Beko BSS-2201 TT User manual

Water Dispenser
User Manual
BSS-2201 TT

Please read this user manual first!
Dear Customer,
Thank you for preferring a Beko product. We hope that you get the best results from your product which
has been manufactured with high quality and state-of-the-art technology. Therefore, please read this
entire user manual and all other accompanying documents carefully before using the product and keep
it as a reference for future use. If you handover the product to someone else, give the user manual as
well. Follow all warnings and information in the user manual.
Symbol meanings
Following symbols are used in the various parts of this manual:
CImportant information and useful hints
about usage.
AWarning for hazardous situations with
regard to life and property.
This product has been manufactured in environmental friendly modern plants without
giving any harm to the nature.
Complies with the WEEE Regulation. Does not contain PCB.
Made in P.R.C.

3 / 11 EN
Water Dispenser / User Manual
CONTENTS
1 Important instructions for safety
and environment 4-5
1.1. General safety . . . . . . . . . . . . . . . . . . . 4
1.2 Compliance with the WEEE Regulation . . 5
1.3 Package information . . . . . . . . . . . . . . . 5
1.4 Things to be done for saving energy. . . . 5
2 Your Water Dispenser 6-7
2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . 6
2.1.1 Controls and parts . . . . . . . . . . . . . . . 6
3 Operation 8-9
3.1 Initial use . . . . . . . . . . . . . . . . . . . . . . . 8
3.1.1 Preparations to be one prior to the
initial use . . . . . . . . . . . . . . . . . . . . . 8
3.1.2 Installatıon guıdelınes. . . . . . . . . . . . . 8
3.2 Operatıon . . . . . . . . . . . . . . . . . . . . . . . 9
4 Cleaning and maintenance 10
4.1 Maintenance. . . . . . . . . . . . . . . . . . . . 10
5 Installation instructions 10
6 Troubleshooting 11
01M-8992981200-2315-01

4 / 11 EN
Water Dispenser / User Manual
1 Important instructions for safety and environment
This section includes safety ins-
tructions that will help ensure the
protection from risks of personal
injuries or materialistic damages.
Failure to follow these instructions
shall void the warranty.
1.1 General safety
•Read all instructions before using
the water dispenser.
•Never clean parts with flammable
fluids. The fumes can create a
fire hazard or explosion
•Do not store or use gasoline or
any other flammable vapors and
liquids in the vicinity of this or any
other water dispenser. The fumes
can create a fire hazard of exp-
losion.
•Do not use the bottle with any
crack, leakage or holes.
•The back of the product sho-
uld be put in shady places and
kept away from wall and high-
temperature elements. Please
also put the product away from
TV, video, or other valuables.
•Do not turn on “heating” switch
until water comes out of hot
water faucet to prevent any da-
mage on the heating tube.
•During operation keep it beyond
the children to avoid scald.
•Never turn on the heating switch
when there is no water.
•When carrying it, the angle of
inclination should be less than
45°.
•Adopt the ground wire to avoid
any electric shock.
•In the process of using, check the
water receptacle frequently. If the
water receptacle is full, please
pour the water out in time.
•Do not turn on and off the “coo-
ling” switch in three minutes to
protect the compressor and ex-
tend the compressor usage life.
•This appliance is not intended for
use by persons (including child-
ren) with reduced physicalsen-
sory or mental capabilities or lack
of experience and knowledge un-
less they have been given super-
vision or instruction concerning
use of the appliance by a person
responsible for their safety.
•Children should be supervised to
ensure that they do not play with
the appliance.
•House hold used only.
•If the supply cord is damaged,it
must be replaced by the manu-
facturer, its service agent or si-
milarly qualified persons in order
toavoid a hazard.

5 / 11 EN
Water Dispenser / User Manual
1 Important instructions for safety and environment
•Do not damage the refrigerant
circuit.
•To avoid a hazard due to insta-
bility of the appliance,it must be
fixed in accordance with the ins-
tructions.
1.2 Compliance with the WEEE
Regulation and Disposing of the
Waste Product
This product does not contain harmful
and forbidden materials described in the
“Regulation on the Control of the Waste
Electrical and Electronic Equipment” is-
sued by the T.R. Ministry of Environment
and City Planning. Complies with the WEEE Re-
gulation. This product has been manufactured
with high quality parts and materials which can
be reused and are suitable for recycling. There-
fore, do not dispose the product with normal do-
mestic waste at the end of its service life. Take it
to a collection point for the recycling of electrical
and electronic equipment. Please consult your
local authorities to learn the nearest collection
point. Help protect the environment and natural
resources by recycling used products.
1.3 Package information
Packaging materials of the product are
manufactured from recyclable materi-
als in accordance with our National En-
vironment Regulations. Do not dispose
of the packaging materials together with the do-
mestic or other wastes. Take them to the packa-
ging material collection points designated by the
local authorities.
1.4 Things to be done for saving en-
ergy
1. Do not pour hot water into the water dispenser.
2. Do not install your water dispenser under di-
rect sunlight or near heat emitting appliances
such as ovens, dishwashers or radiators.
3. Turn the appliance (power) off if you are not
going to use it for a long time or at nights as it
will not be used during the nighttime.

6 / 11 EN
Water Dispenser / User Manual
2 Your Water Dispenser
2.1 Overview
Values stated on the markings on the product or in the printed materials supplied with the product are the values obtained in laboratory in accor-
dance with relevant standards. Such values may vary depending on the usage of the product and the ambient conditions.
2.1.1 Controls and parts
1. Top cover
2. Heating indicator
3. Cooling indicator
4. Body
5. Hot water tap (Red)
6. Cold water tap (Blue)
7. Water receptacle
8. Heating button (Red)
9. Cooling button (Green)
10. Condenser
11. Drain plug
12. Power supply cord

7 / 11 EN
Water Dispenser / User Manual
2 Your Water Dispenser
A
WARNING: Do not damage the components of the cooling system. Service life is 7 years
(period of keeping available spare parts to be required for full functioning of the product).
This appliance is not suitable for use by the physically or mentally handicapped. These
people can use this appliance under the supervision of those that ensure their safety and
take care of them.
Model BSS-2201 TT
Product Category Water Dispenser
Hot water tank capacity (L) 1.2
Cold water tank capacity (L) 3.2
Heating capacity (L/H) 5.0
Cooling capacity (L/H) 2.0
Degree of the hot water (°C) 85-95
Degree of the cold water (°C) 5-10
Cooling Power (V/Hz) 100
Heating Power (W) 500
Height (cm) 96
Width (cm) 31
Depth (cm) 31
Power input (V/Hz) 220/60

8 / 11 EN
Water Dispenser / User Manual
3 Operation
3.1 Initial use
1. Remove all the packaging and label materials
and dispose of them pursuant to the local re-
gulations in force.
2. Clean the appliance before the initial use (see
"Cleaning and maintenance" section).
3. Make sure that the appliance is placed on a
balanced, flat, clean, dry and non slip surface.
3.1.1 Preparations to be done prior to
the initial use
1. Before connecting the appliance to the power
source. Let it stand upright for approximately
2 hours. This will reduce the possibility of
a malfunction in the cooling system from
handling during transportation.
2. Check and make sure the backside hot water
drainage hole cap is not leaked or broken.
3. The water dispenser is pre-cleaned at the
factory but the reservoir and water lines must
be flushed with fresh water before use as
follows:
4. Keep the unit unplugged.
5. Fill water tank with tap water full to capacity.
Wait for 5 minutes until water settles.
6. Push the hot water faucet until water comes
out, then stop the faucet.
7. Plug the dispenser into the electrical outlet.
We are ready to complete the first cycle.
In order to do that, wait for the hot water
to reach temperature in approximately 10
minutes, and then wait for the cold water
to reach temperature in other 40 minutes
approximately.
8. Unplug the dispenser from the electrical outlet.
Proceed to drain the water from the faucets
one at a time until no more water remains.
(Note: To facilitate this operation, use a large
container).
9. Then, drain any water left in the tanks by
opening the backside hot water drainage hole
cap, until all water drains completely. After
that, screw up the cap tightly.
10.Put the bottled purified or other dean water
on the top cover one minute.
11.Push water faucet buttons to insure water
flows from both faucets.
12.Plug dispenser again into the electrical
outlet.
13.Now you are ready to use your water
dispenser.
C
Your water dispenser has been
cleaned and sanitized before
leaving the factory, but in case
a taste problem develops, place
two tablespoons of baking soda
and add tap water. Fill water
tank again and repeat basic op-
erations, except turn hot water
function “OFF” to avoid leaving
residues in hot water tank.
3.1.2 Installatıon guıdelınes
1. Remove the exterior and interior packing.
2. Place your appliance on a floor that is strong
enough to support the dispenser when it is
fully loaded. The unit is provided with four
plastic feet. If it does not sit level on the floor,
adjust the front feet to level the unit well to the
floor.
3. Locate the appliance away from direct
sunlight and sources of heat (stove, heater,
radiator, etc.). Direct sunlight may affect the
acrylic coating and heat sources may increase
electrical consumption. Extreme cold ambient
temperatures may also cause the appliance
not to perform properly.
4. Allow 2 inches of space between the water
dispenser and the wall, which allows for
proper air circulation to cool the compressor.
5. Plug the appliance into an exclusive properly
installed-grounded wall outlet. Do not cut
or remove the third (ground) prong from
the power cord under any circumstances.
Any questions concerning power and/
or grounding should be directed toward a
certified electrician or an authorized products
service center.
6. This water dispenser is not recommended for
outdoor usage.

9 / 11 EN
Water Dispenser / User Manual
3 Operation
7. Do not locate the dispenser in the area where
the temperature may fall below freezing point
(0°C- 32°F).
8. Keep area around dispenser free of dust and
dirt.
9. Keep the reserve supply of water bottles away
from excessive heat and light.
3.2 Operatıon
1. Ambient temperature: 10 ~ 43°
2. Atmosphere 86 ~ 106kpa
3. When using the bottles holding ultra-pure wa-
ter, distilled water or space water with the so-
called clever lid, tear off the hygienic label on
the lid, place the bottles at the intake, then the
core of water guard will automatically open
the valve and seal it in the meantime, when
moving the bottles, the valve will also seal au-
tomatically to avoid any possible oozing.
4. Push the hot water faucet, bubbles are gene-
rated inside the bottle, indicating that water is
flowing into hot water and cold water tanks,
keep pressing the hot water valve until wa-
ter flows out, dispensing cold water required
need no particular adjustment.
5. Do not connect the electrical power plug, until
water comes out of the hot water faucet.
6. After plug, the yellow LED indicator will be on
indicating the power is “ON”.
7. Turn on the heating switch, the red LED indi-
cator will be on and the heating system starts
working. When the hot water comes up to 85-
95° or so, the red light goes off, the heating
system stops working. The machine turns to
the warm-keeping status. When the hot wa-
ter temperature is lower than 85°,the heating
system will resume working automatically.
8. Turn on the cooling switch, the green LED indi-
cator will be on and the cooling system starts
working. When the cold water falls down to
6-10°, the green light goes off, the cooling
system stops working. The machine turns to
the cold-keeping status. When the cold water
temperature goes up to a set degree, the coo-
ling system will resume working automatically.
9. Since the temperature has already been ad-
justed before leaving the factory, it is unne-
cessary for customers to set the temperature.
10.Turn the heating and cooling switches on.
Then the heating and cooling processes start
working together.
11.If the device is not applied for a long time,
after the hot water cools down, please remo-
ve the power plug and revolve the drain cap
to drain the rest water in the hot tank then
tighten the cap. Open the cold water faucet to
drain the rest water in the cold tank.
12.If there is no water flowing from cooling fau-
cet, please shut down the cooling switch until
there is water flowing out.
13.If you do not plan to use the water hea-
ting function for more than three days, we
strongly recommend that you turn off the hot
water function.

10 / 11 EN
Water Dispenser / User Manual
4 Cleaning and maintenance
4.1 Maintenance
1. Remove power plug or disconnect from the
mains before performing any maintenance or
servicing the product.
2. Never use detergent or chemicals harmful to
health to clean the water tanks.
3. Do not directly spray water on the surface of
the product.
4. Wipe the front and back of the product with
water-soaked soft cloth.
5. If dust of other exterior substance has
accumulated on the condenser, wipe off with
water-soaked soft cloth.
In order to ensure the water dispenser with
enough stability, users should follow below
instructions to fix the unit:
1. Remove on the body rear’s screw (upper right
corner or upper left corner) (Picture 1).
6. After cleaning the product, completely dry it. Fill
the water to the tanks until waters comes out of
the hot water faucet, then connect the electric
power plug. If the surface of the electric heater
in the hot water tank is deposited by water
deposition, heating capacity will decrease. Fill
hot water tank with aqueous solution of 2%
aitric acid and keep for about two hours then
cleaning. If the problems can not be solved,
contact your dealer or the Service Center of
our company.
7. If power supply cord on this device is damaged,
it must be replaced with a special power supply
cord that is obtainable at Service Center of our
company
CNever use gasoline, benzene or
similar substances for cleaning
purposes.
5 Installation instructions
2. Install a bracket where you have removed
the screw already, fix the bracket
tightening this removed screw on the
right location (Picture 2).
3. Fix the bracket on the wall side or similer
object (if the wall side is too rigidity), you
can make a hole by electric drill, then
using expanded screw tightening the
bracket (Picture 3).

11 / 11 EN
Water Dispenser / User Manual
6 Troubleshooting
You can solve many common water dispenser problems easily, saving you the cost of a possible ser-
vice call. Try the suggestions outlined below to see if you can solve them before calling the service
center.
Water dispenser does not operate.
• Not plugged in.
Water dispenser is not cold enough.
• Check to be sure the cold switch on the back is turned on.
• The water dispenser does not have enough backside space.
Water dispenser’s hot water is not hot enough.
• Check to be sure the hot switch on the back is turned on
Compressor turns on and off frequently.
• The room temperature is too hot.
• The water dispenser does not have enough backside space.
Vibration
• Make sure that the water dispenser is placed in a balanced manner.
Water dispenser is making a lot of noise during operation.
• Check to assure that the water cooler is placed level.
Water dispenser makes too much noise.
• As each cycle ends, you may hear gurgling sound caused by the flow of refrigerant, which is
normal.
• Contraction and expansion of the inside walls may cause popping and cracking noises.
• The water dispenser is not placed level.

www.beko.com
