User Manual
F5D8631-4
N1 MIMO Wireless
ADSL2+ Modem Router

Table of Contents
1. Introduction .................................................................. 1
Advantages of a Wireless Network ................................. 1
Placement of your N1 Wireless Modem Router ............... 3
2. Product Overview ......................................................... 7
Product Features ........................................................... 7
3. Knowing your Modem Router ......................................10
Package Contents ........................................................10
System Requirements ...................................................10
Setup Assistant Software System Requirements .............10
4. Connecting and Configuring your Modem Router ........14
5. Alternate Setup Method ...............................................23
6. Using the Web-Based Advanced User Interface ..........35
Changing LAN Settings ..................................................36
Viewing the DHCP Client List Page ............................... 38
Configuring the Wireless Network Settings ................... 38
Setting WPA Security .....................................................44
Setting WEP Encryption ................................................46
Using the Access Point Mode .......................................48
Setting MAC Address Control ....................................... 49
Configuring the Firewall ................................................51
Using Dynamic DNS ..................................................... 54
Utilities ........................................................................ 56
Restarting the Modem Router ....................................... 57
Updating the Firmware.................................................. 63
7. Manually Configuring Network Settings .......................71
8. Recommended Web Browser Settings .........................77
9. Troubleshooting............................................................79
10. Information ..................................................................95

2
Introduction
1
2
Thank you for purchasing the Belkin N1 MIMO Wireless ADSL2+ Modem
Router (the Modem Router). Following are two short sections—the first
discusses the benefits of home networking, and the other outlines best
practices that maximize your wireless home network range and performance.
Please be sure to read through this User Manual completely, and pay special
attention to the section entitled “Placement of your Wireless Networking
Hardware for Optimal Performance” on the next page. By following our
simple setup instructions you will be able to use your Belkin Home Network
to:
• Share one high-speed Internet connection with all the computers in
your home
• Share resources, such as files and hard drives among all the connected
computers in your home
• Share a single printer with the entire family
• Share documents, music, video, and digital pictures
• Store, retrieve, and copy files from one computer to another
• Simultaneously play games online, check Internet email, and chat
Advantages of a Wireless Network
Here are some of the advantages of setting up a Belkin Wireless Network:
• Mobility – you’ll no longer need a dedicated “computer room”—now
you can work on a networked laptop or desktop computer anywhere
within your wireless range
• Easy installation – Belkin’s Easy Installation Wizard makes setup simple
• Flexibility – set up and access printers, computers, and other
networking devices from anywhere in your home
• Easy expansion – the wide range of Belkin networking products let you
expand your network to include devices such as printers and gaming
consoles
• No cabling required – you can spare the expense and hassle of
retrofitting Ethernet cabling throughout the home or office
• Widespread industry acceptance – choose from a wide range of
interoperable networking products

2
1
Introduction
2
2
1
3
4
5
6
7
8
9
10
section
Revolutionary N1 Wireless Technology with MIMO (N1 MIMO)
Your Belkin N1 Wireless Modem Router uses a new smart-antenna
technology called Multiple Input Multiple Output (MIMO). N1 MIMO
complies with the IEEE draft 802.11n specification. It increases
speed, range, reliability, and spectral efficiency for wireless
networking systems.
The element that makes Belkin’s N1 MIMO technology different
from a conventional radio is the use of multiple antennas and two
simultaneous data streams to deliver wireless transfers around your
home or office. A conventional radio uses one antenna to transmit
a data stream. Belkin’s N1 MIMO, on the other hand, uses three
antennas. This design helps combat distortion and interference.
Belkin’s N1 MIMO is multidimensional. It builds on one-dimensional
smart-antenna technology by simultaneously transmitting two data
streams through the same channel, which increases
wireless capacity.
Another element that enhances Belkin’s N1 MIMO is the use of
aggregation as specified in the draft 802.11n specification.
By shortening the space between packets and combining multiple
smaller packets into one larger packet, Belkin’s N1 MIMO can
transmit more data through available bandwidth.
Think of conventional radio transmission as a two-lane highway. The
speed limit governs the maximum allowable flow of traffic through
that lane. Compared with conventional radios, one-dimensional smart
antenna systems help move traffic through that lane faster and more
reliably—analogous to a four-lane road on which traffic consistently
moves at a rate closer to the speed limit. Belkin’s N1 MIMO helps
traffic move at the speed limit and opens more lanes—to become the
superhighway in this example. The rate of traffic flow is multiplied by
the number of lanes that are opened.

43
Introduction
4
Introduction
Placement of your N1 MIMO Wireless Modem Router
Important Factors for Placement and Setup
Your wireless connection will be stronger the closer your computer is to
your Modem Router. Typical indoor operating range for wireless devices
is between 100 and 200 feet.
In the same way, your wireless connection and performance will degrade
somewhat as the distance between your Modem Router and connected
devices increases. This may or may not be noticeable to you. As you
move further from your Modem Router, connection speed may decrease.
Factors that can weaken signals simply by getting in the way of your
network’s radio waves are metal appliances or obstructions, and walls.
If you have concerns about your network’s performance that might be
related to range or obstruction factors, try moving the computer to a
position between five and 10 feet from the Modem Router in order to
see if distance is the problem. If difficulties persist even at close range,
please contact Belkin Technical Support.
Note: While some of the items listed below can affect network
performance, they will not prohibit your wireless network from
functioning; if you are concerned that your network is not operating at
its maximum effectiveness, this checklist may help.
1. Modem Router Placement
Place your Modem Router, the central connection point of your network,
as close as possible to the center of your wireless network devices.
To achieve the best wireless network coverage for your “wireless clients”
(i.e., computers enabled by Belkin Wireless Notebook Network Cards,
Wireless Desktop Network Cards, and Wireless USB Adapters):
• Ensure that your Modem Router’s networking antennas are parallel
to each other, and are positioned vertically (toward the ceiling).
If your Modem Router itself is positioned vertically, point the
antennas as much as possible in an upward direction.
• In multistory homes, place the Modem Router on a floor that is as
close to the center of the home as possible. This may mean placing
the Modem Router on an upper floor.
• Try not to place the Modem Router near a cordless 2.4GHz phone.

43
Introduction
Introduction
4
Introduction
2
1
3
4
5
6
7
8
9
10
section
2. Avoid Obstacles and Interference
Avoid placing your Modem Router near devices that may emit radio
“noise,” such as microwave ovens. Dense objects that can inhibit
wireless communication include:
• Refrigerators
• Washers and/or dryers
• Metal cabinets
• Large aquariums
• Metallic-based, UV-tinted windows
If your wireless signal seems weak in some spots, make sure that
objects such as these are not blocking the signal’s path (between
your computers and Modem Router).
3. Cordless Phones
If the performance of your wireless network is impaired after
attending to the above issues, and you have a cordless phone:
• Try moving cordless phones away from your Modem Router and
your wireless-enabled computers.
• Unplug and remove the battery from any cordless phone that
operates on the 2.4GHz band (check manufacturer’s information).
If this fixes the problem, your phone may be interfering.
• If your phone supports channel selection, change the channel on
the phone to the farthest channel from your wireless network.
For example, change the phone to channel 1 and move your
Modem Router to channel 11. See your phone’s user manual for
detailed instructions.
• If necessary, consider switching to a 900MHz or
5GHz cordless phone.
4. Choose the “Quietest” Channel for your Wireless Network
In locations where homes or offices are close together, such as
apartment buildings or office complexes, there may be wireless
networks nearby that can conflict with yours.
Use the Site Survey capabilities found in the Wireless Utility of your
wireless adapter to locate any other wireless networks that are
available (see your wireless adapter’s user manual), and move your
Modem Router and computers to a channel as far away from other
networks as possible.

65
Introduction
6
Introduction
• Experiment with more than one of the available channels, in order to
find the clearest connection and avoid interference from neighboring
cordless phones or other wireless devices.
• For Belkin wireless networking products, use the detailed Site Survey
and wireless channel information included with your wireless network
card. See your network card’s user guide for more information.
These guidelines should allow you to cover the maximum possible area
with your Modem Router. Should you need to cover an even wider area,
we suggest the Belkin Wireless Range Extender/Access Point.
5. Secure Connections, VPNs, and AOL
Secure connections typically require a user name and password, and
are used where security is important. Secure connections include:
• Virtual Private Network (VPN) connections, often used to connect
remotely to an office network
• The “Bring Your Own Access” program from America Online (AOL),
which lets you use AOL through broadband provided by another
cable or DSL service
• Most online banking websites
• Many commercial websites that require a user name and password
to access your account
Secure connections can be interrupted by a computer’s power
management setting, which causes it to “go to sleep.” The simplest
solution to avoid this is to simply reconnect by rerunning the VPN or
AOL software, or by re-logging into the secure website.
A second alternative is to change your computer’s power
management settings so it does not go to sleep; however, this may
not be appropriate for portable computers. To change your power
management setting under Windows, see the “Power Options” item in
the Control Panel.
If you continue to have difficulty with Secure Connections, VPNs, and
AOL, please review the steps above to be sure you have addressed
these issues.

65
Introduction
Introduction
6
Introduction
2
1
3
4
5
6
7
8
9
10
section
Free Tech Support*
You can find additional support information on our website
www.belkin.com/anz through the tech-support area.
If you want to contact technical support by phone, please call the
number you need from the list below*.
Australia - 1800 BELKIN
New Zealand - 0800 BELKIN

87
Product Overview
8
Product Features
In minutes you will be able to share your Internet connection and
network your computers. The following is a list of features that make
your new Belkin N1 Wireless Modem Router an ideal solution for your
home or small office network.
Works with Both PCs and Mac®Computers
The Modem Router supports a variety of networking environments
including Mac OS®8.x, 9.x, X v10.x, Linux®, Windows®98, Me, NT®,
2000, and XP, and others. All that is needed is an Internet browser
and a network adapter that supports TCP/IP (the standard language of
the Internet).
Patent-Pending Network Status Display
Lit LEDs on the front of the Modem Router indicate which functions are
in operation. You’ll know at-a-glance whether your Modem Router is
connected to the Internet. This feature eliminates the need for advanced
software and status-monitoring procedures.
Web-Based Advanced User Interface
You can set up the Modem Router’s advanced functions easily through
your web browser, without having to install additional software onto the
computer. There are no disks to install or keep track of and, best of all,
you can make changes and perform setup functions from any computer
on the network quickly and easily.
NAT IP Address Sharing
Your Modem Router employs Network Address Translation (NAT) to
share the single IP address assigned to you by your Internet Service
Provider while saving the cost of adding additional IP addresses to your
Internet service account.
SPI Firewall
Your Modem Router is equipped with a firewall that will protect your
network from a wide array of common hacker attacks including IP
Spoofing, Land Attack, Ping of Death (PoD), Denial of Service (DoS), IP
with zero length, Smurf Attack, TCP Null Scan, SYN flood, UDP flooding,
Tear Drop Attack, ICMP defect, RIP defect, and fragment flooding.

87
Product Overview
Product Overview
8
2
1
3
4
5
6
7
8
9
10
section
Integrated 10/100 4-Port Switch
The Modem Router has a built-in, four-port network switch to allow
your wired computers to share printers, data and MP3 files, digital
photos, and much more. The switch features automatic detection so it
will adjust to the speed of connected devices. The switch will transfer
data between computers and the Internet simultaneously without
interrupting or consuming resources.
Universal Plug and Play (UPnP)
UPnP is a technology that offers seamless operation of voice
messaging, video messaging, games, and other applications that
are UPnP-compliant.
Support for VPN Pass-Through
If you connect to your office network from home using a VPN
connection, your Modem Router will allow your VPN-equipped computer
to pass through the Modem Router and to your office network.
Built-In Dynamic Host Configuration Protocol (DHCP)
Built-In Dynamic Host Configuration Protocol (DHCP) on-board makes
for the easiest possible connection of a network. The DHCP server
will assign IP addresses to each computer automatically so there is no
need for a complicated networking setup.
Setup Assistant
The Setup Assistant, second generation of Belkin’s renowned Easy
Install Wizard, takes the guesswork out of setting up your Modem
Router. This automatic software determines your network settings for
you and sets up the Modem Router for connection to your Internet
Service Provider (ISP). In a matter of minutes, your Modem Router will
be up and running on the Internet.
Note: Setup Assistant software is compatible with Windows 2000 and
XP. If you are using another operating system, the Modem Router can
be set up using the Alternate Setup Method described in this User
Manual (see page 23).

Product Overview
Integrated N1 Wireless Access Point
N1 MIMO is an exciting new wireless technology based on the draft
IEEE 802.11n specification. It employs MIMO (Multiple Input Multiple
Output) smart-antenna technology that achieves data rates of up to
270Mbps.* Actual throughput is typically lower than the connected
data rate and will vary depending on your networking environment.
*NOTE: The standard transmission rate—270Mbps—is the physical
data rate. Actual data throughput will be lower.
MAC Address Filtering
For added security, you can set up a list of MAC addresses (unique
client identifiers) that are allowed access to your network. Every
computer has its own MAC address. Simply enter these MAC
addresses into a list using the Web-Based Advanced User Interface
and you can control access to your network.
109

Package Contents
• Belkin N1 Wireless ADSL2+ Modem Router
• Quick Installation Guide
• Belkin Setup Assistant Software CD
• RJ11 Telephone Cord
• RJ45 Ethernet Networking Cable
• Power Supply
• User Manual on CD
• Network Status Display Guide
• Wireless Security Setup Guide
System Requirements
• An active ADSL service with a telephone wall jack
for connecting the Modem Router
• At least one computer with an installed network interface adapter
• TCP/IP networking protocol installed on each computer
• No other DHCP server on your local network assigning IP addresses
to computers and devices.
• Internet browser
Setup Assistant Software System Requirements
• A PC running Windows®2000 or XP
• Minimum 500MHz processor and 128MB RAM
• Internet browser
Internet Connection Settings
The Setup Assistant contains a database of Internet Service Provider
(ISP) in each country to help you setup your Modem Router quickly. In
case your ISP is not on the list, please collect the following information
from your ISP before setting up the Modem Router
• Internet connection protocol: _________
(PPPoE, PPPoA, Dynamic IP, Static IP)
• Multiplexing method or Encapsulation: __________ (LLC or VC MUX)
• Virtual circuit: VPI (Virtual Path Identifier) __________
(a number between 0 and 255)
• VCI (Virtual Channel Identifier) __________
(a number between 1 and 65535)
• For PPPoE and PPPoA users: ADSL account user name _____________
and password _______________
• For static IP users: IP Address ___ . ___ . ___ . ___
Subnet Mask ___ . ___ . ___ . ___
Default Gateway Server ___ . ___ . ___ .
• IP address for Domain Name Server ___ . ___ . ___ . ___
(If given by your ISP)
Knowing your Modem Modem Router
10
section
2
1
3
4
5
6
7
8
9
10

1211
Knowing your Modem Router
12
The Modem Router has been designed to be placed on a desktop. All of
the cables exit from the rear of the Modem Router for better organization
and utility. The Network Status Display is easily visible on the FRONT of the
Modem Router to provide you with information about network activity and
status. See the Network Status Display Guide for more detailed information.
A. Wireless Security
OFF Wireless security is off
Solid Blue Wireless security is on
B. Wireless-Computer Status
OFF Wireless computer is not present
Solid Blue Wireless computer is connected to
the Modem Router
Blinking Amber Problem with wireless computer
connecting properly to the Modem Router
C. Wired-Computer Status
OFF Wired computer is not present
Solid Blue Wired computer is connected to
the Modem Router
Blinking Amber Problem with wired computer connecting
properly to the Modem Router
(A) (B) (C) (D/E) (F) (G)

1211
Knowing your Modem Router
Knowing your Modem Router
12
section
2
1
3
4
5
6
7
8
9
10
D. Modem Router/Power Status
When you apply power to the Modem Router or restart it, a short period
of time elapses while the Modem Router boots up. During this time, the
“modem router” icon blinks. When the Modem Router has completely
booted up, the “modem router” icon becomes a solid light, indicating the
Modem Router is ready for use.
OFF Modem Router is off
Blinking Blue Modem Router is booting up
Solid Blue Modem Router is on and ready
E. Wireless Status
OFF Wireless is off
Solid Blue Wireless is on
F. ADSL lineStatus
This icon lights in blue to indicate that your Modem Router is connected
properly to the ADSL line. It turns amber when problem is detected.
OFF Modem Router is NOT connected to a
functioning ADSL line
Solid Blue Modem Router is connected to an ADSL
line and functioning properly
Blinking Amber Problem with ADSL line
G. Internet Status
This unique icon shows you when the Modem Router is connected
to the Internet. When the light is off, the Modem Router is NOT
connected to the Internet. When the light is blinking amber, the Modem
Router is attempting to connect to the Internet. When the light is solid
blue, the Modem Router is connected to the Internet. When using the
“Disconnect after x minutes” feature, this icon becomes extremely
useful in monitoring the status of your Modem Router’s connection.
OFF Modem Router is NOT connected to the
Internet
Blinking Amber Modem Router is attempting to connect to
the Internet
Solid Blue Modem Router is connected to the Internet

1413
Knowing your Modem Router
14
H. Connection to ADSL line - Gray
This port is for connection to your ADSL line. Connect your ADSL
line to this port. A RJ11 telephone cord is provided in the package.
I. Connections to Wired Computers - Yellow
Connect your wired (non-wireless) computers to these ports. These
ports are RJ45, 10/100 auto-negotiation, auto-uplinking ports for
standard UTP category 5 or 6 Ethernet cable. The ports are labeled
1 through 4, with onboard LEDs on the connectors.
J. Reset Button
The “Reset” button is used in rare cases when the Modem Router
may function improperly. Resetting the Modem Router will restore
the Modem Router’s normal operation while maintaining the
programmed settings. You can also restore the factory default
settings by using the “Reset” button. Use the restore option in
instances where you may have forgotten your custom password.
i. Resetting the Modem Router
Push and release the “Reset” button. The lights on the Modem
Router will momentarily flash. The “Power/Ready” light will
begin to blink. When the “Power/Ready” light becomes solid
again, the reset is complete.
ii. Restoring the Factory Defaults
Press and hold the “Reset” button for at least 10 seconds, then
release it. The lights on the Modem Router will momentarily
flash. The “Power/Ready” light will begin to blink. When
the “Power/Ready” light becomes solid again, the restore is
complete.
K. Power Jack – Black
Connect the included 15V/1A DC power supply to this jack.
(K)
(I)(H) (J)

1413
Knowing your Modem Router Connecting and Configuring
your Modem Router
14
section
1
4
5
6
7
8
9
10
Verify the contents of your box. You should have the following:
• Belkin N1 Wireless ADSL2+ Modem Router
• RJ11 Telephone Cord
• RJ45 Ethernet Networking Cable
• Power Supply
• Belkin Setup Assistant Software CD
• User Manual
• Network Status Display Guide
• Wireless Security Setup Guide
Setup Assistant
Belkin has provided our Setup Assistant software to make installing
your Modem Router a simple and easy task. You can use it to get
your Modem Router up and running in minutes. The Setup Assistant
requires that your Windows 2000 or XP computer be connected
directly to your ADSL line and that the Internet connection is active
and working at the time of installation. If it is not, you must use the
“Alternate Setup Method” section of this User Manual to configure
your Modem Router. Additionally, if you are using an operating system
other than Windows 2000 or XP, you must set up the Modem Router
using the “Alternate Setup Method” section of this User Manual.
Step 1 Hardware Connections – Follow the Quick Installation
Brand New Setup
Follow these steps if you are not
replacing an existing modem. If you are
replacing an existing modem, go to the
next section.
A. Unpack your new Modem Router
from the box and place it next to
your computer. Raise the Modem
Router’s antennas.
3
2
modem router
computer

1615
Connecting and Configuring
your Modem Router
16
B. Retrieve the RJ-45 cable that comes
with your Modem Router. First
connect it to any yellow port labeled
“to Wired Computers” on the back of
your Modem Router. Then connect
the other end to the networking port
on the back of your computer.
C. Retrieve the RJ-11 phone core that
comes with your Modem Router.
Connect it to the gray port labeled
“to ADSL” on the back of your
Modem Router. Then connect the
other end to the wall jack you will
be using for ADSL, or into an ADSL
splitter if you are using that.
D. Plug your Modem Router’s power
supply into the black port labeled
“Power” on the back of your Modem
Router.
E. Wait 20 seconds for the Modem
Router to start up. Look at the
display on the front of the Modem
Router. Make sure the “Wired” and
“Modem-Router” icons are lit up in
blue. If they are not, recheck your
connections

1615
Connecting and Configuring
your Modem Router
Connecting and Configuring
your Modem Router
16
section
2
1
3
4
5
6
7
8
9
10
Replacing an Existing Modem or Modem Router
Follow these steps if you currently have a
modem or a modem router that you will be
replacing with your new Modem Router
A. Unpack your new Modem Router
from the box and place it next to
your old modem. Raise the Modem
Router’s antennas. Unplug old
modem’s power cord.
B. Locate the cable that connects your
old modem to your computer. Unplug
that cable from your old modem, and
plug it into any yellow port labeled
“to Wired Computers” on the back of
your new Modem Router.
C. Locate the cable that connects your
old modem to the ADSL wall jack.
Unplug it from your old modem and
then connect it to the gray port
labeled “to ADSL” on the back of
your Modem Router.
D. Plug your Modem Router’s power
supply into the black port labeled
“Power” on the back of your
Modem Router.
E. Wait 20 seconds for the Modem
Router to start up. Look at the
display on the front of the Modem
Router. Make sure the “Wired” and
“Modem-Router” icons are lit up in
blue. If they are not, recheck your
connections.
modem
modem router
computer

1817
Connecting and Configuring
your Modem Router
18
Step 2 Set Up the Modem Router – Run the Setup
A. Shut down any programs that are running on your computer at this time.
Turn off any firewall or Internet-connection-sharing software on your
computer.
B. Insert the CD into your computer. The Setup Assistant will
automatically appear on your computer’s screen within 15 seconds.
Click on “Go” to run the Setup Assistant. Follow the instructions there.
IMPORTANT: Run the Setup Assistant from the computer that is
directly connected to the Modem Router from Step 1 – B.
Note for Windows Users:
If the Setup Assistant does not
start up automatically, select your
CD-ROM drive from “My Computer”
and double-click on the file named
“SetupAssistant” to start the Setup
Assistant.

1817
Connecting and Configuring
your Modem Router
Connecting and Configuring
your Modem Router
18
section
2
1
3
4
5
6
7
8
9
10
Select Country
Select your country from the
drop-down box. Click “Begin” to
continue.
Confirmation Screen
Verify that you have completed all
QIG steps by checking the box to
the right of the arrow. Click “Next”
to continue.
Progress Screen
Setup Assistant will show you a
progress screen each time a step in
the setup has been completed.
1.1 Checking Settings
The Setup Assistant will now
examine your computer’s network
settings and gather information
needed to complete the Modem
Router’s connection to the Internet.
