Beko HTV8733XW0 User manual

2820525274_EN/24-03-16.(14:11)
Washer-Dryer
User Manual
HTV8733XW0
EN
Document Number=

Please read this user manual first!
Dear Customer,
Thank you for choosing a Beko product. We hope that you get the best results from
your product which has been manufactured with high quality and state-of-the-art
technology.Therefore,pleasereadthis entire usermanual andallotheraccompanying
documents carefully before using the product and keep it as a reference for future
use. If you handover the product to someone else, give the user manual as well.
Follow all warnings and information in the user manual.
Throughout this user manual the following symbols are used:
B
DANGER!
Warning for electric shock.
DANGER!
Product weight warning
A
CAUTION
    

A
PRECAUTION
• Precautionsthatneedtobetaken.
This product was manufactured using the latest technology in environmentally friendly conditions.

C
INFORMATION
• Importantinformationorusefulhintsaboutusage.
• Readusermanual.
• Packagingmaterialsoftheproductaremanufactured
from recyclable materials in accordance with
regulations.
• Do not dispose of the Packaging materials together
withthe domesticor otherwastes.Takethemtothe
packagingmaterialcollectionpointsdesignatedbythe
localauthorities.
• AllergyUK,isthebrandofBritishAllergyAssociation.
Theirmainendorsementisthe‚SealofApproval‘.When
you see a product with this logo on it, you have the
reassurancetheproducthasbeenscientificallytested
toproveitisefficientatreducing/removingallergens
fromtheenvironmentofallergyandasthmasufferers
or the products have significantly reduced allergen/
chemicalcontent.
“The wool wash cycle of this machine has been approved by
The Woolmark Company for the washing of machine washable
wool products provided that the products are washed according
to the instructions on the garment label and those issued by the
manufacturer of this washing machine. M1527 “
“In UK, Eire, Hong Kong and India the Woolmark trade mark is a
Certification trade mark.”

4 / EN Washer-Dryer / User’s Manual
TABLE OF CONTENTS
 
1.1 General safety .....................................................................................................................................7
1.1.1 Electrcal safety .........................................................................................................................................7
1.1.2 Product safety ............................................................................................................................................8
1.1.3 Warnngs for dryng..................................................................................................................................10
1.2 Intended use........................................................................................................................................13
1.3 Children's safety.................................................................................................................................13
1.4 Compliance with WEEE Directive and disposing of the waste product...................14
1.5 Package information........................................................................................................................14
 
2.1 Overview................................................................................................................................................15
2.2 Package contents..............................................................................................................................16
2.3 Technical specifications.................................................................................................................17
 
3.1 Appropriate installation location................................................................................................18
3.2 Removing packaging reinforcement........................................................................................19
3.3 Removing the transit bolts...........................................................................................................19
3.4 Connecting water supply..............................................................................................................20
3.5 Connecting to the drain .................................................................................................................21
3.6 Adjusting the feet.............................................................................................................................22
3.7 Electrical connection.......................................................................................................................22
3.8 Transportation of the product....................................................................................................23
 
4.1 Sorting the laundry ..........................................................................................................................25
4.2 Preparing laundry for washing...................................................................................................25
4.3 Tips for energy saving ....................................................................................................................26
4.4 Initial use ..............................................................................................................................................26
4.5 Correct load capacity.......................................................................................................................27
4.6 Loading the laundry ........................................................................................................................27
4.7 Using detergent and softener....................................................................................................28
4.7.1 Detergent drawer.....................................................................................................................................28
4.7.2 Detergent, softener and other cleanng agents .......................................................................28
4.7.3 Choosng the detergent........................................................................................................................29
4.7.4 Adjustng the amount of detergent................................................................................................29
4.7.5 Usng softeners.........................................................................................................................................29
4.7.6 Usng lqud detergents.........................................................................................................................30
4.7.6.1 If the product contans a lqud detergent contaner................................................30
4.7.6.2 If the product does not contan a lqud detergent contaner..............................30
4.7.7 Usng gel and tablet detergent..........................................................................................................30
4.7.8 Usng laundry starch...............................................................................................................................31
4.7.9 Usng bleaches...........................................................................................................................................31

5 / EN Washer-Dryer / User’s Manual
4.7.10 Usng lmescale remover ....................................................................................................................31
4.8 Tips for efficient washing.............................................................................................................32
4.9 Tips for correct drying ....................................................................................................................33
 
5.1 Control panel........................................................................................................................................34
5.2 Display symbols..................................................................................................................................35
5.3 Preparing the machine...................................................................................................................35
5.4 Selecting the washing programme .........................................................................................36
5.5 Washing programmes ....................................................................................................................36
Cottons ...........................................................................................................................................................36
Synthetcs ..................................................................................................................................................... 37
Wool ................................................................................................................................................................. 37
Cottons Eco...................................................................................................................................................38
Delcates.........................................................................................................................................................38
Hand Wash....................................................................................................................................................38
Daly Xpress ..................................................................................................................................................39
Xpress Super Short ...................................................................................................................................39
Shrts................................................................................................................................................................40
Rnse ................................................................................................................................................................40
Spn+Dran ...................................................................................................................................................40
5.6 Temperature selection...................................................................................................................41
5.7 Spin speed selection........................................................................................................................42
5.7.1 If you want to spn your laundry after the Rnse Hold functon: ........................................43
5.7.2 Auxlary functon selecton for dryng...........................................................................................43
5.8 Drying programmes.........................................................................................................................44
Synthetc Dry ...............................................................................................................................................44
Cotton Dry .....................................................................................................................................................44
5.9 Washing and drying programmes.............................................................................................45
4 Kg Wash & Dry .........................................................................................................................................45
Wash & Wear................................................................................................................................................46
BabyProtect+Wash&Dry ........................................................................................................................46
5.10 Programme and consumption table .....................................................................................47
5.11 Auxiliary function selection.......................................................................................................50
Prewash ..........................................................................................................................................................51
Quck Wash.....................................................................................................................................................51
Extra Plus........................................................................................................................................................51
5.12 Drying steps......................................................................................................................................52
5.12.1 Iron Dry ..................................................................................................................................................52
5.12.2 Cupboard Dry .....................................................................................................................................52
5.12.3 Extra Dry ...............................................................................................................................................52
5.12.4 Tme based dryng-mnutes..............................................................................................................52
5.13 Time display ......................................................................................................................................53
5.14 End Time.............................................................................................................................................53
TABLE OF CONTENTS

6 / EN Washer-Dryer / User’s Manual
TABLE OF CONTENTS
5.15 Starting the programme..............................................................................................................54
5.16 Loading door lock............................................................................................................................54
5.17 Changing the selections after programme has started ...............................................55
5.17.1 Addng laundry after the programme has started:.................................................................55
5.17.2 Swtchng the machne to pause mode:......................................................................................55
5.17.3 Changng the programme selecton after programme has started:..............................55
5.17.4 Changng the auxlary functon, spn speed and temperature .......................................56
5.18 Child Lock............................................................................................................................................56
5.18.1 To actvate the chld lock: ...................................................................................................................56
5.18.2 To deactvate the chld lock: .............................................................................................................57
5.19 Cancelling the programme.........................................................................................................57
5.20 End of programme.........................................................................................................................58
5.21 Your machine features a "Standby Mode"...........................................................................58
 
6.1 Cleaning the detergent drawer ..................................................................................................59
6.2 Cleaning the loading door and the drum ...............................................................................59
6.3 Cleaning the body and control panel.......................................................................................60
6.4 Cleaning the water intake filters...............................................................................................60
6.5 Draining remaining water and cleaning the pump filter ................................................61
 

7 / EN Washer-Dryer / User’s Manual
 Important instructions for safety and environment
This section contains safety instructions that will help protect from risk of personal
injury or property damage. Failure to follow these instructions shall invalidate any
warranty.

A
CAUTION
 


      
         





A
PRECAUTION
• Never place the product on a carpet-covered floor.
Otherwise,lackofairflowbeneaththemachinewillcause
electricalpartstooverheat.Thiswillcauseproblemswith
yourproduct.
C
INFORMATION
• Always have the installation procedures carried out
by the competent persons. Manufacturer shall not be
heldliablefordamagesthatmayarisefromprocedures
carriedoutbyunauthorisedpersons.

B
DANGER!
If the product has a failure, it should not be operated
unless it is repaired by the Authorised Service
Agent. There is the risk of electric shock!
Never wash the product by spreading or pouring
water onto it! There is the risk of electric shock!

8 / EN Washer-Dryer / User’s Manual
Important instructions for safety and environment
A
CAUTION
 
       
     


A
PRECAUTION
• Unplugtheproductwhenitisnotinuse.
• Never touchtheplugwithwethands! Neverunplugby
pullingonthecable,alwaysunplugbyholdingtheplug.
• Product should be unplugged during installation,
maintenance,cleaningandrepairprocedures.
• Donotmakeconnectionsviaextensioncablesormulti-
plugs.
C
INFORMATION
• Thisproductisdesignedtoresumeoperatingintheevent
ofpoweringonafterapowerinterruption.Ifyouwishto
canceltheprogramme,see"Cancellingtheprogramme"
section.

A
DANGER!
Never open the loading door or remove the filter
while there is still water in the drum. Otherwise,
risk of flooding and injury from hot water will occur.
A
CAUTION
 



9 / EN Washer-Dryer / User’s Manual
Important instructions for safety and environment
C
INFORMATION
• Donotforceopenthelockedloadingdoor.Doorcanbe
opened a few minutes after the washing cycle ends. If
the machine has not cooled enough at the end of the
programme,loadingdoorcannotbeopened.Donotforce
theloadingdoortoopen.Itmustbelefttocoolitself.The
loadingdoorandthelockmechanismmaygetdamaged.
• Intheinstallationlocationofthisproduct,theremustnot
bealockable,slidingorhingeddoorthatwillrestrictthe
fullopeningoftheloadingdoor.
• Follow the instructions on the textile tags and on the
detergentpackage.
• Useonlydetergents,softenersandsupplementssuitable
forwashingmachines.
• Do not install or leave this product in places where it
mightbeexposedtooutdoorconditions.
• Controlsmustnotbetamperedwith.

10 / EN Washer-Dryer / User’s Manual
Important instructions for safety and environment

DANGER!
Laundry that is previously washed, cleaned, soiled
or stained with petrol / gasoline, dry cleaning
solvents or other flammable or explosive
substances must not be dried in the machine as
they give out flammable or explosive steam. It may
cause fire risk.
Laundry stained with Liquid cooking oil, acetone,
alcohol, petrol, kerosene, spot removers,
turpentine, waxes and wax removers must be
washed in hot water with plenty of detergent
before drying. It may cause fire risk.
Foam rubber (latex foam), shower caps, waterproof
textiles, clothes or pillows with rubber support or
rubber foam pads must not be dried with drying
function. It may cause fire risk.
If you use washing ball, detergent scale, laundry
clothing cages and balls in your machine, they can
melt during drying. Do not use these products if
drying option will be selected. It may cause fire
risk.
When you use industrial chemicals for cleaning, do
not use drying function. It may cause fire risk.
A
DANGER!
Do not touch loading door glass with bare hands
after drying. There is the risk of getting burnt.
In order to maintain laundry in a temperature that
will prevent them from getting damaged, a cooling
step is performed as a final step. You may be
exposed to hot steam if you open the door before
cooling is complete. There is the risk of scalding.
If the drying programmes are interrupted (as a result
of programme cancellation or power failure),
laundry in the machine can be hot. Be careful.

11 / EN Washer-Dryer / User’s Manual
Important instructions for safety and environment
A
CAUTION
 
 


        

       

          

 


12 / EN Washer-Dryer / User’s Manual
Important instructions for safety and environment
A
PRECAUTION
• Do not dry leather laundry or laundry that contains
leather (such as leather jeans label). The colour from
Leatherpartscanrunintoothertextiles.
• In failures that cannot be repaired using information
giveninsafetyinstructions,turnoffthemachine,unplug
thepowercableandcalltheAuthorisedServiceAgent.
• Youcanjustwashlaundry,justdrylaundryorwashand
drylaundryin yourwasher-dryer.Machine must notbe
usedonlytodrywetloadsforalongtime.Whenmachine
isusedonlyfordrying,itmustbeoperatedemptywithout
loadinglaundry ina shortwashprogrammeafterevery
15operation.
• Checkall clothesbeforeloadingthem intothe machine
andensurethattheydonothaveobjectssuchaslighters,
coins,metalpieces,needlesinthepocketsorinside.
• Underwearwithmetalsupportsmustnotbedriedinthe
machine. Metal supports might come off during drying
and cause damage in the machine. Place in a bag or
pillowcase.
• Do not dry large laundry such as tulle curtain, curtain,
bedding,blanket,ruginthemachine.Yourlaundrymight
getdamaged.
C
INFORMATION
• Donotdryunwashedlaundryinthemachine.
• Do not use fabric softeners or static preventers in the
machineunlessrecommendedbythemanufacturer.
• Products such as fabric softeners must be used in
accordancewithmanufacturer'sinstructions.
• Donotdrysensitiveclothessuchassilk,wool,etc.inthe
machine.Otherwise,woolclothesmaygetshrunkenand
othersensitiveclothesmaygetdamaged.
• Checksymbolsonthegarmenttagbeforewashingand
drying.

13 / EN Washer-Dryer / User’s Manual
Important instructions for safety and environment

C
INFORMATION
• Thisproducthasbeendesignedfordomesticuse.Itisnot
suitableforcommercialuseanditmustnotbeusedout
ofitsintendeduse.
• Theproductmustonlybeusedforwashing,rinsingand
dryingoftextileproductsthataremarkedaccordingly.
• Themanufacturerwaivesanyresponsibilityarisenfrom
incorrectusageortransportation.
• Theservicelifeofyourproductis10years.Duringthis
period,originalspare parts willbeavailabletooperate
theproductproperly.

A
CAUTION
 

 


       


       

 

 
         
       


14 / EN Washer-Dryer / User’s Manual
Important instructions for safety and environment


•Thisproductdoesnotcontainharmfulandforbiddenmaterialsdescribedinthe
"Regulation on the Control of the Waste Electrical and Electronic Equipment". It
complies with the WEEE Directive.
This product has been manufactured with high
quality parts and materials which can be reused
and are suitable for recycling. Therefore, do not
dispose the product with normal domestic waste
at the end of its service life. Take it to a collection
point for the recycling of electrical and electronic
equipment. Please consult your local authorities
to learn the nearest collection point. Help protect
the environment and natural resources by
recycling used products. For children's safety, cut
the power cable and break the locking mechanism
of the loading door so that it will be non-functional
before disposing of the product.
Compliance with RoHS Directive:
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.

Packaging materials of the product are manufactured from recyclable materials
in accordance with our National Environment Regulations. Do not dispose of the
packaging with normal domestic waste. Take them to the packaging material
collection points designated by the local authorities.

15 / EN Washer-Dryer / User’s Manual
 Your washer-dryer

1
2
3
4
5
6
7
8
1- Power cable
2- Top panel
3- Control panel
4- Water discharge hose
5- Loading door
6- Filter cover
7- Adjustable feet
8- Detergent drawer

16 / EN Washer-Dryer / User’s Manual
Your washer-dryer
Power cable
Water discharge hose
Transit bolts
Mains water inlet hose
Liquid detergent container (*)
User manual
Plastic plug group

NOTE
•Figuresinthismanualareschematicandmaynotmatchtheproductexactly.
(*) This may be supplied with the machine depending on the model of your product.


17 / EN Washer-Dryer / User’s Manual
Your washer-dryer

Supplier name or trademark Beko
Model name HTV8733XW0
Maximum spin speed (rpm) 1200
Rated capacity - Washing (kg) 7
Rated capacity - Drying (kg) 4
Height (cm) 84
Width (cm) 60
Depth (cm) 54
Net weight (±4 kg.) 66
Single Water inlet / Double Water inlet • / -
• Available
Electrical input (V/Hz) 220 V / 60Hz
Total current (A) 10
Total power (W) 1850
VDE Main model code 9620
Technical specifications may be changed without prior notice to improve the quality of the product.

18 / EN Washer-Dryer / User’s Manual
 Installation
To make the product ready for use, review the information in the user manual and
make sure that the electricity, tap water supply and water drainage systems are
appropriate before calling the Authorised Service Agent. If they are not, call a qualified
technician and plumber to have any necessary arrangements carried out.
B
DANGER!
Make sure that the installation and electrical
connections of the product are performed by
competent persons. Manufacturer shall not be held
liable for damages that may arise from procedures
carried out by unauthorised persons.
DANGER!
Your product is too heavy for one person to carry.
A
CAUTION
        
           

A
PRECAUTION
• Preparationofthelocationandelectrical,tapwaterand
waste water installations at the place of installation is
undercustomer'sresponsibility.
• Make sure that the water inlet and discharge hoses as
wellasthepowercablearenotfolded,pinchedorcrushed
whilepushingtheproductintoitsplaceafterinstallation
orcleaningprocedures.

•Placetheproductonasolidandlevelfloor.Donotplaceitontoacarpetwithhigh
pile or other similar surfaces.
•Donotplacetheproductclosetotheedgeifthefloorcontainssteps.Donotalso
place the product on a platform.
•Donotplacetheproductonthepowercable.
•Donotinstall the productin environmentswherethe temperaturefallsbelow0
ºC.(See. Warnings for Drying)
•Placetheproductatleast1,5cmawayfromtheedgesofotherfurniture.
In the area where this product is installed, there must not be a lockable, sliding or
hinged door that will restrict the full opening of loading door.

19 / EN Washer-Dryer / User’s Manual
Installation
Operate the product in a well ventilated and dust free environment.

Tilt the machine backwards to remove the packaging reinforcement. Remove the
packaging reinforcement attached to the ribbon.
DANGER!
Your product is heavy. Remove packaging
reinforcement as displayed in the figure.
Be careful not to get your hand caught under the
machine during this procedure.

A
PRECAUTION
• Do not remove the transit bolts before removing the
packagingreinforcement.
• Removethe transitbolts beforeoperatingthewashing
machine!Otherwise,theproductwillgetdamaged.
1 2 3
1 Use a tool to loosen all bolts until they rotate freely. (C)
2 Remove the transit bolts by turning them slightly.
3 Attach the plastic covers supplied in the user manual bag into the holes on the rear
panel. (P)

20 / EN Washer-Dryer / User’s Manual
Installation
C
INFORMATION
• Keepthetransitboltsinasafeplacetoreusewhenthe
productneedstobemovedagaininthefuture.
• Nevermovetheproductwithoutthetransitboltsproperly
fixedinplace!

C
INFORMATION
• Thewatersupplypressurerequiredtoruntheproductis
between1to10bars(0.1–1MPa).Itisnecessarytohave
10–80litersofwaterflowingfromthefullyopentapin
oneminutetohaveyourproductrunsmoothly.Attacha
pressurereducingvalveifwaterpressureishigher.
A
CAUTION
         
          


 

1 2 3
1 Connect the special hose supplied with the product to the water inlet on the
product.
