Beko WBI 1200 User manual

WBI 1200
Wine Cooler
Cave à vin
Resfriador de vinho

Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
For this, we recommend you to carefully read the entire manual of your product
before using it and keep it at hand for future references.
This manual
• Will help you use your appliance in a fast and safe way.
• Read the manual before installing and operating your product.
• Follow the instructions, especially those for safety.
• Keep the manual in an easily accessible place as you may need it later.
• Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful usage tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.
This product bears the selective sorting symbol for waste electrical and
electronic equipment (WEEE).
This means that this product must be handled pursuant to European Directive
2002/96/EC in order to be recycled or dismantled to minimize its impact on
the environment. For further information, please contact your local or regional
authorities.
Electronic products not included in the selective sorting process are potentially
dangerous for the environment and human heatlh due to the presence of
hazardous substances.
Recycling

EN
2
Contents
1 Your refrigerator 3
2 Warnings 4
General safety 4
Starting Up 5
If there are any children at home... 5
Intended use 5
Safety instructions 5
HCA Warning 5
3 Installation 6
Preparation 6
Points to be considered when re-
transporting your refrigerator 6
Before operating your refrigerator 6
Electrical connection 7
Disposing of the packaging 7
Disposing of your old refrigerator 7
4 Using your refrigerator 8
Temperature setting button 8
Defrost 8
Using the accessories 8
LED indicators and control panel 10
5 Maintenance and cleaning 11
Protection of plastic surfaces 11
Replacing the interior light module 11
6 Recommended solutions for the
problems 12

EN
3
1- Electronic control indicator panel
2- Odor filter
3- Wooden body shelf
4- Ceiling light
5- Bottle holder
1Your refrigerator
CFigures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
1
4
3
3
3
3
2
5

EN
4
2Warnings
Please examine the following
information. In case these are not
followed, personal injury or material
damage may occur. Then all warranty
and reliability commitments will
become invalid.
The usage life of the unit you
purchased is 10 years. This is the
period for keeping the spare parts
required for the unit to operate as
described.
General safety
• When you want to dispose/scrap
the product, we recommend you
to consult the authorized service in
order to learn the required information
and authorized bodies.
• Consult your authorized service for
all your questions and problems
related to the refrigerator. Do not
intervene or let someone intervene to
the refrigerator without notifying the
authorized services.
• Vapor and vaporized cleaning
materials should never be used in
cleaning and defrosting processes
of your refrigerator. In such cases,
the vapor might get in contact with
the electrical parts and cause short
circuit or electric shock.
• Never use the parts on your
refrigerator such as the door as a
means of support or step.
• Do not use electrical devices inside
the refrigerator.
• Do not damage the cooling circuit,
where the refrigerant is circulating,
with drilling or cutting tools. The
refrigerant that might blow out when
the gas channels of the evaporator,
pipe extensions or surface coatings
are punctured may cause skin
irritations and eye injuries.
• Do not cover or block the ventilation
holes on your refrigerator with any
material.
• Repairs of the electrical appliances
must only be made by qualified
persons. Repairs performed by
incompetent persons may create a
risk for the user.
• In case of any failure or during
a maintenance or repair work,
disconnect your refrigerator’s mains
supply by either turning off the
relevant fuse or unplugging your
appliance.
• Do not pull by the cable when pulling
off the plug.
• Place the beverage with higher
proofs tightly closed and vertically.
• Flammable items or products that
contain flammable gases (e.g.
spray) as well as the explosive
materials should never be kept in the
appliance.
• Do not use mechanical devices
or other means to accelerate the
defrosting process, others than those
recommended by the manufacturer.
• This unit you have purchased is
particularly environment-friendly.
• This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to
ensure that they do not play with the
appliance

EN
5
Starting Up
• Do not operate a damaged
refrigerator. Consult your service if
you have any doubts.
• Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
If there are any children at
home...
• Do not allow children play with
your refrigerator. They might harm
themselves and the refrigerator. (E.g.
do not allow them hang from the
door.)
Intended use
• This product is designed for
domestic use.
• It should not be used outdoors. It
is not appropriate to use it outdoor
even if the place is covered with a
roof.
Safety instructions
• Exposing the product to rain, snow,
sun and wind is dangerous with
respect to electrical safety.
• Contact the authorized service when
there is a power cable damage and
etc. so that it will not create a danger
for you.
• Caution: Never plug the refrigerator
into the wall outlet during installation.
Otherwise, risk of death or serious
injury may arise.
Things to be done for energy
saving
CDo not leave the doors of your
refrigerator open for a long time.
CDo not put hot food or drinks in your
refrigerator.
CDo not overload your refrigerator so
that the air circulation inside of it is
not prevented.
CDo not install your refrigerator
under direct sunlight or near heat
emitting appliances such as ovens,
dishwashers or radiators.
CPay attention to keep your food in
closed containers.
HCA Warning
If your product is equipped with
a cooling system that contains
R600a:
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
keep your product away from potential
fire sources that can cause the
product catch a fire and ventilate the
room in which the unit is placed.
Ignore the warning.
If your product is equipped with
a cooling system that contains
R134a.
You can see the gas used in
production of your product on the
rating plate that is located on the left
inner part of it.
Never dispose the product in fire.

EN
6
3Installation
CPlease remember that the
manufacturer shall not be held
liable if the information given in the
instruction manual is not observed.
Preparation
• Your refrigerator should be installed
at least 30 cm away from heat
sources such as hobs, ovens, central
heater and stoves and at least 5
cm away from electrical ovens and
should not be located under direct
sunlight.
• The ambient temperature of
the room where you install your
refrigerator should at least be 10°C.
Operating your refrigerator under
cooler conditions than this is not
recommended with regard to its
efficiency.
• Please make sure that the interior
of your refrigerator is cleaned
thoroughly.
• When you operate your refrigerator
for the first time, please observe the
following instructions during the initial
six hours.
- The door should not be opened
frequently.
- It must be operated empty without
any food in it.
- Do not unplug your refrigerator; if
a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
• Original packaging and foam
materials should be kept for future
transportations or moving.
Points to be considered
when re-transporting your
refrigerator
1. Your refrigerator must be
emptied and cleaned prior to any
transportation.
2. Shelves, accessories, crisper and
etc. in your refrigerator must be
fastened securely by adhesive tape
against any jolt before repackaging.
3. Packaging must be tied with thick
tapes and strong ropes and the
rules of transportation printed on the
package must be followed.
Please remember…
Every recycled material is an
indispensable source for the nature
and for our national resources.
If you wish to contribute to recycling
the packaging materials, you can
get further information from the
environmental bodies or local
authorities.
Before operating your
refrigerator
Before starting to use your refrigerator
check the following:
1- Is the interior of the refrigerator dry
and can the air circulate freely in the
rear of it?
2- Clean the interior of the refrigerator as
recommended in the “Maintenance
and cleaning” section.
3- Plug the refrigerator into the wall
outlet. When the door is open the
respective interior light will come on.

EN
7
4- You will hear a noise as the
compressor starts up. The liquid and
gases sealed within the refrigeration
system may also give rise to noise,
even if the compressor is not running
and this is quite normal. Air flow noise
can be heard with some products
when the fan inside of the product
operates. This is quite normal and is
not a fault.
5- Front edges of the refrigerator may
feel warm. This is normal. These
areas are designed to be warm to
avoid condensation.
Electrical connection
Connect your refrigerator to a
grounded socket which is being
protected by a fuse with the
appropriate capacity.
Important:
• The connection must be in
compliance with national regulations.
• The power cable plug must be easily
accessible after installation.
• Voltage and permitted fuse protection
are indicated in the “Specifications”
section.
• The specified voltage must be equal
to your mains voltage.
• Extension cables and multiway plugs
must not be used for connection.
BA damaged power cable must be
replaced by a qualified electrician.
BThe appliance must not be operated
before it is repaired! There is danger
of electric shock!
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose them of by
classifying them in accordance
with the waste instructions. Do not
dispose them of along with the normal
household waste.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old machine without
giving any harm to the environment.
• You may consult your authorized
dealer or waste collection center of
your municipality about the disposal
of your refrigerator.
Before disposing of your refrigerator,
cut out the electric plug and, if there
are any locks on the door, make them
inoperable in order to protect children
against any danger.

EN
8
4Using your refrigerator
Temperature setting button
The interior temperature of your
refrigerator changes for the following
reasons;
• Seasonal temperatures,
• Frequent opening of the door and
leaving the door open for long
periods,
• Food put into the refrigerator
without cooling down to the room
temperature,
• The location of the refrigerator in the
room (e.g. exposing to sunlight).
If you want to make the compartment
temperatures cooler or hotter, you can
change this by pressing the button of
the relevant compartment.
Defrost
It is normal that ice crystals build up
on the surface of the rear wall of your
refrigerator while it is operating. There
is no need to scrape of wipe them off.
Your refrigerator defrosts automatically.
Water resulting from the defrosting
passes from the water collection
groove and flows into the evaporator
through the drain pipe and evaporates
here by itself.
Using the accessories
Bottle holder
You can use this bottle holder to serve
the drinks on tables or counters.

EN
9
Useful information
1- Suggestions on opening time of the wine before it is tasted :
Normal quality wines Just before drinking
Quality white wines Approximately 10 minutes before
Young red wines Approximately 10 minutes before
Dense and mature red wines Approximately 3-60 minutes before
2- How long an opened wine can be stored?
Mouth of the wine bottles that you did not fully consume after opening and
intend to stored in order to drink later must be securely closed and the bottle
must be stored in a cool and dry place. Carbon dioxide in the wine mixes into
the air (evaporates) together with various valuable aromatic substances and
thus, the bouquet and taste of the wine lose its freshness.
Therefore, the best and the most enjoyable option is to completely consume
the opened wines and those at best time to drink.
However, wines that are securely closed can be stored in cool places with the
following periods (not advised).
Normal and quality white wines Normal and high quality red wines
%75 Full bottle 3 – 5 days 4 – 7 days
%50 Full bottle 2 – 3 days 3 – 5 days
Less 1 days 2 days
3- Suggested optimum service temperatures of some wines
6 °C Sweet white wines
6 – 8 °C Semidry white and sparkling wine
8 – 10 ° C Dry white and dry rose
16 – 18 ° C Dry red wines
Silver
Inner surfaces of the refrigerator are rendered antibacterial by means of the
silver-ion additive. Thus, growth and reproduction of bacteria on interior body
parts are prevented.

EN
10
Green LED (5): Lights up continuously
after plugging in your refrigerator.
Red LED (6): It warns you by lighting
up continuously when your refrigerator
starts to operate, if not enough cooling
effect is obtained, when the door of
your refrigerator remains open for a
long time and when excessive food is
loaded.
If the red LED lights up continuously
when the conditions stated in the
adjacent column do not exist, then call
our Authorized Service.
LED indicators and control
panel
LED indicators in the front section of
your refrigerator are intended to help
you in monitoring the operation of your
appliance.
Keep your food in the refrigerator in a
safe manner by monitoring and using
these LEDs and controls as explained
below:
Quick Cool Button (1): Used to cool
the food quickly. Compressor may not
operate immediately but after some
time when the button is pressed and
this is quite normal.
Thermostat Setting Button (2): Used to
set your refrigerator between minimum
and maximum values.
Temperature Indicator (3): Displays the
inner temperature of your refrigerator.
Orange LED (4): Lights up when the
quick cool button on the LED panel is
pressed. In this case, your refrigerator
operates continuously.
Press the button again when the food
you would like to quick cool comes
to the desired temperature and the
orange LED will turn off.

EN
11
5Maintenance and cleaning
A Never use gasoline, benzene or
similar substances for cleaning
purposes.
BWe recommend that you unplug the
appliance before cleaning.
• Never use any sharp abrasive
instrument, soap, household
cleaner, detergent and wax polish for
cleaning.
• Use lukewarm water to clean the
cabinet of your refrigerator and wipe
it dry.
• Use a damp cloth wrung out in
a solution of one teaspoon of
bicarbonate of soda to one pint of
water to clean the interior and wipe it
dry.
• Make sure that no water enters the
lamp housing and other electrical
items.
• If your refrigerator is not going to be
used for a long period of time, unplug
the power cable, remove all food,
clean it and leave the door ajar.
• Check door seals regularly to ensure
they are clean and free from food
particles.
• To remove door racks, remove all the
contents and then simply push the
door rack upwards from the base.
Protection of plastic
surfaces
• Do not put the liquid oils or oil-
cooked meals in your refrigerator
in unsealed containers as they
damage the plastic surfaces of your
refrigerator. In case of spilling or
smearing oil on the plastic surfaces,
clean and rinse the relevant part of
the surface at once with warm water.
Replacing the interior light
module
To change the light module of your
refrigerator, please call your Authorized
Service.

EN
12
6Recommended solutions for the problems
Please review this list before calling the service. It might save you time and
money. This list includes frequent complaints that are not arising from defective
workmanship or material usage.
Complaint Possible Reason Solution
The refrigerator
does not
operate
Is the refrigerator properly
plugged in?
Insert the plug to the wall
socket.
Is the fuse of the socket which
your refrigerator is connected to
or the main fuse blown out?
Check the fuse.
Condensation
on the side wall
of the fridge
compartment.
Very cold ambient conditions.
Frequent opening and closing
of the door. Highly humid
ambient conditions. Storage of
food containing liquid in open
containers. Leaving the door ajar.
Switching the thermostat to a
colder degree.
Decreasing the time the
door left open or using it less
frequently.
Covering the food stored in
open containers with a suitable
material.
Wipe the condensation using
a dry cloth and check if it
persists.
Compressor is
not running
Protective thermic of the
compressor will blow out during
sudden power failures or plug-
out plug-ins as the refrigerant
pressure in the cooling system
of the refrigerator has not been
balanced yet.
Your refrigerator will start
running approximately after
6 minutes. Please call the
service if your refrigerator does
not startup at the end of this
period.
The fridge is in defrost cycle. This is normal for a full-
automatically defrosting
refrigerator. Defrosting cycle
occurs periodically.
Your refrigerator is not plugged
into the socket.
Make sure that he plug is
inserted tightly to the wall
socket.
Are the temperature adjustments
correctly made?
There is a power failure. Call your electricity supplier.

EN
13
The fridge
is running
frequently or for
a long time.
Your new refrigerator may be
wider than the previous one.
This is quite normal. Large
refrigerators operate for a
longer period of time.
The ambient room temperature
may be high.
This is quite normal.
The refrigerator might have been
plugged in recently or might have
been loaded with food.
Cooling down of the
refrigerator completely may last
for a couple of hours longer.
Doors might have been opened
frequently or left ajar for a long
time.
The warm air that has entered
into the refrigerator causes the
refrigerator to run for longer
periods. Open the doors less
frequently.
Doors might have been left ajar. Check if the doors are tightly
closed.
The
temperatures
are too low
The temperature of your
refrigerator is adjusted to a very
low degree.
Adjust the temperature of your
refrigerator to a higher degree
and check.
The
temperatures
are too high.
The temperature of your
refrigerator is adjusted to a very
high degree.
Change the temperature of the
fridge or freezer until the fridge
or freezer temperature reaches
to a sufficient level.
Doors might have been opened
frequently or left ajar for a long
time.
Warm air rushes into the fridge
compartment when the doors
are opened. Open the doors
less frequently.
The door might be left ajar. Close the door completely.
The refrigerator might have been
plugged in recently.
Cooling down of the
refrigerator completely takes
time because of the size.
Noise
The operation
noise increases
when the
refrigerator is
running.
The operating performance
characteristics of the refrigerator
may change according to
the changes in the ambient
temperature.
It is normal and not a fault.

EN
14
Vibrations or
noise.
The floor is not even or it is weak.
The refrigerator rocks when
moved slowly.
Make sure that the floor is
level, strong and capable to
carry the refrigerator.
The noise may be caused by the
items put onto the refrigerator.
Such items should be removed
from the top of the refrigerator.
There are
noises like
liquid spilling or
spraying.
Liquid and gas flows happen in
accordance with the operating
principles of your refrigerator.
It is normal and not a fault.
Water/condensation in the refrigerator.
Condensation
on the inner
walls of
refrigerator.
Hot and humid weather increases
the condensation.
It is normal and not a fault.
The doors are ajar. Make sure that the doors are
closed completely.
Doors might have been opened
very frequently or they might have
been left open for along time.
Open the door less frequently.
Water/condensation outside the refrigerator.
Humidity
occurs on the
outside of the
refrigerator or
between the
doors.
The weather may be humid. This is quite normal in humid
weather. When the humidity
is less, condensation will
disappear.
Bad odor inside
the refrigerator.
Inside of the refrigerator must be
cleaned.
Clean the inside of the
refrigerator with a sponge,
warm water or carbonated
water.
Some containers or packaging
materials might be causing the
smell.
Use a different container or
different brand packaging
material.
Opening and closing of the doors

EN
15
The door(s)
is (are) not
closing.
Food packages may prevent the
door’s closing.
Replace the packages that are
obstructing the door.
The floor is not level or strong.
Make sure that the floor is
level and capable to carry the
refrigerator.

Veuillez d’abord lire la notice d’utilisation !
Chère cliente, cher client,
Nous espérons que votre produit, qui a été fabriqué dans des usines modernes
et vérifié au terme des procédures de contrôle de qualité les plus méticuleuses,
vous aidera efficacement.
Pour cette raison, nous vous conseillons de lire attentivement tout le manuel
d’utilisation de votre produit avant de vous en servir, et de le conserver ensuite
pour une utilisation ultérieure.
Le présent manuel
• Vous aidera à utiliser votre produit avec rapidité et sécurité.
• Lisez le manuel avant d’installer et de faire fonctionner votre produit.
• Respectez les instructions, notamment celles relatives à la sécurité.
• Conservez ce manuel dans un endroit facilement accessible car vous pouvez
en avoir besoin ultérieurement.
•En plus, lisez également les autres documents fournis avec votre produit.
Veuillez noter que ce manuel peut également être valide pour d’autres modèles.
Symboles et descriptions
Vous retrouverez les symboles suivants dans le présent manuel :
CInformations importantes ou astuces.
AAvertissement relatif aux conditions dangereuses pour la vie et la propriété.
BAvertissement relatif à la tension électrique.

FR
2
Table des matières
1 Votre réfrigérateur 3
2 Avertissements 4
Sécurité générale...............................4
Mise en marche.................................5
Si vous avez des enfants à la
maison... ...........................................5
Utilisation prévue ...............................5
Instructions de sécurité......................5
Avertissement HCA ...........................6
3 Installation 7
Préparation........................................7
Points à prendre en compte lorsque
vous transportez à nouveau votre
produit...............................................7
Avant de faire fonctionner votre
réfrigérateur.......................................7
Branchement électrique.....................8
Mise au rebut de l’emballage.............8
Mise au rebut de votre ancien
réfrigérateur.......................................8
4 Utilisation de votre
réfrigérateur 9
Bouton de réglage de la température.9
Décongélation ...................................9
Utilisation des accessoires.................9
Voyants DEL et bandeau de
commande......................................11
5 Entretien et nettoyage 12
Protection des surfaces en
plastique. ........................................12
Remplacement du module de
l’éclairage intérieur...........................12
6 Solutions recommandées
aux problèmes 13

FR
3
1- Bandeau indicateur de commande électronique
2- Filtre d’odeurs
3- Etagère en bois
4- Plafonnier
5- Range-bouteilles
1Votre réfrigérateur
C Les illustrations présentées dans cette notice d’utilisation sont schématiques
et peuvent ne pas correspondre exactement à votre produit. Si des pièces
présentées ne sont pas comprises dans le produit que vous avez acheté, elles
sont valables pour d’autres modèles.
1
4
3
3
3
3
2
5

FR
4
2Avertissements
Veuillez examiner les informations
suivantes: Si elles ne sont pas
respectées, des blessures
personnelles ou un dommage matériel
peut survenir. Dans ce cas, tout
engagement lié à la garantie et à la
fiabilité du produit devient invalide.
La durée de vie du produit que vous
avez acheté est de 10 ans. Il s’agit
ici de la période au cours de laquelle
vous devez conserver les pièces
de rechange nécessaires à son
fonctionnement.
Sécurité générale
• Avant de vous débarrasser de
votre appareil, veuillez consulter les
autorités locales ou votre revendeur
pour connaître le mode opératoire et
les organismes agréés de collecte.
• Consultez le service après-vente
agréé concernant toutes questions
ou problèmes relatifs au réfrigérateur.
N’intervenez pas ou ne laissez
personne intervenir sur le réfrigérateur
sans le communiquer au service
après-vente agréé.
• La vapeur et des matériaux de
nettoyage pulvérisés ne doivent
jamais être utilisés pour les processus
de nettoyage ou de dégivrage de
votre réfrigérateur. La vapeur pourrait
pénétrer dans les pièces électriques
et provoquer des courts-circuits ou
des électrocutions.
• Ne jamais utiliser les pièces de votre
réfrigérateur telles que la porte,
comme un support ou une marche.
• N’utilisez pas d’appareils électriques
à l’intérieur du réfrigérateur.
• N’endommagez pas le circuit
de refroidissement où circule le
liquide réfrigérant avec des outils
de forage ou coupants. Le liquide
réfrigérant qui pourrait s’échapper
si les canalisations de gaz de
l’évaporateur, les rallonges de tuyau
ou les revêtements de surface
étaient percés, peut irriter la peau et
provoquer des blessures aux yeux.
• Ne pas couvrir ou obstruer les orifices
de ventilation du réfrigérateur.
• Les réparations de l’appareillage
électrique doivent être réalisées
par des techniciens qualifiés.
Les réparations réalisées par des
personnes ne présentant pas les
compétences requises peuvent
présenter un risque pour l’utilisateur.
• En cas de dysfonctionnement ou
lors d’opérations d’entretien ou de
réparation, débranchez l’alimentation
électrique du réfrigérateur soit en
désactivant le fusible correspondant,
soit en débranchant l’appareil.
• Ne tirez pas sur le câble lorsque vous
débranchez la prise.
• Placez les boissons alcoolisées
verticalement, dans des récipients
convenablement fermés.
• Les articles inflammables ou les
produits contenants des gaz
inflammables (par ex. : aérosols)
ainsi que les matériaux explosifs ne
doivent jamais être conservés dans
l’appareil.
• N’utilisez pas d’outils mécaniques ou
autres dispositifs pour accélérer le
processus de décongélation autres
que ceux qui sont recommandés par
le fabricant.
• Le présent produit que vous
avez acheté est particulièrement
écologique.
