MW855UST+/ MH856UST+
Projector RS232 Command Control
Installation Guide

2
Table of Contents
Introduction ............................................................................................................................................. 3
Wire arrangement........................................................................................................................................................3
RS232 pin assignment..................................................................................................................................................3
Connections and communication settings......................................................................................... 4
RS232 serial port with a crossover cable ...............................................................................................................4
Settings ..................................................................................................................................................................4
RS232 via LAN..............................................................................................................................................................6
Settings ..................................................................................................................................................................6
RS232 via HDBaseT.....................................................................................................................................................6
Settings ..................................................................................................................................................................6
Command table....................................................................................................................................... 8

3
Introduction
The document describes how to control your BenQ projector via RS232 from a computer. Follow the
procedures to complete the connection and settings first, and refer to the command table for RS232
commands.
Available functions and commands vary by model. Check the specifications and user manual of the purchased projector for
product functions.
Wire arrangement
Wire Arrangement
P1
Color
P2
1
Black
1
2
Brown
3
3
Red
2
4
Orange
4
5
Yellow
5
6
Green
6
7
Blue
7
8
Purple
8
9
Gray
9
Case
Drain wire
Case
RS232 pin assignment
Pin
Description
Pin
Description
1
NC
2
RXD
3
TXD
4
NC
5
GND
6
NC
7
RTS
8
CTS
9
NC

4
Connections and communication settings
Choose one of the connections and set up properly before RS232 control.
RS232 serial port with a crossover cable
Settings
On-screen images in this document are for reference only. The screens may vary depending on your Operating System,
I/O ports used for connection, and the specifications of the connected projector.
1. Determine the COM Port name used for the RS232 communications in Device Manager.
PC or laptop
Communication cable (crossover)
D-Sub 9 pin (female)
D-Sub 9 pin (male) on a projector

5
2. Choose Serial and the corresponding COM port as the communication port. In this given example,
COM6 is selected.
3. Finish Serial port setup.
Baud rate
9600 / 14400 / 19200 / 38400 / 57600 / 115200 bps
Check the baud rate of the connected projector from its OSD menu.
Data length
8 bit
Parity check
None
Stop bit
1 bit
Flow control
None

6
RS232 via LAN
Settings
1. Find the Wired LAN IP address of the connected projector from the OSD menu and make sure the
projector and the computer are within the same network.
2. Input 8000 in the TCP port # field.
RS232 via HDBaseT
Settings
1. Determine the COM Port name used for the RS232 communications in Device Manager.
2. Choose Serial and the corresponding COM port as the communication port. In this given example,
COM6 is selected.
PC or laptop
RJ45 port on a projector
LAN cable
PC or laptop
HDBaseT compatible device
D-Sub 9 pin
RJ45
RJ45 port on a projector
LAN cable
D-Sub 9 pin

7
3. Finish Serial port setup.
Baud rate
9600 / 14400 / 19200 / 38400 / 57600 / 115200 bps
Check the baud rate of the connected projector from its OSD menu.
Data length
8 bit
Parity check
None
Stop bit
1 bit
Flow control
None

8
Command table
Available features differ by projector specification, input sources, settings, etc..
Commands are working if the standby power is 0.5W or a supported baud rate of the projector is set.
Uppercase, lowercase, and a mixture of both types of characters are accepted for a command.
If a command format is illegal, it will echo Illegal format.
If a command with correct format is not valid for the projector model, it will echo Unsupported item.
If a command with correct format cannot be executed under certain condition, it will echo Block item.
If RS232 control is performed via LAN, a command works whether it starts and ends with <CR>. All the commands and
behaviors are identical with the control through a serial port.
Function
Type
Operation
ASCII
Supported
Power
Write
Power On
<CR>*pow=on#<CR>
YES
Write
Power Off
<CR>*pow=off#<CR>
YES
Read
Power Status
<CR>*pow=?#<CR>
YES
Source
Selection
Write
COMPUTER/YPbPr
<CR>*sour=RGB#<CR>
YES
Write
COMPUTER 2/YPbPr2
<CR>*sour=RGB2#<CR>
NO
Write
COMPUTER 3/YPbPr3
<CR>*sour=RGB3#<CR>
NO
Write
Component
<CR>*sour=ypbr#<CR>
NO
Write
Component2
<CR>*sour=ypbr2#<CR>
NO
Write
DVI-A
<CR>*sour=dviA#<CR>
NO
Write
DVI-D
<CR>*sour=dvid#<CR>
NO
Write
HDMI(MHL)
<CR>*sour=hdmi#<CR>
YES
Write
HDMI 2(MHL2)
<CR>*sour=hdmi2#<CR>
YES
Write
Composite
<CR>*sour=vid#<CR>
YES
Write
S-Video
<CR>*sour=svid#<CR>
NO
Write
Network
<CR>*sour=network#<CR>
NO
Write
USB Display
<CR>*sour=usbdisplay#<CR>
NO
Write
USB Reader
<CR>*sour=usbreader#<CR>
NO
Write
HDbaseT
<CR>*sour=hdbaset#<CR>
NO
Write
DisplayPort
<CR>*sour=dp#<CR>
NO
Write
3G-SDI
<CR>*sour=sdi#<CR>
NO
Write
Smart System
<CR>*sour=smartsystem#<CR
>
NO
Read
Current source
<CR>*sour=?#<CR>
YES
Audio Control
Write
Mute On
<CR>*mute=on#<CR>
YES
Write
Mute Off
<CR>*mute=off#<CR>
YES
Read
Mute Status
<CR>*mute=?#<CR>
YES
Write
Volume +
<CR>*vol=+#<CR>
YES
Write
Volume -
<CR>*vol=-#<CR>
YES

9
Write
Volume level for customer
<CR>*vol=value#<CR>
YES
Read
Volume Status
<CR>*vol=?#<CR>
YES
Write
Mic.Volume +
<CR>*micvol=+#<CR>
NO
Write
Mic.Volume -
<CR>*micvol=-#<CR>
NO
Read
Mic.Volume Status
<CR>*micvol=?#<CR>
NO
Audio source
select
Write
Audio pass Through off
<CR>*audiosour=off#<CR>
YES
Write
Audio-Computer1
<CR>*audiosour=RGB#<CR>
YES
Write
Audio-Computer2
<CR>*audiosour=RGB2#<CR>
NO
Write
Audio-Video/S-Video
<CR>*audiosour=vid#<CR>
YES
Write
Audio-Component
<CR>*audiosour=ypbr#<CR>
NO
Write
Audio-HDMI
<CR>*audiosour=hdmi#<CR>
YES
Write
Audio-HDMI2
<CR>*audiosour=hdmi2#<CR>
YES
Read
Audio pass Status
<CR>*audiosour=?#<CR>
YES
Picture Mode
Write
Dynamic
<CR>*appmod=dynamic#<CR>
NO
Write
Presentation
<CR>*appmod=preset#<CR>
NO
Write
sRGB
<CR>*appmod=srgb#<CR>
YES
Write
Bright
<CR>*appmod=bright#<CR>
YES
Write
Living Room
<CR>*appmod=livingroom#<C
R>
NO
Write
Game
<CR>*appmod=game#<CR>
NO
Write
Cinema
<CR>*appmod=cine#<CR>
NO
Write
Standard/Vivid
<CR>*appmod=std#<CR>
NO
Write
Football
<CR>*appmod=football#<CR>
NO
Write
Football Bright
<CR>*appmod=footballbt#<CR
>
NO
Write
DICOM
<CR>*appmod=dicom#<CR>
NO
Write
THX
<CR>*appmod=thx#<CR>
NO
Write
Silence mode
<CR>*appmod=silence#<CR>
NO
Write
DCI-P3 mode
<CR>*appmod=dci-p3#<CR>
NO
Write
Vivid
<CR>*appmod=vivid#<CR>
YES
Write
Infographic
<CR>*appmod=infographic#<C
R>
YES
Write
User1
<CR>*appmod=user1#<CR>
YES
Write
User2
<CR>*appmod=user2#<CR>
YES
Write
User3
<CR>*appmod=user3#<CR>
NO
Write
ISF Day
<CR>*appmod=isfday#<CR>
NO
Write
ISF Night
<CR>*appmod=isfnight#<CR>
NO
Write
3D
<CR>*appmod=threed#<CR>
YES

10
Read
Picture Mode
<CR>*appmod=?#<CR>
YES
Picture Setting
Write
Contrast +
<CR>*con=+#<CR>
YES
Write
Contrast -
<CR>*con=-#<CR>
YES
Write
Set Contrast value
<CR>*con=value#<CR>
YES
Read
Contrast value
<CR>*con=?#<CR>
YES
Write
Brightness +
<CR>*bri=+#<CR>
YES
Write
Brightness -
<CR>*bri=-#<CR>
YES
Write
Set Brightness value
<CR>*bri=value#<CR>
YES
Read
Brightness value
<CR>*bri=?#<CR>
YES
Write
Color +
<CR>*color=+#<CR>
YES
Write
Color -
<CR>*color=-#<CR>
YES
Write
Set Color value
<CR>*color=value#<CR>
YES
Read
Color value
<CR>*color=?#<CR>
YES
Write
Sharpness +
<CR>*sharp=+#<CR>
YES
Write
Sharpness -
<CR>*sharp=-#<CR>
YES
Write
Set Sharpness value
<CR>*sharp=value#<CR>
YES
Read
Sharpness value
<CR>*sharp=?#<CR>
YES
Write
Flesh Tone +
<CR>*fleshtone=+#<CR>
NO
Write
Flesh Tone -
<CR>*fleshtone=-#<CR>
NO
Write
Set Flesh Tone value
<CR>*fleshtone=value#<CR>
NO
Read
Flesh Tone value
<CR>*fleshtone=?#<CR>
NO
Write
Color Temperature-Warmer
<CR>*ct=warmer#<CR>
NO
Write
Color Temperature-Warm
<CR>*ct=warm#<CR>
YES
Write
Color Temperature-Normal
<CR>*ct=normal#<CR>
YES
Write
Color Temperature-Cool
<CR>*ct=cool#<CR>
YES
Write
Color Temperature-Cooler
<CR>*ct=cooler#<CR>
NO
Write
Color Temperature-lamp
native
<CR>*ct=native#<CR>
NO
Read
Color Temperature Status
<CR>*ct=?#<CR>
YES
Write
Aspect 4:3
<CR>*asp=4:3#<CR>
YES
Write
Aspect 16:6
<CR>*asp=16:6#<CR>
NO
Write
Aspect 16:9
<CR>*asp=16:9#<CR>
YES
Write
Aspect 16:10
<CR>*asp=16:10#<CR>
YES
Write
Aspect Auto
<CR>*asp=AUTO#<CR>
YES
Write
Aspect Real
<CR>*asp=REAL#<CR>
YES
Write
Aspect Letterbox
<CR>*asp=LBOX#<CR>
NO
Write
Aspect Wide
<CR>*asp=WIDE#<CR>
NO
Write
Aspect Anamorphic
<CR>*asp=ANAM#<CR>
NO

11
Write
Aspect Anamorphic 2.35
<CR>*asp=ANAM2.35#<CR>
NO
Write
Aspect Anamorphic 16:9
<CR>*asp=ANAM16:9#<CR>
NO
Read
Aspect Status
<CR>*asp=?#<CR>
NO
Write
Vertical Keystone +
<CR>*vkeystone=+#<CR>
YES
Write
Vertical Keystone -
<CR>*vkeystone=-#<CR>
YES
Read
Vertical Keystone value
<CR>*vkeystone=?#<CR>
YES
Write
Horizontal Keystone +
<CR>*hkeystone=+#<CR>
YES
Write
Horizontal Keystone -
<CR>*hkeystone=-#<CR>
YES
Read
Horizontal Keystone value
<CR>*hkeystone=?#<CR>
YES
Write
Overscan Adjustment +
<CR>*overscan=+#<CR>
NO
Write
Overscan Adjustment -
<CR>*overscan=-#<CR>
NO
Read
Overscan Adjustment value
<CR>*overscan=?#<CR>
NO
Write
4 Corners Top-Left-X
Decrease
<CR>*cornerfittlx=-#<CR>
YES
Write
4 Corners Top-Left-X
Increase
<CR>*cornerfittlx=+#<CR>
YES
Read
4 Corners Top-Left-X Status
<CR>*cornerfittlx=?#<CR>
YES
Write
4 Corners Top-Left-Y
Decrease
<CR>*cornerfittly=-#<CR>
YES
Write
4 Corners Top-Left-Y
Increase
<CR>*cornerfittly=+#<CR>
YES
Read
4 Corners Top-Left-Y Status
<CR>*cornerfittly=?#<CR>
YES
Write
4 Corners Top-Right-X
Decrease
<CR>*cornerfittrx=-#<CR>
YES
Write
4 Corners Top-Right-X
Increase
<CR>*cornerfittrx=+#<CR>
YES
Read
4 Corners Top-Right-X
Status
<CR>*cornerfittrx=?#<CR>
YES
Write
4 Corners Top-Right-Y
Decrease
<CR>*cornerfittry=-#<CR>
YES
Write
4 Corners Top-Right-Y
Increase
<CR>*cornerfittry=+#<CR>
YES
Read
4 Corners Top-Right-Y
Status
<CR>*cornerfittry=?#<CR>
YES
Write
4 Corners Bottom-Left-X
Decrease
<CR>*cornerfitblx=-#<CR>
YES
Write
4 Corners Bottom-Left-X
Increase
<CR>*cornerfitblx=+#<CR>
YES

12
Read
4 Corners Bottom-Left-X
Status
<CR>*cornerfitblx=?#<CR>
YES
Write
4 Corners Bottom-Left-Y
Decrease
<CR>*cornerfitbly=-#<CR>
YES
Write
4 Corners Bottom-Left-Y
Increase
<CR>*cornerfitbly=+#<CR>
YES
Read
4 Corners Bottom-Left-Y
Status
<CR>*cornerfitbly=?#<CR>
YES
Write
4 Corners Bottom-Right-X
Decrease
<CR>*cornerfitbrx=-#<CR>
YES
Write
4 Corners Bottom-Right-X
Increase
<CR>*cornerfitbrx=+#<CR>
YES
Read
4 Corners Bottom-Right-X
Status
<CR>*cornerfitbrx=?#<CR>
YES
Write
4 Corners Bottom-Right-Y
Decrease
<CR>*cornerfitbry=-#<CR>
YES
Write
4 Corners Bottom-Right-Y
Increase
<CR>*cornerfitbry=+#<CR>
YES
Read
4 Corners Bottom-Right-Y
Status
<CR>*cornerfitbry=?#<CR>
YES
Write
Digital Zoom In
<CR>*zoomI#<CR>
YES
Write
Digital Zoom out
<CR>*zoomO#<CR>
YES
Write
Auto
<CR>*auto#<CR>
YES
Write
Brilliant color on
<CR>*BC=on#<CR>
YES
Write
Brilliant color off
<CR>*BC=off#<CR>
YES
Read
Brilliant color status
<CR>*BC=?#<CR>
YES
Write
Reset picture settings
<CR>*rstpicsetting#<CR>
YES
Operation
Settings
Write
Projector Position-Front
Table
<CR>*pp=FT#<CR>
YES
Write
Projector Position-Rear
Table
<CR>*pp=RE#<CR>
YES
Write
Projector Position-Rear
Ceiling
<CR>*pp=RC#<CR>
YES
Write
Projector Position-Front
Ceiling
<CR>*pp=FC#<CR>
YES
Read
Projector Position Status
<CR>*pp=?#<CR>
YES
Write
Quick cooling on
<CR>*qcool=on<CR>
NO
Write
Quick cooling off
<CR>*qcool=off<CR>
NO

13
Read
Quick cooling status
<CR>*qcool=?<CR>
NO
Write
Quick auto search
<CR>*QAS=on#<CR>
YES
Write
Quick auto search
<CR>*QAS=off#<CR>
YES
Read
Quick auto search status
<CR>*QAS=?#<CR>
YES
Write
Menu Position - Center
<CR>*menuposition=center#<
CR>
YES
Write
Menu Position - Top-Left
<CR>*menuposition=tl#<CR>
YES
Write
Menu Position - Top-Right
<CR>*menuposition=tr#<CR>
YES
Write
Menu Position -
Bottom-Right
<CR>*menuposition=br#<CR>
YES
Write
Menu Position - Bottom-Left
<CR>*menuposition=bl#<CR>
YES
Read
Menu Position Status
<CR>*menuposition=?#<CR>
YES
Write
Direct Power On-on
<CR>*directpower=on#<CR>
YES
Write
Direct Power On-off
<CR>*directpower=off#<CR>
YES
Read
Direct Power On-Status
<CR>*directpower=?#<CR>
YES
Write
Signal Power On-on
<CR>*autopower=on#<CR>
YES
Write
Signal Power On-off
<CR>*autopower=off#<CR>
YES
Read
Signal Power On-Status
<CR>*autopower=?#<CR>
YES
Write
Standby Settings-Network
on
<CR>*standbynet=on#<CR>
YES
Write
Standby Settings-Network
off
<CR>*standbynet=off#<CR>
YES
Read
Standby Settings-Network
Status
<CR>*standbynet=?#<CR>
YES
Write
Standby Settings-Microphone
on
<CR>*standbymic=on#<CR>
NO
Write
Standby Settings-Microphone
off
<CR>*standbymic=off#<CR>
NO
Read
Standby Settings-Microphone
Status
<CR>*standbymic=?#<CR>
NO
Write
Standby Settings-Monitor
Out on
<CR>*standbymnt=on#<CR>
YES
Write
Standby Settings-Monitor
Out off
<CR>*standbymnt=off#<CR>
YES
Read
Standby Settings-Monitor
Out Status
<CR>*standbymnt=?#<CR>
YES
Baud Rate
Write
2400
<CR>*baud=2400#<CR>
NO
Write
4800
<CR>*baud=4800#<CR>
NO

14
Write
9600
<CR>*baud=9600#<CR>
YES
Write
14400
<CR>*baud=14400#<CR>
YES
Write
19200
<CR>*baud=19200#<CR>
YES
Write
38400
<CR>*baud=38400#<CR>
YES
Write
57600
<CR>*baud=57600#<CR>
YES
Write
115200
<CR>*baud=115200#<CR>
YES
Read
Current Baud Rate
<CR>*baud=?#<CR>
YES
Lamp Control
Read
Lamp
<CR>*ltim=?#<CR>
YES
Read
Lamp2 Hour
<CR>*ltim2=?#<CR>
NO
Write
Normal mode
<CR>*lampm=lnor#<CR>
YES
Write
Eco mode
<CR>*lampm=eco#<CR>
YES
Write
SmartEco mode
<CR>*lampm=seco#<CR>
YES
Write
SmartEco mode 2
<CR>*lampm= seco2#<CR>
YES
Write
SmartEco mode 3
<CR>*lampm= seco3#<CR>
NO
Write
Dimming mode
<CR>*lampm=dimming#<CR>
NO
Write
Custom mode
<CR>*lampm=custom#<CR>
NO
Write
Light level for custom mode
<CR>*lampcustom=value#<CR
>
NO
Read
Light level status for custom
mode
<CR>*lampcustom=?#<CR>
NO
Write
(dual
lamp)
Dual Brightest
<CR>* lampm =dualbr#<CR>
NO
Write
(dual
lamp)
Dual Reliable
<CR>* lampm =dualre#<CR>
NO
Write
(dual
lamp)
Single Alternative
<CR>* lampm =single#<CR>
NO
Write
(dual
lamp)
Single Alternative Eco
<CR>* lampm
=singleeco#<CR>
NO
Read
Lamp Mode Status
<CR>*lampm=?#<CR>
YES
Miscellaneous
Read
Model Name
<CR>*modelname=?#<CR>
YES
Read
System F/W Version
<CR>*sysfwversion=?#<CR>
YES
Read
Scaler F/W Version
<CR>*scalerfwversion=?#<CR>
YES
Read
Lan F/W Version
<CR>*lanfwversion=?#<CR>
YES
Read
MCU F/W Version
<CR>*mcufwversion=?#<CR>
YES

15
Read
Ballast F/W Version
<CR>*ballastfwversion=?#<CR>
YES
Write
Blank On
<CR>*blank=on#<CR>
YES
Write
Blank Off
<CR>*blank=off#<CR>
YES
Read
Blank Status
<CR>*blank=?#<CR>
YES
Write
Freeze On
<CR>*freeze=on#<CR>
YES
Write
Freeze Off
<CR>*freeze=off#<CR>
YES
Read
Freeze Status
<CR>*freeze=?#<CR>
YES
Write
Menu On
<CR>*menu=on#<CR>
YES
Write
Menu Off
<CR>*menu=off#<CR>
YES
Read
Menu Status
<CR>*menu=?#<CR>
YES
Write
Up
<CR>*up#<CR>
YES
Write
Down
<CR>*down#<CR>
YES
Write
Right
<CR>*right#<CR>
YES
Write
Left
<CR>*left#<CR>
YES
Write
Enter
<CR>*enter#<CR>
YES
Write
Back
<CR>*back#<CR>
NO
Write
Source Menu On
<CR>*sourmenu=on#<CR>
YES
Write
Source Menu Off
<CR>*sourmenu=off#<CR>
YES
Read
Source Menu Status
<CR>*sourmenu=?#<CR>
YES
Write
3D Sync Off
<CR>*3d=off#<CR>
YES
Write
3D Auto
<CR>*3d=auto#<CR>
YES
Write
3D Sync Top Bottom
<CR>*3d=tb#<CR>
YES
Write
3D Sync Frame Sequential
<CR>*3d=fs#<CR>
YES
Write
3D Frame packing
<CR>*3d=fp#<CR>
YES
Write
3D Side by side
<CR>*3d=sbs#<CR>
YES
Write
3D inverter disable
<CR>*3d=da#<CR>
YES
Write
3D inverter
<CR>*3d=iv#<CR>
YES
Write
2D to 3D
<CR>*3d=2d3d#<CR>
NO
Write
3D nVIDIA
<CR>*3d=nvidia#<CR>
NO
Read
3D Sync Status
<CR>*3d=?#<CR>
NO
Write
Remote Receiver On
<CR>*rr=on#<CR>
NO
Write
Remote Receiver Off
<CR>*rr=off#<CR>
NO
Write
Remote Receiver-front+rear
<CR>*rr=fr#<CR>
NO
Write
Remote Receiver-front
<CR>*rr=f#<CR>
NO
Write
Remote Receiver-rear
<CR>*rr=r#<CR>
NO
Write
Remote Receiver-top
<CR>*rr=t#<CR>
NO
Write
Remote Receiver-top+front
<CR>*rr=tf#<CR>
NO
Write
Remote Receiver-top+rear
<CR>*rr=tr#<CR>
NO

16
Read
Remote Receiver Status
<CR>*rr=?#<CR>
NO
Write
Instant On-on
<CR>*ins=on#<CR>
YES
Write
Instant On-off
<CR>*ins=off#<CR>
YES
Read
Instant On Status
<CR>*ins=?#<CR>
YES
Write
Lamp Saver Mode-on
<CR>*lpsaver=on#<CR>
NO
Write
Lamp Saver Mode-off
<CR>*lpsaver=off#<CR>
NO
Read
Lamp Saver Mode Status
<CR>*lpsaver=?#<CR>
NO
Write
Projection Log In Code on
<CR>*prjlogincode=on#<CR>
NO
Write
Projection Log In Code off
<CR>*prjlogincode=off#<CR>
NO
Read
Projection Log In Code
Status
<CR>*prjlogincode=?#<CR>
NO
Write
Broadcasting on
<CR>*broadcasting=on#<CR>
NO
Write
Broadcasting off
<CR>*broadcasting=off#<CR>
NO
Read
Broadcasting Status
<CR>*broadcasting=?<CR>
NO
Write
AMX Device Discovery-on
<CR>*amxdd=on#<CR>
YES
Write
AMX Device Discovery-off
<CR>*amxdd=off#<CR>
YES
Read
AMX Device Discovery
Status
<CR>*amxdd=?#<CR>
YES
Read
Mac Address
<CR>*macaddr=?#<CR>
YES
Write
High Altitude mode on
<CR>*Highaltitude=on#<CR>
YES
Write
High Altitude mode off
<CR>*Highaltitude=off#<CR>
YES
Read
High Altitude mode status
<CR>*Highaltitude=?#<CR>
YES
Installation
Write
Load Lens memory 1
<CR>*lensload=m1#<CR>
NO
Write
Load Lens memory 2
<CR>*lensload=m2#<CR>
NO
Write
Load Lens memory 3
<CR>*lensload=m3#<CR>
NO
Write
Load Lens memory 4
<CR>*lensload=m4#<CR>
NO
Write
Load Lens memory 5
<CR>*lensload=m5#<CR>
NO
Write
Load Lens memory 6
<CR>*lensload=m6#<CR>
NO
Write
Load Lens memory 7
<CR>*lensload=m7#<CR>
NO
Write
Load Lens memory 8
<CR>*lensload=m8#<CR>
NO
Write
Load Lens memory 9
<CR>*lensload=m9#<CR>
NO
Write
Load Lens memory 10
<CR>*lensload=m10#<CR>
NO
Read
Read Lens memory status
<CR>*lensload=?#<CR>
NO
Write
save Lens memory 1
<CR>*lenssave=m1#<CR>
NO
Write
save Lens memory 2
<CR>*lenssave=m2#<CR>
NO
Write
save Lens memory 3
<CR>*lenssave=m3#<CR>
NO
Write
save Lens memory 4
<CR>*lenssave=m4#<CR>
NO
Write
save Lens memory 5
<CR>*lenssave=m5#<CR>
NO

17
Write
save Lens memory 6
<CR>*lenssave=m6#<CR>
NO
Write
save Lens memory 7
<CR>*lenssave=m7#<CR>
NO
Write
save Lens memory 8
<CR>*lenssave=m8#<CR>
NO
Write
save Lens memory 9
<CR>*lenssave=m9#<CR>
NO
Write
save Lens memory 10
<CR>*lenssave=m10#<CR>
NO
Write
Reset Lens to center
<CR>*lensreset=center#<CR>
NO
Color
Calibration
(only for
service)
Write
Tint +
<CR>*tint=+#<CR>
NO
Write
Tint -
<CR>*tint=-#<CR>
NO
Write
Set Tint value
<CR>*tint=value#<CR>
NO
Read
Get Tint value
<CR>*tint=?#<CR>
NO
Write
Set BenQ gamma value
<CR>*gamma=value#<CR>
NO
Read
Gamma value status
<CR>*gamma=?#<CR>
NO
Write
Set HDR Brightness value
<CR>*hdrbri=value#<CR>
NO
Read
Get HDR Brightness value
<CR>*hdibri=?#<CR>
NO
Write
Red Gain +
<CR>*RGain=+#<CR>
NO
Write
Red Gain -
<CR>*RGain=-#<CR>
NO
Write
Set Red Gain value
<CR>*RGain=value#<CR>
NO
Read
Get Red Gain value
<CR>*RGain=?#<CR>
NO
Write
Green Gain +
<CR>*GGain=+#<CR>
NO
Write
Green Gain -
<CR>*GGain=-#<CR>
NO
Write
Set Green Gain value
<CR>*GGain=value#<CR>
NO
Read
Get Green Gain value
<CR>*GGain=?#<CR>
NO
Write
Blue Gain +
<CR>*BGain=+#<CR>
NO
Write
Blue Gain -
<CR>*BGain=-#<CR>
NO
Write
Set Blue Gain value
<CR>*BGain=value#<CR>
NO
Read
Get Blue Gain value
<CR>*BGain=?#<CR>
NO
Write
Red Offset +
<CR>*ROffset=+#<CR>
NO
Write
Red Offset -
<CR>*ROffset=-#<CR>
NO
Write
Set Red Offset value
<CR>*ROffset=value#<CR>
NO
Read
Get Red Offset value
<CR>*ROffset=?#<CR>
NO
Write
Green Offset +
<CR>*GOffset=+#<CR>
NO
Write
Green Offset -
<CR>*GOffset=-#<CR>
NO
Write
Set Green Offset value
<CR>*GOffset=value#<CR>
NO
Read
Get Green Offset value
<CR>*GOffset=?#<CR>
NO
Write
Blue Offset +
<CR>*BOffset=+#<CR>
NO
Write
Blue Offset -
<CR>*BOffset=-#<CR>
NO
Write
Set Blue Offset value
<CR>*BOffset=value#<CR>
NO
Read
Get Blue Offset value
<CR>*BOffset=?#<CR>
NO

18
Write
Primary Color
<CR>*primcr=value#<CR>
NO
Read
Primary Color Status
<CR>*primcr=?#<CR>
NO
Write
Hue +
<CR>*hue=+#<CR>
NO
Write
Hue -
<CR>*hue=-#<CR>
NO
Write
Set Hue value
<CR>*hue=value#<CR>
NO
Read
Get Hue value
<CR>*hue=?#<CR>
NO
Write
Saturation +
<CR>*saturation =+#<CR>
NO
Write
Saturation -
<CR>*saturation =-#<CR>
NO
Write
Set Saturation value
<CR>*saturation =value#<CR>
NO
Read
Get Saturation value
<CR>*saturation =?#<CR>
NO
Write
Gain +
<CR>*gain=+#<CR>
NO
Write
Gain -
<CR>*gain=-#<CR>
NO
Write
Set Gain value
<CR>*gain=value#<CR>
NO
Read
Get Gain value
<CR>*gain=?#<CR>
NO
Write
Color Gamut Auto
<CR>*cgamut=auto#<CR>
NO
Write
Color Gamut BT.709
<CR>*cgamut=bt.709#<CR>
NO
Write
Color Gamut BT.2020
<CR>*cgamut=bt.2020#<CR>
NO
Write
Color Gamut DCI-P3
<CR>*cgamut=dci-p3#<CR>
NO
Read
Color Gamut Value
<CR>*cgamut=?#<CR>
NO
Write
Dynamic Iris ON
<CR>*diris=on#<CR>
NO
Write
Dynamic Iris OFF
<CR>*diris=off#<CR>
NO
Read
Dynamic Iris status
<CR>*diris=?#<CR>
NO
Service
(Only for
service)
Write
Service mode enable for
error report
<CR>*error=enable#<CR>
YES
Read
Error code report
<CR>*error=report#<CR>
YES
Read
FAN 1 speed
<CR>*fan1=?#<CR>
YES
Read
FAN 2 speed
<CR>*fan2=?#<CR>
YES
Read
FAN 3 speed
<CR>*fan3=?#<CR>
YES
Read
FAN 4 speed
<CR>*fan4=?#<CR>
YES
Read
Temperature 1
<CR>*tmp1=?#<CR>
YES
Read
Temperature 2
<CR>*tmp2=?#<CR>
NO
Read
Temperature 3
<CR>*tmp3=?#<CR>
NO
Read
LED indicator
<CR>*led=?#<CR>
YES

19
BenQ.com
© 2018 BenQ Corporation
All rights reserved. Rights of modification reserved.
Version: 1.01-C
