Beko BSS 4600 TT User manual

Water Dispenser
User Manual BSS 4600 TT

Please read this user manual first!
Dear Customer,
Thank you for preferring a Beko product. We hope that you get the best results from your product which
has been manufactured with high quality and state-of-the-art technology. Therefore, please read this
entire user manual and all other accompanying documents carefully before using the product and keep
it as a reference for future use. If you handover the product to someone else, give the user manual as
well. Follow all warnings and information in the user manual.
Symbol meanings
Following symbols are used in the various parts of this manual:
CImportant information and useful hints
about usage.
AWarning for hazardous situations with
regard to life and property.
This product has been manufactured in environmental friendly modern plants without
giving any harm to the nature.
Complies with the WEEE Regulation. Does not contain PCB.
Made in P.R.C.

3 / 14 EN
Water Dispenser / User Manual
CONTENTS
1 Important instructions for safety
and environment 4-8
1.1. General safety . . . . . . . . . . . . . . . . . . . 4
1.2 Compliance with the WEEE Regulation . . 8
1.3 Package information . . . . . . . . . . . . . . .8
1.4 Things to be done for saving energy. . . . 8
2 Your Water Dispenser 9-10
2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . 9
2.1.1 Controls and parts . . . . . . . . . . . . . . . 9
3 Operation 11-12
3.1 Initial use . . . . . . . . . . . . . . . . . . . . . . 11
3.1.1 Preparations to be one prior to the
initial use . . . . . . . . . . . . . . . . . . . . 11
3.1.2 Things to be done in order to get
hot water . . . . . . . . . . . . . . . . . . . . 11
3.1.3 Things to be done in order to get
cold water. . . . . . . . . . . . . . . . . . . .11
3.1.4 Display Information . . . . . . . . . . . . . 12
3.1.5 There is no pump and water . . . . . . . 12
4 Cleaning and maintenance 13
4.1 Cleaning. . . . . . . . . . . . . . . . . . . . . . . 13
5 Troubleshooting 14

4 / 14 EN Water Dispenser / User Manual
1 Important instructions for safety and environment
This section includes safety ins-
tructions that will help ensure the
protection from risks of personal
injuries or materialistic damages.
Failure to follow these instructions
shall void the warranty.
1.1 General safety
•Do not use this product outdoors
or in the bathroom.
•We shall not be held responsible
or accept the warranty claims for
the damages arising from misuse
or inconvenient transportation of
the product.
•Do not disassemble the product.
We shall not accept the warranty
claims for the damages due to
misuse.
•Always use the appliance on a
balanced, flat, clean, dry and non
slip surface.
•This appliance must not be ope-
rated with an external timer or
a separate remote controller
system.
•Prior to operating your water
dispenser, please read the user
manual carefully that includes
important information such as
installation, usage and mainte-
nance of your product.
•Your Beko Water Dispenser
conforms to the valid safety
standards; therefore in order to
prevent any danger, when the
appliance or the power cable is
damaged, they must be repaired
or replaced by the authorized
service. Faulty or insufficient
repairing procedures might cause
dangers and risks to the user.
•Make sure that your mains power
supply is in conformity with the
information given on the rating
plate of the appliance. The only
way to disconnect the appliance
from the power supply is to unp-
lug it.
•Connect the appliance to a gro-
unded socket.
•Do not use it if the power cable or
the product is damaged.
•Do not use this product with an
extension cable.
•Before connecting it to power
and mounting its parts, dry the
product and all the parts of it.
•Do not touch the appliance or its
plug when your hands are damp
or wet.
•Place the product so that it can
always reach the electrical outlet.

5 / 14 EN
Water Dispenser / User Manual
1 Important instructions for safety and environment
•In order to prevent the power
cable from getting damaged,
make sure that it doesn't get
stuck, twisted or rub against
sharp surfaces. Keep the power
cable away from hot surfaces and
open flame.
•Make sure that the power cable
doesn't accidentally get unplug-
ged or someone doesn't trip over
the cable during the operation of
the appliance.
•If there is a breakdown after using
the product, unplug it.
•Always unplug the appliance
before cleaning and never clean it
while the appliance is being used.
•Never operate any part of this
appliance on or near hot surfaces
such as gas stoves, electric sto-
ves or heated ovens or place it on
these surfaces.
•Never use the appliance at or
near the places where there are
explosive or inflammable atmosp-
here or materials.
•The ambient temperature of the
room where your water dispen-
ser is placed must be between
10 - 43 ˚C. Operating your water
dispenser under cooler or warmer
conditions is not recommended
with regard to its efficiency.
•Leave an open space of minimum
15 cm. at the back of the water
dispenser to ensure proper ven-
tilation.
•If two water dispensers are to be
installed side by side, there sho-
uld be at least 2 cm distance bet-
ween them.
•Your water dispenser is supposed
to operate and stop without vib-
ration. Make sure that your water
dispenser is balanced on a hori-
zontal and steady surface. This
should be done before the water
bottle is placed.
•Your water dispenser is cleaned
at the manufacturing plant after
the production. Moreover, the
product is put into service after
being cleaned by our authorized
services with the Special Clea-
ning Agent during the installation.

6 / 14 EN Water Dispenser / User Manual
1 Important instructions for safety and environment
•Your water dispenser must be
cleaned every 3 months in order
to prevent the contaminations
that might occur during the use.
You may get this done by our aut-
horized service agents for a fee.
•When there is no water in the hot
water tank, do not turn the hea-
ting switch on.
•After the transportation, the
cooling switch must be turned
off for the first four hours.
•While using the product, do not
place a new bottle unless the
water in the bottle on the dispen-
ser is not completely finished.
This is required so that the water
level in the product remains ba-
lanced.
•If there isn't a function appara-
tus on the lid of the water bottle,
make notches on the center of
the bottle lid with a sharp tool
(knife, etc.) in order to ease the
water intake into the tanks.
•Place the water dispenser in a
shady area away from the elect-
ronics and valuables such as TV,
CD player or music system.
•Do not operate the damaged
water dispenser. Consult the ser-
vice.
•Do not use drilling or cutting tools
on the rear parts where the refri-
gerant of the water dispenser is
circulating. The refrigerant that
might blow out when the gas
channels of the condenser or
pipe extensions are punctured
may cause skin irritations and eye
injuries.
•Do not cover or block the product
with any material.
•Flammable items or products that
contain flammable gases (e.g.
spray) as well as the explosive
materials should never be kept
near the appliance.
•Do not tip the appliance at angle
of more than 45˚ during the trans-
portation or displacement.
•Do not use the bottles that leak
water due to cracks, holes, etc.
•In order not to damage the he-
ating system, never turn the he-
ating function on before water
comes out of hot water tap.
•Do not turn the heating function
on when there isn't a water bottle
placed on the appliance.
•Please drain the water in the drip
tray below the taps if they are fil-
led due to daily use.

7 / 14 EN
Water Dispenser / User Manual
1 Important instructions for safety and environment
•Do not turn the cooling function
on and off within time periods
less than 3 minutes. This is im-
portant in order to ensure a lon-
ger service life by protecting the
compressor.
•If you are not going to be using
the water dispenser for a long
time, completely drain the water
inside it. In order to completely
drain the water inside it after the
water coming out of the taps is
finished, open the drainage cover
at the back of the appliance and
wait until the water is finished.
•Water kept inside the appliance
for a long time might cause a bad
smell and if it is exposed to a cold
environment, it might cause the
deformation of the water tanks by
freezing.
•This product has been designed
for domestic and office use.
•The product you've purchased
has been designed to be used
only with "19l polycarbonate
water bottles".
•This product was produced to only
heat and cool drinking water. Do
not use it in order to cool ayran,
lemonade or alcoholic beverages.
•Do not use the appliance for pur-
poses other than its intended use.
•This product can be used by child-
ren at and above the age of 8 and
individuals with limited physical,
sensory or mental capacities or
people that do not have informa-
tion and experience on condition
that they are supervised or given
instructions for using the appli-
ance in a safe manner and that
they understand the dangers rela-
ted with the product use. Children
must not play with the product.
Cleaning and maintenance works
should not be performed by child-
ren unless they are supervised by
an adult.
•Suffocation hazard! Keep all the
packaging materials away from
children.
•Make sure that the appliance is
kept in a safe place away from the
reach of children.
•Do not allow children play with
the appliance. For instance, keep
it away from the reach of children
so that they do not get injured by
opening the hot water tap.

8 / 14 EN Water Dispenser / User Manual
1 Important instructions for safety and environment
1.2 Compliance with the WEEE
Regulation and Disposing of the
Waste Product
This product does not contain harmful
and forbidden materials described in
the "Regulation on the Control of the
Waste Electrical and Electronic Equip-
ment" issued by the T.R. Ministry of
Environment and City Planning. Complies with
the WEEE Regulation. This product has been ma-
nufactured with high quality parts and materials
which can be reused and are suitable for recy-
cling. Therefore, do not dispose the product with
normal domestic waste at the end of its service
life. Take it to a collection point for the recycling
of electrical and electronic equipment. Please
consult your local authorities to learn the nearest
collection point. Help protect the environment
and natural resources by recycling used pro-
ducts.
1.3 Package information
Packaging materials of the product are
manufactured from recyclable materi-
als in accordance with our National
Environment Regulations. Do not dis-
pose of the packaging materials together with
the domestic or other wastes. Take them to the
packaging material collection points designated
by the local authorities.
1.4 Things to be done for saving
energy
1. Do not pour hot water into the water dispen-
ser.
2. Do not install your water dispenser under di-
rect sunlight or near heat emitting appliances
such as ovens, dishwashers or radiators.
3. Turn the appliance (power) off if you are not
going to use it for a long time or at nights as
it will not be used during the nighttime.

9 / 14 EN
Water Dispenser / User Manual
2 Your Water Dispenser
2.1 Overview
Values stated on the markings on the product or in the printed materials supplied with the product are the values obtained in laboratory in accor-
dance with relevant standards. Such values may vary depending on the usage of the product and the ambient conditions.
2.1.1 Controls and parts
1. Hot water button with child lock
2. Ambient water button
3. Cold water button
4. On / Off indicator
5. Hot water indicator
6. Cold water indicator
7. Bottle empty indicator
8. Hot water tap
9. Ambient water tap
10. Cold water tap
11. Drip tray
12. Pump
13. Bottle lid
14. Bottle
15. Door
16. Door switch
17. Panel
18. Led lighting
19. Cold water switch (green)
20. Hot water switch (red)
21. LED lighting switch (blue)
21
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20

10 / 14 EN Water Dispenser / User Manual
2 Your Water Dispenser
A
WARNING: Do not damage the components of the cooling system. Service life is 7 years
(period of keeping available spare parts to be required for full functioning of the product).
This appliance is not suitable for use by the physically or mentally handicapped. These
people can use this appliance under the supervision of those that ensure their safety and
take care of them.
Model BSS 4600 TT
Product Category Water Dispenser
Hot water tank capacity (L) 1,1
Cold water tank capacity (L) 4
Heating capacity (L/H) 4
Cooling capacity (L/H) 2,5
Degree of the hot water (°C) 80 ~ 90
Degree of the cold water (°C) ≤10
Power (V/Hz) 220-240~, 50
Heating Power (W) 420
Cooling power (W) 100
Height (cm) 104
Width (cm) 31
Depth (cm) 36
Weight (kg) 18,5

11 / 14 EN
Water Dispenser / User Manual
3 Operation
3.1 Initial use
1. Remove all the packaging and label materials
and dispose of them pursuant to the local re-
gulations in force.
2. Clean the appliance before the initial use (see
"Cleaning and maintenance" section).
3. Make sure that the appliance is placed on a
balanced, flat, clean, dry and non slip surface.
3.1.1 Preparations to be done prior to
the initial use
1. Do NOT plug the water dispenser.
2. Check the drain cover at the back of the water
dispenser and make sure that it is tightly clo-
sed.
3. Place the water bottle in the bottom compart-
ment in a manner that the plastic hose will be
inside it. Place the bottle lid on the hose.
4. Plug the water dispenser.
5. Press the on/off button. Pump will automati-
cally start working. Wait 4 minutes until the
pump fills the tanks of the water dispenser.
6. Press the hot and cold taps until water comes
out of the taps.
7. After water comes out of the hot and cold
water taps, to produce hot water switch the
hot water button (20) found at backside of the
product to position 1.
8. To produce cold water, switch the cold water
button (19) found at backside of the product to
position 1.
9. To activate the LED lighting found under the
taps, switch the blue button (21) found on the
left of the backside of the product to position
1.
AWARNING: Do not push the
Hot/+ button until water comes
out of the hot water tap.
3.1.2 Things to be done in order to get
hot water
1. Turn the heating switch on. Hot water symbol
will be seen on the display and the heating
system will start operating.
2. Red light will be off when the hot water
reaches a temperature between 85˚- 95˚C.
Now you can get hot water from the hot
water tap. When the heating system stops,
the system keeps the water temperature at
the same level. When the water temperature
in the tank falls below 85˚C, heating system
automatically continues operating again.
A
WARNING: Water coming out of
the hot water tap might cause
injury to the user in case of direct
contact. Be careful. Pay special
attention when carrying hot
water in a glass or a container
in order to prevent injuries or
damages due to spillage.
3.1.3 Things to be done in order to get
cold water
1. To produce cold water, switch the cold water
button (19) found at backside of the product
to position 1.
2. Cold water symbol will be seen on the display
and the heating system will start operating.
3. Cold water symbol will disappear when the
cold water reaches a temperature between
6˚- 9˚C. Now you can get cold water from the
cold water tap.
4. When the cooling system stops, the system
keeps the water temperature at the same
level. When the temperature of the cold water
rises to the preset (factory settings) degree,
the cooling system automatically continues
operating again.
5. As the water temperature settings of your
product are done at the manufacturing plant,
you do not need to make any adjustments.

12 / 14 EN Water Dispenser / User Manual
3 Operation
6. If the appliance hasn't been used for a long
time, disconnect it from power after the
hot water cools down and drain the water
remaining in the hot water tank through the
drain channel by pushing the hot water tap.
7. Push the tap in order to drain the water in
the cold water tank, if water doesn't come out
of the cold water tap, please turn the cooling
switch off until water comes out.
3.1.4 Display Information
The degree of the hot water is shown at the right
of the display and the degree of the cold water is
shown at the left.
3.1.5 There is no pump and water
1. Press the ON/OFF button, the water dispen-
ser will switch to the idle mode. Pump symbol
appears on the display and the pump starts
working. When it reaches the water level, the
pump will stop working.
2. When the no water symbol is seen on the
display, the heating and cooling functions au-
tomatically stop. There is no water left in the
water bottle.
3. When putting water into the bottle, open the
door of the compartment, take the bottle out
by turning its collar. Place the new bottle in
the bottom compartment, put the lid on the
bottle and tighten it.

13 / 14 EN
Water Dispenser / User Manual
4 Cleaning and maintenance
4.1 Cleaning
1. Prior to cleaning, disconnect the power supply
of your appliance by unplugging it or turning
off the fuse.
2. Vapor and vaporized cleaning materials should
never be used for cleaning purposes, water
shouldn't be directly sprayed on the product.
In such cases, the vapor or water droplets
might get in contact with the electrical parts
in your appliance and cause short circuit or
electric shock.
3. Clean the outer surfaces of your appliance
with a soft cloth or sponge soaked with carbo-
nated warm water (soda). Wring well the cloth
or sponge before use. Never use scratching or
corrosive materials (thinner, bleaching liquid,
powder detergent).
4. Never use chemical substances or detergents
that are harmful to health while cleaning the
water reservoirs.
5. Vacuum-clean or brush the dusts at the back
of the appliance once a year. If the condenser
is covered with dust or foreign substances,
clean it with a soft cloth soaked in water.
6. Completely dry the appliance after cleaning.
7. The promotion label stuck on the door of your
appliance can be removed (period for remo-
ving is 1 year). To remove this label, pull it up
from one corner and pull towards the opposite
direction. If the label is torn into pieces, do not
scratch the remaining pieces; remove the re-
maining traces of the label by wetting with the
aid of a wet sponge.
CNever use gasoline, benzene or
similar substances for cleaning
purposes.

14 / 14 EN Water Dispenser / User Manual
5 Troubleshooting
Water dispenser isn't working.
• The appliance is not plugged into the socket.
• Fuse is blown or broke down.
Water coming out of the cold water tap isn't cold enough.
• Make sure that the cold water switch at the back is on.
• Water dispenser was not placed at a proper distance from the wall.
Water dispenser doesn't heat the water adequately.
• Make sure that the hot water switch at the back is on.
• There might be deposit formations (calcareous) on the surface of the heater in the hot water tank.
• Read the text regarding the cleaning of the water dispenser and put it into practice.
Compressor frequently starts and stops.
• Room temperature is above normal range.
• Water dispenser was not placed at a proper distance from the wall.
There is a vibration.
• Make sure that the water dispenser is placed in a balanced manner.
Water dispenser is making a lot of noise during operation.
• Noise might be due to the flow of the cooling agent.
• This is normal.
• You may hear a flowing sound at the end of each cycle.
• There might be rattling sounds due to the expansion and contraction arising from the heating and
cooling of the water tanks.
• Make sure that the water dispenser is placed in a balanced manner.

www.beko.com
