Beko DN152003X User manual

DN152003X
RDNE420K20ZX
RDNE455K20ZX
RDNE455K20ZT
RDNE455E30ZX
Refrigerator

Please read ths user manual frst!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked
under the most meticulous quality control procedures, will provide you an effective
service.
Therefore, read this entire user manual carefully before using the product and keep
it as a reference. If you handover the product to someone else, give the user manual
as well.
The user manual wll help you use the product n a fast and safe way.
•Read the manual before nstallng and operatng the product.
•Make sure you read the safety nstructons.
•Keep the manual n an easly accessble place as you may need t later.
•Read the other documents gven wth the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanaton of symbols
Throughout ths user manual the followng symbols are used:
CImportant nformaton or
useful hnts.
ARsk of njury and damage to
the property.
BRsk of electrc shock.
Packagng materals of
the product are manufac-
tured from recyclable ma-
terals n accordance wth
our Natonal Envronment
Regulatons.

2 /35 EN Refrgerator / User Manual
1Safety and environment instructions3
1.1. General safety . . . . . . . . . . . . . . . . . . . 3
1.1.1 HC warning . . . . . . . . . . . . . . . . . . . . . . 5
1.1.2 For models with water fountain 5
1.2. Intended use. . . . . . . . . . . . . . . . . . . . . 6
1.3. Child safety . . . . . . . . . . . . . . . . . . . . . . 6
1.4. Compliance with WEEE Directive and
Disposing of the Waste Product. 6
1.5. Compliance with RoHS Directive 7
1.6. Package information . . . . . . . . . . . . 7
2Your appliance 8
3Installation 9
3.1. Appropriate installation location 9
3.2. Installing the plastic wedges. . . . 9
3.3. Adjusting the feet . . . . . . . . . . . . . .10
3.4. Electrical connection . . . . . . . . . . .10
3.5. Reversing the doors . . . . . . . . . . . . 11
3.6. Reversing the doors . . . . . . . . . . . . 12
4Preparation 13
4.1. Things to be done for energy
saving. . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2. Initial use . . . . . . . . . . . . . . . . . . . . . . . 13
5Operating the product 14
5.1. Temperature setting button . . . 14
5.2. Fast freeze . . . . . . . . . . . . . . . . . . . . . 14
5.3. Vacation function . . . . . . . . . . . . . . 15
5.4. Indicator panel. . . . . . . . . . . . . . . . . .16
5.5. Twist Ice – matic . . . . . . . . . . . . . . .22
5.6. Ice container . . . . . . . . . . . . . . . . . . . .22
5.7. Egg holder . . . . . . . . . . . . . . . . . . . . . .23
5.8. Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
5.9. Crisper . . . . . . . . . . . . . . . . . . . . . . . . . .23
5.10.Chiller compartment . . . . . . . . . . .23
5.11.Moving door shelf . . . . . . . . . . . . . .24
5.12 Sliding storage container . . . . . .24
5.13.Blue light . . . . . . . . . . . . . . . . . . . . . . .24
5.14.Humidity controlled crisper . . . .25
5.15.Auto Icematic . . . . . . . . . . . . . . . . . .25
5.16.Description and cleaning of odor
filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
5.17.Freezing fresh food. . . . . . . . . . . . .27
5.18.Recommendations for preserving
the frozen food . . . . . . . . . . . . . . . . .28
5.19.Deep-freeze information . . . . . .28
5.20.Placing the food. . . . . . . . . . . . . . . .29
5.21.Door open warning. . . . . . . . . . . . .30
5.22.Changing the door opening
direction . . . . . . . . . . . . . . . . . . . . . . . .30
5.23.Illumination lamp. . . . . . . . . . . . . . .30
6 Maintenance and cleaning 31
6.1. Avoiding bad odors . . . . . . . . . . . . . 31
6.2. Protecting the plastic surfaces 31
6.3. Door Glasses . . . . . . . . . . . . . . . . . . . 31
7Troubleshooting 33
Contents

3/35 EN
Refrgerator / User Manual
This section provides
the safety instructions
necessary to prevent the
risk of injury and material
damage. Failure to observe
these instructions will
invalidate all types of
product warranty.
1.1. General safety
• Ths product should
not be used by
persons wth physcal,
sensory and mental
dsabltes, wthout
suffcent knowledge
and experence or by
chldren. The devce
can only be used by
such persons under
supervson and
nstructon of a person
responsble for ther
safety. Chldren should
not be allowed to play
wth ths devce.
• In case of malfuncton,
unplug the devce.
• After unpluggng, wat
at least 5 mnutes before
pluggng n agan.
• Unplug the product
when not n use.
• Do not touch the plug
wth wet hands! Do not
pull the cable to plug off,
always hold the plug.
• Wpe the power plug’s tp
wth a dry cloth before
pluggng n.
• Do not plug n the
refrgerator f the socket
s loose.
• Unplug the product
durng nstallaton,
mantenance, cleanng
and repar.
• If the product wll not be
used for a whle, unplug
the product and remove
any food nsde.
• Do not use the product
when the compartment
wth crcut cards located
on the upper back part
of the product (electrcal
card box cover) (1) s
open.
1Safety and environment instructions

Instructons for safety and envronment
4 / 35 EN Refrgerator / User Manual
• Do not use steam or
steamed cleanng
materals for cleanng
the refrgerator and
meltng the ce nsde.
Steam may contact the
electrfed areas and
cause short crcut or
electrc shock!
• Do not wash the
product by sprayng
or pourng water on
t! Danger of electrc
shock!
• In case of malfuncton,
do not use the product,
as t may cause electrc
shock. Contact the
authorzed servce
before dong anythng.
• Plug the product nto
an earthed socket.
Earthng must be
done by a qualfed
electrcan.
• If the product has LED
type lghtng, contact
the authorzed servce
for replacng or n case
of any problem.
• Do not touch frozen
food wth wet hands!
It may adhere to your
hands!
• Do not place lquds
n bottles and cans
nto the freezer
compartment. They
may burst out!
• Place lquds n uprght
poston after tghtly
closng the ld.
• Do not spray
flammable substances
near the product, as t
may burn or explode.
• Do not keep flammable
materals and products
wth flammable gas
(sprays, etc.) n the
refrgerator.
• Do not place contaners
holdng lquds on
top of the product.
Splashng water on an
electrfed part may
cause electrc shock
and rsk of fre.

Instructons for safety and envronment
5/35 EN
Refrgerator / User Manual
• Exposng the product
to ran, snow, sunlght
and wnd wll cause
electrcal danger. When
relocatng the product,
do not pull by holdng
the door handle. The
handle may come off.
• Take care to avod
trappng any part of
your hands or body
n any of the movng
parts nsde the
product.
• Do not step or lean on
the door, drawers and
smlar parts of the
refrgerator. Ths wll
cause the product to
fall down and cause
damage to the parts.
• Take care not to trap
the power cable.
1.1.1 HC warning
If the product
comprses a coolng
system usng R600a
gas, take care to
avod damagng the
coolng system and
ts ppe whle usng
and movng the
product. Ths gas
s flammable. If the
coolng system s
damaged, keep the
product away from
sources of fre and
ventlate the room
mmedately.
C
The label on the
nner left sde
ndcates the type
of gas used n the
product.
1.1.2 For models
with water
fountain
• In order for the water
system nsde the
refrgerator to operate
properly, pressure n
the water mans must
be between 1-8 bars.

Instructons for safety and envronment
6 / 35 EN Refrgerator / User Manual
A pressure regulator
must be used f the
pressure n the water
mans s hgher than 5
bars. If the pressure n
the mans s hgher than
8 bars, the refrgerator
must not be connected
to the mans. If you
are not sure about
how to measure the
water pressure, ask for
professonal help.
• Use drnkng water only.
1.2. Intended use
• Ths product s desgned
for home use. It s not
ntended for commercal
use.
• The product should be
used to store food and
beverages only.
• Do not keep senstve
products requrng
controlled temperatures
(vaccnes, heat
senstve medcaton,
medcal supples, etc.) n
the refrgerator.
• The manufacturer
assumes no
responsblty for any
damage due to msuse
or mshandlng.
• The product’s bench
lfe s 10 years. The
spare parts necessary
for the product to
functon wll be
avalable for ths
perod.
1.3. Child safety
• Keep packagng
materals out of
chldren’s reach.
• Do not allow the
chldren to play wth
the product.
• If the product’s door
comprses a lock,
keep the key out of
chldren’s reach.
1.4. Compliance
with WEEE Directive
and Disposing of
the Waste Product
Ths product comples wth EU
WEEE Drectve (2012/19/EU).
Ths product bears a classfcaton
symbol for waste electrcal and
electronc equpment (WEEE).

Instructons for safety and envronment
7/35 EN
Refrgerator / User Manual
Ths product has been
manufactured wth hgh
qualty parts and materals
whch can be reused and
are sutable for recyclng.
Do not dspose of the
waste product wth normal
domestc and other wastes at the
end of ts servce lfe. Take t to the
collecton center for the recyclng of
electrcal and electronc equpment.
Please consult your local authortes
to learn about these collecton
centers.
1.5.Compliance with
RoHS Directive
• Ths product comples wth EU
WEEE Drectve (2011/65/EU).
It does not contan harmful and
prohbted materals specfed n
the Drectve.
1.6.Package
information
• Packagng materals of the product
are manufactured from recyclable
materals n accordance wth our
Natonal Envronment Regulatons.
Do not dspose of the packagng
materals together wth the
domestc or other wastes. Take
them to the packagng materal
collecton ponts desgnated by the
local authortes.

8 /35 EN Refrgerator / User Manual
1. Frdge - compartment
door shelf
2. Temperature settng
button
3. Freezer compartment
door shelf
4. Storage contaner under
the door shelf
5. Movng door shelf
6. Adjustable feet
7. Crsper
8. Chller compartment
9. Lock and key
10. Bottle shelf
11. Frdge - compartment
glass shelf
12. Fan
13. Freezer compartment
shelf
14. Icebox / Ice-makng
compartment
15. Freezer compartment
16. Frdge compartment
2Your applance
C*optional:Fgures n ths user manual are gven as an example and may not
match the product exactly. If the relevant parts are not avalable n the product you
purchased, the fgure apples to other models.
*1
*3
*4
*2
*5
6
*7
*8
*9
*10
*11
12
12
15
16
*13
*14
*14
6

9/35 EN
Refrgerator / User Manual
3Installaton
3.1.Appropriate
installation location
Contact an Authorized Service for the
installation of the product. In order to
prepare the product for use, refer the
information in the user manual and
ensure that electrical installation and
water installation are appropriate. If not,
call a qualified electrician and technician
to have any necessary arrangements
carried out.
BWARNING: Manufacturer shall
not be held lable for damages that
may arse from procedures carred
out by unauthorzed persons.
BWARNING: Product must not
be plugged n durng nstallaton.
Otherwse, there s the rsk of
death or serous njury!
A
WARNING: If the door clearance
of the room where the product
shall be place s so tght to prevent
passng of the product, remove
the door of the room and pass
the product through the door by
turnng t to ts sde; f ths does
not work, contact the authorzed
servce.
•Placetheproductonanevenfloor
surface to prevent jolts.
•Installtheproductatleast30cm
away from heat sources such as hobs,
heater cores and stoves and at least 5
cm away from electrcal ovens.
•Productmustnotbesubjectedto
drect sun lght and kept n humd
places.
•Appropriateairventilationmustbe
provded around your product n order
to acheve an effcent operaton. If the
product s to be placed n a recess n
the wall, pay attenton to leave at least
5 cm dstance wth the celng and sde
walls.
•Donotinstalltheproductinplaces
where the temperature falls below
-5°C.
3.2.Installing the
plastic wedges
Plastc wedges suppled wth the
product are used to create the
dstance for the ar crculaton
between the product and the rear
wall.
1. To nstall the wedges, remove the
screws on the product and use the
screws suppled together wth the
wedges.
2. Insert the 2 plastc wedges onto the
rear ventlaton cover as llustrated n
the fgure.

Installation
10 / 35 EN Refrgerator / User Manual
3.3.Adjusting the feet
If the product stands
unbalanced after nstallaton,
adjust the feet on the front by
rotatng them to the rght or
left.
3.4. Electrical
connection
AWARNING: Do not make
connectons va extenson
cables or mult-plugs.
BWARNING: Damaged power
cable must be replaced by the
Authorzed Servce Agent.
CIf two coolers are to be
nstalled sde by sde, there
should be at least 4 cm
dstance between them.
• Our company shall not be lable
for any damages that wll arse
when the product s used
wthout groundng and electrcal
connecton n accordance wth the
natonal regulatons.
• Power cable plug must be wthn
easy reach after nstallaton.
• Connect your refrgerator to a
grounded outlet rated for a voltage
value of 220-240V /50 Hz. Outlet
shall have 10 to 16A fuse.
• Do not extenson cords or cordless
multple outlets between your
product and the wall outlet.

Installation
11 / 35 EN
Refrgerator / User Manual
3.5.Reversing the doors
Proceed in numerical order .
10
10
5
4
1
6
4
12 13
3
7
89
14
19
19
22
17
180°
23
21
16
15
24
24
11
45°
2
20
18

Installation
12 / 35 EN Refrgerator / User Manual
3.6. Reversing the doors
Proceed in numerical order .
10
10
5
4
1
6
4
12 13
3
7
89
14
19
19
22
17
180°
23
21
16
15
2
20
11
45°
18

13/35 EN
Refrgerator / User Manual
4.1. Things to be done
for energy saving
AConnectng the product to electrc
energy savng systems s rsky
as t may cause damage on the
product.
• Do not leave the doors of your
refrgerator open for a long tme.
• Do not put hot food or drnks n your
refrgerator.
• Do not overload the refrgerator,
coolng capacty wll fall when the ar
crculaton nsde s hndered.
• In order to store maxmum amount
of food n the freezer compartment,
the cematc, avalable n the freezer
compartment and easly removable by
hand, shall be taken out. Net volume
and energy consumpton values
declared on the power data plate of
your refrgerator are measured and
tested by removng the cematc. Do
not remove the shelves nsde the
freezer compartment and on the door
of freezer compartment shall not be
removed and they shall always be
used they provde ease of use and
effcency n energy consumpton.
• Arflow should not be blocked by
placng foods on the sdes of the
freezer compartment fan. A mnmum
dstance of 3 cm shall be provded on
the sdes of protectve fan cover.
• The baskets/drawers that are
provded wth the chll compartment
must always be n use for low energy
consumpton and for better storage
condtons.
• Food contact wth the temperature
sensor n the freezer compartment
may ncrease energy consumpton of
the applance. Thus any contact wth
the sensor(s) must be avoded.
• Dependng on the features of your
product, thawng frozen food n
frdge compartment wll both provde
energy savng and preserve the food
qualty.
4Preparaton
• Do not allow contact of the food wth
the frdge compartment temperature
sensor shown n the fgure below.
4.2. Initial use
Before startng to use your
refrgerator, ensure that all
preparatons are made n
accordance wth the nstructons
n sectons "Instructons for
safety and envronment" and
"Installaton".
• Run the product wthout puttng any
food for 6 hours and do not open ts
door unless certanly requred.
CYou wll hear a nose when the
compressor starts up. The lquds
and gases sealed wthn the
refrgeraton system may also
gve rse to nose, even f the
compressor s not runnng and ths
s qute normal.
CFront edges of the product may
feel warm. Ths s normal. These
areas are desgned to be warm to
avod condensaton.
CIn some models, the nstrument
panel automatcally turns off
5 mnutes after the door has
closed. It wll be reactvated when
the door has opened or pressed
on any key.

14 /35 EN Refrgerator / User Manual
5Operating the product
5.1.Temperature
setting button
The nteror temperature of your
refrgerator changes for the followng
reasons;
•Seasonal temperatures,
•Frequent openng of the door and
leavng the door open for long perods,
•Food put nto the refrgerator
wthout coolng down to the room
temperature,
•The locaton of the refrgerator n the
room (e.g. exposng to sunlght).
•You may adjust the varyng nteror
temperature due to such reasons by
usng the settng button.
The numbers around the control knob
ndcate the temperature values n “°C”.
If the ambent temperature s 25°C, we
recommend you to use the temperature
control knob of your refrgerator at 4°C. Ths
value may be ncreased or decreased as
requred n other ambent temperatures.
5.2.Fast freeze
If large amounts of fresh food are going
to be frozen, adjust the temperature
control knob to ( ) max. 24 hours
before putting the fresh food in the fast
freeze compartment.
It is strongly recommended to keep the
knob at this position at least 24 hours
to freeze maximum amount of fresh
food declared as freezing capacity. Take
special care not to mix frozen food and
fresh food.
Remember to turn the temperature
control knob back to its previous position
once food has frozen.

Operating the product
15/35 EN
Refrgerator / User Manual
5.3.Vacation function
If the doors of the product are
not opened for 12 hours after the
temperature control knob is switched
to the hottest position, then the
vacation function will be activated
automatically.
To cancel the function, change the
knob setting.
It is not recommended to store food
in cooler compartment when the
vacation function is active.
•When the settng operaton s
completed, you may press the
temperature control knob and have
t hdden.

Operating the product
16 /35 EN Refrgerator / User Manual
C*Optonal: Figures in this user manual are schematic and may not match
the product exactly. If the subject parts are not included in the product you
have purchased, then those parts are valid for other models.
5.4. Indicator panel
Indicator panel allows you to set the temperature and control the
other functions related to the product without opening the door of the
product. Just press the inscriptions on relevant buttons for function
settings.
1. Power falure/Hgh temperature /
error warnng ndcator
This indicator ( ) illuminates during
power failure, high temperature
failures and error warnings. During
sustained power failures, the
highest temperature that the freezer
compartment reaches will flash on the
digital display. After checking the food
located in the freezer compartment (
) press the alarm off button to clear the
warning.
Please refer to "remedies advised
for troubleshooting" section on
your manual if you observe that this
indicator is illuminated.
2. Energy savng functon (dsplay
off):
If the product doors are kept closed
for a long time energy saving
function is automatically activated
and energy saving symbol is
illuminated. ( )
When energy saving function is
activated, all symbols on the display
other than energy saving symbol will
turn off. When the Energy Saving
function is activated, if any button
is pressed or the door is opened,
energy saving function will be
canceled and the symbols on display
will return to normal.
1 2
3
45
6
789
10
12
11

Operating the product
17/35 EN
Refrgerator / User Manual
Energy saving function is activated
during delivery from factory and
cannot be canceled.
3.Quck frdge functon
The button has two functons.
To actvate or deactvate the
quck cool functon press t
brefly. Quck Cool ndcator wll
turn off and the product wll
return to ts normal settngs. (
)
CUse quck coolng functon
when you want to quckly cool
the food placed n the frdge
compartment. If you want to
cool large amounts of fresh
food, actvate ths functon
before puttng the food nto
the product.
CIf you do not cancel t, quck
coolng wll cancel tself
automatcally after 8 hours or
when the frdge compartment
reaches to the requred
temperature.
CIf you press the quck coolng
button repeatedly wth short
ntervals, the electronc crcut
protecton wll be actvated
and the compressor wll not
start up mmedately.
CThs functon s not recalled
when power restores after a
power falure.
4. Frdge compartment
temperature settng button
Press this button to set the
temperature of the fridge
compartment to 8, 7,6, 5,4,3, 2, 8...
respectively. Press this button to set
the fridge compartment temperature
to the desired value. ( )
5.Vacation Function
In order to activate vacation function,
press the this button ( ) for 3
seconds, and the vacation mode
indicator ( ) will be activated. When
the vacation function is activated,
“- -” is displayed on the fridge
compartment temperature indicator
and no active cooling is performed
on the fridge compartment. It is not
suitable to keep the food in the fridge
compartment when this function is
activated. Other compartments shall
be continued to be cooled as per their
set temperature.
To cancel this function press Vacation
function button again.
6. Alarm off warnng:
In case of power failure/high
temperature alarm, after checking
the food located in the freezer
compartment press the alarm off
button ( ) to clear the warning.
7. Key lock
Press key lock button ( )
simultaneously for 3 seconds. Key
lock symbol
( ) will light up and key lock mode
will be activated. Buttons will
not function if the Key lock mode
is active. Press key lock button
simultaneously for 3 seconds again.
Key lock symbol will turn off and the
key lock mode will be exited.
Press the key lock button if you
want to prevent changing of
the temperature setting of the
refrigerator ( ).

Operating the product
18 /35 EN Refrgerator / User Manual
8. Eco fuzzy
Press and hold eco fuzzy button
for 1 seconds to activate eco fuzzy
function. Refrigerator will start
operating in the most economic
mode at least 6 hours later and the
economic usage indicator will turn
on when the function is active (
). Press and hold eco fuzzy function
button for 3 seconds to deactivate
eco fuzzy function.
This indicator is illuminated after 6
hours when eco fuzzy is activated.
9. Freezer compartment
temperature settng button
Press this button to set the
temperature of the freezer
compartment to -18,-19,-20,-21,
-22, -23,-24, -18... respectively.
Press this button to set the freezer
compartment temperature to the
desired value.( )
10. Icematic off indicator
Indicates whether the icematic is on
or off. ( )If On, then the icematic
is not operating. To operate the
icematic again press and hold the On-
Off button for 3 seconds.
CWater flow from water tank
wll stop when ths functon s
selected. However, ce made
prevously can be taken from
the cematc.
11. Quck freeze functon button/
cematc on-off button
Press this button to activate or
deactivate the quick freezing
function. When you activate the
function, the freezer compartment
will be cooled to a temperature lower
than the set value. ( )
To turn on and off the icematic press
and hold it for 3 seconds.
CUse the quck freeze functon
when you want to quckly
freeze the food placed n frdge
compartment. If you want to
freeze large amounts of fresh
food, actvate ths functon
before puttng the food nto
the product.
CIf you do not cancel t, Quck
Freeze wll cancel tself
automatcally after 4 hours or
when the frdge compartment
reaches to the requred
temperature.
CThs functon s not recalled
when power restores after a
power falure.
12. Economc usage ndcator
Indicates that the product is running
in energy-efficient mode. ( )This
indicator will be active if the Freezer
Compartment temperature is set to
-18 or the energy efficient cooling
is being performed due to Eco-Extra
function.
CEconomc usage ndcator s
turned off when quck coolng
or quck freeze functons are
selected.

Operating the product
19/35 EN
Refrgerator / User Manual
12
457 6 89
10
3
1. Economy
This symbol is illuminated when
the freezer compartment is set to
-18°C'ye as the most economical
setting value ( ). Economy
indicator is turned off when quick
cooling or quick freeze functions are
selected.
2. Hgh temperature / error
warnng ndcator
This indicator ( ) illuminates during
high temperature failures and error
warnings. Please refer to "remedies
advised for troubleshooting" section
on your manual if you observe that
this indicator is illuminated.
C*Optonal: Figures in this user manual are schematic and may not match
the product exactly. If the subject parts are not included in the product you
have purchased, then those parts are valid for other models.
3. Quck cool
Quick cooling indicator ( ) is
illuminated when quick cooling
function is activated and fridge
compartment temperature indicator
value is displayed as 1. To cancel this
function press Quick cooling button
again. Quick cooling indicator will
turn off and refrigerator will return
to its normal settings. Quick cooling
function is canceled automatically in
1 hour if you do not cancel it before.
If you want to cool large amounts of
fresh food, press the Quick cooling
button before putting the food into
the fridge compartment.
