BenQ T2200HD User manual

T2200HD/T2200HDA
21.5’’ Wide-Screen LCD Monitor
User Manual

Table of Contents2
Table of Contents
Package contents ..................................................................................................................3
Installation .............................................................................................................................4
To connect the monitor to your PC .......................................................................... 4
To connect the monitor to the power source ............................................................ 4
Adjusting your monitor ........................................................................................................5
Functions of the buttons and indicator ..................................................................... 5
OSD icon list ............................................................................................................... 5
Troubleshooting ....................................................................................................................7
Specifications .........................................................................................................................8
21.5’’ Wide-Screen LCD monitor .............................................................................. 8

3Package contents
1. Package contents
1. LCD Monitor
2. Monitor Base (the shape of base may vary according to
the monitor model)
3. Power Cord (plug may vary according to the electrical
standards for your area)
4. Analog Signal Cable
5. Quick Installation Guide
6. CD-ROM (contains user manual)

4 Installation
2. Installation
To connect the monitor to your PC
1. Make sure that the PC and monitor are unplugged.
2. Connect the signal cable (VGA or DVI) to the monitor and the PC.
To connect the monitor to the power source
Connect the separate power cable to the monitor and a grounded outlet.

5Adjusting your monitor
3. Adjusting your monitor
Functions of the buttons and indicator
OSD icon list
Item Function
Enter Enter OSD menu, select item, enter submenu, and confirm recall.
X
1. Positive adjustment, change within several selections.
2. Hot key of "Brightness".
W
1. Minus adjustment, change within several selections.
2. Hot key of "Contrast".
Exit
1. Leave menu, cancel recall. (Settings will be saved automatically after
adjustments are made.)
2. Hot key of "Input Select".
Auto Hot key of auto adjustment (for geometric settings only).
Icon Function Description
Auto Adjust * Optimize the picture performance automatically
Input Select
* Select the input from Analog and Digital Inputs
* Factory default: Analog (VGA)
Note: Not for T2200HDA.
Luminance * Select "Brightness" and "Contrast" adjustment submenu
Geometry * Select "H. Position", "V. Position", "Pixel Clock" and "Phase"
adjustment submenu
Color * Select color temperature or to set up user mode
OSD * Adjust the position and time of OSD menu on the screen
Language * Select your own preference of language of OSD menu
Recall * Reset monitor parameters back to factory preset value
Miscellaneous * Select "Miscellaneous" adjustment submenu
Brightness * Adjust the luminance of the screen

6 Adjusting your monitor
Contrast * Adjust the contrast level of the screen
H. Position * Shift the screen left or right
V. Position * Shift the screen up or down
Pixel Clock * Adjust the monitor internal sampling clock rate
Phase * Adjust the monitor internal signal phase
OSD H. Position * Shift the OSD left or right
OSD V. Position * Shift the OSD up or down
OSD Time * Set OSD display duration time
Sharpness * Adjust the sharp level of the screen
DDC/CI * Switch "DDC/CI" On or Off
Information * Show the display information
DCR * Switch "DCR" On or Off
Display Mode * Switch "Display Mode": Aspect/Full

7Troubleshooting
4. Troubleshooting
Symptom Remedy
*Blank Screen*
Power indicator is off • Make sure the power cable is connected properly (see
Installation on page 4).
• Make sure that the monitor was turned on using the
power switch (see To connect the monitor to your PC
on page 4).
Power indicator lights orange • Perhaps a power saving mode is active? Press any key
on your keyboard or move the mouse.
Power indicator lights green • A screen saver may have activated automatically after a
certain period of inactivity. Press any key on your key-
board or move the mouse.
"No Signal Detected!" message • Is the signal cable connected to the monitor and the
PC's graphics port (see Installation on page 4)?
• Is the PC turned on (see your PC's documentation)?
*Display Problems*
Image is displaced to the left/right
or to the top/bottom
• If the image appears normal but off-center, you can
adjust it using the OSD functions. For further informa-
tion, see "Auto Adjust" in the OSD icon list section.
Image is blurred • Check brightness and contrast settings (see "Lumi-
nance" in the OSD icon list section).
• Check the sharpness setting (see "Sharpness" in the
OSD icon list section).
Color problems • If the colors are off (e.g., white is not really displayed as
white etc.), you should adjust the color temperature
(see "Color" in the OSD icon list section).

8 Specifications
5. Specifications
21.5’’ Wide-Screen LCD monitor
Item T2200HD/T2200HDA
Panel Display Size 476.64 (H) x 268.11 (V) mm
Pixel Pitch 0.248 (H) x 0.248 (V) mm
Monitor Display Colors 16.7M colors
Input Signal Frequency Horizontal: 30 - 83 KHz
Vertical: 56 - 76 Hz
Connector Analog D-sub 15 pin
Digital DVI 24 pin (Not for T2200HDA)
Tilt Tilt Angle -5° - 20°
Dimensions
(W x H x D) Net 516.4(W) x 386.7(H) x 211.6(D) mm
Weight Net 4.2 kg
Power AC AC 100-240V, 50-60 Hz
Consumption Active: < 47W / Standby: < 2W
