Equator EZ 1720 User manual

Combo Washer-Dryer
EZ 3720 CEE
EZ 1720 V
OWNER’S MANUAL
Colors: Platinum & White

1
Combo Washer
-
Dryer Owner’s Manual
TABLE OF CONTENTS
Warranty……………………………………………………………………………2-3
Introduction ………………………………………………………………………….4
Important Safety Instructions ………………………………………………………5
Picture of the Combo Washer-Dryer ……………………………………………8
Installation ……………………………………………………………………….9-11
Control Panel……………………………………………………………………12-13
Operating Instructions …………………………………………………………….14
Program Selection Chart………………………………………………………….15
How to dry ………………………………………………………………………….16
Stain removal Chart ………………………………………………………….17-18
Maintenance ……………………………………………………………………….20
Technical Data …………………………………………………………………….20
Troubleshooting .………………………………………………….……………… 21
Company Information …………………………………………………………….22
Please read the Owner’s Manual carefully before using your
new Equator Washer-Dryer

2
Combo Washer
-
Dryer Owner’s Manual
WARRANTY INFORMATION
Your Equator®appliance is protected by this warranty under
normal, personal, family or household use (1 Year),
and limited commercial use (90 days),in the USA and Canada.
WARRANTY
Equator Advanced Appliances undertakes to the consumer-owner to repair or, at Equator
Advanced Appliances’ option, to replace any part of this product which proves to be
defective in workmanship or material under normal personal, family or household use, in the
USA and Canada, for a period of one year from the date of original purchase. For
commercial use, the product is warranteed for a period of 90 days. During this period,
Equator Advanced Appliances will provide all labor and parts necessary to correct such
defect, free of charge, if the appliance has been installed and operated in accordance with
Equator Advanced Appliances’ written instructions with the appliance. Ready access to the
appliance, for service, is the responsibility of the consumer-owner.
EXCLUSIONS
In no event shall Equator Advanced Appliances be liable for incidental or consequential
damages or for damages resulting from external causes such as abuse, misuse, incorrect
voltage or acts God. This warranty does not cover service calls which do not involve
defective workmanship or materials covered by this warranty. Accordingly, diagnosis and
repair costs for a service call which does not involve defective workmanship or materials will
be the responsibility of the consumer-owner.
Specifically, the following work is not covered under warranty and does not constitute
warranty work:
§Installation –e.g. improper hook-up or leveling or non-removal of shipping bolts
§Maintenance –e.g. cleaning of air and/or water filter
§Damage –e.g. replacing broken door handle
Most work is covered. The defining factor is, has the machine malfunctioned (Equator is
responsible) or has the customer omitted or done something to cause machine to
malfunction (customer is responsible). Some States do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation or exclusion may not apply
to you.

3
Combo Washer
-
Dryer Owner’s Manual
WARRANTY SERVICE
This warranty is given by:
Equator Advanced Appliances
2801 W Sam Houston Parkway N, Ste. 150
Houston, TX 77043-1611
Service under this warranty must be obtained by the following steps, in order:
Call an Authorized Service Agent (obtain number of nearest agent from your dealer or
by calling 1-800-776-3538). Under normal circumstances, Service will be provided
during regular business hours (9:00 a.m. to 5:00 p.m. weekdays).
GENERAL
Since it is responsibility of the consumer-owner to establish the warranty period by verifying
the original purchase date, Equator Advanced Appliances recommends that a receipt,
delivery slip or some other appropriate payment record be kept for that purpose. Remember
to send in your Warranty Registration Card so that a proof of your purchase exists with
Equator. You can also register online at www.iEquator.com/warranty.This warranty gives
you specific legal rights, and you may also have other rights which vary from State to State.
Corporate Office
EQUATOR ADVANCED APPLIANCES
2801 W Sam Houston Parkway N, Ste. 150
Houston, Texas 77043-1611
Tel: [phone]
Fax: [phone]
Toll Free: 800-935-1955
Electrical Testing Laboratories
US N° 3094367 CANADA
The ETL Listed Mark is the legal equivalent to the UL and CSA Listed Marks
EQUATOR CONTACTS
Service: 1-800-776-3538
[e-mail]
Parts & Accessories: [e-mail]

4
Combo Washer
-
Dryer Owner’s Manual
INTRODUCTION
Congratulations on your new Equator Washer-Dryer. In addition to its award winning
design, this is a highly sophisticated engineered product that will give you many
years of satisfaction.
Here are 10 of the best reasons for buying your Equator Washer-Dryer
1. Energy Savings
This appliance is engineered to provide valuable energy savings when compared to
other washer-dryers.
2. Maintenance
Since the machine has a self-cleaning pump, this appliance needs no cleaning of lint
after drying. Instead, there is a convenient coin trap.
3. Water Savings
This appliance uses little water for washing and drying (EZ 3720), far less than a
standard full-size top-loading washer.
4. Improved Operation
With a high spin speed, more water is extracted, allowing improved dry times.
5. Convenience
This appliance can be permanently installed and be made portable with the installation
of the portability kit (sold separately) where needed.
6. Combined Washing & Drying
No need for two separate machines for two tasks and no more transferring clothes from
one to the other. Program the Washer-Dryer and you have a two-in-one.
7. Better Clothing Appearance
This Washer-Dryer has no agitator to damage your clothes so they look better and last
longer.
8. Placement Options
The Washer-Dryer’s sleek design makes it a perfect appliance for any Kitchen or
Laundry Room. Its compact size makes the Washer-Dryer perfect for placement on
each floor of your home.
9. Easy Operation
This appliance is simple to use as a washer or as a dryer –or it can go seamlessly from
wash to the dry functions.
10. Space Savings
By combining the two functions of washer and dryer in one unit, the space taken for the
second unit, i.e. separate dryer, is saved.

5
Combo Washer
-
Dryer Owner’s Manual
IMPORTANT SAFETY INSTRUCTIONS
Your safety and that of you children
Your washing machine has been built in compliance with safety regulations, to
protect you and all your family.
WARNING –To reduce the risk of fire, electric shock, or injury to persons when
using your appliance, follow basic precautions, including the following:
SAVE THESE INSTRUCTIONS
1. Read all instructions before using the appliance.
2. Do not wash or dry articles that have been previously cleaned in, washed in, or spotted with
gasoline, dry-cleaning solvents, other flammable or explosive substances, as they emit vapors
that could ignite or explode.
3. Do not allow children to play on or in the appliance. Close supervision of children is necessary
when the appliance is used near children.
4. Before the appliance is removed from service or discarded, remove the door.
5. Do not reach into the appliance if the tub or drum is moving.
6. Do not install or store this appliance where it will be exposed to the weather.
7. Do not tamper with controls.
8. Do not repair or replace any part of the appliance or attempt any servicing unless specifically
recommended in the user-maintenance instructions or in published user-repair instructions that
you understand and have skills to carry out.
9. Do not add gasoline, dry-cleaning solvents, or other flammable or explosive substances to the
wash water. These substances give off vapors that could ignite or explode.
10. Under certain conditions, hydrogen gas may be produced in a hot water system that has not
been used for 2 weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water system has
not been used for such a period, before using a washing machine or combination washer-dryer,
turn on all hot water faucets and let the water flow from each for several minutes. This will
release any accumulated Hydrogen.
11. Do not use fabric softeners or products to reduce static unless recommended by the
manufacturers of the fabric softener product.
12. Do not use heat to dry articles containing foam rubber or similarly textured rubber-like
materials.
13. Check the Coin Trap every few months to remove any coins, buttons or similar size objects.
14. For vented washer-dryers keep the exhaust opening and surrounding areas free from
accumulation of lint, dust, and dirt.
15. Do not place items exposed to cooking oils in your dryer. Item contaminated with cooking oils
may contribute to a chemical reaction that could cause a load to catch fire.

6
Combo Washer
-
Dryer Owner’s Manual
HELPFUL HINTS
•Your Washer-Dryer spins at a high speed, which will extract more water especially from
absorbent fabrics and reduce the degree of dampness as the machine goes into the drying mode.
This will cut down on your drying time.
•Use Liquid Fabric Softener. Fill the softener compartment up to the level marked. Using fabric
softener fluffs out clothes immediately after the wash cycle. This helps speed drying time and
reduces wrinkles.
•This Washer-Dryer is a 110 Volt machine, so the heating element requires more time to achieve
full heat than a larger 220 volt unit requires. The heating element will take about 10 minutes to
reach full heat.
•To dry your laundry, the Washer-Dryer blows heated air into the rotating drum. As the drum
tumbles your laundry, the warm air dries it. If the drum is overfilled with laundry, the air is not
allowed to circulate and clothes will not dry properly.
•Use High Efficiency (HE) Detergent. This is recommended for all front loading washers. It
ensures there is no over sudsing, which may reduce the performance of your machine. Also, this
prevents damage to your machine which may be caused by excess suds entering the condensing
chamber [EZ 3720 CEE] and clogging the fan blower mechanism [EZ 3720 CEE/EZ 1720 V] with
lint. If you have any problem obtaining High Efficiency (HE) detergent, please order Equator HE
detergent available online at www.equatorappliances.com.
•When sorting laundry always take into consideration the quantity and type of fabric contained in
the load. Highly absorbent fabrics such as those used in towels or jeans will absorb more water
and become very heavy when saturated. If you notice that your clothes are taking longer than
usual to dry you may be overloading the machine, or washing too many highly absorbent articles
for a single load.
DRYER EFFICIENCY
Your Washer-Dryer operates on 120 volts. It will take a longer time to dry clothes than a traditional
dryer (which operates on 220 volts). However, with the following tips, you can increase the efficiency
of the dryer.
1. FABRIC SOFTENER: After the wash cycle, the clothes can get stuck to the sides of the drum.
USING LIQUID FABRIC SOFTENER WILL CAUSE THE CLOTHES TO UNSTICK IMMEDIATELY
AND TUMBLE IN THE DRY CYCLE. THIS HELPS DRY CLOTHES FASTER AND CAUSES LESS
WRINKLES.
2. OVERLOADING: The drum has a capacity of 14 lbs (1.90 cu. ft.) While this unit has one of the
largest drum available on any combination washer-dryer, it is smaller than a standard U.S. washer.
The EZ 3720 CEE/EZ 1720 V drum should not be overloaded. With too many clothes, airflow is
reduced, increasing drying time. The drum should be filled to a maximum 2/3rd full.
3. OVER DRYING: [EZ 3720 CEE] uses a condensing dryer. In this cold water is used to condense
the moisture from the hot air. Since there is no external exhaust system, the moisture remains in the
machine. Frequently, when it seems the clothes are damp, it is actually the remaining moisture (like
dew). Take clothes out and within a few minutes they will be dry. Do not over-dry the clothes.
4. USE HIGH EFFICIENCY (HE) DETERGENT: By using High Efficiency (HE) detergent (Equator
brand or any other), you are preventing suds from entering the condensing chamber [EZ 3720 CEE].
When suds enter the condensing chamber, lint particles can clog up the chamber and the fan blower
[EZ 3720 CEE/EZ 1720 V]. Over time, this reduces drying efficiency and may require the fan blower
(impeller) to be cleaned. For this and all other front-loading/horizontal-axis units, High Efficiency
(HE) detergents go a long way to improve the efficiency of the units.

7
Combo Washer
-
Dryer Owner’s Manual
SAFETY
The model number of this product may be found on
the back of the unit; the serial number of the label
affixed to the back of the unit.
You should note the model and serial numbers of
this unit in the space provided. Retain this booklet
as a permanent record of your purchase to aid in
identification in the event of theft.
MODEL#
SERIAL#
INTRODUCTION
Your new appliance is carefully engineered product. Many times what appears to be a reason to call
service, the problem may require nothing more than a simple adjustment you can easily make in your
own home.
You will be charged for a service call while the appliance is in warranty if the problem is not
caused by defective product workmanship or materials covered by this warranty.
To avoid a charge for an unnecessary service call, and before calling a serviceman, please refer to
the troubleshooting section for situations that you can remedy. This section is included on pages 21 of
this Owner’s Manual.
Your Washer-Dryer is front loading, with an extra large door opening for easier access. It has 10
wash programs.
You will obviously want to obtain the best possible wash. By reading and following the instructions in
this booklet you will achieve excellent results.
Please, ensure that the instructions are followed. If you should need any further advice or assistance,
please, contact the dealer where your machine was purchased, or contact Customer Service at
[e-mail]
This appliance is an automatic washer-dryer with a capacity of up to:
-WASH 14 Lbs
-WASH & DRYING 9Lbs dry weight of clothes
PRE-INSTALLATION
1. The unit must be installed on a strong level floor, and in protected, dry, and well-ventilated area
close to a power and water supply of sufficient capacity, and a sufficient outlet.
2. Installation on Carpet or Wood increases vibrations.
• Carpets –place on light carpet only.
• Wood –brace floor with screws and place additional sheets of plywood before installation.
3. This unit’s installation and grounding should be done in accordance with local codes by a qualified
installer. “Installation Instructions” are included in this manual for the Installer’s reference.
4. The unit should be plugged into a properly grounded three (3) prong electrical outlet of 110V/60Hz
with minimum 15 Amps, It should not be controlled by a wall switch or pull cord which might be turned
off accidentally.
CAUTION
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER
SERVICABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PROFESSIONALS.
RISK OF ELECTRIC SHOCK
DO NOT OPEN

8
Combo Washer
-
Dryer Owner’s Manual
PICTURE OF THE COMBO WASHER-DRYER
Control panel Dryer knob Washer knob
Detergent dispenser
Door
Adjustable feet Coin trap

9
Combo Washer
-
Dryer Owner’s Manual
INSTALLATION
UNPACKING, LEVELING, & POSITIONING
Remove the packing and check that the Washer-Dryer is undamaged. If you have any doubt,
do not use the Washer-Dryer and call Equator Customer Service. Keep all packing parts
(plastic bag, foam rubber, screws, etc.) out of the reach of children since they could be
dangerous.
Important: The inside of the Washer-Dryer consists of a free floating drum that is affixed
with shipping bolts at the back of the cabinet (Fig.1) during transport. Before starting the
machine, remember to remove the shipping bolts. Close the holes left open by the bolts
with the plastic caps provided.
It is important for the machine to be perfectly level. For this reason, the machine is fitted with
adjustable feet used for leveling the machine before use (Fig.2).
(Fig.1) (Fig.2)
ELECTRICAL CONNECTION
Connect the plug to a power outlet –110V/60Hz with minimum 15 Amps. Make sure that the
voltage and frequency available correspond with those stated on the serial number plate
located on the machine. Do not use adaptors or extension cords since they could result in
overheating and burn out.

10
Combo Washer
-
Dryer Owner’s Manual
GROUNDING
This appliance must be grounded. In the event of malfunction or breakdown, grounding will
reduce the risk of electric shock by providing a path of least resistance for electric current.
This appliance is equipped with a power cord having an equipment-grounding conductor and
a grounding plug. The plug must be plugged into an appropriate outlet that is properly
installed and grounded in accordance with all local codes and ordinances.
WARNINGS
-Improper connection of the equipment-grounding conductor can result in a risk of electric
shock. Check with a qualified or service representative or personnel if you are in doubt
as to whether the appliance is properly grounded.
-Do not modify the plug provided with the appliance: if it will not fit the outlet, have a
proper outlet installed by a qualified electrician.
CONNECTING TO THE WATER FAUCET
Please read the following steps carefully (Fig.3, Fig.4)
1. Connect the gray end of the hoses supplied to the faucet (Fig.3).
2. Connect two pressure-reducing valves [2] to each inlet valve [1] (see Fig.4).
Note: Cold water hookup is needed for drying (Ventless models only).
3. Connect the white end of hosesto the pressure-reducing valve at the appropriate inlet
valve (marked “H” or “C”) (Fig.4).
CONNECTING THE DRAIN HOSE
Connect the drain hose to a drain duct (with internal diameter of at least 1.6 inches) or place
it for drainage in to a sink or a tub, ensuring that there are no kinks or bends. The free end
must be at a height of 28”-36” from the floor, the hose can be held in place using the black
plastic clamp on the upper part of the back panel (Fig.4)
(Fig.3) (Fig.4)

11
Combo Washer
-
Dryer Owner’s Manual
Connectingthe dryer vent hose
For EZ 1720 V, the machine vents the moist hot air out of
the unit and require a vent hose to be installed.
To install the vent hose, attach the vent hose 2 into the
connector 1(Fig.5).
A flexible aluminum vent hose is recommended.
Fig.5
RECESSED, CLOSET AND INSTALLATION (Instructions)
The machine may be installed in a recessed area, closet or alcove.
The installation spacing is in inches and is the minimum acceptable.
Closet installation must be exhausted.
Other installations must use the minimum dimension indicated.
?Additional clearances for wall, door and floor molding may be required.
?? Additional space is needed when an external exhaust elbow is used.
NOTE: If a door is installed that potentially encloses the unit while running, the door must
allow for a minimum of 20 square inches of free air movement. There must also be a 1”
space in front of the unit to the closed door and 1” from the back of the unit to the wall.
Additional spacing should be considered for easy installation, servicing and compliance with
applicable local, state, and federal codes.
For EZ 1720 V, see Fig 6,
For EZ 3720 CEE, see Fig 7.
(Fig.6)
(Fig.7)

12
Combo Washer
-
Dryer Owner’s Manual
CONTROL PANEL
A Detergent dispenser EPower indicator light
BPower button F Dryer knob
C ½ load button GWasher knob
D ½ heat button
BCDE
AFG
ADetergent Dispenser
The detergent dispenser has 3 compartments,
marked A, B, and C.
A. Pre-wash detergent
B. Wash Detergent, Bleach (e.g. Clorox®)
C. Fabric softener (e.g. Downey®)
Note: The Bleach must be filled into “B”
compartment.
BPower button.
Pressed in for ON
Not pressed for OFF
C½Load button.
If you have half a load or a light load, press this button.

13
Combo Washer
-
Dryer Owner’s Manual
D½Heat button.
When drying Cotton-mix fabrics, press the½Heat button for
best results and to prevent overheating.
EPower Indicator Light
This light indicates when the power is turned on.
FDryer Knob Turn dryer knob to set minutes for drying.
Note: also see instructions on using the ½ Heat
button
FWasher Knob
Turn the washer knob clockwise to
choose the wash cycle.

14
Combo Washer
-
Dryer Owner’s Manual
Warning —to reduce the risk of fire, electric shock, or injury to person, read the
IMPORTANT SAFETY INSTRUCTIONS before operating this appliance.
OPERATING INSTRUCTIONS
1. Make sure Washer-Dryer is turned off. (Power Indicator light should be off).
2. Separate clothes into cottons, permanent press and delicates.
3. Load clothes of the selected type loosely into the drum. If you are only washing clothes, you can
fill the drum. However, if you are washing and then drying, please don’t load clothes more than
2/3 full.
4. Close the Washer-Dryer door. You will hear a click when it is correctly closed.
5. Add detergent to the center compartment of the dispenser (2). Use low-sudsing detergent –
about 1 tablespoon. If desired, you can add pre-wash detergent, fabric softener and bleach as
shown in the diagram (see fig. Aon page 12).
6. Choose a Wash program by turning the washer knob clockwise to the desired setting on the
control panel. (See chart on page 15).
7. Turn the Dryer knob to the desired amount of minutes for drying.
8. If you have a light load or ½ load of clothes, press the ½ load button.
9. For delicates only (wool, silk, etc.) if you do not want the drum to spin, press the no spin button.
Keep in mind that the clothes will retain a fair amount of water.
10. Review these steps and check all the settings on the control panel before starting the machine.
11. Press the Power button. The indicator light will come on and in a few seconds, you will hear the
cycle begin.
12. When the Washer-Dryer has completed the cycle, the machine will stop automatically, although
the indicator light will remain on until you manually press out the Power button.
Note: The door switch of the Washer-Dryer is electronic and locks automatically during the Wash
cycle. Wait at least 2 minutes after the Wash cycle has stopped to open the door. Please do not try
to force the door open. Breaking of the door handle is not covered by warranty.
You can open the door any time during the Dry cycle without waiting.
STARTING THE WASHER-DRYER
Starting your washer-dryer in the right way is important for the quality of your wash, to help prevent
future problems and enhance life expectancy of your appliance. Once you have loaded your
washer-dryer and added the detergent together with any fabric conditioner, always check that:
4. The door is closed correctly. 2) The plug is secured in the socket. 3) The water supply is turned
on.
Choose the desired program
The program is selected according to the type of garments that need to be washed. To choose a
program, refer to the table on page 15, then:
1) Turn Washer knob until the selected program is aligned with the mark on the knob,
2) Turn Dryer knob to the desired position,
3) If necessary use buttons ½Load and ½Heat.
4) Press the Power button.
At the end of the wash cycle…
Turn the washer-dryer off by pressing Power button. You can now open the washer-dryer door safely.
After having removed the freshly cleaned laundry, leave the door open to allow air circulation inside
the drum. Remember that, in the event of a power failure, or should the washer-dryer switch itself off,
the program chosen will remain in memory.

15
Combo Washer
-
Dryer Owner’s Manual
PROGRAM SELECTION CHART
Program Description of
load Features Suggested
Drying heat and
times
1 -Pre-wash Heavy, soiled
clothing
Prewash
Cold water wash
High spin
High heat
120 minutes
2 -Heavy Thick cottons
(towels, jeans) Hot water wash High spin High heat 90 minutes
3 -Towels/Sheets Mixed cottons
(t-shirts, jeans) Warm water wash High spin High heat 90 minutes
4 -Active Wear Delicate colors Cold water wash
High spin High heat 90 minutes
5 -Easy Care Mixed cottons Cold water rinse
High spin High heat 90 minutes
6 -Normal Cotton mix, light
fabrics Warm water wash Medium spin Medium or high heat –at least 60 minutes
7 -Casual Cotton mix, light
fabrics Cold water wash Medium spin Medium or high heat –at least 60 minutes
8 -Quick Cotton mix, light
fabrics Cold water wash Medium spin Medium or high heat –at least 60 minutes
9 -Delicates Wools, silks Cold water wash
Low spin No Dry cycle after Wash cycle ends
10 -Wools Wools, silks Cold water rinse
Low spin No Dry cycle after Wash cycle ends

16
Combo Washer
-
Dryer Owner’s Manual
HOW TO DRY
Combined (Wash & Dry)
• Look at table Ato the side and follow the instructions provided for MAX load to have an automatic
washing and drying cycle.
• Follow the instructions for wash only (see page14, the section "Starting the Washer-Dryer")
• Set the dryer time on Dryer knob.
• Press the Power button.
Table A: The best dry time also depends on the amount of laundry to be dried.
Selecting the correct drying time, Use the following table as a guide:
Fabric Load Max load
(lbs) Drying Knob Sector Drying Time (minutes)
Cottons Laundry of
different sizes 8High Heat 120
Cottons Only terry towels 7High Heat 120
Mixed fabric
(cotton+ polyster) Sheets or shirts 5.5 Less Heat 80-90
Acrylics Pajamas. Socks
etc 4Less Heat 60-70
Nylon Petticoats.
Stockings etc 4Less Heat 40-50
If the laundry load to be washed and dried exceeds the maximum load (see table A), then:
-follow the instructions provided for wash only (page 14, in section "Starting the Washer-Dryer" and
follow these instructions.
-when the wash cycle is finished, remove your washing, divide it up and replace part of it inside the
drum.
Now follow the instructions provided for dry only cycle. Repeat this procedure for the rest of the load.
Dry only
• Load the clothes no more than 9lbs for cottons, (see table for other fabrics), make sure that:
-the door is shut correctly;
-the plug is inserted in the socket;
-the water faucet is turned on (EZ 3720 CEE)
-Power button has not been pressed
• Set the Washer knob to the appropriate “Off-Dry” setting depending on the type of fabric
• Set dryer time on the Dryer knob
• Press Power button to start.
When Drying is Complete...
Turn the washer-dryer off by pressing the Power button. Now you can open the appliance door.
Once you have removed the dry clothes from the appliance, leave the door open or ajar to avoid
the formation of bad odors and turn off the water (if attached with a faucet adapter kit.)
USEFUL TIPS
Denim Alert:
Some overalls have straps with hooks that can damage the drum of your washing machine or
other garments during the wash. To minimize the risk, place hooks in the pocket and fasten with
safety pins.
Vacations: unplug the appliance:
It is recommended that you should unplug the machine from the socket and turn off the water
supply. Leave the door ajar to allow air circulation to the draw and the door gasket area. This will
prevent unpleasant odors.

17
Combo Washer
-
Dryer Owner’s Manual
STAIN REMOVAL CHART
Blood
Rinse or soak fresh stain in cold water. Work
detergent into any remaining stain. Rinse. If
stain persists, put a few drops of ammonia on
stain and repeat detergent treatment. Rinse. If
necessary bleach.
Burn Marks
Rinse or soak in cold water. Work detergent
into stain. Rinse. Bleach, if necessary. Stain
may be impossible to re move
Candle Wax
Scrape off excess. Place stain between clean
white blotters or several layers of facial
tissues. Press with warm iron. Sponge with
cleaning fluid. If dye spot remains, bleach.
Chewing Gum
Rub with ice to harden. Scrape off excess with
dull blade. Sponge with cleaning fluid.
Chocolate or Cocoa
Soak 15 minutes in cold water. Rub detergent
paste into stain, then rinse thoroughly.
Launder in hottest water safe for fabric. If
colored stain remains, sponge with hydrogen
peroxide, rinse and launder.
Cod liver Oil
Sponge article with cleaning fluid. Soak in
warm suds. If stain persists, wash with bleach
safe for fabric. To remove yellow stain, sponge
with hydrogen peroxide. Rinse and launder.
Old stains may be nearly impossible to
remove.
Coffee or Tea (Black)
Soak fresh stains immediately in cold water.
Then use bleach treatment with hottest water
safe for fabric. Or if safe for the fabric pour
boiling water through spot from a height of 1 to
3 feet. Launder.
Coffee or Tea (With Cream)
Rinse or soak in cold water. Work detergent
into stain. Rinse. Dry. If grease stain remains,
sponge with cleaning fluid. Repeat, if
necessary. If stain remains, bleach.
Cosmetics: eye shadow, lipstick, liquid
make-up, mascara, powder, pancake
make-up or rouge
Apply undiluted liquid detergent to stain, or
dampen stain and rub in soap or detergent
paste until thick suds are formed. Work in until
stain is gone, rinse well. Repeat if necessary.
If color remains, bleach if safe for fabrics.
Cream, Ice Cream or Milk
Sponge stain with cool water or soak stain in
cool water for 30 minutes or longer. If stain
remains, work a detergent in-to spot then
rinse. Bleach if necessary.
Deodorants and Antiperspirants
Wash or sponge stain thoroughly with warm
water and detergent; rinse. If stain remains,
bleach with hot sudsy water. Launder. You
may be able to restore fabric color by
sponging with ammonia. Rinse thoroughly.
Dye
Rinse or soak in cold water. Work detergent
into stain. Rinse. If necessary, bleach. Stain is
not always possible to remove. A commercial
color remover may also be used.
Egg or Meat Juice
Rinse in cold water. If stain remains, sprinkle
with meat tenderizer, let stand 15-20 minutes.
If stain still remains, sponge with cleaning
fluid or diluted bleach. Launder in hot water.
The use of hot water first may set stain.
Fabric Softener Stain
Rub with bar soap until stain has lightened.
Rinse thoroughly. Launder. Rubbing alcohol is
sometimes effective in the color of the garment
can take it. Launder. If desired, dry cleaning
can be used.
Felt tip pen
Spray spot with cleaners suitable to this
purpose. Sponge stain thoroughly. Rinse with
cold water. Reapply cleaner if necessary .
Fruit, Wine
Soak fresh stains immediately with cool water.
Then use bleach treatment with hottest water
safe for fabrics, pour boiling water through
spot from a height of 1 to 3 feet. Launder.

18
Combo Washer
-
Dryer Owner’s Manual
Grass
Work detergent into stain. Sponge with
denatured alcohol. Bleach, if necessary.
Grease or Oil
Scrape away excess. Rub detergent paste or
a general purpose liquid household cleaner
into stain, rinse with hot water. If stain remains,
sponge thoroughly with a grease solvent. Dry.
Repeat if necessary. To remove yellow stain,
use a chlorine or oxygen bleach.
Ink. Ball-point
Same ball-point inks are set by water. First
test a scrap of cloth. Sponge stain repeatedly
with acetone, amyl acetate or rubbing alcohol.
Hair spray is effective. Launder. Bleach if
necessary. Use amyl acetate on triacetate,
arnel, dynel and verel. Use acetone on other
fabrics. NOTE: Some inks cannot be removed.
Ketchup
Scrape of excess. Soak in cold water 30
minutes. Pre-treat with a detergent paste.
Launder.
Mildew
Brush off surface growth to keep mold spores
from spreading. Dip article into solution of ½
cup bleach per 1 gallon of cool sudsy water for
5 to 10 minutes. Rinse well. Launder.
Mud
Let stain dry; then brush well. Rinse
repeatedly in cool water until mud comes out.
Launder. (Hot soaps suds set a red or yellow
clay stain).
Mustard
Soak in hot detergent water for several hours.
If stain remains, bleach.
Nail Polish
Treat while fresh, scraping or wiping off as
much as possible, before it dries. Place stain
face down on white paper towels. Sponge
back of stain acetone (nail polish remover) or
sponge with denatured alcohol and a few
drops of household ammonia. Sponge stain
frequently. Launder with water at temperature
suitable for fabric. Do not use acetone on
acetate, arnel, dynel or rayon.
Paint
Sponge or soak in turpentine or solvent
recommended as a thinner on label. Launder.
Perfume
Rinse in cold water. Rub undiluted liquid
detergent or a detergent paste into stain.
Rinse. If stain remains, bleach.
Perspiration
Wash or sponge stain thoroughly with warm
water and detergent paste. If perspiration has
changed the color of the fabric, restore it by
treating with ammonia or vinegar. Apply
ammonia to fresh stains; rinse with water.
Apply vinegar to old stains; rinse with water.
Rust and Iron
Apply commercial rust remover, according to
manufacturer’s directions. Rinse. Or, if safe for
fabric, boil stained article in solution of 4
teaspoons of cream of tartar to 1 pint water.
Shoe Polish
Scrape off as much as possible. Pre-treat with
a detergent paste; rinse. If stain persists,
sponge with rubbing alcohol (1 part to 2 parts
water) or turpentine. Remove turpentine by
sponging again with warm detergent solution
or with alcohol. Bleach if necessary.
Soft Drinks
Sponge with cold water, some stains are
invisible when they have dried, but turn brown
when heated and may be impossible to
remove.
Tar and Asphalt
Act quickly before stain is dry. Sponge with
grease solvent or turpentine. Launder.
Urine
Soak in cool water. If stain is dry, work a
detergent paste into the spot then rinse. If
necessary, bleach.

19
Combo Washer
-
Dryer Owner’s Manual
UNDERSTANDING FABRIC CARE LABELS
The symbols on labels of your garments will help you in choosing the suitable wash
program, the right temperature, wash cycles, and ironing methods. Don’t forget to give a
glance to these useful indications!
WINTERIZING YOUR WASHER-DRYER
To winterize your Washer-Dryer please, follow the instructions below to avoid damage
to your unit due to freezing:
1. With the unit off, remove wash filter. This will allow the water remaining in the pump and
drain hose to be evacuated. Replace filter.
2. Close the inlet shut-off valves (provided by installer) and disconnect the inlet
hoses. There should be no water in the hoses where they attach at the back of the
machine.
IF ANTIFREEZE IS BEING USED IN THE SYSTEM FOLLOW THESE INSTRUCTIONS:
(not necessary if the above drain procedure is followed)
1. When putting antifreeze into the water system of your coach, set the washer to the NORMAL
wash setting and allow water to flow into unit until antifreeze is detected.
2. Turn off Power. Advance the washer knob to the “Rinse” position and allow water to flow for 10
seconds.
3. Turn off Power. Advance the washer knob on “Spin” to remove the majority of the water
from the unit.
4. Turn off Power. With the unit off, remove coin trap from the unit. This will allow the water
remaining in the pump and drain hose to be evacuated. Replace coin trap.
5. If you elect you may close the inlet shut-off valves (provided by installer) and disconnect the
inlet hoses.
6. Any water remaining in the unit should contain antifreeze and be protected from freezing.
Note: When placing unit into service allow unit to operate for one complete cycle before
doing laundry to ensure all antifreeze has been purged from the unit.
If you have any further questions pertaining to this matter please contact Technical Support at
[e-mail].
