Belleze 014-HG-PS06 User manual

Propane Fire Bowl
item no. 014-HG-PS06
www.belleze.com
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide
which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space
such as a camper, tent, car or home.
If you smell gas:
•
•
•
•
Shut off gas supply to the appliance.
Extinguish any open flame.
lf odor continues, leave the area immediately.
After leaving the area, call your gas supplier
or fire department.
Failure to follow these instructions could result
personal injur y,or death.
in fire or explosion, which could cause property
damage,
WARNING: For Outdoor Use Only.
FIRE OR EXPLOSION HAZARD
Installation and service must be performed
by a qualified installer, service agency, or
the gas supplier.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
[e-mail]
1-800-682-6376
@bellezefurniture
FOLLOW US: CONTACT INFO: NOTE:
The instruction booklet contains IMPORTANT safety
information Please read and keep for future reference.
OFF

04
05-06
07
08
09
10

3
PACKAGE CONTENT
Fire bowl w/ gas line
LPG cylinder stabilizer Lava Rocks
SAFETY INFORMATION
Your safety and the safety of the others are very important.
This manual provides many important safety information. Always read and obey all
safety message.
DANGER
WARNING
CAUTION
You can be killed or seriously injured if you
failed to comply to the instruction immediately.
You can be killed or seriously injured if you
failed to comply to the instruction.
You can be injured if you failed to comply to the
instruction.
Keep this manual for future reference.
OFF

4
ASSEMBLY INSTRUCTION (Rocks Placement)
1
Open the bag containing small rocks and arrange the rocks in the burner area.
ATTENTION: Do not put more than 11 lb / 5 kg of rocks into the bowl.
ATTENTION: Do not touch or arrange the rocks when the product is in use or before the rocks
are fully cool down.
OFF

5
ASSEMBLY INSTRUCTION (LPG cylinder)
LPG cylinder used with the product must be:
• Constructed and marked in accordance with the for
petroleum gases standard, CAN/CSAB339, Cylinders,
Spheres, and Tubes for the Transportation of Dangerous Goods.
• Provided with a listed prevention device.
• Provided with a cylinder connection device compatible with the con-
nection for outdoor cooking appliances.
• Max capacity: 20lb.
• Max input: 58,000 BTU
• Max gas supply pressure: 250 PSI
• Not beyond 80% full
The use of an approved LPG cylinder stabilizing base is recommended in
order to prevent the LPG cylinder from tipping over.
Enclosures for Self-Contained LPG supply systems:
An enclosure for LPG cylinder shall be ventilated by openings at both the upper and lower levels
of the enclosure. This shall be accompanied by one of the following:
• One side of the enclosure shall be completely open.
For enclosure having four sides, a top and a bottom:
• At least two ventilation openings shall be provided in the sidewalls of the enclosure, located
within 5” (217mm) of the top of the enclosure, equally sized, spaced a minimum of 90°
(1.57 rad), and unobstructed. The opening(s) shall have a total free area of not less than 1”/lb
of stored fuel capacity.
• Ventilation opening(s) shall be provided at level of the enclosure and shall have a total
free area of not less than 1.27”/lb of stored fuel capacity. If ventilation openings at level
are in a side wall, there shall be at least two openings. The bottom of the openings shall be
1” or less from the level and the upper edge no more than 5” above the level. The
opening(s) shall be equally sized, spaced at a minimum of 90°(1.57 rad), and unobstructed.
• Every opening shall have minimum dimensions so as to permit the entrance of a 1/8” (3.2 mm)
diameter rod.
• Ventilation openings in sidewalls shall not communicate directly with other enclosure of the
appliance.
LIQUEFIED PETROLEUM GAS (LPG) SAFETY INFORMATION
• DO NOT store or use gasoline, liquid or vapors in the vicinity of the
bowl.
• Any petroleum gas (LPG) cylinder not connected for use shall not be stored
in the vicinity of the bowl.
WARNING
