Beko CFX6114 S User manual

CXF6114 S
Frost Free Combi
Fridge / Freezer

Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in a 1st class
manufacturing facility and checked under the most meticulous quality control
procedures, will provide you with years of good service.
For this, we recommend you to carefully read the entire manual of your product
before using it and keep it at hand for future reference.
This manual
• Will help you use your appliance quickly and safely.
• Read the manual before installing and operating your product.
• Follow the instructions, especially those for safety.
• Keep the manual in an easily accessible place as you may need it later.
• Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful usage tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.
This product is supplied with the selective sorting symbol for waste electrical
and electronic equipment (WEEE).
This means that this product must be handled pursuant to European Directive
2002/96/EC in order to be recycled or dismantled to minimise its impact on
the environment. For further information, please contact your local or regional
authorities.
Electronic products not included in the selective sorting process are potentially
dangerous for the environment and human health due to the presence of
hazardous substances.
Recycling

EN
3
CONTENTS
1 Your refrigerator 4
2 Warnings 5
Electrical Requirements ..................... 6
Warning! This Appliance Must Be
Earthed ............................................. 6
Energy Saving Tips............................ 7
3 Installation 8
TRANSPORTATION INSTRUCTIONS. 8
INSTALLATION INSTRUCTIONS........ 8
REPLACING THE INTERIOR LIGHT
BULB ............................................. 10
Reversing The Doors ....................... 11
Reversing the doors ........................ 13
4 Before operating 14
Final Check ..................................... 14
5 Using your refrigerator 15
TEMPERATURE CONTROL AND
ADJUSTMENT................................. 15
SUGGESTED ARRANGEMENT OF
FOOD IN THE FRIDGE/FREEZER .... 16
STORING FROZEN FOOD............... 17
FREEZING FRESH FOOD................ 17
MAKING ICE CUBES....................... 18
DEFROSTING.................................. 18
6 Maintenance and
cleaning 19
7 Do’s and Don’ts 20

EN
4
1Your refrigerator
1. Thermostat control
2. Interior Light
3. Adjustable body shelves
4. Defrost water collection
channel - Drain tube
5. Crisper cover
6. Crisper
7. Icebank tray
8. Deep-freeze compartment
9. Adjustable front feet
10. Fridge compartment door
shelves
11. Egg holders
12. Wine rack
13. Shelter wire
14. Fridge compartment
15. Freezer compartment
CFigures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
3
5
8
8
7
3
3
6
4
10
15
14
13
8
9
11
10
12
2
1
8
10
*

EN
5
2Warnings
• Do not connect your appliance to
the electricity supply until all packing
and transit protectors have been
removed.
• If transported horizontally leave
to stand upright for at least 4
hours before switching on to allow
compressor oil to settle
• If you are discarding an old
refrigerator with a lock or latch fitted
to the door, disable the lock/latch,
ensure that it is left in a safe condition
to prevent the entrapment of young
children.
• This fridge/freezer must only be used
for its intended purpose i.e the storing
and freezing of edible foodstuff.
• Do not dispose of the appliance
on a fire. At BEKO, the care and
protection of our environment is an
ongoing commitment. This appliance
which is among the latest range
introduced is particularly environment
friendly. Your appliance contains non
CFC / HFC natural substances in the
cooling system (Called R600a) and in
the insulation (Called cyclopentane)
which are potentially flammable
if exposed to fire. Therefore, take
care not to damage, the cooling
circuit / pipes of the appliance in
transportation and in use. In case of
damage do not expose the appliance
to fire or potential ignition source and
immediately ventilate the room where
the appliance is situated.
• We suggest you contact your local
authority for disposal information and
facilities available.
• See Installation Instructions on on
page 8 for information on suitable
location.
• To obtain the best possible
performance and trouble free operation
from your appliance it is very important
to carefully read these instructions.
• On delivery, check to make sure that
the product is not damaged and that
all the parts and accessories are in
perfect condition.
• Ensure that the plug remains readily
accessible. Do not use multiple
adapter or extension cable.
• Failure to observe these instructions
may invalidate your right to free service
during the guarantee period.
• Keep ventilation openings, in the
appliance enclosure or in the built-in
structure, clear of obstruction.
• Do not use mechanical devices
or other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances
inside the food storage compartments
of the appliance, unless they are
of the type recommended by the
manufacturer.
• We suggest you keep these
instructions in a safe place for easy
reference.
• This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to
ensure that they do not play with the
appliance.

EN
6
Electrical Requirements
Before you insert the plug into the wall
socket make sure that the voltage and
the frequency shown on the rating
plate inside the appliance corresponds
to yourelectricity supply.
Rating label is on the left hand side of
fridge inner liner.
We recommend that this appliance be
connected to the mains supply via a
suitable switched and fused socket.
The appliance must be positioned so
that the plug is accessible.
Should the mains lead of the appliance
become damaged or should it need
replacing at any time, it must be
replaced by a special purpose made
mains lead which can only be obtained
from a BEKO Authorised Service
Agent.
Warning! This Appliance
Must Be Earthed
If the fitted moulded plug is not
suitable for your socket, then the plug
should be cut off and an appropriate
plug fitted. Destroy the old plug which
is cut off as a plug with bared cord
could cause a shock hazard if inserted
into a socket elsewhere in the house.
The moulded plug on this appliance
incorporates a 13 A fuse. Should
the fuse need to be replaced an
ASTABEAB approved BS 1362 fuse
of the same rating must be used. Do
not forget to refit the fuse cover. In the
event of losing the fuse cover the plug
must not be used until a replacement
fuse cover has been fitted.
Colour of the replacement fuse cover
must be the same colour as that
visible on the pin face of the plug. Fuse
covers are available from any good
electrical store.
Important! Fitting A Different Plug
As the colours of the wires in the
mains lead of this appliance may
not correspond with the coloured
markings identifying the terminals in
your plug proceed as follows: (See
diagram).
1. Connect the green-yellow or green
(Earth) wire to the terminal in the plug
marked ‘E’ or with the symbol or
coloured green and yellow or green.
2. Connect the blue (Neutral) wire to
the terminal in the plug marked ‘N’ or
coloured black.
3. Connect the brown (Live) wire to
the terminal in the plug marked ‘L’ or
coloured red.
With alternative plugs a 13 A fuse must
be fitted either in the plug or adaptor
or in the main fuse box. If in doubt
contact a qualified electrician.
FITTED WITH
BS 1362 13A FUSE ALWAYS
FIT BS 1362 REPLACEMENT
CARTRIDGE FUSE
GREEN &
YELLOW
OR
GREEN
N
BLUE
OR
BLACK
L
BROWN
OR
RED
22mm.
6mm.
6mm.
6mm. 32mm.
12mm.
FUSE
CORD GRIP

EN
7
Energy Saving Tips
1- Ensure your appliance is installed in
a well ventilated area.
2- Ensure the time between buying
chilled/frozen food and placing them
in your appliance is kept at minimum,
particularly in summer. We recommend
you use a cool bag or a special carrier
bag to carry perishable food.
3- Do not leave the door (s) of your
appliance open longer than necessary
and ensure they are closed properly
after each opening.
4- Defrost frozen food in the fridge
compartment, so that frozen food acts
as an ice pack to assist cooling in the
fridge.

EN
8
TRANSPORTATION
INSTRUCTIONS
1. The appliance should be
transported only in a vertical upright
position. The packing as supplied
must be intact during transportation.
2. If during the course of transport
the appliance has to be transported
horizontally, it must only be laid on its
right hand side when standing in the
front of the appliance. After bringing
it to upright position,it must not be
operated for at least 4 hours to allow
the system to settle.
3. Failure to comply with the
above instructions could result in
damage occuring to the appliance.
The manufacturer will not be held
responsible if these instructions are
disregarded.
4. The appliance must be protected
against rain, moisture and other
atmospheric influences.
5. When positioning your appliance
take care not to damage your flooring,
pipes, wall coverings etc. Do not move
the appliance by pulling by the door or
handle.
6. Empty any water in the drain
tray before moving. See section
‘Defrosting’ and ‘Care & cleaning’ for
further information.
7. Make sure that the defrost water
pipe at the back of the product is fixed
to the plastic evaporating pan on the
top of the compressor, to avoid defrost
water spillage on the floor.
IMPORTANT : Care must be taken
while cleaning / carrying the appliance
to avoid touching the bottom of the
condenser metal wires at the back of
the appliance as you might injure your
fingers and hands.
Do not attempt to sit or stand on top
of your appliance as it is not designed
for such use. You could injure yourself
or damage the appliance.
“IMPORTANT: Make sure that
mains cable is not caught under the
appliance during and after carrying
/ moving the appliance, to avoid
the mains cable becoming cut or
damaged.”
Do not allow children to play with the
appliance or tamper with the controls.
BEKO declines to accept any liability
should the instructions not be
followed.
INSTALLATION
INSTRUCTIONS
1. The space in the room where the
appliance is installed must not be
smaller than 10 cubic metres.
2. This appliance is equipped with
'Freezer Guard' which ensures that
at the advised setting [4 - four on
the control] the frozen food in the
freezer will not defrost even if the
ambient temperature falls as low as
-15 °C. So you may then install your
appliance in a garage or an unheated
room without having to worry about
frozen food in the freezer being spoilt.
However at low ambient temperatures
mentioned above, fridge contents are
3Installation

EN
9
likely to freeze, so check and consume
food in the fridge accordingly. When
the ambient temperature returns to
normal, you may change the control
setting to suit your needs.
3. Do not place the appliance near
cookers, radiators or in direct sunlight
as this will cause your appliance to
work harder. If installed next to a
source of heat or freezer, maintain the
following minimum side clearances:
From Cookers 50 mm (2”)
From Radiators 300 mm (12”)
From Freezers 25 mm (1”)
4. Make sure that sufficient room is
provided around the appliance to
ensure free air circulation. Fit the two
plastic wall spacers supplied with the
appliance to the condenser on the
back of the appliance by rotating 1/4
turn.
(See Diagram).
5. The fridge/freezer should be located
on a smooth surface. The two front
feet can be adjusted as required. To
ensure that your appliance is standing
upright adjust the two front feet by
turning clockwise or anti-clockwise,
until the product is in firm contact with
the floor. Correct adjustment of feet
avoids excessive vibration and noise.
6. Refer to cleaning and care section
to prepare your appliance for use.
7. A special receptacle is supplied to
store the mains plug during transit.
The receptacle is fixed at the back
of the cabinet, on the side of the
compressor. (See diagram) Gently
remove the plug from the receptacle.
Never pull the mains cord, you may
damage the appliance. In the case
of transportation, ensure you locate
the plug in the receptacle provided to
avoid transit damage.

EN
10
REPLACING THE INTERIOR
LIGHT BULB
Should the light fail to work, proceed
as follows.
1. Switch off at the socket outlet and
pull out the mains plug.
• You may find it useful to remove
shelves for easy access.
2. Use a flat tipped screwdriver to
remove the light diffuser cover by
inserting the blade in each of the two
recesses to prise off each side.
3. First check that the bulb hasn’t
worked loose by ensuring it is screwed
securely in the holder. Replace the
plug and switch on. If the bulb works,
replace the light cover by inserting the
rear lug and pushing up to locate the
front two lugs.
4. If the light still fails to work, switch
off at the socket outlet and pull out
the mains plug. Replace the bulb with
a new 15 watt (max) screw cap (SES)
bulb.
5. Carefully dispose of the burnt-out
light bulb immediately. Replacement
light bulbs can be obtained from a
good local electrical or DIY store.

EN
11
Reversing The Doors
We recommend that you reverse doors
before fitting the handles and switching
on for the first time.
Tools required: Small and
medium size flat and cross-headed
screwdrivers, a pair of pliers.
Spare Parts supplied in the plastic
bag: The following parts, which are
exclusively for left hand side fitted
hinge operation are supplied in a
plastic bag with the appliance:
- Upper door top trim hinge covers –
there are 2 different parts, one for each
side of top trim.
- Upper door middle hinge bushing/
door stopper assembly.
We suggest you keep all the parts
supplied in the plastic bag and also
parts, which have been removed when
reversing doors, in a safe place for
possible future, re-use.
IMPORTANT: We suggest you ask
somebody to help you when moving
the appliance around and to hold
doors when removing / re-fitting
hinges and doors to avoid any injury
and damage to the product.
Please refer to diagrams supplied. To
follow numbers in brackets below,
refer to the main diagram.
1.Switch off the appliance at the
socket outlet and pull out the mains
plug.
2.Remove all loose items and fittings
and food, if any, from inside the
appliance and door racks.
3.Gently prise off plastic hinge covers
on both sides of upper door top trim
and front top panel using a small flat-
headed screwdriver. (1)
4.Gently tilt the appliance back
against a strong wall on its rear side
sufficiently to allow the lower hinge
to be removed. Take care to protect
the appliance, your wall and floor
coverings. You can utilise the original
packaging to do this. Once you tilt the
appliance back, check to make sure
the appliance is completely stable and
safe before you carry on. (2)
5.Unscrew and remove the lower hinge
using a cross-headed screwdriver
while holding the lower door firmly.(3)
6.Remove lower door carefully off the
middle hinge and stand door upright in
a safe place.(4)
7.Open upper door and unscrew and
remove the middle hinge while holding
the upper door firmly. Use a flat-
headed screwdriver. Middle hinge will
need to be rotated 180 degrees before
re-fitting on the opposite side.(5)
8.Remove upper door carefully off the
upper hinge and stand door upright in
a safe place.(6)
9.Unscrew and remove the upper
hinge using a flat-headed screwdriver.
(7)
10.Rotate the upper hinge 180
degrees and then unscrew and
remove the hinge pin using a pair of
pliers and re-fit to opposite side of
hinge.(8)
11.Reposition plugs and hinge pin
bushings on top of doors on the
opposite side of both doors. Use small
flat-headed screwdrivers to remove
plugs and bushings. Take care not to
mark doors.(9)

EN
12
12.Reposition left hand side feet
on the opposite side. Unscrew and
reposition the bottom hinge bushing.
(10)
13.Unscrew and remove the upper
door middle hinge pin bushing/
door stopper using a cross-headed
screwdriver. Important: This part
cannot be used on the opposite
side; left hand side middle hinge pin
bushing/door stopper part is supplied
in the plastic bag.(11)
14.Re-fit the upper hinge on the
left hand side using flat-headed
screwdriver.(12)
15.Fit upper door left hand side middle
hinge pin bushing/door stopper
supplied in the plastic bag using cross-
headed screwdriver.(13)
16.Reposition three small plastic
plugs on the left hand side, which
are covering middle hinge holes, on
the opposite side to cover holes left
empty.(14)
17.Locate and re-fit upper door to
upper hinge and hold the door firmly.
(15)
18.Locate the middle hinge pin to
middle hinge pin bushing of upper
door on the left hand side and re-fit the
middle hinge.(16)
19.Reposition the two screws fitted to
lower hinge holes on the left hand side
at the bottom of the cabinet on the
opposite side.(17)
20.Locate and re-fit lower door to
middle hinge pin and then re-fit the
lower hinge on the left hand side.(18),
(19)
21.Carefully stand the appliance
upright and adjust the two front feet if
necessary.
22.Check that doors open and close
easily, they are aligned correctly and
that there are no gaps allowing air into
the cabinet. If there are gaps between
the door seal and the cabinet, adjust
the door seal by gently pulling away
from the door using fingers.
23.Check that all the hinge screws are
tightened. Avoid over tightening the
screws.
24.Put all items, fittings back in the
appliance.
25.Fit upper door top trim and front
top panel plastic hinge covers.
Upper door top trim hinge covers are
supplied in the plastic bag.(20)
26.Fit the door handle to the opposite
side of the door and tighten the bolts.
(21).
27.Wait for at least 4 hours to allow the
system to settle before switching on.
28.Once the correct storage
temperatures have been reached in
the appliance, put back all the food.

EN
13
Reversing the doors
Proceed in numerical order .
1
17
1
20
11
13 9
2
10
5
3
20
20
8
18
17
19
14
12
16
21
21
45°
180°
(8) (13)
6
4
15

EN
14
4Before operating
Final Check
Before you start using the fridge/
freezer check that:
1. The feet have been adjusted for
perfect levelling.
2. The interior is dry and air can
circulate freely at the rear of the
cabinet.
3. Clean the interior as recommended
under “CLEANING AND CARE.”
4. Insert the plug into the wall socket
and switch on the electricity supply.
• When the door is open the fridge
interior light will come on.
5. You will hear a noise as the
compressor starts up. The liquid and
gases sealed within the refrigeration
system may also give rise to noise,
whether the compressor is running or
not which is quite normal.
“Due to operation of the fan inside
the frost free freezer compartment,
overall noise level is slightly higher
in comparison to non-frost free
appliances. This is quite normal and is
not a fault.”
6. Set the thermostat control half way
between 1 and 5.
7. Front edges of the cabinet may feel
warm. This is normal. These areas
are designed to be warm to avoid
condensation.
8. “Do not load the appliance
immediately it is switched on. Wait
until the correct storage temperature
has been reached. We recommend
that you check the temperature
with an accurate thermometer
see “(Temperature Control and
Adjustment)”
9. When the freezer reaches the
desired temperature the freezer fan will
stop. When the freezer fan is on, the
noise will be louder when the freezer
door is opened.
10. Avoid spillage of food particularly
small items like rice, peas, beans
through the fan guard as they may
cause the cooling system to block and
therefore operate less efficiently.

EN
15
5Using your refrigerator
TEMPERATURE CONTROL
AND ADJUSTMENT
Operating temperatures are controlled
by the thermostat control (see
diagram) located on the ceiling of the
fridge compartment. Settings may be
made from 1 to 5, 5 being the coldest
position.
When the appliance is switched
on for the first time, the thermostat
should be adjusted so that after 24
hours, the average fridge temperature
is no higher than +5°C (+41°F). We
recommend you set the thermostat
half way between the 1 and 5 setting
and monitor to obtain the desired
temperature i. e. towards 5 you will
obtain a colder fridge temperature and
vice versa. Some sections of the fridge
may be cooler or warmer ( such as the
salad crisper and the top part of the
cabinet ) which is quite normal.
The normal storage temperature of the
freezer should be -18°C (0°F). Lower
temperatures may be obtained by
adjusting thermostat knob towards 5
position.
We recommend that you check
the temperature with an accurate
thermometer to ensure that the
storage compartments are kept to the
desired temperature.
Remember you must take your reading
very quickly since the thermometer
temperature will rise very rapidly after
you remove it from the appliance.
Please remember each time the door
is opened cold air escapes and the
internal temperature rises. Therefore
never leave the door open and ensure
it is closed immediately after food is
put in or removed.
In case of a temporary ice build up in
the fridge compartment, reduce the
thermostat setting to 1, monitoring
at the same time that the fridge
temperature is maximum +5 degrees
C [41 degrees F]. Once the ice build
up disappears and the appliance
starts auto defrosting again as normal,
then you may increase the thermostat
setting, if required.

EN
16
SUGGESTED
ARRANGEMENT OF FOOD
IN THE FRIDGE/FREEZER
2
310
7
9
8
1
4
6
5
5
Arrangement Examples (See diagram)
1. Baked, chilled cooked food, dairy
products, cans.
2. Meat, sausages, cold cuts.
3. Fruit, vegetables, salads.
4. Making, storing ice cubes.
5. Frozen food.
6. Frozen food and freezing of fresh
food.
7. Butter, cheese.
8. Small bottles, cans, tubes.
9. Eggs.
10. Tall/large bottles.
The following guidelines and
recommendations are suggested to
obtain the best results and storage
hygiene.
1. The fridge compartment is for the
short term storage of fresh food and
drinks.
2. The freezer compartment is
rated and suitable for the freezing
of fresh food the and storage of pre
frozen food. The recommendation for
storage as stated on the food
packaging should be observed at all
times.
3. Cooked dishes must be stored in
airtight covered containers.
4. Fresh wrapped produce can be
placed on the shelf. Fresh fruit and
vegetables should be cleaned and
stored in the crisper bins.
5. Bottles can be placed in the door
section.
6. To store raw meat, wrap in
polythene bags and place on the
lowest shelf. Do not allow to come
into contact with cooked food to avoid
contamination. For safety, only store
raw meat for two to three days.
7. Keep the food packed wrapped
or covered. Allow hot food and
beverages to cool before placing them
in the fridge. Do not store explosive
substances. High proof alcohol must
be stored upright in sealed containers.
Left over canned food should not be
stored in the can.
8. Fizzy drinks should not be frozen
and products such as flavoured water
ices should not be consumed too cold.
9. Some fruit and vegetables suffer
damage if kept at temperatures near

EN
17
0°C. Therefore wrap pineapples,
melons, cucumbers, tomatoes and
similar produce in polythene bags.
10. Place chilled cooked food and
similar food near the rear of the fridge
inner liner where the cold wall is
located.
11. Shelves, racks, crisper bins,
drawers, flaps, bottle grippers are all
removable.
12. Do not leave frozen food at room
temperature to thaw; the best way to
defrost food is to put it in the fridge
to thaw slowly. Make sure you avoid
defrosting food or food juices drip onto
other food.
13. For hygiene reasons, always
wrap food using a suitable packaging
material before storing in your
appliance to avoid contact with the
appliance surface.
STORING FROZEN FOOD
Prepacked commercially frozen food
should be stored in accordance
with the frozen food manufacturer’s
instructions for a frozen food
storage compartment.
To ensure that the high quality chieved
by the frozen food manufacturer and
the food retailer is maintained, the
following should be remembered:
1. Put packets in the freezer as quickly
as possible after purchase.
2. Ensure that contents are labelled
and dated.
3. Do not exceed “Use By”, “Best
Before” dates on the packaging.
If there is a power failure do not open
the door. Frozen food should not be
affected if the failure lasts for less than
18 hrs. If the failure is longer, then the
food should be checked and either
eaten immediately or cooked and then
re-frozen.
FREEZING FRESH FOOD
Please observe the following
instructions to obtain the best results.
Do not freeze too large a quantity
max/kg at any one time max 6 kg/
24 hours. The quality of the food is
best preserved when it is frozen right
through to the core as quickly as
possible.
Placing warm food into the freezer
compartment causes the refrigeration
compressor to operate continuously
until the food is frozen solid. This can
temporarily lead to excessive cooling
of the refrigeration compartment.
When freezing fresh food turn the
setting control toward. Max small
quantities of food up to 1/2 kg. (1 lb)
can be frozen without having to rotate
the temperature control knob.
You may place fresh food to be frozen
in any part of the freezer.
Take special care not to mix already
frozen food and fresh food.

EN
18
12
MAKING ICE CUBES
Fill the ice - cube tray 3/4 full with
water and place it in the Ice Bank.
Loosen frozen trays with the handle
of a spoon, never use sharp edged
objects such as knives, forks. Store
ice-cubes in the Ice Bank.
Note: If freshly made ice cubes are
not consumed for several weeks
and stored in Ice Bank, they will
slowly reduce in size and eventually
disappear completely.
DEFROSTING
A) FRIDGE COMPARTMENT
The fridge compartment defrosts
automatically. The defrosting water
runs to the drain tube via a collection
container at the back of the appliance
(1).(see diagram) During defrosting
water droplets may form at the back of
the fridge compartment
where concealed evaporator is
located.Some droplets may remain on
the liner and refreeze when defrosting
is completed. Do not use pointed or
sharp edged objects such as knives,
forks to remove the droplets which
have frozen.
If at any time the defrost water does
not drain from the collection channel,
check to ensure that no food particles
have blocked the drain tube. The drain
tube can be cleared by pushing the
special plastic plunger provided down
the drain tube (2). If the frost layer
reaches about 1/4”(7 mm), reduce
the setting (i.e. from 4 to 1) to restart
automatic defrosting.
B) FREEZER COMPARTMENT
The freezer compartment defrosts
automatically.
Warnings!
The fan inside the freezer compartment
circulates cold air. Never insert
any object through the guard. Do not
allow children to play with
the freezer fan.
Never store products that contain
inflammable propellant gas
(eg dispensers, spray cans etc.) or
explosive substances.
Don’t cover the shelves with any
protective materials, which may
obstruct air circulation.
Do not allow children to play with the
appliance or tamper with the controls.
Do not obstruct the freezer fan guard
to ensure that you obtain the best
possible performance from your
appliance.

EN
19
6Maintenance and cleaning
** We recommend that you switch
off the appliance at the socket outlet
and pull out the mains plug before
cleaning.
** Never use any sharp abrasive
instrument, soap, household cleaner,
detergent and wax polish for cleaning.
** Use luke warm water to clean the
cabinet of the appliance and wipe it
dry.
** Use a damp cloth wrung out
in a solution of one teaspoon of
bicarbonate of soda to one pint of
water to clean the interior and wipe it
dry.
** Make sure that no water enters the
lamp housing.
** If the appliance is not going to be
used for a long period of time switch it
off, remove all food, clean it and leave
the door ajar.
** Any dust that gathers on the
condenser, which is located at the
back of the appliance, should be
removed once a year with a vacuum
cleaner.
** Check door seals regularly to ensure
they are clean and free from food
particles.
** Removal of door rack
• To remove door racks, remove
all the contents and then simply push
the door rack upwards from the base.
** To remove a freezer drawer, pull
it as far as possible, and then tilt
it upwards, and then pull it out
completely.
** To remove the freezer flap door, first
open the door 3” and then gently pull it
off. Make sure that the flap is in place
before closing the freezer door.
** Make sure that the special plastic
container (drain tray) at the back of the
appliance which collects defrost water
is clean at all times.
** Avoid spillage of food particularly
small items like rice, peas, beans
through the fan guard as they may
cause the cooling system to block and
therefore operate less efficiently.

EN
20
7Do’s and Don’ts
Do- Clean your appliance regularly
(See “Cleaning and Care”)
Do- Keep raw meat and poultry below
cooked food and dairy products.
Do- Take off any unusable leaves on
vegetables and wipe off any soil.
Do- Leave lettuce, cabbage, parsley
and cauliflower on the stem.
Do- Wrap cheese firstly in greaseproof
paper and then in a polythene bag
excluding as much air as possible.
For best results take out of the
fridge compartment an hour before
eating.
Do- Wrap raw meat and poultry
loosely in polythene or aluminium
foil. This prevents drying.
Do- Wrap fish and offal in polythene
bags.
Do- Wrap food which have a strong
odour or can dry out in polythene
bags, aluminium foil or place in an
airtight container.
Do- Wrap bread well to keep it fresh.
Do- Chill white wines, beer, lager and
mineral water before serving.
Do- Check contents of the freezer
every so often.
Do- Keep food for as short a time
as possible and adhere to “Best
Before”, “Use by” etc. dates.
Do- Store commercially frozen food in
accordance with the instructions
given on the packets that you buy.
Do- Always choose high quality fresh
food and be sure it is thoroughly
clean before you freeze it.
Do- Prepare fresh food for freezing
in small portions to ensure rapid
freezing.
Do- Wrap all food in aluminium foil or
freezer quality polythene bags and
make sure any air is excluded.
Do- Wrap frozen food when you buy it
and put it in to the freezer as soon
as possible.
Do- Defrost food in the fridge
compartment.
Do- Remove ice cream from the
freezer 10-20 minutes before
serving.
Don’t- Store bananas in your fridge
compartment.
Don’t- Store melon in your fridge. It
can be chilled for short periods as
long as it is wrapped to avoid it
flavouring other food.
Don’t- Store poisonous or any
dangerous substances in your
appliance. It has been designed
for the storage of edible foodstuffs
only.
Don’t- Consume food which has been
stored for an excessive time in the
fridge.
Don’t- Store cooked and fresh food
together in the same container.
They should be packaged and
stored seperately.
Don’t- Let defrosting food or food
juices drip onto food.
Don’t- Leave the door open for long
periods as this will make the
appliance more costly to run and
cause excessive ice formation.
Don’t- Put hot food into the appliance.
Let it cool down first.
Don’t- Put liquid-filled bottles or sealed
cans containing carbonated liquids
into the freezer as they may burst.
