Beko RDNE65X User manual

RDNE500K21S-RDNE500K21W-RDNE550K21W-RDNE550K21S
RDNE610K21T-RDNE600K20X-RDNE480K20W-RDNE500K21SX
RDNE48W-RDNE48SX-RDNE480K20S-RDNE65X-RDNE510M21XP
RDNE55X
EN/FR
57 5789 0000/BA - 1/2 EN-FR
Refrigerator
User Manual
Réfrigérateur
Manuel d’utilisation

Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked
under the most meticulous quality control procedures, will provide you an effective
service.
Therefore, read this entire user manual carefully before using the product and keep
it as a reference. If you handover the product to someone else, give the user manual
as well.
The user manual will help you use the product in a fast and safe way.
Read the manual before installing and operating the product.
Make sure you read the safety instructions.
Keep the manual in an easily accessible place as you may need it later.
Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or
useful hints.
ARisk of injury and damage to
the property.
BRisk of electric shock.
Packaging materials of
the product are manufac-
tured from recyclable ma-
terials in accordance with
our National Environment
Regulations.
RDNE500K21S-RDNE500K21W-RDNE550K21W-RDNE550K21S
RDNE610K21T-RDNE600K20X-RDNE480K20W-RDNE500K21SX
RDNE48W-RDNE48SX-RDNE480K20S-RDNE65X-RDNE510M21XP
RDNE55X

2 /40 EN Refrigerator / User Manual
1. Safety and environment instructions3
1.1. General safety . . . . . . . . . . . . . . . . . . . 3
1.1.1 HC warning . . . . . . . . . . . . . . . . . . . . . . 5
1.1.2 For models with water dispenser5
1.2. Intended use. . . . . . . . . . . . . . . . . . . . . 5
1.3. Child safety . . . . . . . . . . . . . . . . . . . . . . 6
1.4. Compliance with WEEE Directive and
Disposing of the Waste Product. 6
1.5. Compliance with RoHS Directive 6
1.6. Package information . . . . . . . . . . . . 6
2 Your appliance 7
3 Installation 8
3.1. Appropriate installation location 8
3.2. Installing the plastic wedges. . . . 8
3.3. Adjusting the feet . . . . . . . . . . . . . . . 9
3.4. Electrical connection . . . . . . . . . . . . 9
3.5. Reversing the doors . . . . . . . . . . . . 10
3.6. Reversing the doors . . . . . . . . . . . . 11
4 Preparation 12
4.1. Things to be done for energy
saving. . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.2. Initial use . . . . . . . . . . . . . . . . . . . . . . . 12
5 Operating the product 13
5.1. Temperature setting button . . . 13
5.2. Fast freeze . . . . . . . . . . . . . . . . . . . . . 13
5.3. Vacation function . . . . . . . . . . . . . . 14
5.4. Indicator panel. . . . . . . . . . . . . . . . . . 15
5.5. Indicator panel. . . . . . . . . . . . . . . . . . 17
5.6. Twist Ice – matic . . . . . . . . . . . . . . .22
5.7. Ice container . . . . . . . . . . . . . . . . . . . .23
5.8. Egg holder . . . . . . . . . . . . . . . . . . . . . .23
5.9. Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
5.10 Crisper. . . . . . . . . . . . . . . . . . . . . . . . . .23
5.11.Chiller compartment. . . . . . . . . . . .23
5.12.Moving door shelf . . . . . . . . . . . . . .24
5.13.Sliding storage container . . . . . .24
5.14.Blue light . . . . . . . . . . . . . . . . . . . . . . .24
5.15.Humidity controlled crisper . . . .25
5.16.Auto Icematic . . . . . . . . . . . . . . . . . .25
5.17.Description and cleaning of odor
filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
5.18.Using the water dispenser. . . . .27
5.19.Using the water dispenser . . . . .27
5.20.Filling the water dispenser's tank2 8
5.21. Cleaning the water tank . . . . . . .29
5.22.Drip tray . . . . . . . . . . . . . . . . . . . . . . . .30
5.23.HerbBox/HerbFresh . . . . . . . . . . .30
5.24.Freezing fresh food . . . . . . . . . . . . 31
5.25.Recommendations for preserving
the frozen food . . . . . . . . . . . . . . . . .32
5.26.Deep-freeze information . . . . . .32
5.27.Placing the food . . . . . . . . . . . . . . . .32
5.28.Door open warning . . . . . . . . . . . .32
5.29.Changing the door opening
direction . . . . . . . . . . . . . . . . . . . . . . . .32
5.30.Illumination lamp. . . . . . . . . . . . . . .33
5.31. Recommendations for preserving
the frozen food . . . . . . . . . . . . . . . . .33
5.32.Deep-freeze information . . . . . .33
5.33.Placing the food . . . . . . . . . . . . . . . .34
5.34.Door open warning . . . . . . . . . . . .34
5.35.Changing the door opening
direction . . . . . . . . . . . . . . . . . . . . . . . .34
5.36.Illumination lamp. . . . . . . . . . . . . . .34
6 Maintenance and cleaning 35
6.1. Avoiding bad odors . . . . . . . . . . . . .35
6.2. Protecting the plastic surfaces 35
6.3. Door Glasses . . . . . . . . . . . . . . . . . . .35
7Troubleshooting 36
Contents

3/40 EN
Refrigerator / User Manual
This section provides the safety
instructions necessary to prevent
the risk of injury and material
damage. Failure to observe these
instructions will invalidate all
types of product warranty.
Intended use
A
WARNING:
Keep ventilation
openings, in the appliance
enclosure or in the built-
instructure, clear of
obstruction.
A
WARNING:
Do not use mechanical
devices or other means
to accelerate the
defrosting process,
other than those
recommended by the
manufacturer.
AWARNING:
Do not damage the
refrigerant circuit.
A
WARNING:
Do not use electrical
appliances inside
the food storage
compartments of
the appliance, unless
they are of the type
recommended by the
manufacturer.
This appliance is intended to be
used in household and similar
applications such as
– staff kitchen areas in shops,
offices and other working
1. Safety and environment instructions
environments;
– farm houses and by clients
in hotels, motels and other
residential type environments;
– bed and breakfast type
environments;
– catering and similar non-retail
applications.
1.1.General safety
 This product should not be used by
persons with physical, sensory and
mental disabilities, without sufficient
knowledge and experience or by
children. The device can only be used
by such persons under supervision
and instruction of a person responsible
for their safety. Children should not be
allowed to play with this device.
 In case of malfunction, unplug the
device.
 After unplugging, wait at least 5
minutes before plugging in again.
 Unplug the product when not in use.
 Do not touch the plug with wet hands!
Do not pull the cable to plug off, always
hold the plug.
 Do not plug in the refrigerator if the
socket is loose.
 Unplug the product during installation,
maintenance, cleaning and repair.
 If the product will not be used for a
while, unplug the product and remove
any food inside.
 Do not use the product when the
compartment with circuit cards located
on the upper back part of the product
(electrical card box cover) (1) is open.

Instructions for safety and environment
4 / 40 EN Refrigerator / User Manual
1
1
 Do not use steam or steamed
cleaning materials for cleaning
the refrigerator and melting the
ice inside. Steam may contact the
electrified areas and cause short
circuit or electric shock!
 Do not wash the product by spraying
or pouring water on it! Danger of
electric shock!
 In case of malfunction, do not use
the product, as it may cause electric
shock. Contact the authorised
service before doing anything.
 Plug the product into an earthed
socket. Earthing must be done by a
qualified electrician.
 If the product has LED type lighting,
contact the authorised service for
replacing or in case of any problem.
 Do not touch frozen food with wet
hands! It may adhere to your hands!
 Do not place liquids in bottles and
cans into the freezer compartment.
They may explode.
 Place liquids in upright position after
tightly closing the lid.
 Do not spray flammable substances
near the product, as it may burn or
explode.
 Do not keep flammable materials and
products with flammable gas (sprays,
etc.) in the refrigerator.
 Do not place containers holding
liquids on top of the product.
Splashing water on an electrified part
may cause electric shock and risk of
fire.
 Exposing the product to rain, snow,
sunlight and wind will cause electrical
danger. When relocating the product,
do not pull by holding the door
handle. The handle may come off.
 Take care to avoid trapping any part
of your hands or body in any of the
moving parts inside the product.
 Do not step or lean on the door,
drawers and similar parts of the
refrigerator. This will cause the
product to fall down and cause
damage to the parts.
 Take care not to trap the power cable.

 When positioning the appliance,
ensure the supply cord is not trapped
or damaged.
 Do not locate multiple portable
socket-outlets or portable power
supplies at the rear of the appliance.
 Children aged from 3 to 8 years
are allowed to load and unload
refrigerating appliances.

Instructions for safety and environment
5/40EN
Refrigerator / User Manual
 To avoid contamination of food,
please respect the following
instructions:
 – Opening the door for long
periods can cause a significant
increase of the temperature in the
compartments of the appliance.
 – Clean regularly surfaces that
can come in contact with food and
accessible drainage systems.
 – Clean water tanks if they have not
been used for 48 h; flush the water
system connected to a water supply
if water has not been drawn for 5
days.
 – Store raw meat and fish
in suitable containers in the
refrigerator, so that it is not in
contact with or drip onto other food.
 – Two-star frozen-food
compartments are suitable for
storing pre-frozen food, storing or
making icecream and making ice
cubes.
 – One-, two- and three-star
compartments are not suitable for
the freezing of fresh food.
 – If the refrigerating appliance is
left empty for long periods, switch
off, defrost, clean, dry, and leave
the door open to prevent mould
developing within the appliance.
1.1.1 HC warning
If the product comprises a
cooling system using R600a
gas, take care to avoid
damaging the cooling system
and its pipe while using and
moving the product. This gas
is flammable. If the cooling
system is damaged, keep the
product away from sources
of fire and ventilate the room
immediately.
CThe label on the inner left
side indicates the type of
gas used in the product.
1.1.2 For models with
water dispenser
 Pressure for cold water inlet shall
be maximum 90 psi (6.2 bar). If
your water pressure exceeds 80 psi
(5.5 bar), use a pressure limiting
valve in your mains system. If you
do not know how to check your
water pressure, ask for the help of a
professional plumber.
 If there is risk of water hammer
effect in your installation, always
use a water hammer prevention
equipment in your installation.
Consult Professional plumbers if you
are not sure that there is no water
hammer effect in your installation.
 Do not install on the hot water inlet.
Take precautions against of the
risk of freezing of the hoses. Water
temperature operating interval shall
be 33°F (0.6°C) minimum and
100°F (38°C) maximum.
 Use drinking water only.
1.2.Intended use
 This product is designed for
home use. It is not intended for
commercial use.
 The product should be used to store
food and beverages only.

Instructions for safety and environment
6 / 40 EN Refrigerator / User Manual
 Do not keep sensitive products
requiring controlled temperatures
(vaccines, heat sensitive medication,
medical supplies, etc.) in the
refrigerator.
 The manufacturer assumes no
responsibility for any damage due to
misuse or mishandling.
 Original spare parts will be provided
for 10 years, following the product
purchasing date.
1.3.Child safety
 Keep packaging materials out of
children’s reach.
 Do not allow the children to play
with the product.
 If the product’s door comprises a
lock, keep the key out of children’s
reach.
1.4. Compliance
with WEEE Directive
and Disposing of
the Waste Product
This product complies with
EU WEEE Directive (2012/19/EU).
This product bears a classification
symbol for waste electrical and
electronic equipment (WEEE).
This product has been
manufactured with high
quality parts and materials
which can be reused and
are suitable for recycling.
Do not dispose of the
waste product with normal
domestic and other wastes at the
end of its service life. Take it to the
collection center for the recycling of
electrical and electronic equipment.
Please consult your local authorities
to learn about these collection
centers.
1.5.Compliance with
RoHS Directive
 This product complies with EU WEEE
Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified
in the Directive.
1.6.Package
information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations.
Do not dispose of the packaging
materials together with the domestic
or other wastes. Take them to the
packaging material collection points
designated by the local authorities.

7/40 EN
Refrigerator / User Manual
1. Fridge - compartment door shelf
2. Temperature setting button
3. Water dispenser filling tank
4. Egg section
5. Water dispenser reservoir
6. Storage container under the door shelf
7. Moving door shelf
8. Adjustable feet
9. Crisper
10. Chiller compartment
11. Lock and key
12. Bottle shelf
13. Fridge - compartment glass shelf
14. Fan
15. Freezer compartment shelf
16. Icebox / Ice-making compartment
17. Freezer compartment
18. Fridge compartment
2Your appliance
C*optional:Figures in this user manual are given as an example and may not
match the product exactly. If the relevant parts are not available in the product you
purchased, the figure applies to other models.
*1
*3
*5
*4
*6
*2
*7
8
*9
*10
*11
*12
*13
14
14
17
18
*15
*16
*16
8

8 /40 EN Refrigerator / User Manual
3Installation
3.1.Appropriate
installation location
Contact an Authorized Service for the
installation of the product. In order to
prepare the product for use, refer the
information in the user manual and
ensure that electrical installation and
water installation are appropriate. If not,
call a qualified electrician and technician
to have any necessary arrangements
carried out.
BWARNING: Manufacturer shall
not be held liable for damages that
may arise from procedures carried
out by unauthorized persons.
BWARNING: Product must not
be plugged in during installation.
Otherwise, there is the risk of
death or serious injury!
A
WARNING: If the door clearance
of the room where the product
shall be place is so tight to prevent
passing of the product, remove
the door of the room and pass
the product through the door by
turning it to its side; if this does
not work, contact the authorized
service.

surface to prevent jolts.

away from heat sources such as hobs,
heater cores and stoves and at least 5
cm away from electrical ovens.

direct sun light and kept in humid
places.

provided around your product in order
to achieve an efficient operation. If the
product is to be placed in a recess in
the wall, pay attention to leave at least
5 cm distance with the ceiling and side
walls.

where the temperature falls below
-5°C.
3.2.Installing the
plastic wedges
Plastic wedges supplied with the
product are used to create the distance
for the air circulation between the
product and the rear wall.
1. To install the wedges, remove the
screws on the product and use the
screws supplied together with the
wedges.
2. Insert the 2 plastic wedges onto the
rear ventilation cover as illustrated in
the figure.

Installation
9 /40 EN
Refrigerator / User Manual
3.3.Adjusting the feet
If the product stands unbalanced
after installation, adjust the feet on
the front by rotating them to the
right or left.
3.4. Electrical
connection
AWARNING:Do not make
connections via extension
cables or multi-plugs.
BWARNING: Damaged power
cable must be replaced by the
Authorized Service Agent.
CIf two coolers are to be
installed side by side, there
should be at least 4 cm
distance between them.
 Our company shall not be liable for any
damages that will arise when the product
is used without grounding and electrical
connection in accordance with the national
regulations.
 Power cable plug must be within easy
reach after installation.
 Do not extension cords or cordless multiple
outlets between your product and the wall
outlet.
C
Hot Surface Warning!
Side walls of your product is
equipped with refrigerant
pipes to improve the cooling
system. Refrigerant with
high temperatures may flow
through these areas, resulting
in hot surfaces on the side
walls. This is normal and does
not need any servicing. Please
pay attention while touching
these areas.

Installation
10 / 40EN Refrigerator / User Manual
3.5.Reversing the doors
Proceed in numerical order .
4
1
5
10 11
3
6
78
12
19
18
14
13
21
21
9
45 °
2
17
16
20
15

Installation
11 /40 EN
Refrigerator / User Manual
3.6. Reversing the doors
Proceed in numerical order .
1
5
10 11
3
6
78
19
18
14
13
9
45 °
2
17
16
12
4
15
20

12 /40 EN Refrigerator / User Manual
4.1. Things to be done
for energy saving
AConnecting the product to electric
energy saving systems is risky
as it may cause damage on the
product.
 Do not leave the doors of your refrigerator open
for a long time.
 Do not put hot food or drinks in your refrigerator.
 Do not overload the refrigerator, cooling capacity
will fall when the air circulation inside is
hindered.
 In order to store maximum amount of food
in the freezer compartment, the icematic,
available in the freezer compartment and easily
removable by hand, shall be taken out. Net
volume and energy consumption values declared
on the power data plate of your refrigerator
are measured and tested by removing the
icematic. Do not remove the shelves inside the
freezer compartment and on the door of freezer
compartment shall not be removed and they
shall always be used they provide ease of use
and efficiency in energy consumption.
 Airflow should not be blocked by placing foods
on the sides of the freezer compartment fan. A
minimum distance of 3 cm shall be provided on
the sides of protective fan cover.
 The baskets/drawers that are provided with the
chill compartment must always be in use for
low energy consumption and for better storage
conditions.
 Food contact with the temperature sensor in
the freezer compartment may increase energy
consumption of the appliance. Thus any contact
with the sensor(s) must be avoided.
 Since hot and humid air will not directly
penetrate into your product when the doors are
not opened, your product will optimize itself
in conditions sufficient to protect your food.
Functions and components such as compressor,
fan, heater, defrost, lighting, display and so on
will operate according to the needs to consume
minimum energy under these circumstances.
 Depending on the features of your product,
thawing frozen food in fridge compartment will
both provide energy saving and preserve the
food quality.
 Do not allow contact of the food with the fridge
compartment temperature sensor shown in the
figure below.
4Preparation
4.2. Initial use
Before starting to use your refrigerator, ensure that
all preparations are made in accordance with the
instructions in sections "Instructions for safety and
environment" and "Installation".
 Run the product without putting any food for 6
hours and do not open its door unless certainly
required.
CYou will hear a noise when the
compressor starts up. The liquids
and gases sealed within the
refrigeration system may also
give rise to noise, even if the
compressor is not running and this
is quite normal.
CFront edges of the product may
feel warm. This is normal. These
areas are designed to be warm to
avoid condensation.
CIn some models, the instrument
panel automatically turns off
5 minutes after the door has
closed. It will be reactivated when
the door has opened or pressed
on any key.

13/40 EN
Refrigerator / User Manual
5Operating the product
5.1. Temperature setting button
The interior temperature of your
refrigerator changes for the following
reasons;
Seasonal temperatures,
Frequent opening of the door and
leaving the door open for long periods,
Food put into the refrigerator
without cooling down to the room
temperature,
The location of the refrigerator in the
room (e.g. exposing to sunlight).
You may adjust the varying interior
temperature due to such reasons by
using the setting button.
The numbers around the control knob
indicate the temperature values in “°C”.
If the ambient temperature is 25°C,
we recommend you to use the
temperature control knob of your
refrigerator at 4°C. This value may be
increased or decreased as required in
other ambient temperatures.
5.2. Fast freeze
If large amounts of fresh food are going
to be frozen, adjust the temperature
control knob to ( ) max. 24 hours
before putting the fresh food in the fast
freeze compartment.
It is strongly recommended to keep the
knob at this position at least 24 hours
to freeze maximum amount of fresh
food declared as freezing capacity. Take
special care not to mix frozen food and
fresh food.
C*Optional: Figures in this user manual are schematic and may not match the
product exactly. If the subject parts are not included in the product you have
purchased, then those parts are valid for other models.

Operating the product
14 / 40 EN Refrigerator / User Manual
Remember to turn the temperature
control knob back to its previous
position once food has frozen.
5.3. Vacation function
If the doors of the product are
not opened for 12 hours after the
temperature control knob is switched
to the hottest position, then the
vacation function will be activated
automatically.
To cancel the function, change the
knob setting.
It is not recommended to store food
in cooler compartment when the
vacation function is active.
When the setting operation is
completed, you may press the
temperature control knob and have
it hidden.
1. Fridge Compartment Indicator
2. Error status indicator
3. Temperature indicator
4. Vacation function button
5. Temperature setting button
6. Compartment selection button
7. Freezer compartment indicator
8. Economy mode indicator
9. Vacation function indicator
*optional

Operating the product
15/40EN
Refrigerator / User Manual
5.4. Indicator panel
Indicator panels may vary according to the product model.
Audio – visual functions on the indicator panel helps you in using your product.
45
76
*8
9
123
1. Fridge Compartment Indicator
2. Error status indicator
3. Temperature indicator
4. Vacation function button
5. Temperature setting button
6. Compartment selection button
7. Freezer compartment indicator
8. Economy mode indicator
9. Vacation function indicator
*optional
C*Optional: Figures in this user manual are schematic and may not match the
product exactly. If the subject parts are not included in the product you have
purchased, then those parts are valid for other models.

Operating the product
16 / 40 EN Refrigerator / User Manual
1. Fridge compartment indicator
Fridge compartment light is
illuminated while the fridge
compartment temperature is set.
2. Error status indicator
If your refrigerator does not perform
enough cooling or in case of a sensor
fault, this indicator is activated.
When this indicator is activated,
“E” is displayed on the freezer
compartment temperature indicator,
and numbers such as “1,2,3...” are
displayed on the fridge compartment
temperature indicator. These
numbers on the indicator inform
service personnel about the error.
3. Temperature indicator
Indicates freezer, fridge compartment
temperature.
4. Vacation function button
Press on Vacation Button for 3
seconds to activate this function.
When the vacation function is
activated, “- -” is displayed on the
fridge compartment temperature
indicator and no active cooling
is performed on the fridge
compartment. It is not suitable
to keep the food in the fridge
compartment when this function is
activated. Other compartments shall
be continued to be cooled as per their
set temperature.
To cancel this function press Vacation
button again.
5. Temperature setting button
Changes the temperature of the
relevant compartment between
-24°C... -18°C and 8°C...1°C.
6. Compartment selection button
Selection button: Press compartment
selection button to switch between
fridge and freezer compartments.
7. Freezer compartment indicator
Fridge compartment light is
illuminated while the freezer
compartment temperature is set.
8. Economy mode indicator
Indicates that the refrigerator
operates in energy saving mode.
This display shall be activated if the
freezer compartment temperature is
set to -18°C.
9. Vacation function indicator
Indicates that vacation is activated.

Operating the product
17/40EN
Refrigerator / User Manual
saving symbol is illuminated. ( )
When energy saving function is
activated, all symbols on the display
other than energy saving symbol will
turn off. When the Energy Saving
function is activated, if any button
is pressed or the door is opened,
energy saving function will be
canceled and the symbols on display
will return to normal.
Energy saving function is activated
during delivery from factory and
cannot be canceled.
3.Quick fridge function
The button has two functions. To
activate or deactivate the quick cool
C*Optional: Figures in this user manual are schematic and may not match the
product exactly. If the subject parts are not included in the product you have
purchased, then those parts are valid for other models.
5.5. Indicator panel
Indicator panel allows you to set the temperature and control the other
functions related to the product without opening the door of the product. Just
press the inscriptions on relevant buttons for function settings.
1
3
45
6
789
11
2
*10
*12
1. Power failure/High temperature / error
warning indicator
This indicator ( ) illuminates during
power failure, high temperature
failures and error warnings. During
sustained power failures, the
highest temperature that the freezer
compartment reaches will flash on the
digital display. After checking the food
located in the freezer compartment (
) press the alarm off button to clear the
warning.
2. Energy saving function (display off):
If the product doors are kept closed
for a long time energy saving function
is automatically activated and energy

Operating the product
18 / 40 EN Refrigerator / User Manual
function press it briefly. Quick Cool
indicator will turn off and the product
will return to its normal settings. ( )
CUse quick cooling function
when you want to quickly cool
the food placed in the fridge
compartment. If you want to
cool large amounts of fresh
food, activate this function
before putting the food into
the product.
CIf you do not cancel it, quick
cooling will cancel itself
automatically after 1 hours or
when the fridge compartment
reaches to the required
temperature.
CIf you press the quick cooling
button repeatedly with short
intervals, the electronic circuit
protection will be activated
and the compressor will not
start up immediately.
CThis function is not recalled
when power restores after a
power failure.
4. Fridge compartment temperature setting
button
Press this button to set the
temperature of the fridge
compartment to 8, 7,6, 5,4,3, 2, 8...
respectively. Press this button to set
the fridge compartment temperature
to the desired value. ( )
5.Vacation Function
In order to activate vacation function,
press the this button ( ) for 3
seconds, and the vacation mode
indicator ( ) will be activated. When
the vacation function is activated,
“- -” is displayed on the fridge
compartment temperature indicator
and no active cooling is performed
on the fridge compartment. It is not
suitable to keep the food in the fridge
compartment when this function is
activated. Other compartments shall
be continued to be cooled as per their
set temperature.
To cancel this function press Vacation
function button again.
6. Alarm off warning:
In case of power failure/high
temperature alarm, after checking
the food located in the freezer
compartment press the alarm off
button ( ) to clear the warning.
7. Key lock
Press key lock button ( )
simultaneously for 3 seconds. Key
lock symbol
() will light up and key lock mode
will be activated. Buttons will
not function if the Key lock mode
is active. Press key lock button
simultaneously for 3 seconds again.
Key lock symbol will turn off and the
key lock mode will be exited.
Press the key lock button if you
want to prevent changing of
the temperature setting of the
refrigerator ( ).
8. Eco fuzzy
Press and hold eco fuzzy button
for 1 seconds to activate eco fuzzy
function. Refrigerator will start
operating in the most economic
mode at least 6 hours later and the
economic usage indicator will turn
on when the function is active (

Operating the product
19/40EN
Refrigerator / User Manual
). Press and hold eco fuzzy function
button for 3 seconds to deactivate
eco fuzzy function.
This indicator is illuminated after 6
hours when eco fuzzy is activated.
9. Freezer compartment temperature setting
button
Press this button to set the
temperature of the freezer
compartment to -18,-19,-20,-21,
-22, -23,-24, -18... respectively.
Press this button to set the freezer
compartment temperature to the
desired value.( )
10. Icematic off indicator
Indicates whether the icematic is on
or off. ( )If On, then the icematic
is not operating. To operate the
icematic again press and hold the On-
Off button for 3 seconds.
CWater flow from water tank
will stop when this function is
selected. However, ice made
previously can be taken from
the icematic.
11. Quick freeze function button/ icematic
on-off button
Press this button to activate or
deactivate the quick freezing
function. When you activate the
function, the freezer compartment
will be cooled to a temperature lower
than the set value. ( )
To turn on and off the icematic press
and hold it for 3 seconds.
CUse the quick freeze function
when you want to quickly
freeze the food placed in fridge
compartment. If you want to
freeze large amounts of fresh
food, activate this function
before putting the food into
the product.
CIf you do not cancel it, Quick
Freeze will cancel itself
automatically after 25 hours or
when the fridge compartment
reaches to the required
temperature.
CThis function is not recalled
when power restores after a
power failure.
12. Economic usage indicator
Indicates that the product is running
in energy-efficient mode. ( )This
indicator will be active if the Freezer
Compartment temperature is set to
-18 or the energy efficient cooling
is being performed due to Eco-Extra
function.
CEconomic usage indicator is
turned off when quick cooling
or quick freeze functions are
selected.
