Beko ASGL142PX User manual

EN
ASD241B
ASD241S
ASD241X
ASD241W
ASL141B
ASL141S
ASL141W
ASL141X
ASDL251B
ASDM241PX
ASL141PX
ASGL142PX
ASDM241Z

Please read these instructions first before using your appliance
Thank you for choosing a Beko appliance.
Please take some time to read this user manual before using your appliance, to ensure you know how to
safely operate the controls and functions.
Carefully follow all unpacking and installation instructions to ensure the appliance is correctly connected
and fitted prior to use.
Please write your product model and serial number on the last page of this user manual, and store in a
safe location close to the appliance for easy future reference.
This user manual may also be applicable for several other models. Differences between models will be
listed.
If you have any questions or concerns, please call our contact centre or find help and information online
at www.beko.co.uk
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful usage tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.

2 /32 EN Refrigerator / User Manual
1. Safety and environment
instructions 3
1.1. General safety . . . . . . . . . . . . . . . . . . . 3
1.2. Intended use. . . . . . . . . . . . . . . . . . . . . 4
1.3. Child safety . . . . . . . . . . . . . . . . . . . . . . 5
1.4. Compliance with WEEE Directive and
Disposing of the Waste Product. 5
1.5. Compliance with RoHS Directive 5
1.6. Package information . . . . . . . . . . . . 5
2Your refrigerator 6
3Installation 7
3.1. Appropriate installation location 7
3.2. Installing the plastic wedges. . . . 7
3.3. Electrical connection . . . . . . . . . . . . 8
3.4. Adjusting the feet . . . . . . . . . . . . . . . 8
3.5. Illumination lamp . . . . . . . . . . . . . . . . 9
3.6. Door open warning . . . . . . . . . . . . . . 9
3.7. Transportation of the product . . 9
4Preparation 10
4.1. Things to be done for energy
saving . . . . . . . . . . . . . . . . . . . . . . . . . . .10
4.2. Efficient operation . . . . . . . . . . . . . 10
4.3. Recommendations on the fridge
compartment . . . . . . . . . . . . . . . . . . . 10
4.4. Initial use . . . . . . . . . . . . . . . . . . . . . . . 11
5Operating the product 12
5.1. Indicator panel. . . . . . . . . . . . . . . . . . 12
5.2. Neo-Frost Cooling System . . . . . 15
5.3. Freezing fresh food. . . . . . . . . . . . . 15
5.4. Recommendations for preserving the
frozen food . . . . . . . . . . . . . . . . . . . . . 16
5.5. Placing the food . . . . . . . . . . . . . . . . 16
5.6. Deep-freeze information. . . . . . .16
5.7. Icematic and ice storage
container . . . . . . . . . . . . . . . . . . . . . . . 17
5.8. Ice making . . . . . . . . . . . . . . . . . . . . . . 17
5.9. Chiller compartment. . . . . . . . . . . .18
5.10.Butter & cheese section . . . . . . .18
5.11.Egg section . . . . . . . . . . . . . . . . . . . . .18
5.12.Crisper . . . . . . . . . . . . . . . . . . . . . . . . . .18
5.13.Odour filter . . . . . . . . . . . . . . . . . . . . .19
5.14.Drip tray . . . . . . . . . . . . . . . . . . . . . . . .19
5.15.Water Dispenser. . . . . . . . . . . . . . . .20
5.16.Using the water dispenser . . . . .20
5.17.Filling the water dispenser's tank20
5.18.Cleaning the water tank . . . . . . . 21
5.19.Humidity controlled crisper . . . .22
6Maintenance and cleaning 23
6.1 Avoiding bad odours. . . . . . . . . . . .23
6.2 Protecting the plastic surfaces 23
7. Troubleshooting 24

3 /32EN
Refrigerator / User Manual
Ths secton provdes the safety
nstructons necessary to prevent
the rsk of njury and materal
damage. Falure to observe these
nstructons wll nvaldate all
types of product warranty.
Intended use
A
WARNING:
Keep ventlaton
openngs, n the applance
enclosure or n the bult-
nstructure, clear of
obstructon.
A
WARNING:
Do not use mechancal
devces or other means
to accelerate the
defrostng process,
other than those
recommended by the
manufacturer.
AWARNING:
Do not damage the
refrgerant crcut.
A
WARNING:
Do not use electrcal
applances nsde
the food storage
compartments of
the applance, unless
they are of the type
recommended by the
manufacturer.
1.1.General safety
• This product should not be used by
persons with physical, sensory and
mental disabilities, without sufficient
knowledge and experience or by
children. The device can only be used
by such persons under supervision
and instruction of a person responsible
for their safety. Children should not be
allowed to play with this device.
• In case of malfunction, unplug the
device.
• After unplugging, wait at least 5
minutes before plugging in again.
• Unplug the product when not in use.
• Do not touch the plug with wet hands!
Do not pull the cable to plug off, always
hold the plug.
• Do not plug in the refrigerator if the
socket is loose.
• Unplug the product during installation,
maintenance, cleaning and repair.
• If the product will not be used for a
while, unplug the product and remove
any food inside.
• Do not use the product when the
compartment with circuit cards located
on the upper back part of the product
(electrical card box cover) (1) is open.
1
1
• Do not use steam or steamed cleaning
materials for cleaning the refrigerator
and melting the ice inside. Steam may
contact the electrified areas and cause
short circuit or electric shock!
• Do not wash the product by spraying or
pouring water on it! Danger of electric
shock!
• In case of malfunction, do not use
the product, as it may cause electric
shock. Contact the authorised service
before doing anything.
1. Safety and envronment nstructons

4 /32 EN Refrigerator / User Manual
Important instructions for safety and environment
• Plug the product into an earthed
socket. Earthing must be done by a
qualified electrician.
• If the product has LED type lighting,
contact the authorised service for
replacing or in case of any problem.
• Do not touch frozen food with wet
hands! It may adhere to your hands!
• Do not place liquids in bottles and cans
into the freezer compartment. They
may explode.
• Place liquids in upright position after
tightly closing the lid.
• Do not spray flammable substances
near the product, as it may burn or
explode.
• Do not keep flammable materials and
products with flammable gas (sprays,
etc.) in the refrigerator.
• Do not place containers holding liquids
on top of the product. Splashing water
on an electrified part may cause
electric shock and risk of fire.
• Exposing the product to rain, snow,
sunlight and wind will cause electrical
danger. When relocating the product,
do not pull by holding the door handle.
The handle may come off.
• Take care to avoid trapping any part
of your hands or body in any of the
moving parts inside the product.
• Do not step or lean on the door,
drawers and similar parts of the
refrigerator. This will cause the product
to fall down and cause damage to the
parts.
• Take care not to trap the power cable.
1.1.1 HC warning
If the product comprses a coolng
system usng R600a gas, take
care to avod damagng the
coolng system and ts ppe whle
usng and movng the product.
Ths gas s flammable. If the
coolng system s damaged, keep
the product away from sources
of fre and ventlate the room
mmedately.
CThe label on the nner left
sde ndcates the type of
gas used n the product.
1.1.2 For models with
water dispenser
• Pressure for cold water inlet shall be
maximum 90 psi (620 kPa). If your
water pressure exceeds 80 psi (550
kPa), use a pressure limiting valve in
your mains system. If you do not know
how to check your water pressure, ask
for the help of a professional plumber.
• If there is risk of water hammer effect
in your installation, always use a water
hammer prevention equipment in
your installation. Consult Professional
plumbers if you are not sure that there
is no water hammer effect in your
installation.
• Do not install on the hot water inlet.
Take precautions against of the
risk of freezing of the hoses. Water
temperature operating interval shall
be 33°F (0.6°C) minimum and 100°F
(38°C) maximum.
• Use drinking water only.
1.2.Intended use
• This product is designed for home use.
It is not intended for commercial use.
• The product should be used to store
food and beverages only.

5 /32EN
Refrigerator / User Manual
Important instructions for safety and environment
• Do not keep sensitive products
requiring controlled temperatures
(vaccines, heat sensitive medication,
medical supplies, etc.) in the
refrigerator.
• The manufacturer assumes no
responsibility for any damage due to
misuse or mishandling.
• Original spare parts will be provided
for 10 years, following the product
purchasing date.
1.3.Child safety
• Keep packaging materials out of
children’s reach.
• Do not allow the children to play with
the product.
• If the product’s door comprises a lock,
keep the key out of children’s reach.
1.4. Compliance
with WEEE Directive
and Disposing of the
Waste Product
Ths product comples wth
EU WEEE Drectve (2012/19/EU). Ths
product bears a classfcaton symbol
for waste electrcal and electronc
equpment (WEEE).
Ths product has been
manufactured wth hgh
qualty parts and materals
whch can be reused and are
sutable for recyclng. Do not
dspose of the waste product
wth normal domestc and
other wastes at the end of ts servce
lfe. Take t to the collecton center for
the recyclng of electrcal and electronc
equpment. Please consult your local
authortes to learn about these
collecton centers.
1.5.Compliance with
RoHS Directive
• This product complies with EU WEEE Directive
(2011/65/EU). It does not contain harmful and
prohibited materials specified in the Directive.
1.6.Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
materials together with the domestic or other
wastes. Take them to the packaging material
collection points designated by the local
authorities.

6 /32 EN Refrigerator / User Manual
2Your refrgerator
C*Optonal: Fgures n ths user manual are schematc and may not match
the product exactly. If the relevant parts are not avalable n the product you
purchased, t apples to other models.
1- Freezer compartment
2- Fridge compartment
3- Fan
4- Butter-cheese compartments
5- Glass shelves
6- Fridge compartment door racks and
egg compartment
7- Water dispenser tank
8- Odour filter
9- Chiller compartment
10- Crisper compartment
11- Adjustable feet
12- Frozen food storage compartments
13- Freezer compartment door racks
14- Ice makers
2
1
3*4
5
*6
*7
11
11
10
13
9
8
*14
12
*14
Congratulations on your choice a Beko quality Appliance which has been designed to give you service
for many years.

7 /32EN
Refrigerator / User Manual
Always have the repair procedures carried out by
the Authorised Service Agent. Manufacturer shall
not be held liable for damages that may arise from
procedures carried out by unauthorised persons.
To make the product ready for use, make sure
that the electricity installation is appropriate before
calling the Authorised Service Agent. If not, call
a qualified electrician to have any necessary
arrangements carried out.
C
Preparaton of the locaton and
electrcal nstallaton at the
place of nstallaton s under
customer's responsblty.
B
Product must not be plugged n
durng nstallaton. Otherwse,
there s the rsk of death or
serous njury!
B
WARNING: Manufacturer shall
not be held lable for damages
that may arse from procedures
carred out by unauthorsed
persons.
A
WARNING: Pror to nstallaton,
vsually check f the product
has any defects on t. If so, do
not have t nstalled. Damaged
products cause rsks for your
safety.
C
Make sure that the power
cable s not pnched or crushed
whle pushng the product nto
ts place after nstallaton or
cleanng procedures.
3.1.Appropriate
installation location
A
WARNING: If the door of the
room where the product wll be
placed s too small for the product
to pass, then the product's doors
can removed and the product
turned asde to pass t through.

use the product comfortably.

from heat sources such as hobs, ovens,
heaters and stoves.Product must not
be subjected to drect sun lght and
kept n humd places after nstallaton.

provded around your product n order
to acheve an effcent operaton. If the
product s to be placed n a recess n
the wall, pay attenton to leave at least
5 cm dstance wth the celng and sde
walls.

materals such as rugs or carpets.

surface to prevent jolts.

where the temperature falls below
-5°C.
C
If two coolers are to be nstalled
sde by sde, there should be at
least 4 cm dstance between
them.
3.2.Installing the
plastic wedges
Plastic wedges are used to create the distance
for the air circulation between the product and
the rear wall. Insert the 2 plastic wedges onto the
rear ventilation cover as illustrated in the figure.
To install the wedges, remove the screws on the
product and use the screws given in the same
pouch with the wedges.
3Installaton

8 /32 EN Refrigerator / User Manual
Installation
3.3.Electrical connection
Connect the product to a grounded outlet
protected by a fuse complying with the values in
the rating plate. Our company shall not be liable
for any damages that will arise when the product
is used without grounding in accordance with the
local regulations.
•Electrical connection must comply with national
regulations.
•Power cable plug must be within easy reach after
installation.
•The voltage and allowed fuse or breaker
protection are specified in the Rating Plate which
is affixed to interior of the product. If the current
value of the fuse or breaker in the house does not
comply with the value in the rating plate, have a
qualified electrician install a suitable fuse.
•The specified voltage must be equal to your
mains voltage.
•Do not make connections via extension cables or
multi-plugs.
BWARNING:Damaged power
cable must be replaced by the
Authorised Servce Agents.
B
WARNING: If the product
has a falure, t should not be
operated unless t s repared by
the Authorised Servce Agent!
There s the rsk of electrc
shock!
3.4. Adjusting the feet
If the product stands unbalanced after installation
adjust the feet. Taking help from someone to
slightly lift the refrigerator will facilitate this
process.
B
WARNING: Frst unplug the
product. Product must not be
plugged n when adjustng the
feet. There s the rsk of electrc
shock!
Turn the front feet to balance the product. The
corner where the foot exists is lowered when you
turn in the direction of arrow and raised when you
turn it in the opposite direction.
In order to adjust the doors vertically,
•Loosen the fixing nut at the bottom
•Screw adjusting nut (CW/CCW) according to the
position of the door
•Tighten the fixing nut for the final position
In order to adjust the doors horizontally,
• Loosen the fixing bolt on the top
• Screw the adjusting bolt (CW/CCW) on the side
according to the position of the door
• Tighten the fixing bolt on the top for the final
position

9 /32EN
Refrigerator / User Manual
Installation
3.5.Illumination lamp
Do not attempt to repair yourself but call the
Authorised Service Agent if the LED illumination
lamps do not go on or are out of order.
The lamp(s) used in this appliance is not suitable
for household room illumination. The intended
purpose of this lamp is to assist the user to place
foodstuffs in the refrigerator/freezer in a safe and
comfortable way.
3.6. Door open warning
(This feature is optional)
An audio warning signal will be given when the
door of your product is left open for 1 minute. This
warning will be muted when the door is closed or
any of the display buttons (if any) are pressed.
3.7.Transportation
of the product
1. Unplug the product before transporting it.
2. Remove any other connections.
3. Secure the shelves, accessories, crisper and
etc. in the refrigerator by adhesive tape before
repackaging it.
adjusting nut
fixing nut
fixing nut
adjusting nut
CPackagng must be adequate and
the rules of transportaton prnted
on the package must be followed.
COrgnal packagng and foam
materals should be kept for future
transportatons.
AWARNING: Packagng materals
are dangerous for the chldren.
Keep packagng materals n a
safe place away from reach of the
chldren.
