Beko BCSA283E3S Instruction Manual

EN | DE | FR | NL | HU
Instruction of use
Gebrauchsanweisung
Notice d'utilisation
Gebruiksaanwijzing
Használati útmutató
Refrigerator
Kühlschrank
Réfrigérateur
Koelkast
Hűtőszekrény
BCSA283E3S

Please read this user manual first
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
Therefore, read this entire user manual carefully before using the product and
keep it as a reference. If you handover the product to someone else, give the user
manual as well.
The user manual will help you use the product in a fast and safe way.
• Read the manual before installing and operating the product.
• Make sure you read the safety instructions.
• Keep the manual in an easily accessible place as you may need it later.
• Read the other documents given with the product.
•Remember that this user manual is also applicable for several other models.
• Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
C Important information or useful tips.
A Warning against dangerous conditions for life and property.
B Warning against electric voltage.
This product is supplied with the selective sorting symbol for waste electrical
and electronic equipment (WEEE).
This means that this product must be handled pursuant to European
Directive 2002/96/EC in order to be recycled or dismantled to minimise its
impact on the environment. For further information, please contact your local
or regional authorities.
Electronic products not included in the selective sorting process are
potentially dangerous for the environment and human health due to the
presence of hazardous substances.
Recycling
WARNING!
In order to ensure a normal operation of your refrigerating appliance, which uses
a completely environmentally friendly refrigerant the R600a (flammable only
under certain conditions) you must observe the following rules:
•
•
•
•
Do not hinder the free circulation of the air around the appliance.
Do not use mechanical devices in order to accelerate the defrosting,
others than the ones recommended by the manufacturer.
Do not destroy the refrigerating circuit.
Do not use electric appliances inside the food keeping compartment, other
than those that might have been recommended by the manufacturer.

EN
2
1 Your refrigerator 3
2 Important Safety
Warnings 4
Intended use .....................................4
General safety ...................................4
For products with a water dispenser...6
Child safety........................................6
HCA warning.....................................6
Things to be done for energy saving..6
3 Installation 7
Points to be paid attention to when the
relocation of the refrigerator...............7
Before you start the refrigerator..........7
Electrical connection..........................7
Disposing of the packaging ...............8
Disposing of your old refrigerator .......8
Placing and Installation ......................8
Replacing the interior lamp ................8
Reversing the doors ...........................9
CONTENTS
4 Preparation 10
5 Using your refrigerator 11
Control panel ...................................11
Defrost ............................................12
6 Maintenance and
cleaning 13
Protection of plastic surfaces...........13
7 Troubleshooting 14
Zero temperature compartment........12

EN
3
Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
productyou have purchased, then itisvalid for other models.
1Your refrigerator
9-Freezer compartment draers
10-Adjustable door shelves
11-Egg tray
12-Bottle shelf
13-Fridge compartment
14-Freezer compartment
1-Control panel
2-Interior light
3-Movable shelves
4-Wine rack
5-Zero degree compartment
6-Defrost water collection channel - drain tube
7-Crisper cover
8-Crisper
C
2
9
9
3
4
9
3
10
6
1
13
14
11
8
7
10
5
10
12

4 EN
2Important Safety Warnings
Please review the following information.
Failure to observe this information may
cause injuries or material damage.
Otherwise, all warranty and reliability
commitments will become invalid.
Original Spare parts will be provided
for 10 years, following the product
purchasing date.
Intended use
This product is intended to be used:
• indoors and in closed areas such as
homes;
• in closed working environments such
as stores and offices;
• in closed accommodation areas such
as farm houses, hotels, pensions.
• It should not be used outdoors.
General safety
•When you want to dispose/scrap
the product, we recommend you to
consult the authorized service in
order to learn the required
information and authorized bodies.
•Consult your authorized service for
all your questions and problems
related to the refrigerator. Do not
intervene or let someone intervene to
the refrigerator without notifying the
authorised services.
•For products with a freezer
compartment; Do not eat cone ice
cream and ice cubes immediately
after you take them out of the freezer
compartment! (This may cause
frostbite in your mouth.)
• For products with a freezer
compartment; Do not put bottled and
canned liquid beverages in the
freezer compartment. Otherwise,
these may burst.
•Do not touch frozen food by hand;
they may stick to your hand.
•Unplug your refrigerator before
cleaning or defrosting.
•Vapor and vaporized cleaning
materials should never be used in
cleaning and defrosting processes of
your refrigerator. In such cases, the
vapor may get in contact with the
electrical parts and cause short circuit
or electric shock.
•Never use the parts on your
refrigerator such as the door as a
means of support or step.
•Do not use electrical devices inside
the refrigerator.
•Do not damage the parts, where
the refrigerant is circulating, with
drilling or cutting tools. The refrigerant
that might blow out when the gas
channels of the evaporator, pipe
extensions or surface coatings are
punctured causes skin irritations and
eye injuries.
•Do not cover or block the ventilation
holes on your refrigerator with any
material.
•Electrical devices must be repaired
by only authorised persons. Repairs
performed by incompetent persons
create a risk for the user.
•In case of any failure or during
a maintenance or repair work,
disconnect your refrigerator’s mains
supply by either turning off the
relevant fuse or unplugging your
appliance.
•Do not pull by the cable when pulling
off the plug.
•Place the beverage with higher proofs
tightly closed and vertically.

EN
5
•Never store spray cans containing
flammable and explosive substances
in the refrigerator.
•Do not use mechanical devices
or other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.
•This product is not intended to be
used by persons with physical,
sensory or mental disorders or
unlearned or inexperienced people
(including children) unless they are
attended by a person who will be
responsible for their safety or who will
instruct them accordingly for use of
the product.
•Do not operate a damaged
refrigerator. Consult with the service
agent if you have any concerns.
•Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
•Exposing the product to rain, snow,
sun and wind is dangerous with
respect to electrical safety.
•Contact authorized service when
there is a power cable damage to
avoid danger.
•Never plug the refrigerator into
the wall outlet during installation.
Otherwise, risk of death or serious
injury may arise.
•This refrigerator is intended for only
storing food items. It must not be
used for any other purpose.
•Label of technical specifications is
located on the left wall inside the
refrigerator.
•Never connect your refrigerator to
electricity-saving systems; they may
damage the refrigerator.
•If there is a blue light on the
refrigerator, do not look at the blue
light with optical tools.
•For manually controlled refrigerators,
wait for at least 5 minutes to start the
refrigerator after power failure.
•This operation manual should be
handed in to the new owner of the
product when it is given to others.
•Avoid causing damage on power
cable when transporting the
refrigerator. Bending cable may
cause fire. Never place heavy
objects on power cable.
•Do not touch the plug with wet
hands when plugging the product.
•Do not plug the refrigerator if the
wall outlet is loose.
•Water should not be sprayed on
inner or outer parts of the product
for safety purposes.
•Do not spray substances containing
inflammable gases such as propane
gas near the refrigerator to avoid fire
and explosion risk.
•Never place containers filled with
water on top of the refrigerator; in
the event of spillages, this may
cause electric shock or fire.
•Do not overload the refrigerator with
food. If overloaded, the food items
may fall down and hurt you and
damage refrigerator when you open
the door.
•Never place objects on top of the
refrigerator; otherwise, these
objects may fall down when you
open or close the refrigerator's
door.
•As they require a precise
temperature, vaccines, heat-
sensitive medicine and scientific
materials and etc. should not be
kept in the refrigerator.

6 EN
•If not to be used for a long time,
refrigerator should be unplugged.
A possible problem in power cable
may cause fire.
•The plug's tip should be cleaned
regularly with a dry cloth; otherwise,
it may cause fire.
•Refrigerator may move if adjustable
legs are not properly secured on the
floor. Properly securing adjustable
legs on the floor can prevent the
refrigerator to move.
•When carrying the refrigerator, do
not hold it from door handle.
Otherwise, it may be snapped.
•When you have to place your
product next to another refrigerator
or freezer, the distance between
devices should be at least 8 cm.
Otherwise, adjacent side walls may
be humidified.
For products with a water
dispenser
Pressure of water mains should be
minimum 1 bar. Pressure of water
mains should be maximum 8 bars.
•Use only potable water.
Child safety
•If the door has a lock, the key should
be kept away from reach of children.
•Children must be supervised to
prevent them from tampering with
the product.
•Do not leave the doors of your
refrigerator open for a long time.
•Do not put hot food or drinks in your
refrigerator.
•Do not overload your refrigerator so
that the air circulation inside of it is
not prevented.
•Do not install your refrigerator under
direct sunlight or near heat emitting
appliances such as ovens,
dishwashers or radiators. Keep your
refrigerator at least 30 cm away from
heat emitting sources and at least
5 cm from electrical ovens.
•Pay attention to keep your food in
closed containers.
•For products with a freezer
compartment; You can store
maximum amount of food items in
the freezer when you remove the
shelf or drawer of the freezer. Energy
consumption value stated for your
refrigerator has been determined
by removing freezer shelf or drawer
and under maximum load. There
is no harm to use a shelf or drawer
according to the shapes and size of
food to be frozen.
•Thawing frozen food in fridge
compartment will both provide
energy saving and preserve the food
quality.
HCA warning
If your product's cooling system
contains R600a:
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
keep your product away from potential
fire sources that can cause the product
catch a fire and ventilate the room in
which the unit is placed.
Ignore this warning if your
product's cooling system contains
R134a.
Type of gas used in the product is
stated in the type label which is on the
left wall inside the refrigerator.
Never throw the product in fire for
disposal.
Things to be done for energy
saving

7 EN
3Installation
BIn case the information which are
given in the user manual are not
taken into account, manufacturer will
not assume any liability for this.
Points to be paid attention
to when the relocation of the
refrigerator
1. Your refrigerator should be
unplugged. Before transportation of
your refrigerator, it should be
emptied and cleaned.
2. Before it is re-packaged, shelves,
accessories, crisper, etc. inside your
refrigerator should be fixed with
adhesive tape and secured against
impacts. Package should be bound
with a thick tape or sound ropes
and the transportation rules on the
package should be strictly
observed.
3. Original packaging and foam
materials should be kept for future
transportations or moving.
Before you start the
refrigerator
Check the following before you start to
use your refrigerator:
1. Is the interior of the refrigerator dry
and can the air circulate freely in the
rear of it?
2. Clean the interior of the refrigerator
as recommended in the
“Maintenance and cleaning” section.
3. Connect the plug of the refrigerator
to the wall socket. When the fridge
door is opened, fridge internal lamp
will turn on.
4. When the compressor starts to
operate, a sound will be heard. The
liquid and gases sealed within the
refrigeration system may also give rise
to noise, even if the compressor is
not running and this is quite normal.
5. Front edges of the refrigerator may
feel warm. This is normal. These
areas are designed to be warm to
avoid condensation.
Electrical connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
The connection must be in compliance
with national regulations.
•The power plug must be easily
accessible after installation.
•Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
•The voltage stated on the label
located at left inner side of your
product should be equal to your
network voltage.
•Extension cables and multi plugs
must not be used for connection.
BA damaged power cable must be
replaced by a qualified electrician.
BProduct must not be operated before
it is repaired! There is the risk of
electric shock!

8 EN
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose of them by
classifying them in accordance with
the waste instructions stated by your
local authorities. Do not throw away
with regular house waste, throw away
on packaging pick up spots
designated by the local authorities.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old refrigerator without
giving any harm to the environment.
•You may consult your authorized
dealer or waste collection center of
your municipality about the disposal
of your refrigerator.
Before disposing of your refrigerator,
cut out the electric plug and, if there
are any locks on the door, make them
inoperable in order to protect children
against any danger.
Placing and Installation
AIf the entrance door of the room
where the refrigerator will be installed
is not wide enough for the refrigerator
to pass through, then call the
authorized service to have them
remove the doors of your refrigerator
and pass it sideways through the door.
1. Install your refrigerator to a place
that allows ease of use.
2. Keep your refrigerator away from
heat sources, humid places and
direct sunlight.
3. There must be appropriate air
ventilation around your refrigerator in
order to achieve an efficient
operation. If the refrigerator is to be
placed in a recess in the wall, there
must be at least 5 cm distance with
the ceiling and at least 5 cm with the
wall. Do not place your product on
the materials such as rug or carpet.
4. Place your refrigerator on an even
floor surface to prevent jolts.
5. Do not keep your refrigerator in
ambient temperatures under 10°C.
Replacing the interior lamp
To change the Bulb/LED used for
illumination of your refrigerator,
call your Authorised Service.
The lamp(s) used in this appliance is
not suitable for household room
illumination. The intended purpose of
this lamp is to assist the user to place
foodstuffs in the refrigerator/freezer in a
safe and comfortable way. The lamps
used in this appliance have to
withstand extreme physical conditions
such as temperatures below -20°C.

EN
9
Reversing the doors
Proceed in numerical order.
1
4
3
6
2
5
7
8
9
10
16
18
19
20
14
15
17
12
13
11

EN
10
4Preparation
• Your refrigerator should be installed at
least 30 cm away from heat sources
such as hobs, ovens, central heater
and stoves and at least 5 cm away
from electrical ovens and should not
be located under direct sunlight.
• The ambient temperature of the room
where you install your refrigerator
should at least be 10°C. Operating
your refrigerator under cooler
conditions is not recommended with
regard to its efficiency.
• Please make sure that the interior of
your refrigerator is cleaned thoroughly.
• If two refrigerators are to be installed
side by side, there should be at least
2 cm distance between them.
• When you operate your refrigerator for
the first time, please observe the
following instructions during the initial
six hours.
• The door should not be opened
frequently.
• It must be operated empty without
any food in it.
• Do not unplug your refrigerator. If
a power failure occurs out of your
control, please see the warnings in
the “Troubleshooting” section.
• Original packaging and foam
materials should be kept for future
transportations or moving.

EN
11
Control Panel
5Using your refrigerator
1- On/Off function
Press the On/Off button for 3
seconds to turn off or turn on the
fridge.
2- Fridge Set Function
This function allows you to make the
fridge compartment temperature
setting. Press this button to set the
temperature of the fridge
compartment to - (warmest), --, ---,
----, ----- (coldest) respectively.
3- Fridge Compartment
Temperature Setting Indicator
Indicates the temperature set for the
Fridge Compartment. Settings are -
(warmest), --, ---, ----, ----- (coldest).
4- High Temperature Error /
Warning Indicator
This light comes on during high
temperature failures and error
warnings.
5- Quick Fridge Indicator
This icon lits when the Quick Fridge
function is active.
6- Quick Fridge Function
When you press Quick Fridge button,
the temperature of the compartment
will be colder than the adjusted values.
This function can be used for food
placed in the fridge compartment and
required to be cooled down rapidly.
If you want to cool large amounts of
fresh food, it is recommended to active
this feature before putting the food into
the fridge. Quick Fridge indicator will
remain lit when the Quick Fridge
function is enabled. To cancel this
function press Quick Fridge button
again. Quick Fridge indicator will turn
off and return to its normal settings.
If you do not cancel it, Quick Fridge
will cancel itself automatically after 8
hours or when the fridge compartment
reaches to the required temperature.
This function is not recalled when
power restores after a power failure.
7- Alarm Off
When the fridge door is opened for 2
minutes or when there is a sensor
failure, a sound alarm turns on. Alarm
can be turned off by pressing "Alarm
Off" button.
Sensor failure alarm will not sound till
power failure. If you close the door and
then open again "Door open alarm" will
be activated again after 2 minutes later.
1 2 3 4 5 6 7

EN
12
Defrost
A) Fridge compartment
Fridge compartment performs full-
automatic defrosting.
Water drops and a frosting up to 7-8
mm can occur on the inner rear wall of
the fridge compartment while your
refrigerator cools down. Such formation
is normal as a result of the cooling
system. The frost formation is defrosted
by performing automatic defrosting with
certain intervals thanks to the automatic
defrosting system of the rear wall. User
is not required to scrape the frost or
remove the water drops. Water
resulting from the defrosting passes
from the water collection groove and
flows into the evaporator through the
drain pipe and evaporates here by itself.
Check regularly to see if the drain pipe
is clogged or not and clear it with the
stick in the hole when necessary.
Do not use pointed or sharp-edged
objects, such as knives or forks to
remove the frost. Never use hair dryers,
electrical heaters or other such
electrical appliances for defrosting.
Sponge out the defrost water collected
in the bottom of the freezer
compartment. After defrosting, dry the
interior thoroughly.
Insert the plug into the wall socket and
switch on the electricity supply.
B) Freezer compartment
Deep freezer compartment does not
perform automatic defrosting in order to
prevent decaying of the frozen food.
Defrosting is very straightforward and
without mess, thanks to a special defrost
collection basin. Defrost twice a year or
when a frost layer of around 7 (1/4”) mm
has formed. To start the defrosting
procedure, switch off the appliance at the
socket outlet and pull out the mains plug.
All food should be wrapped in several
layers of newspaper and stored in a cool
place (e.g. fridge or larder). Containers of
warm water may be placed carefully in
the freezer to speed up the defrosting.
Zero temperature
compartment
This compartment has been designed to
store frozen food which would be thawed
slowly (meat, fish, chicken, etc.) as
required. The Zero temperature
compartment is the coldest place of your
refrigerator in which dairy products
(cheese, butter), meat, fish or chicken
may be kept at ideal storage conditions.
Vegetables and/or fruits must not be
placed in this compartment.

6Maintenance and cleaning
ANever use gasoline, benzene or
similar substances for cleaning
purposes.
BWe recommend that you unplug the
appliance before cleaning.
BNever use any sharp abrasive
instrument, soap, household
cleaner, detergent and wax polish for
cleaning.
CUse lukewarm water to clean the
cabinet of your refrigerator and wipe it
dry.
CUseadamp cloth wrung out in
a solution of one teaspoon of
bicarbonate of soda to one pint of
water to clean the interior and wipe it
dry.
BMake sure that no water enters the
lamp housing and other electrical
items.
BIf your refrigerator is not going to be
used for a long period of time, unplug
the power cable, remove all food,
clean it and leave the door ajar.
CCheck door seals regularly to ensure
they are clean and free from food
particles.
ATo remove door racks, remove all the
contents and then simply push the
door rackupwards from the base.
ANever use cleaning agents or water
that contain chlorine to clean the
outer surfaces and chromium coated
parts of the product. Chlorine causes
corrosion on such metal surfaces.
Protection of plastic
surfaces
CDo not put the liquid oils or oil-cooked
meals in your refrigerator in unsealed
containers as they damage the
plastic surfaces of your refrigerator. In
case of spilling or smearing oil on the
plastic surfaces, clean and rinse the
relevant part of the surface at once
with warm water.
EN
13

7Troubleshooting
Please review this list before calling the service. It will save your time and
money. This list includes frequent complaints that are not arising from defective
workmanship or material usage. Some of the features described here may not
exist in your product.
The refrigerator does not operate.
•The plug is not inserted into the socket correctly. >>>Insert the plug into the
socket securely.
•The fuse of the socket which your refrigerator is connected to or the main fuse
have blown out. >>>Check the fuse.
Condensation on the side wall of the fridge compartment (MULTIZONE, COOL
CONTROL and FLEXI ZONE).
•Ambient is very cold. >>>Do notinstall the refrigerator in places where the
temperature falls below 10°C.
•Door has been openedfrequently. >>>Do not open and close the door of
refrigerator frequently.
•Ambient is very humid. >>>Do not install your refrigerator into highly humid
places.
•Food containing liquid is stored in open containers. >>>Do not store food with
liquid content in open containers.
•Door of the refrigerator is left ajar. >>>Close the door of the refrigerator.
•Thermostat is set to avery cold level. >>>Set the thermostatto a suitable level.
Compressor is not running.
•Protective thermic of the compressor will blow out during sudden power
failures or plug-out plug-ins as the refrigerant pressure in the cooling system
of the refrigerator has not been balanced yet. The refrigerator will start running
approximately after 6 minutes. Please call the service if the refrigerator does not
startup at the end of this period.
•The fridge is in defrost cycle. >>>This is normal for a full-automatically defrosting
refrigerator. Defrosting cycle occurs periodically.
•The refrigerator is not plugged into the socket. >>>Make sure that the plug is fit
into the socket.
•Temperature settings are not made correctly. >>>Select the suitable temperature
value.
•There is a power outage. >>>Refrigerator returns to normal operation when the
power restores.
EN
14

The operation noise increases when the refrigerator is running.
•The operating performance of the refrigerator may change due to the changes in
the ambient temperature. It is normal and not a fault.
The refrigerator is running frequently or for a long time.
•New product may be wider than the previous one. Larger refrigerators operate
for a longer period of time.
•The room temperature may be high. >>>It is normal that the product operates
for longer periods in hot ambient.
•The refrigerator might be plugged in recently or might be loaded with food.
>>>When the refrigerator is plugged in or loaded with food recently, it will take
longer for it to attain the set temperature. This is normal.
•Large amounts of hot food might be put in the refrigerator recently. >>>Do not
put hot food into the refrigerator.
•Doors might be opened frequently or left ajar fora long time. >>>The warm air
that has entered into the refrigerator causes the refrigerator to run for longer
periods. Do not open the doors frequently.
•Freezer or fridge compartment door might be leftajar. >>>Check if the doors are
closed completely.
•The refrigerator is adjusted to a very low temperature. >>>Adjust the refrigerator
temperature to a warmer degree and wait until the temperature is achieved.
•Door seal of the fridge or freezer may be soiled, worn out, broken or not
properly seated. >>>Clean or replace the seal. Damaged/broken seal causes
the refrigerator to run for a longer period of time in order to maintain the current
temperature.
Freezer temperature is very low while the fridge temperature is sufficient.
•The freezer temperature is adjusted to a very low value. >>>Adjust the freezer
temperature to a warmer degree and check.
Fridge temperature is very low while the freezer temperature is sufficient.
•The fridge temperature is adjusted to a very low value. >>>Adjust the fridge
temperature to a warmer degree and check.
Food kept in the fridge compartment drawers is frozen.
•The fridge temperature is adjusted to a very high value. >>>Adjust the fridge
temperature to a lower value and check.
EN
15

Temperature in the fridge or freezer is very high.
•The fridgetemperature is adjusted to a very high value.>>>Fridge compartment temperature
setting has an effect on the temperature of the freezer. Changethe temperatures of the fridge or
freezer and wait until the relevant compartments
attain a sufficient temperature.
•Doors are opened frequently or left ajar for a long time. >>>Do not open the
doors frequently.
•Door is ajar. >>>Close the door completely.
•The refrigerator is plugged in or loaded with food recently. >>>This is normal. When the
refrigerator is plugged in or loaded with food recently, it will take longer for it to attain the set
temperature.
•Large amounts of hot food might be put in the refrigerator recently. >>>Donot put hot food into
the refrigerator.
Vibrations or noise.
•The floor is not level or stable.>>> If the refrigerator rocks when moved slowly, balance it by
adjusting itsfeet. Also make sure that the floor is strong enough to carry the refrigerator, and
level.
•The items put onto the refrigerator may cause noise. >>>Remove the items on top of the
refrigerator.
There are noises coming from the refrigerator like liquid flowing, spraying, etc.
•Liquid and gas flows occur in accordance with the operating principles of your refrigerator. It
is normaland not a fault.
Whistle comes from the refrigerator.
•Fans are used in order to cool the refrigerator. It is normal and not a fault.
Condensation on the inner walls of refrigerator.
•Hot and humid weather increases icing and condensation. It is normal and not a
fault.
•Doors are opened frequently or left ajar for a long time. >>>Do not open the doors frequently.
Close themif they are open.
•Door is ajar. >>>Close the door completely.
Humidity occurs on the outside of the refrigerator or between the doors.
•There might be humidity in the air; this is quite normal in humid weather. When the humidity is
less, condensation will disappear.
EN
16
Bad odour inside the refrigerator.
•No regular cleaning is performed. >>>Clean the inside of the refrigerator regularly with a sponge,
lukewarm water or carbonate dissolved in water.
•Some containers or package materials may cause the smell. >>>Use a different container or
different brandpackaging material.
•Food is put into the refrigerator in uncovered containers. >>>Keep the food in closed containers.
Microorganisms spreading out from uncovered containers
can cause unpleasant odours.
•Remove the foods that have expired bestbefore dates and spoiled fromthe
refrigerator.
The door is not closing.
•Food packages are preventing the door from closing.>>>Replace the packages that are
obstructing the door.
•The refrigerator is not completely even on the floor. >>>Adjust the feet to balancethe
refrigerator.
•The floor is not level or strong. >>>Make sure that the floor is level and capable to carry the
refrigerator.
Crispers are stuck.
•The food is touching the ceiling of the drawer. >>>Rearrange food in the drawer.

Bitte lesen Sie zuerst diese Anleitung!
Lieber Kunde,
Wir sind sicher, dass Ihnen dieses Produkt, das in modernsten Fertigungsstätten
hergestellt und den strengsten Qualitätsprüfungen unterzogen wurde, lange Zeit
gute Dienste leisten wird.
Wir empfehlen Ihnen, vor Inbetriebnahme des Gerätes das gesamte Handbuch
durchzulesen und es anschließend aufzubewahren.
Diese Anleitung...
•Hilft Ihnen, Ihr Gerät schnell und sicher zu bedienen.
• Lesen Sie die Anleitung, bevor Sie Ihr Gerät aufstellen und bedienen.
•Halten Sie sich an die Anweisungen, beachten Sie insbesondere die
Sicherheitshinweise.
• Bewahren Sie die Anleitung an einem leicht zugänglichen Ort auf, damit Sie
jederzeit darin nachschlagen können.
• Lesen Sie auch die weiteren Dokumente, die mit Ihrem Produkt geliefert wurden.
•Bitte beachten Sie, dass diese Anleitung eventuell auch für andere Geräte
eingesetzt werden kann.
Symbole und ihre Bedeutung
In dieser Anleitung finden Sie die folgenden Symbole:
C Wichtige Informationen oder nützliche Tipps.
A Warnung vor Verletzungen oder Sachschäden.
B Warnung vor elektrischem Strom.
Dieses Produkt ist mit dem selektiven Entsorgungssymbol für elektrische und
elektronische Altgeräte (WEEE) gekennzeichnet.
Das bedeutet, dass dieses Produkt gemäß der europäischen Direktive 2002/96/EC
gehandhabt werden muss, um mit nur minimalen umweltspezifischen
Auswirkungen recycelt oder zerlegt werden zu können. Weitere Informationen
erhalten Sie von Ihren regionalen Behörden.
Elektronikprodukte, die nicht durch den selektiven Entsorgungsvorgang erfasst
werden, stellen durch das Vorhandensein potenziell gefährlicher Substanzen
umwelt- und gesundheitsrelevante Risiken dar.
Recycling
WARNUNG!
Ihr Gerät verwendet ein umweltverträgliches Kältemittel, R600a (nur unter
bestimmten Umständen brennbar). Um einen einwandfreien Betrieb Ihres
Gerätes sicherzustellen, beachten Sie bitte folgende Vorschriften:
•
•
•
•
Die Luftzirkulation um das Gerät darf nicht behindert sein.
Verwenden Sie außer der vom Hersteller empfohlenen, keine
mechanischen Hilfsmittel, um den Abtauprozess zu beschleunigen.
Der Kältemittelkreislauf darf nicht beschädigt werden.
Verwenden Sie im Lebensmittelaufbewahrungsbereich Ihres Gerätes
keine elektrischen Geräte, es sei denn, sie sind vom Hersteller empfohlen.

2DE
INHALT
1 Ihr Kühlschrank 3
2 Wichtige
Sicherheitshinweise 4
Bestimmungsgemäßer Einsatz...........4
Allgemeine Hinweise zu Ihrer
Sicherheit ..........................................4
Bei Geräten mit Wasserspender ........6
Kinder – Sicherheit ............................6
HCA-Warnung ...................................6
Tipps zum Energiesparen ..................6
3 Installation 7
Was Sie bei einem weiteren Transport
Ihres Kühlschranks beachten müssen ...7
Bevor Sie Ihren Kühlschrank
einschalten ........................................7
Verpackungsmaterialien entsorgen ....8
Altgeräte entsorgen ...........................8
Aufstellung und Installation ................8
Austausch der Innenbeleuchtung ......8
Türanschlag umkehren .....................9
4 Vorbereitung 10
5 Nutzung des
Kühlschranks 11
Bedienfeld .......................................11
0°C-Fach ........................................12
Abtauen ...........................................12
6 Wartung und Reinigung 13
Schutz der Kunststoffflächen ..........13
7 Empfehlungen zur
Problemlösung 14
Elektrischer Anschluss ......................7
