Gigabit Ethernet
ExpressCard
™

User Manual
F5U250
Add a Gigabit Ethernet port to your notebook computer
using ExpressCard technology
Gigabit Ethernet
ExpressCard
™

1. Introduction
......................................................................
1
Features
........................................................................
2
System Requirements
...................................................
3
Package Contents
.........................................................
3
2. Hardware Installation
......................................................
4
3. Verifying Proper Installation
...........................................
5
4. Troubleshooting
...............................................................
6
5. Information
......................................................................
8
Table of Contents

Congratulations and thank you for purchasing the Gigabit
Ethernet ExpressCard from Belkin. This ExpressCard
offers notebook users a fast and convenient way to add
a Gigabit Ethernet port that can take advantage of the
increased bandwidth and features the new ExpressCard I/O
interconnection standard delivers.
Why ExpressCard?
ExpressCard, the standard destined to replace CardBus,
quadruples your computing bandwidth. This results in
faster music downloads, smoother streaming video, and
lightning-fast access to mass-storage devices.
The ExpressCard provides the perfect solution for
simultaneously streaming movies and downloading video
from your camcorder to your hard drive—without risking
that your computer will freeze, crash, or slow to a trickle.
ExpressCard future-proofs your computer with technology
so advanced that it exceeds the processing speed of many
devices currently on the market. This means that installing
the ExpressCard now assures you of device-upgrade
expansion room for many years to come.
Please carefully review this User Manual so that you can
take full advantage of all the capabilities the Belkin Gigabit
Ethernet ExpressCard offers.
Introduction
1
2
3
4
5
1

2
Introduction
1
2
3
4
5
Features
• PCI Express Base Specification Revision 1.0a Compliance
• Single-lane (x1) PCI Express throughput support rates
of 2.5Gbps
• Compliance with 10/100/1000 IEEE 802.3 specification
• 10/100/1000M data-rate auto-negotiation
• Active state power management (L0s) support
• LEDs indicating data-transmission status
• Automatic MDI/MDIX crossover at all speeds
• Wake On LAN
®
(WOL) power management support
• Compliance with ExpressCard 34mm-wide
module specification
• 1 external, independent Gigabit Ethernet port

3
System Requirements
• Windows
®
based notebook with available ExpressCard slot
• Windows 2000, XP, Server 2003
Package Contents
• Gigabit Ethernet ExpressCard
• User Manual
• CD Driver
Introduction
1
2
3
4
5

4
1
2
3
4
5
1.
Locate your notebook’s ExpressCard slot(s).
2.
With your notebook on, slide the ExpressCard into the
unused 34mm ExpressCard bus slot.
Note: Do not plug any devices into the ExpressCard until
you have completely fi nished the driver installation.
3.
The “New Hardware Wizard” will launch and recognize
the ExpressCard.
4.
The Windows “Found New Hardware Wizard” will pop up.
Select “Yes, this time only” and click “Next”.
5.
The “Ethernet Controller” will be detected by your system.
Select “Install from a list or specific location (advanced)”
and click “Next”.
6.
Insert the CD driver into your CD-/DVD-ROM.
7.
Select “Include this location in the search” and click
“Browse” to specify the Gigabit Ethernet ExpressCard
driver located on the CD [<drive>:\Win 2000 or
WinXP&2003 (depending on your operating system)].
Then, click “Next”.
Note:
“<drive>” represents the
letter that identifies your CD-ROM driver under “My
Computer”—e.g., if the CD is in drive D, enter “D:\
WinXP&2003”.
8.
Windows will automatically install the correct driver.
Click “Finish” to finish driver installation.
9.
Installation is now complete and the ExpressCard is ready
to use.
LED Status Identification
• Green LED steady at 10/100Mbps
• Blue LED steady at 1000Mbps
Hardware Installation

5
Verifying Proper Installation
Check the “Windows Device Manager” to confirm that
your ExpressCard has been properly installed.
1.
Right-click on “My Computer” and select “Manage”.
2.
Select the “Device Manager” tab.
3.
Click the (+) sign next to “Network adapters”. The
“Network adapters” will now include one entry that
reads “Generic Marvell Yukon Chipset based Gigabit
Ethernet Controller”.
1
2
3
4
5

Troubleshooting
666
1
2
3
4
5
The ExpressCard and devices connected to the
computer do not work properly.
Please do the following:
1.
Check that all the cables you are using are the correct
types, and that they are all securely connected.
2.
Make sure all devices are powered on and connected to
the proper power supply and source.
3.
Reconnect daisy-chained devices you may have
disconnected for installation. If reconnecting does not
clear up the problem, restart your computer.
4.
Make sure you have properly installed the ExpressCard.
The computer did not detect the ExpressCard.
1.
Make sure that the ExpressCard is correctly plugged into
the ExpressCard slot; if not, plug it in securely.
2.
If the ExpressCard is plugged in correctly, see if its gold
connectors are clean; if not, clean the connector surface.
3.
Follow the procedure on page 5 titled “Verifying Proper
Installation”. If the ExpressCard designation “Generic
Marvell Yukon Chipset based Gigabit Ethernet Controller”
does not appear in the Device Manager, update your
computer BIOS to the latest version (contact your
computer manufacturer for details). If after updating
your BIOS, your computer still does not detect the
ExpressCard, contact your computer manufacturer for
advanced support for BIOS.

Troubleshooting
777
1
2
3
4
5
I cannot install the ExpressCard driver.
Ensure that your Microsoft Windows operating system
is upgraded to the latest “Service Pack” (please check
the Microsoft website). It is highly recommended that
you update your system to Windows 2000 service pack
4, Windows XP service pack 2, or Windows Server 2003
service pack 1 (or later).

888
Information
CE Declaration of Conformity
We, Belkin Corporation, declare under our sole responsibility that the F5U250, to
which this declaration relates, is in conformity with Generic Emissions Standard
EN55022:1998 Class B, EN50081-1, and with Generic Immunity Standard
EN50082-1:1992.
Belkin Corporation Limited Lifetime Product Warranty
What this warranty covers.
Belkin Corporation warrants to the original purchaser of this Belkin product
that the product shall be free of defects in design, assembly, material, or
workmanship.
What the period of coverage is.
Belkin Corporation warrants the Belkin product for the lifetime of the product.
What will we do to correct problems?
Product Warranty.
Belkin will repair or replace, at its option, any defective product free of charge
(except for shipping charges for the product).
What is not covered by this warranty?
All above warranties are null and void if the Belkin product is not provided to
Belkin Corporation for inspection upon Belkin’s request at the sole expense
of the purchaser, or if Belkin Corporation determines that the Belkin product
has been improperly installed, altered in any way, or tampered with. The
Belkin Product Warranty does not protect against acts of God (other than
lightning) such as flood, earthquake, war, vandalism, theft, normal-use wear
and tear, erosion, depletion, obsolescence, abuse, damage due to low voltage
disturbances (i.e. brownouts or sags), non-authorized program, or system
equipment modification or alteration.
DECLARATION OF CONFORMITY WITH FCC RULES FOR
ELECTROMAGNETIC COMPATIBILITY
We, Belkin Corporation, of 501 West Walnut Street, Compton, CA 90220,
declare under our sole responsibility that the product:
F5U250
to which this declaration relates:
Complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may
cause undesired operation.
FCC Statement
1
2
3
4
5

999
Information
How to get service.
To get service for your Belkin product you must take the following steps:
1. Contact Belkin Corporation at 501 W. Walnut St., Compton CA 90220, Attn:
Customer Service, or call (800)-223-5546, within 15 days of the Occurrence. Be
prepared to provide the following information:
a. The part number of the Belkin product.
b. Where you purchased the product.
c. When you purchased the product.
d. Copy of original receipt.
2. Your Belkin Customer Service Representative will then instruct you on how to
forward your receipt and Belkin product and how to proceed with your claim.
Belkin Corporation reserves the right to review the damaged Belkin product. All
costs of shipping the Belkin product to Belkin Corporation for inspection shall
be borne solely by the purchaser. If Belkin determines, in its sole discretion, that
it is impractical to ship the damaged equipment to Belkin Corporation, Belkin
may designate, in its sole discretion, an equipment repair facility to inspect
and estimate the cost to repair such equipment. The cost, if any, of shipping
the equipment to and from such repair facility and of such estimate shall be
borne solely by the purchaser. Damaged equipment must remain available
for inspection until the claim is finalized. Whenever claims are settled, Belkin
Corporation reserves the right to be subrogated under any existing insurance
policies the purchaser may have.
How state law relates to the warranty.
THIS WARRANTY CONTAINS THE SOLE WARRANTY OF BELKIN
CORPORATION, THERE ARE NO OTHER WARRANTIES, EXPRESSED
OR, EXCEPT AS REQUIRED BY LAW, IMPLIED, INCLUDING THE IMPLIED
WARRANTY OR CONDITION OF QUALITY, MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, AND SUCH IMPLIED WARRANTIES, IF ANY,
ARE LIMITED IN DURATION TO THE TERM OF THIS WARRANTY.
Some states do not allow limitations on how long an implied warranty lasts, so
the above limitations may not apply to you.
IN NO EVENT SHALL BELKIN CORPORATION BE LIABLE FOR INCIDENTAL,
SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR MULTIPLE DAMAGES
SUCH AS, BUT NOT LIMITED TO, LOST BUSINESS OR PROFITS ARISING OUT
OF THE SALE OR USE OF ANY BELKIN PRODUCT, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
This warranty gives you specific legal rights, and you may also have other rights,
which may vary from state to state. Some states do not allow the exclusion or
limitation of incidental, consequential, or other damages, so the above limitations
may not apply to you.
