Belleze Tristan Sideboard 014-HG-41018 User manual

Tristan Sideboard
www.belleze.com
[email protected]
1-800-682-6376
@bellezefurniture
FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-41018
The instruction booklet contains IMPORTANT
safety information. Please read it in full and
keep it for future reference.

2
LB
Estimated time for assembly:
Weight limitations are as follows:
180 mins
Scan this QR Code
to view our online tutorial
Maximum Load
70 lb
Maximum Load
20 lb
Maximum Load
10 lb

3v.03152022
Assemble the furniture on an empty carton, carpet, or rug to prevent scratches
or damage.
For safety, please keep pets and children away from the assembly area.
Ensure the product is fully assembled before use. If you are missing any
hardware or products, do not use it until you have restored the missing parts.
This furniture requires 2 people for assembly.
Read this instruction manual prior to assembly to familiarize yourself with the
various steps.
Lay out all components and hardware separately on a at surface and make
sure that no parts are missing or damaged before assembly. Do not destroy or
discard any packaging until you are certain that you have all the necessary parts
for assembly.
CAUTION
There are small components used in the construction of this product.
Loose items should be kept away from pets and children to avoid a choking
hazard.
Keep all plastic bags and packaging lm away from pets and children to avoid
su󰀨ocation.

4
PACKAGE CONTENTS
1
2
3
4
8
8
11
21
22
20
15
15
18
19
17
17
16
1614
14
23
13
13
11
12
10
9
7
7
6
5
2x

5v.03152022
PACKAGE CONTENTS
CODE DESCRIPTION QTY
1 Top Panel 1
2 Left Side Panel 1
3 Right Side Panel 1
4 Left Partition Panel 1
5 Right Partition Panel 1
6 Center Storage Shelf Panel 1
7 Adjustable Storage Shelf Panel 2
8 Cabinet Door 2
9 Center Upper Back Panel 1
10 Bottom Panel 1
11 Side Back Panel 2
12 Center Lower Back Panel 1
13 Long Base Panel 2
14 Short Base Panel 2
15 Side Leg #1 2
16 Side Leg #2 2
17 Support Leg 2
18 Drawer Front Panel 2
19 Drawer Left Panel 2
20 Drawer Right Panel 2
21 Drawer Back Panel 2
22 Drawer Bottom Panel 2
23 Drawer Crossbar 2

6
PACKAGE CONTENTS
34x 34x 36x 8x
24x
10x
4x 20x 8x
Ø6 x 30
Ø4 x 20 Ø4 x 14
Ø4 x 14
Ø3 x 14 Ø3 x 12
Ø4 x 30
Ø4 x 35
4x
8x
4x
8x
8x
2x
A
B
CD
E
F
GH
IJK
L
M
N
O

7v.03152022
PACKAGE CONTENTS
P
Q
R
T
U
VW
2x 14x 4x
4x 4x 1x 4x
Ø8 x 30

8
M2
M1
Required tools for assembly (Not included)
1
M
Seperate the drawer slide brackets from the slides

9v.03152022
5
2
4
Attach cam bolts on the partition panels.
8xA
A

10
3
NN
N N
Attach drawer slide brackets to the partition panel.
M2
M2
54
4x
8x
M2
N
Ø3 x 12

11 v.03152022
4
5
5
9
6
B
B
C
5
Attach the center upper back panel to the right partition panel.
Attach the center storage shelf panel to the right partition panel.
2xB
2x
2x
B
C

12
6
6
12
5
5
7
6
4
4
Attach the left partition panel to the center back panel and storage shelf panel.
Slide the lower back panel under the center storage shelf panel.
4x
2x
B
B
C
C

13 v.03152022
4x
4x
4x
4x
C
C
D
D
8
9
4
4
10
10
5
2
3
C
C
D
D
Attach the bottom panel under the partition panels.
Attach side panels to the bottom panel.
Ø4 x 35 Ø4 x 35

14
15
15
15
15
14
14
16
16
B
10
11
Attach cam bolts on the side legs.
Attach side legs on the short base panels.
8x
A
16
16
A
8xB

15 v.03152022
3
Q
13
13
2
C
C
10
R
12 Attach side legs to the long base panels.
Attach wood dowels underneath the bottom panel.
14
14
13
8x
8x
4x
4x
C
C
Q
R

16
14
Q
14
14
13
13
15
Attach the base under the bottom panel.
Secure the base to the bottom panel.
10x
4x
Q
W
W

17 v.03152022
2x
8x
J
J
K
K
16
17
17
17
Ø4 x 14
Attach two center support legs bracket on the bottom panel.
Attach support legs under the bottom panel.

18
T
19
18
11
11
Attach protective pad under the legs and cover the bolts on the legs.
Slide the side back panels into the sideboard.
4x
4x
T
U
U

19 v.03152022
1
20
21
Attach cam bolts underneath the top panel.
Attach the top panel to the sideboard.
A
1
8x
A
8x
8x
B
B
C
C

20
22
H
H
G
88
7
7
23 Attach door hinges to the cabinet doors.
4x
8x
8x
G
H
I
I
Ø4 x 14
Attach shelf pegs and put on the side storage boards.
