BenQ W770ST Use and maintenance manual

BenQ America Corp.
15375 Barranca Parkway. Suite A-205. Irvine, CA 92618 Tel: [phone] www.BenQ.us
BenQ is a registered trademark of BenQ Corp. DLP®is a registered trademark of Texas Instruments. All rights reserved.
Product names, logos, brands, and other trademarks featured or referred to in this materials are the property of their respective trademark holders.
Specifications subject to change without notice.
1
2
3
4
5
6
7
HDMI
Composite Video In (RCA)
USB (Type Mini B)
Computer in (D-sub 15pin)
S-Video In (Mini DIN 4pin)
Audio L/R in (RCA)
Audio in (Mini Jack)
RS232 (DB-9pin)
Component Video in
Audio out (Mini Jack)
12345
9
8
9
10
10
67
8
I
W770ST
DIGITAL
PROJECTOR
Features Specications
Native 720p (1280 x 720) Resolution
2,500 ANSI Lumens
13,000:1 Contrast Ratio
SmartEco™ Power Saving Technology
Blu-ray Full HD 3D Support
Projection System
Native Resolution
Brightness
Contrast Ratio
Display Color
Lens
Aspect Ratio
Throw Ratio
Image Size (Diagonal)
Zoom Ratio
Lamp Type
Lamp Life
Keystone Adjustment
Projection Offset
Resolution Support
Horizontal Frequency
Vertical Scan Rate
Compatibility
Interface
Dimensions (WxHxD)
Weight
Power Supply
Power Consumption
Audible Noise
On-Screen Display
Languages
Picture Modes
Accessories (Standard)
Accessories (Optional)
UPC / Part #
Limited Warranty
0.62’’ DC3 DLP®DMD
720p (1280 x 720)
2,500AL
13,000:1
1.07 Billion Colors
F=2.6-2.78, f=10.2-12.24mm
Native 16:9 (5 aspect ratio selectable)
0.72-0.87 (62.5”@1M )
36”-300”
1.2:1
210W
4,000/5,000/6,500 hours
1D, Vertical +/- 40 degrees
115% ±5%
Up to UXGA(1600 x 1200)
15K~102KHz
23~120Hz
HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Video Compatibility: NTSC, PAL, SECAM, SDTV
Computer in (D-sub 15pin) x 1
HDMI x 2
Composite Video in (RCA) x 1
S-Video in (Mini DIN 4pin) x 1
Component Video in x 1
Audio in (Mini Jack) x 1
Audio L/R in (RCA) x 1
Audio out (Mini Jack) x 1
Speaker 10W x 1
USB (Type mini B) x 1
RS232 (DB-9pin) x 1
IR Receiver x 2
12.7” x 4.5” x 10.0” (324.7 x 113.8 x 253.4 mm)
5.9 lbs (2.7 kg)
AC 100 to 240 V, 50/60 Hz
275W (typical), Standby< 0.5W
34/30 dBA (Normal/Economic mode)
Arabic/Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/
French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/
Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/
Russian/ Simplied Chinese/Spanish/ Swedish/ Turkish/ Thai/
Traditional Chinese (28 Languages)
Dynamic/Standard/Cinema/3D/User 1/User 2/User 3
Carry Bag, Remote Control w/ Battery, Power Cord, User Manual CD,
Quick Start Guide, Warranty Card, VGA (D-sub 15pin) Cable
Spare Lamp Kit P/N: 5J.J7K05.001
Ceilling Mount P/N: 5J.J4N10.001
3D Glasses P/N: 5J.J7K25.001
8400460-2793-3 / 9HJ8477.17A
1-Year Parts & Labor / 180 days or 500 hours of lamp life
W770ST 05-07-13-BQus
*Lamp life results will vary depending on environmental conditions and usage. Actual product’s features and specications are
subject to change without notice.
Input and Output Terminals
HIGH-DEFINITION MULTIMEDIA INTERFACE
TM

Distance Chart
Wall Mount Chart
Dimensions
W770ST Digital Projector
4.5”
10.0”
12.7”
Unit: inch
Unit: inch
Installation for a 16:9 ratio screen Screen Dimensions Projection Distance <D> (inch) Vertical offset
<E> (inch)
Diagonal <A> Height <B>
(inch)
Width <C>
(inch)
Min Distance Average Max Distance
Inch mm (with max zoom) (with min zoom)
40 1016 20 34 25.1 27.7 30.2 1.4
50 1270 24 44 31.4 34.6 37.7 1.8
60 1524 29 52 37.7 41.5 45.3 2.2
70 1778 34 61 44.1 48.5 52.9 2.5
80 2032 38 70 50.3 55.4 60.4 2.9
90 2286 44 78 56.6 62.3 68.0 3.3
100 2540 49 87 62.9 69.2 75.5 3.6
110 2794 54 96 69.2 76.2 83.1 4.0
120 3048 59 104 75.5 83.1 90.7 4.4
130 3302 64 113 81.8 90.0 98.2 4.7
140 3556 68 122 88.1 97.0 105.8 5.1
150 3810 73 130 94.4 103.9 113.3 5.5
160 4064 78 139 100.7 110.8 120.9 5.8
170 4318 83 148 107.0 117.7 128.5 6.2
180 4572 88 156 113.3 124.7 136.1 6.6
190 4826 93 165 119.6 131.6 143.6 6.9
200 5080 98 174 125.9 138.5 151.1 7.3
250 6350 122 218 157.4 173.2 188.9 9.2
300 7620 147 261 188.9 207.8 226.7 11.0
