BEMIS BioBidet BB-270 User manual

User Manual
BB-270

3
TABLE OF
CONTENTS
PRODUCT INFORMATION
Features...............................................................................5
Parts.......................................................................................7
Dimensions......................................................................8
PRODUCT INSTALLATION
Pre-Installation..............................................................9
Installation......................................................................10
PRODUCT OPERATION
How To Use.....................................................................15
MAINTENANCE
Cleaning............................................................................16
Short Term Non-Use................................................17
Warranty............................................................................18

5
•High-quality ABS material with full body panel
•Premium quality metal inlet and installation parts
•Continuous warm water
•Self clean
•Cold water bypass
•P.S.P.C technology
•Splash guarded nozzle
•Ambient temperature bidet wash
•Adjustable water pressure
•Unified internal brass valve
•Durable braided metal cold water hose
•No electricity or batteries required
•Adjustable toilet fit
•One-year warranty
FEATURES

6 7
Bidet attachment
PARTS
*2 T-Valves
3/8” - Hot
7/8” - Cold
25.5” Braided
metal hose
2 Protective O-rings
3 Toilet bumpers
*Alternate fittings available, contact [email protected]om
78.7” Hot
water hose
2 White washers

8 9
DIMENSIONS
7.87 in
17.30 in
0.47 in
3.41 in
2.73 in
8.00 in
5.51 in
8.07 in
4.88 in
9.56 in
3.51 in
0.46 in
PRE-INSTALLATION
Please be advised that the provided T-Valve
should be installed at the fill valve under the
toilet tank, NOT down at the water supply
coming from the wall.
Inspect your current water supply line that
connects to the toilet tank fill valve to ensure it
is a flexible water supply hose before installing
the BB-270. The hose needs to be 7/8” (to
connect to the T-Valve we provided) on one
end and either 3/8” or 1/2”, depending on your
wall valve, on the other end.
If you do not have access to the fill valve under
the toilet tank, contact Bio Bidet Customer
Service at 847.458.2334 and we may be able
to provide alternative fittings.
WARNING: Use care to avoid cross threading
or over tightening the connection. Over
tightening can cause leaking.
NOTICE: Observe all local plumbing, electrical
and building codes. This device is designed
for connection to a cold water source with
a pressure of 20-80 psi.

10 11
INSTALLATION
1. Remove the existing
toilet seat by locating the
bolts and nuts, typically
under a plastic cover, and
removing them first.
2. Close the water supply
valve and flush the toilet
completely so that there
is little to no water left in
the toilet tank.
3. Disconnect the water
hose from underneath
the toilet tank.
4. Connect the 7/8” T-Valve
to the toilet fill valve
where you just removed
the water hose from.
Make sure the rubber
washer is properly seated
with the narrow side up.
5. Attach the water supply
hose that comes from
the water shut off to the
bottom of the T-Valve.
6. Connect the 25.5” metal
hose we supplied
to the open side of
the T-Valve.
7. To install the hot water
line, close the water
supply valves underneath
your sink.
8. Disconnect the water
hose from your sink’s
hot water supply valve.

12 13
9. Connect the 3/8” T-valve
to the hot water
supply valve where
you just removed your
water hose. Make sure the
runner washer is included
into the connection.
10. Attach the water
supply hose that
comes from the water
shut off to the top
of the T-valve.
11. Connect the 78.7” metal
hose we supplied to the
open side of the T-valve.
12. Place the bidet on the
toilet with the mounting
brackets over the
bolt holes. Center the
bidet on the toilet so
that you can see the
bolt holes through the
mounting brackets
of the bidet. Place the
Protective O-rings under
the mounting bracket to
protect and secure the
bidet on the toilet.
O-rings
INSTALLATION (CONT.)
16. After installing your
bidet attachment, check
to see if there is a gap
between the toilet base
and toilet seat.
13. Place the toilet seat
back on the toilet over
the bidet and secure
the bolts down so that
the seat and bidet
attachment are stable.
14. Connect the hoses
from step 6 & 10 to
the corresponding
hot and cold bidet
water connections
underneath the
handle of the BB-270.
15. Slowly turn the water
supply valve back
on and check for leaks
and test the unit
for functionality.

14 15
INSTALLATION (CONT.)
17. If necessary, place
the bumpers on the
underside of your toilet
seat as indicated above.
If there are no immediate leaks, check again in
about 5-10 minutes and your BB-270 is ready
for use!
If any leaks occur, check all rubber washers and
make sure all connections are tight and secure.
CAUTION: Do not turn to the highest
temperature at once to prevent being
burned by hot water.
HOW TO USE
Water can spray when no one is sitting on the
seat. Do not activate the water until seated.
For feminine cleaning, turn the
function selection knob to the right towards
the “ “ position.
For self cleaning function, turn the
function selection knob to the left towards the
“ “ position.
For rear wash function, turn the function
selection knob to the middle towards the
“ “ position.
Adjust the water pressure control knob,
choose the comfortable pressure you want.
The water pressure control knob doesn’t reset
automatically, please turn it off manually.
Adjust the water temperature control knob
and choose the comfortable temperature
you want.

16 17
CLEANING SHORT TERM NON-USE
If the product will not be used for more than
a few days, it is highly recommended that the
water supply valve is turned off.
Your BB-270 is made with a high grade
fire-retardant ABS resin. Using hard cleaning
chemicals can weaken the material, causing
it to damage and develop cracks.
1. Clean the BB-270 by wiping the
surface area with a damp cloth regularly.
2. Do not use harsh detergents or any
cleaning tools with bristles on your bidet.
Steam cleaning is the preferred cleaning
method for your bidet. For a deep, chemical
free clean, consider the BioMist Bidet Cleaner.

18
WARRANTY
Your Bio Bidet is warranted against defects in materials or workmanship for
(1) year from the date of original purchase. Defective parts or a defective products
returned to Bio Bidet will be repaired with new or comparable rebuilt parts
or exchanged for a refurbished Bio Bidet as determined by Bio Bidet in their
sole discretion.
This limited warranty given by Bio Bidet covers all defects encountered
in normal use of Bio Bidet, and do not apply in the following cases:
1. Loss of or damage to Bio Bidet due to abuse, misuse, tampering. Mishandling,
improper packaging by you, alteration or fail to follow operating instructions.
2. Use of parts or supplies (other than those by Bio Bidet’s dealers)
that cause damage to Bio Bidet.
3. Replacement of discolored or stained parts caused by chlorine, bleach,
ammonia and other chemicals, cleaning supplies, oxidation,
normal wear and tear.
4. Damage to or malfunction of the unit as a result of
improper and negligent installation.
5. Any and all damages to plumbing, walls, floors, ceiling and personal
properties resulting from water leaks or breakage. The product must be used
at the user’s own risk. Therefore, the owner hereby releases the manufacturer
and distributor from any and all claims for damages where the above
condition exits.
No implied warranty, including any implied warranty of merchantability or fitness
or a particular purpose, applies to BBC Innovation LLC bidet after the applicable
period of the express limited warranty stated above, and no other express warranty
or guarantee, except as mentioned above, given by any person or entity with
respect to Bio Bidet shall bind Bio Bidet, (Some States and provinces do not allow
limitations on how long an implied warranty, so the above limitation may not apply
to you) BBC Innovation LLC shall not be liable for revenues or profits, inconvenience,
expense for substitute equipment or service, or any other special, incidental or
consequential damages caused by the use or misuse of, or inability to use, Bio
Bidet, regardless of the possibility and foresee-ability of such damages. In no
event shall recovery of any kind against BBC Innovation LLC be greater in amount
than the purchase price of the product and causing the alleged damage. Without
limiting the foregoing, you assume all risk and liability for loss, damage or injury to
you and your property and to others and their property arising out of use or misuse
of, or inability to use, the Bio Bidet not caused directly by the negligence or BBC
Innovation LLC. This limited warranty shall not extend to anyone other than the
original purchaser of the Bio Bidet.

Thank You
Technical Support/Customer Service
7900 S Route 31 Crystal Lake, IL 60014
T: 847.458.2334
U.S TOLL FREE: 877.339.5214
[email protected]om
www.biobidet.com
