air for a
prolonged period of time.
•Do not allow children to play
with the air conditioner. Children
must be supervised around the
unit at all times.
•If the air conditioner is used
together with burners or other
heating devices, thoroughly
ventilate the room to avoid
oxygen deficiency.
•In certain functional
environments, such as
kitchens, server rooms, etc.,
the use of specially designed
air-conditioning units is highly
recommended.
Cleaning and
maintenance warnings
•Turn off the device and
disconnect the power before
cleaning. Failure to do so can
cause electrical shock.
•Do not clean the air conditioner
with excessive amounts of water.
•Do not clean the air conditioner
with combustible cleaning
agents. Combustible cleaning
agents can cause fire or
deformation.
Caution
•Turn off the air conditioner and
disconnect the power if you are
not going to use it for a long time.
•Turn off and unplug the unit
during storms.
•Make sure that water
condensation can drain
unhindered from the unit.
•Do not operate the air
conditioner with wet hands.
This may cause electric shock.
1 Safety precautions

8 / 200 EN Split type air conditioner / User Manual
•Do not use device for any other
purpose than its intended use.
•Do not climb onto or place
objects on top of the outdoor unit.
•Do not allow the air conditioner to
operate for long periods of time
with doors or windows open, or if
the humidity is very high.
Electrical warnings
•Only use the specified power cord.
If the power cord is damaged,
it must be replaced by the
manufacturer, its service agent or
similarly qualified persons in order
to avoid a hazard.
•Keep power plug clean.
Remove any dust or grime that
accumulates on or around the
plug. Dirty plugs can cause fire
or electric shock.
•Do not pull power cord to
unplug unit. Hold the plug firmly
and pull it from the outlet.
Pulling directly on the cord can
damage it, which can lead to fire
or electric shock.
•Do not modify the length of
the power supply cord or use
an extension cord to power the
unit.
•Do not share the electrical outlet
with other appliances. Improper
or insufficient power supply can
cause fire or electrical shock.
•The product must be properly
grounded at the time of
installation, or electrical shock
may occur.
•For all electrical work, follow
all local and national wiring
standards, regulations, and the
Installation Manual. Connect
cables tightly, and clamp them
securely to prevent external
forces from damaging the
terminal. Improper electrical
connections can overheat and
cause fire, and may also cause
shock. All electrical connections
must be made according to the
Electrical connection diagram
located on the panels of the
indoor and outdoor units.
1 Safety precautions

Split type air conditioner / User Manual 9 / 200 EN
•All wiring must be properly
arranged to ensure that the
control board cover can close
properly. If the control board
cover is not closed properly, it
can lead to corrosion and cause
the connection points on the
terminal to heat up, catch fire, or
cause electrical shock.
•If connecting power to fixed
wiring, an all-pole disconnection
device which has at least 3mm
clearances in all poles, and
have a leakage current that
may exceed 10mA, the residual
current device (RCD) having
a rated residual operating
current not exceeding 30mA,
and disconnection must be
incorporated in the fixed wiring
in accordance with the wiring
rules.
Take note of fuse
specications
The air conditioner’s circuit board
(PCB) is designed with a fuse to
provide overcurrent protection.
The specifications of the fuse are
printed on the circuit board, such
as:
T3.15AL/250VAC,
T5AL/250VAC, T3.15A/250VAC,
T5A/250VAC, T20A/250VAC,
T30A/250VAC,etc.
C
Note: For the units
using R32 or R290
refrigerant, only the
blast-proof ceramic
fuse can be used.
1 Safety precautions

10 / 200 EN Split type air conditioner / User Manual
HygieneMax(UV-C lamp)
(Applicable to the unit
contains HygieneMax
feature only)
This appliance contains a
HygieneMax(UV-C lamp). Please
read the following instructions
before opening the appliance.
1. Do not operate
HygieneMax(UV-C lamp)
outside of the appliance.
2. Appliances that are obviously
damaged must not be
operated.
3. Unintended use of the
appliance or damage to the
housing may result in the
escape of dangerous UV-C
radiation. UV-C radiation may,
even in small doses, cause
harm to the eyes and skin.
4. The appliance must be
disconnected from the supply
mains before cleaning your
unit or any other maintenance.
5. UV-C barriers bearing the
ultraviolet radiation hazard
symbol should not be
removed.
A
Warning: This
appliance contains
an UV emitter. Do
not stare at the light
source.
Warnings for product
installation
1. Installation must be performed
by an authorized dealer or
specialist. Defective installation
can cause water leakage,
electrical shock, or fire.
2. Installation must be performed
according to the installation
instructions. Improper
installation can cause water
leakage, electrical shock, or
fire.
1 Safety precautions
