Beko WDIY854310 User manual

W asher-Dryer
User Manual
WDIY854310

User’s Manual
LAUNDRY WASH SYMBOLS
Machine
Wash
Symbols
Normal wash No Iron Sensitive- Delicate wash Hand wash Not washable No Spin
WASH Water
Temperatures
Maximum 950C700C600C500C400C300C
Symbol(s) lll
lll
lll
l l
ll
ll
lll l l l
Drying
Symbols Suitable for
dryer No Iron Sensitive /
Delicate dry
Do not dry
with dryer
Do not dry Do not dry-
clean
DRYING
Drying
Settings
At any temperature At high temperature At medium temperature At low temperature Without heating Hang to dry Lay to dry Hang wet to dry Lay in shadow to dry Dry-cleanable
Iron -
IRON Dry or Steam
Iron at high
temperature
Iron at medium
temperature
Iron at low
temperature
Do not iron Iron without steam Maximum temperature 200 0C150 0C110 0C
All bleaches are allowed
Bleach (sodium
hypochlorite)
can be used
Bleach is not
allowed
Only bleaches without
chlorine are allowed
BLEACH
Preparation

User’s Manual
Preparation

Energy efficiency will be improved by using lower temperature programmes and
appropriate detergents.
• Operatetheproductinthehighestcapacityallowedbytheprogrammeyouhave
selected, but do not overload; see, "Programme and consumption table". See,
“Programme and consumption table"
• Alwaysfollowtheinstructionsonthedetergentpackaging.
• Washslightlysoiledlaundryatlowtemperatures.
• Usefasterprogrammesforsmallquantitiesoflightlysoiledlaundry.
• Donotuseprewashandhightemperaturesforlaundrythatisnotheavilysoiledor
stained.
• Ifyouplantodryyourlaundryinadryer,selectthehighestspinspeedrecommended
during washing process.
• Donotusemoredetergentthantherecommendedonthedetergentpackaging.
Preparation

The maximum load capacity depends on the type of laundry, the degree of soiling
and the desired washing programme.
The product automatically adjusts the water amount according to the weight of the
laundry put inside it.
Laundry type Weight (g) Laundry type Weight (g)
Bathrobe 1200 Hand towel 100
Fabric napkin 100 Women‘s night
gown 200
Bed sheet 700 Underclothing 100
Bed sheet 500 Men’s overalls 600
Pillowcase 200 Men’s shirt 200
Tablecloth 250 Men’s pyjamas 500
Towel 200 Blouses 100

Washer-Dryer
C
INFORMATION
• Never leave the detergent drawer open while the
washingprogrammeisrunning!
• When using a programme without prewash, do not
put any detergent into the prewash compartment
(compartmentnr.“I“).
• Donotselectaprogrammewithprewashifyouareusing
adetergentbagordispensingball.Placethedetergent
bagorthedispensingballdirectlyamongthelaundryin
themachine.Removetheseifdrying
• WhenmachineisinDryingstep,donotaddanywashing
chemicals(Liquiddetergent,Softener,etc.).

Before starting the washing Programme, put powder detergent into the
left compartment with number “II”. Powder bleach/stain remover must also be
put into this compartment.
Put the liquid detergent into the main wash compartment with number “II
” before starting the washing Programme. Liquid stain remover must be put into
this compartment.
Put the suggested amount of liquid detergent into the left compartment with “II
” symbol and dilute it to the maximum filling level line (max. II ) with warm water.
Particularly the concentrated detergents must be diluted with warm water;
otherwise, the siphon may get clogged in time.
Do not fill the detergent above the maximum filling level line; otherwise the excess
amount of detergent will reach the laundry without water and may cause stains on
the garments.In this case you will need to refill the compartment. Do not pour the
detergent onto the laundry directly since this may cause stains on the garments.

Put the suggested amount of liquid softener into the right compartment with “
” symbol and dilute it to the maximum filling level line (max. ) with warm water.
Particularly the concentrated softeners must be diluted with warm water;
otherwise, the siphon may get clogged in time.
Do not fill the softener above the maximum filling level line; otherwise the excess
amount of softener will get mixed with the washing water and you will need to refill
the compartment. Do not pour the softener onto the laundry directly since this may
cause stains on the garments.
Liquid softener will be dispensed automatically at the final rinsing step of the
washing Programme.

User’s Manual
Preparation

Put the powder pre-wash detergent or powder stain remover into the
middle compartment with number “I”.
You can also put liquid bleach into this compartment while the machine takes in
water during pre-wash or first rinsing step. Adding the liquid bleach while the
machine takes in water allows it to be diluted before it is poured onto the laundry.
You must select extra rinsing option if you use liquid bleach in a washing Programme.
Bleach must be removed from the laundry with rinsing; otherwise it may cause
itching on the skin.
C
INFORMATION
• Readthedosageinstructionsandlabelofyourgarments
carefullybeforeusingtheliquidbleach.
A
CAUTION
      

 

The amount of washing detergent to be used depends on the amount of laundry,
the degree of soiling and water hardness.
• Do not use amounts exceeding the dosage quantities recommended on the
detergent package to avoid problems of excessive foam, poor rinsing, financial
savings and finally, environmental protection.
• Uselesserdetergentforsmallamountsorlightlysoiledclothes.

• If the gel detergent thickness is fluidal and your machine does not contain a
special liquid detergent cup, put the gel detergent into the main wash detergent
compartment during first water intake. If your machine contains a liquid detergent
container, fill the detergent into this container before starting the programme.

Washer-Dryer

ae

g
h
i
a- Washing indicator
b - Rinsing indicator
c - Spinning indicator
d- Drying indicator
e- End indicator
f- No Water indicator
g - Duration Information display
h- Loading Door Lock indicator
i- Child Lock indicator

User’s Manual

1. Determine the programme suitable for the type, quantity and soiling level of the
laundry in accordance with the "Programme and consumption table".
2.Select the desired programme with the Programme Selection knob.
C
INFORMATION
• Programmes are limited with the highest spin speed
appropriateforthatparticulartypeoffabric.
• Whenselectingaprogramme,alwaysconsiderthetype
of fabric, colour, soiling level and permissible water
temperature.
• Always  select the lowest appropriate temperature.
Higher temperature means higher electricity
consumption.

Depending on the type of fabric, use the following main programmes.
C
INFORMATION
• Youcansetyoumachinetoswitchtodryingstepatthe
endofwashingcyclebypressingtheDryingbuttonafter
you have selected the washing programme for your
laundry.Eachtimeyoupressthebutton,infolineshows
atwhichstepthedryingprocesswilltakeplaceandthe
relevantsymbolwillturnon.Ifyouwant,bycontinuing
to press the button, you can perform drying for the
maximum period of time allowed by the machine for
drying.
• Symbolsinthedisplayareschematicandmaynotmatch
theproductexactly.
• Whenyouwillperformwashinganddryingbyusingthe
Dryingfunctionofyourmachine,loadmaximum5kgof
laundry into the machine. If you load excessively, your
laundrywillnotdryandmachinewilloperateforalong
timeandconsumemoreenergy.

Washer-Dryer

Use for your cotton laundry (such as bed sheets, duvet and pillowcase sets, towels,
bathrobes, underwear, etc.). Your laundry will be washed with vigorous washing
action for a longer washing cycle.
C
INFORMATION
• You can dry your laundry after the washing cycle
withoutanyinterruption(automaticortimeddryingcan
be performed after washing). For this, you must also
selecttheDryingfunctionbeforestartingthewashing
programme.
• According to the drying selections which you will add
to the washing programmes, you can see when the
programmewillendonthedisplayofthemachine.
• Ifyoudon'twantdryingtotakeplaceaftertheprogramme
you haveselected,pressand hold theDrying auxiliary
functionbuttonuntiltheDryinglightisturnedoff.

Use to wash your synthetic clothes (shirts, blouses, synthetic/cotton blends, etc.).
Your laundry will be washed with a gentle action for a shorter washing cycle when
compared to the Cottons programme.
For curtains and tulle, use the Synthetic 40˚C programme with prewash and anti-
creasing functions selected. As their meshed texture causes excessive foaming,
wash the veils/tulle by putting little amount of detergent into the main wash
compartment. Do not put detergent in the prewash compartment.
C
INFORMATION
• You can dry your laundry after the washing cycle
withoutanyinterruption(automaticortimeddryingcan
be performed after washing). For this, you must also
selecttheDryingfunctionbeforestartingthewashing
programme.
• According to the drying selections which you will add
to the washing programmes, you can see when the
programmewillendonthedisplayofthemachine.
• Ifyoudon'twantdryingtotakeplaceaftertheprogramme
you haveselected,pressand hold theDrying auxiliary
functionbuttonuntiltheDryinglightisturnedoff.

User’s Manual

Use to wash your woollen laundry. Select the appropriate temperature complying
with the tag of your clothes. Use appropriate detergents for woollens.
C
INFORMATION
• Dryingfunctioncannotbeselectedforthewoollenwash
programme.

Use to wash your normally soiled, durable cotton and linen laundry. Although it
washes longer than all other programmes, it provides significant energy and water
savings. Actual water temperature may be different from the stated washing
temperature. When you load the machine with less laundry (e.g. ½ capacity or less),
programme duration may automatically get shorter. In this case, energy and water
consumption will decrease more, providing a more economic wash. This programme
is available in the models with the remaining time indicator.
C
INFORMATION
• You can dry your laundry after the washing cycle
withoutanyinterruption(automaticortimeddryingcan
be performed after washing). For this, you must also
selecttheDryingfunctionbeforestartingthewashing
programme.
• According to the drying selections which you will add
to the washing programmes, you can see when the
programmewillendonthedisplayofthemachine.
• Ifyoudon'twantdryingtotakeplaceaftertheprogramme
you have selected, press and hold the Drying auxiliary
functionbuttonuntiltheDryinglightisturnedoff.

Use to wash your delicate laundry. Your laundry will be washed with more gentle
washing action compared to the Synthetics programme.

Washer-Dryer

Use to wash woollen/delicate laundry that bear “not machine-washable” care labels
and for which hand wash is recommended. Your laundry will be washed with a very
gentle washing action in order not to damage the clothes.

Use to wash your lightly soiled and unstained cotton laundry in a short time.
C
INFORMATION
• You can dry your laundry after the washing cycle
withoutanyinterruption(automaticortimeddryingcan
be performed after washing). For this, you must also
select the Drying function before starting the washing
programme.
• According to the drying selections which you will add
to the washing programmes, you can see when the
programmewillendonthedisplayofthemachine.
• Ifyoudon'twantdryingtotakeplaceaftertheprogramme
you have selected, press and hold the Drying auxiliary
functionbuttonuntiltheDryinglightisturnedoff.

Use it to wash a small amount of lightly soiled cotton laundry in a short time. This
programme washes your laundry in 14 minutes.
C
INFORMATION
• You can dry your laundry after the washing cycle
withoutanyinterruption(automaticortimeddryingcan
be performed after washing). For this, you must also
selecttheDryingfunctionbeforestartingthewashing
programme.
• According to the drying selections which you will add
to the washing programmes, you can see when the
programmewillendonthedisplayofthemachine.
• Ifyoudon'twantdryingtotakeplaceaftertheprogramme
you haveselected,pressand hold theDrying auxiliary
functionbuttonuntiltheDryinglightisturnedoff.

Washer-Dryer

Whenever a new programme is selected, the recommended temperature for the
programmeappearsonthetemperatureindicator.Itispossiblethattherecommended
temperature value is not the maximum temperature that can be selected for the
current programme.
Press the Temperature Adjustment button to change the temperature.
C
INFORMATION
• TemperatureAdjustmentbuttonworksonlybackwards.
For example, when you want to select 60 0C when the
display shows 40 0C you need to press the button for
severaltimesuntilyoureach600Cbygoingbackwards
from400C.
• IfyouscrolltoColdWashoptionandpressTemperature
Adjustment button again, the recommended maximum
temperature for the selected programme is displayed.
Press the Temperature Adjustment button again to
decreasethetemperature.
Finally, Cold light indicating the cold wash option appears on the display.
You can also change the temperature after the washing has started. You can select
the desired temperature after washing starts but you must do this before heating
step starts.

User’s Manual

Whenever a new programme is selected, the spin speed recommended for the
selected programme is displayed on the Spin Speed indicator.
C
INFORMATION
• Itispossiblethattherecommendedspinspeedvalueis
notthemaximumspinspeedthatcanbeselectedforthe
currentprogramme.
Press the Spin Speed Adjustment button to change the spin speed. Spin speed
decreases gradually.
Then, depending on the model of the product, "Rinse Hold" and "No Spin" options
appear on the display.
C
INFORMATION
• Spin Speed Adjustment button works only backwards.
Forexample,whenyouwanttoselect1000rpmwhen
thedisplayshows800rpm,youneedtopressthebutton
for several times until you reach 1000 rpm by going
backwardsfrom800rpm.
• Rinse Hold option is indicated with “ ” symbol and No
Spinoptionisindicatedwith“ ”symbol.

Washer-Dryer

- Adjust the Spin Speed.
- Press Start / Pause / Cancel button. The programme resumes. Machine drains
the water and spins the laundry.
If you want to drain the water at the end of the programme without spinning, use
No Spin function.
C
INFORMATION
• Inprogrammesthatdonotallowspinspeedadjustment,
when Spin Speed adjustment button is pressed, spin
speedlightdoesnotchangeandthebuzzerisheard.
You can also change the Spin Speed after the washing starts. You can select spin
speed by pressing spin speed adjustment button after washing has started but
before the spinning step.

When a new programme is selected, press Auxiliary Function Selection button to
adjust the drying option that is suitable for the selected washing programme.
C
INFORMATION
• In programmes that do not allow drying adjustment,
whenDryingauxiliaryfunctionbuttonispresseddrying
lightdoesnotchangeandthebuzzerisheard.
• Only for drying programmes, press Auxiliary Function
Selectionbuttontoadjustthesuitabledryingoption.
