Frigidaire FFWC38F6LS User manual

FFWC38F6LS Cover.jpg FFWC38F6LS Parts.eps LFWC38F6LS Wiring
Diagram.tif
Product No. FFWC38F6LS
Series Frigidaire
Market North America
Color glass/steel
Volts 115
Owner's Guide 242101900
Frigidaire
P.O. BOX 8020
CHARLOTTE, NC 28262
Publication No.
5995573317
10/09/10
(EN/SERVICE/KC)
099
WINE COOLER
Model No.
FFWC38F6L

Publication No: 5995573317 FFWC38F6LS
09/10 2
RECOMMENDED SPARES

FFWC38F6LS Publication No: 5995573317
# Functional Parts 3 09/10
* Non-Illustrated Parts
RECOMMENDED SPARES
POS. NO PART NO. DESCRIPTION
2 5304479779 Plug, hinge hole, cabinet
3 5304479780 Washer, top hinge
4 5304479781 Hinge, top
5 5304480019 Screw, tapping
6 5304479782 Cover, top hinge
7 # 5304479803 Lamp Assembly, LED
8 5304479804 Screw, tapping, stainless steal
9 5304479805 Cover, temp sensor
10 # 5304479806 Evaporator
11 5304479807 Screw, tapping, stainless steel
12 5304479874 Panel, divider, top
13 5304479875 Divider, styrofoam
14 5304480020 Screw, tapping
15 # 5304479935 Fan
16 5304479876 Panel, divider, bottom
17 5304479808 Gasket, door
18 5304479809 Plug, door hole
19 5304479810 Door Assembly, glass
20 5304479789 Bushing, hinge
21 5304479811 Screw, shoulder, door handle
22 5304479812 Handle Assembly, door
23 5304479813 Screw, tapping, door
24 5304479790 Stop, door
25 5304479791 Bracket, door switch
26 5304479814 Control Panel, console
27 5304479936 Push Button, light switch
28 5304479815 Cover, display board
29 # 5304479816 PC Board, input, display
30 5304479817 Screw, tapping
31 5304479818 Base, display board
32 5304479792 Hinge, bottom
33 5304479819 Foot, leveling screw, cabinet
34 5304479794 Button, push, light switch
35 5304479795 Latch, door
37 5304479820 Shelf, wine, wood
38 5304479821 Rack, removeable, bottom
39 5304479822 Cover, access, rear
40 5304480022 Screw, tapping
41 5304479823 Clamp, strain relief, power cord
42 5304479838 Sleeve, power wire
43 # 5304479824 Power Cord, electric
44 5304479825 Base
45 # 5304479826 Tube, adapter
46 # 5304479827 Compressor
47 5304479828 Pad, thermal mastic
48 5304479799 Tray, drip pan
49 # 218944002 Drier-filter, R134a System
50 # 5304479834 Wiring Harness, electrical
51 5304479835 Cover, control box
52 # 5304479836 PC Board, power, main

Publication No: 5995573317 FFWC38F6LS
09/10 4
WIRING DIAGRAM
