Benibela JT101M-B02 User manual

说明书
尺寸：200*140mm
材质：128g哑面铜板纸
印刷：彩色印刷，打钉

Get 24/7 Assistance at
Or Visit: https://benibela.afterservice.vip
Use camera or QR scanner to scan
E-mail: [email protected]
https://benibela.afterservice.vip
E-mail: [email protected]
BB
To love and
To be loved
User Manual
JT101M-B02
10.1

Benibela
Quick Start Guide
To love and to be loved
To love and to be loved
Scan to Extend Warranty to 12+6 MONTHS!
Email: [email protected]
Or Visit: https://benibela.afterservice.vip
Get 24/7 Assistance at
Or Visit: https://benibela.afterservice.vip
Use camera or QR scanner to scan
E-mail: [email protected]
After-sales service

Step 3:
Step 1:
Step 2:
Preload photos, videos and a gift message
Tear to scan the back gift setup code
Download vphoto App
How to setup the gift by giver
Receiving as a gift
Please do not scan the gift setup code on the box; it is not intended for the gift recipient.
Instead, follow the user manual to set up your frame and/or vist
https://benibela.afterservice.vip if have any inquiries.
Gift Setup–Giving and Receiving
What is gift Setup?
Gift Setup feature allows you to preload photos, videos and a gift message onto the frame
before you give it to the recipient. The recipient can get the message and preloaded
photos/videos after the frame was connected to WiFi. 3
4
13
21
21
25
27
26
8. Technical Specification
1.
2.
3.
4.
5.
6.
7.
9.
Contents
Frequently Asked Questions

1 piece
1 piece
1 piece
1 piece
1. 10.1'' Digital Photo Frame
2. AC/DC Adapter
4.
5.
User Manual
Micro USB Cable
3. Bracket
1 piece
8
5
6
7
8. Micro SD card slot
7. DC IN
6. USB
5. Micro USB
1. Motion sensor lens
2. Frame bracket
3. Wall mounted hole
4. Speaker
E-mail: [email protected] E-mail: [email protected]https://benibela.afterservice.vip https://benibela.afterservice.vip
01 02
JT101M-B02
PACKAGE CONTENTS
FRAME OVERVIEW
FRAME OVERVIEW

E-mail: [email protected] E-mail: [email protected]https://benibela.afterservice.vip https://benibela.afterservice.vip
03 04
UPLOADING PHOTOS AND VIDEOS
Upload Photos and Videos Via VPHOTO App
Please download and install the VPhoto app on your mobile device by searching VPhoto
on the App Store or Google Play.
2. Create an Account
After opening the VPhoto app, please set your user name and your profile photo.
3. Pair Your Frame via the App
You will be required to enter the connection code or scan the QR code of your frame. It’s in
[Settings→ My Frame] on your frame. Once the process is completed, you will see a pop-up
message [Bind success].
Notes:
① Connection code is a 9-digit series number which can be found in your frame,
[device main interface→Settings →My frame].
② The connection code and QR code will refresh every 12 hours.
③ Before you view the connection code and QR code, please make sure your frame is
connected to Wi-Fi, otherwise the connection code and QR code will not load out.
1. Download the VPhoto App
1. Plug in Your Frame
Plug the socket in the back and connect the photo frame to a power source. The frame will
power on in seconds. You can place the frame either in landscape or portrait mode
(we recommend you place it in landscape mode during the first setup).
2. Initial Settings
There are several initial settings (Language, Wi-Fi, Nickname, City, Timezone, etc.) when you
enter the system for the first time.
3. Connect to Wi-Fi
You can connect to Wi-Fi during the initial settings or under the Wi-Fi setting. Select the Wi-Fi
network you would like to connect to and enter the correct password if required. If your Wi-Fi
network is not on the list, restart the router or move your frame closer to your router, wait for
seconds and check it again.
Notes:
①The photo frame supports 2.4GHz Wi-Fi networks only.
②A private Wi-Fi network is highly recommended.
GETTING STARTED

https://benibela.afterservice.vip https://benibela.afterservice.vipE-mail: [email protected] E-mail: [email protected]
05 06
4. Upload Photos and Videos to Your Frame
After connecting the app to your frame, you can start adding photos and videos to your frame
anywhere and anytime as below two ways:
① Select the photos or videos of your albums of your phone to upload and choose the frame
to send. Click the Next Step, you can write caption for each photo and choose the frame
you want to send. Click the right arrow icon to confirm.
② Click Camera icon to take new photos or videos and choose the frame you would like to
send to. Click the right arrow icon to confirm. The photo frame will receive the photos or
videos in seconds, and you can check the photo or video library on the frame.
Notes:
① If the frame didn’t receive the photos or videos, please reboot the product or check
the Wi-Fi network.
② Each video clip is limited to 200MB.
UPLOADING PHOTOS AND VIDEOS

https://benibela.afterservice.vip https://benibela.afterservice.vipE-mail: [email protected] E-mail: [email protected]
07 08
5. Invite Your Families & Friends to Connect Your Frame
Your families and friends can share their happy moments to your frame by following steps:
① Download and install the app.
② After opening the app, please set user name and profile photo.
③ Get the connection code shared by you to connect to your frame.
④ Start sending the photos and videos to your frame.
Here are two ways to share you connection code:
① Take a picture of the connection code on the frame to send.
② Open your VPhoto app, click More icon on the upper left corner and choose
Connected Device, select the frame you want your friend to connect, click the
Share icon. You will receive a picture of QR code and Connection code. Send
this to your families and friends.
Notes:
Connection Code is a 9-digit series number which can be found in your frame,
[device main interface→Settings →My frame].
UPLOADING PHOTOS AND VIDEOS

https://benibela.afterservice.vip https://benibela.afterservice.vipE-mail: [email protected] E-mail: [email protected]
09 10
UPLOADING PHOTOS AND VIDEOS
Upload Photos and Videos Via Email
You and your friends can also send photos and videos to the frame via your Email.
1. Connect your Email address to the frame via two methods:
① By pressing [+] in [User Management], and then add mailboxes, you will receive an
email to inform your binding request is completed and the way to send photos and
videos to the frame.
② Send an email to the mailbox specified in [My Frame], with the subject: bd Connection
Code ( For Example, bd1234576789).

https://benibela.afterservice.vip https://benibela.afterservice.vipE-mail: [email protected] E-mail: [email protected]
11 12
UPLOADING PHOTOS AND VIDEOS
Upload Photos and Videos Via Computer
If you would like to upload large files to the frame, you can use computer to connect to
your frame via USB cable simply. You can transfer photos and videos from
computer in large quantities.
1. Connect your computer and frame with the USB cable.
2. Find your frame disk that named after the frame’s model number in your computer.
3. Add media files that you would like to play on your frame to exact sub-folder in
your frame disk. (Pictures into ‘Pictures’ folder, videos into ‘Movies’ folder, etc.)
4. In your frame, the photos, videos and music you upload from your computer will be
stored in ‘‘Internal Storage’’ in the library.
UPLOADING PHOTOS AND VIDEOS
2. Upload Photos and Videos to Your Frame
After adding your email address to the frame, you can email photos and videos to the mailbox
of the frame.
Your photos and videos will be received in minutes, and you can check the photo or video
library on the frame. Each video clip is limited to 200MB.
Upload Photos and Videos Via USB Drive/Micro SD/SD Card
The frame can also support some external drive to add photos and videos to the frame.
1. Insert a USB drive/Micro SD/SD card into the frame, and wait for seconds, the frame will
notify you when successfully connected.
2. Enter the Photo or Video library, click USB/SD card and you will see all the photos or videos
stored in the USB drive/SD card.
3. Click the More icon at the upper right corner, select the photos or videos you would like to
copy to the internal memory of the frame.
4. Click the Copy icon at the top then choose OK to import the photos or videos.
5. Your photos or videos will be reserved in internal storage in seconds, you can check the
photo or video library on the frame.
Notes:
① Max support a 32GB Micro SD/SD Card.
② Please remove all your external devices when you reset the photo frame.
③ If you have too many files stored in the card, it will take more time to read.
④ Not all models support external drive. Please take the actual product as the standard.

https://benibela.afterservice.vip https://benibela.afterservice.vipE-mail: [email protected] E-mail: [email protected]
13 14
• [All], is including pictures in internal storage and external device. The default playlist is [All].
You also can choose [Internal Storage] by tapping one picture of it to start slideshow.
Pictures Slideshow
Enter [Picture] in the upper-left part of homepage. You will find [All], [Internal Storage],
[SD Card], [USB], [Folder], [Favorites] and user list; you can check all pictures of each playlist
and operate in batch.
KEY FEATURES KEY FEATURES
•[Internal Storage], is all of the pictures sent from app, email, copied from external device.

https://benibela.afterservice.vip https://benibela.afterservice.vipE-mail: [email protected] E-mail: [email protected]
15 16
• [SD Card]/[USB], shows the pictures in external drive like USB Drive, Micro SD or SD card.
To add pictures to [Internal Storage] from [SD Card]/[USB], you can click [┇] in upper-right
corner, choose the pictures you want to add to [Internal Storage] and then click [ ] and
[OK] to confirm the process.
KEY FEATURES KEY FEATURES
• [Folder], you can create folders and name them. Only pictures in [Internal Storage] can
be added.

https://benibela.afterservice.vip https://benibela.afterservice.vipE-mail: [email protected] E-mail: [email protected]
17 18
KEY FEATURES KEY FEATURES
• [Image Filter], this function is a one-click filter function. If you are not satisfied with the color
of the picture, you can add a filter in this function to make the picture more colorfully and
personalized.
• [Favorites], you can add favorite to your photos. Only pictures in [Internal Storage] can
be added to favorites, you can tap [ ♡ ] on the bottom column while playing pictures to
add pictures to favorites.

[Face], face recognition can distinguish the front face and then classify the photos. You can
get the photos for same person quickly.
https://benibela.afterservice.vip https://benibela.afterservice.vipE-mail: [email protected] E-mail: [email protected]
19 20
KEY FEATURES KEY FEATURES
•

https://benibela.afterservice.vip https://benibela.afterservice.vipE-mail: [email protected] E-mail: [email protected]
21 22
•
At [Users], it allows you to manage the connected account of the frame. Pressing the
account name, you can view Photos/Remark Name/Delete User/Delete User&Photos.
[Album Settings]
• Brightness
Adjust the brightness of the screen.
•
•
Sound
Adjust the media volume.
Touch Sounds
Choose the sound on or off when touching the screen.
• Assistive Touch
Turn on this button, the assistive touch will appear on the screen. It is a quick navigation key
to help you easily go to the Home page and adjust the volume.
•
•
Language: English, Deutsch, Español, Français, Italiano, русский, 日本語, 简体中文. Choose
the system language.
Slideshow
Set Slideshow time to make the frame automatically display photos after a period time of
inactivity.
• Slideshow Mode
Choose either Sequential or Random mode to display photos.
MULTIPLE FUNCTIONS
GENERAL SETTINGS
Music
Choose [Music] in the homepage, select the music you want to play.
Weather Forecast
Choose [Weather] in homepage, you can check the weather of three days. Both [℃] and [℉]
are available, switch to the temperature format you want to use. By pressing [+] on upper-left
part to add several cities, you can know the weather of the city you add.
Alarm
Choose [Alarm] to set up alarm clock. [Add] for adding new alarm clock and [Edit] for adjusting
the set time and deleting the alarm clock you choose.
[My Frame] shows your frame connection code and managing users.
•The Connection code and QR code will refresh every 12 hours.
You can also refresh the code manually by pressing .
•To nickname your frame, press the name of the frame on the right corner to edit; it will
show on the app when you connect the frame.
•For sending photos and videos to your frame via email, you can easily press [＋ ] at
[User Management] to add the email address.
Please refer to “UPLOADING PHOTOS VIA EMAIL” for details.
GENERAL SETTINGS

https://benibela.afterservice.vip https://benibela.afterservice.vipE-mail: [email protected] E-mail: [email protected]
23 24
• Sort By
Choose the pictures to be sorted by time or name.
• Caption
Turn on this button, and the caption you write will be presented with the photo.
• Date and Time
Set the date and time according to your preference.
•
•
Sleep
Set the Auto-On/Off time, as Sleep Schedule, to make the display automatically turn on and
off at a specific time.
Motion Sensor
Turn on this button, the frame will turn off when the room is empty for energy saving.
• Auto-rotate Screen
With auto-rotate screen button on, you can place it in portrait and landscape, the frame will
adjust the picture automatically.
• Notification Sound
Choose to be notified new message with sound or not.
[Wi-Fi]
Select the Wi-Fi you want your frame to connect with.
[Factory Data Reset]
1. Click Factory data reset.
[About]
It’s the product information about your frame like Version, Frame ID, Serial Number, etc.
When you contact us, sometimes our customer service may ask for frame information
to better know the question. You may find it here.
2. Here are two kinds of reset:
① choose ‘Delete all users and restore the device to inactive’; device files will be reset and all
bound users will be unbound.
② not choosing the option, only device files will be back to default setting. Bound users
remain.
3. Click OK to reset your frame.
[Help]
Simple guide for you to share your pictures.
GENERAL SETTINGS GENERAL SETTINGS

TECHNICAL SPECIFICATION
• Model Number: JT101M-B02
• Screen Size: 10.1 inch IPS
• Resolution: 800*1280 pixels
• Aspect Ratio: 16:10
• Working Temperature: 0℃~40℃, Humidity: 10-85%
• Adapter: Input 100-240V 50/60HZ; Output 5V/2A, 10W
• Picture Format: BMP, JPG, GIF, PNG
• Audio Format: Mp3, OGG, AAC, APE, FLAC, WAV
• Video Format: MPEG1, MPEG2, MPEG4, Xvid, AVI, M-JPEG, H.264, MOV, VOB, MKV,
DIVX4, DIVX5, DIVX33GP
• External Support: Max 32GB USB Drive/Card
• Only Support 2.4GHz WiFi network
1. Does the frame have to be plugged in all the time?
This frame needs to connect an DC outlet all the time.
2. Why cannot this frame connect to Wi-Fi?
Select the Wi-Fi network you would like to connect to and enter the password correctly if
required. If your Wi-Fi network is not on the list, restart your router or move your frame closer
to your router, wait for seconds and check it again.
3. Does this frame have to be Wi-Fi connected to work or just in the setup process?
This frame needs to connect to a Wi-Fi network for setup, receiving new photos/videos,
receiving user requests and software updates. Other than that, the frame can play photos or
video without a Wi-Fi connection.
4. Why does not the frame have sound?
Please check whether the volume is correct and the player is not in Mute mode.
5.Can I share photos and videos to the frame?
Yes, you can share both photos and videos (up to 200MB) to the frame.
6.Can I cycle pictures and videos together?
You could only play photos or videos separately.
7.Can this frame automatically turn on/off at a specific time?
You can go to the Sleep setting and set the auto on/off time as you want.
8.Why is there no files after sharing video or picture to cloud server?
Please check whether the upload process is completed or not.
FREQUENTLY ASKED QUESTIONSFREQUENTLY ASKED QUESTIONS FREQUENTLY ASKED QUESTIONSFREQUENTLY ASKED QUESTIONS
9.Why cannot this frame play the file?
Please confirm if the file format is compatible with the frame.
10.Can I change the image transitions and displaying speed?
Yes, the speed can be adjusted in bottom column while pictures are displaying.
https://benibela.afterservice.vip https://benibela.afterservice.vipE-mail: [email protected] E-mail: [email protected]
25 26

Get 24/7 Assistance at
Or Visit: https://benibela.afterservice.vip
Use camera or QR scanner to scan
E-mail: [email protected]
CONTACTING US
For any inquiries with Benibela products, please feel free to contact us, we will respond within
24 hours.
E-mail: [email protected]
https://benibela.afterservice.vipE-mail: [email protected] 27
