Bentone BG550 Series Technical specifications

Providing sustainable energy solutions worldwide
178 028 82-1 2015-11-20
Installation- and maintenance instruction
BG550/BG650
Modell 2, M

3
Bentone BG550/650
Contents
1. Technical data _________________________________________________________________ 8
1.1 Dimensions ________________________________________________________________ 8
1.2 Output range______________________________________________________________ 9
1.3 Working field ____________________________________________________________ 10
2. Skeleton diagrams ________________________________________________________11
2.1 Multi-Bloc MB-DLE403.....B01 ___________________________________ 11
2.2 Multi-bloc MBZRD-LE......B07 ____________________________________ 14
2.3 Multi-bloc MB-VEF 407-412.....B01 ____________________________ 17
2.5 Multi-bloc MB-VEF 415-420.....B01 ____________________________ 17
2.4 Electritrical connection MB-VEF 407-420_____________________ 17
3. Description_____________________________________________________________________ 18
3.1 2-Stage/Modulating __________________________________________________ 18
4. Mounting of the burner_________________________________________________19
4.1 Inspection of gas assembly ________________________________________ 19
4.2 Adjustment of the position of the shrouded disc in the blast
tube_________________________________________________________________________ 20
4.3 Wiring diagram LFL1... (BG550/BG650) 2-Steg____________ 21
4.4 Wiring diagram LFL1... (BG550/BG650) Modulating _____ 22
4.5 List of components LFL1... (BG550/BG650) ________________ 23
4.6 Funktion LFL1...________________________________________________________ 24
4.7 Control programme under fault conditions and lockout indica-
tion LFL1....______________________________________________________________ 25
5. Measures and checks
before start-up ______________________________________________________________26
5.1 2-Stage or modulating burners___________________________________ 26
6. Determination of gas volume for the installation_______ 28
6.1 Example how to calculate the gas volume (natural gas) _ 28
7. Gas pressure regulator Type FRS _______________________________ 29
8. Multi-bloc,
_____________________________________________________________________ 30
8.1 MB-ZRDLE 405-415....B07________________________________________ 30
8.2 Mounting K01/1________________________________________________________ 31
8.3 Flow adjustment 2-stage design _________________________________ 32
8.4 Adjustment of of main valve damper ___________________________ 32
8.5 MULTI-BLOC, MB-VEF 412-415.... B01 ______________________ 33
8.6 MULTI-BLOC, MB-VEF 420-425.... B01 ______________________ 34
8.7 Technical data___________________________________________________________ 35
8.8 Mounting instruction - impulse lines PL, PFoch PBr__________________ 35
8.9 Adjustment possibilities _____________________________________________ 35
8.10 MULTI-BLOC, MB-DLE 403.... B01_____________________________ 36
8.11 Flow adjustment _______________________________________________________ 37
8.12 Adjustment of start gas flow_______________________________________ 37
8.13 Adjustment of governor _____________________________________________ 37
9. Damper motor 2-stage _________________________________________________ 38
9.1 Air adjustment __________________________________________________________ 38
9.2 Releasing button:______________________________________________________ 38
10. Damper motor modulating___________________________________________39
10.1 Air adjustment __________________________________________________________ 39
10.2 Releasing button:______________________________________________________ 39
11. General Instructions______________________________________________________40
11.1 Adjustment of burner_________________________________________________ 40
11.2 Service_____________________________________________________________________ 40
11.3 Flame monitoring and measurement of ionisation current41
11.4 UV-detector______________________________________________________________ 41
11.5 Adjustment of air pressure switch _______________________________ 42
11.6 Adjustment of min. gas pressure switch (option)___________ 42
11.7 Adjustment of max. gas pressure switch (option) __________ 42
12. Leakage control, Dungs VPS 504 series 2 (option) ___ 43
12.1 Technical data___________________________________________________________ 43
12.2 Programme sequence _______________________________________________ 43
12.3 Program sequence schedule______________________________________ 44
12.4 Electrical connection VPS 504 ___________________________________ 44
13. Handing over of the installation___________________________________45
13.1 Fault location, functional troubles________________________________ 45
14. Fault location guide ______________________________________________________46
15. General instructions for gasburners ___________________________49
15.1 Installation________________________________________________________________ 49
15.2 Maintenance_____________________________________________________________ 49

4Bentone BG550/650
Warning
!
Important to remember!
This installation and maintenance manual is intended for the user and
qualified professionals. It should be taken into account by all those who work
with the burner and associated system components. Work with the boiler
may only be carried out by individuals who have completed certified training.
• This manual is to be regarded as part of the burner and must always
be kept near the installation site. Enertech AB reserves the right to
make changes and correct any printing errors.
• All products are packed to prevent any damage occurring when they
are handled. Handle the products with care. Two or more people are
needed to move large packages. All products must be stored upright
on a level, dry surface.
• The weight is on the label cardboard box.
• The burner may be installed by authorised personnel only.
• Check that the burner is compatible with the boiler’s output range.
• The burner must be installed so that it complies with local regulations
on fire safety, electrical safety and boiler and fuel distribution.
• Make sure when installing the equipment that enough room is left to
service the burner.
• Permitted temperature during operation +3 to +30°C
• Temperature during transport/storage -10 to +60°C
• Max. relative air humidity 80%, no condensate
• The installer must ensure that the room has sufficient fresh air
ventilation as per local norms.
• The room must comply with local regulations applicable to its intended
use.
• If any electrical connection is used other than that recommended by
Enertech, there may be a danger of damage to property and personal
injury.
• The electrical installation must be carried out in accordance with
applicable heavy current regulations and in a professional manner,
avoiding the risk of gas leaks, fire or personal injury.
• Care should be taken by the installer to ensure that no electrical
cables or gas pipelines are crushed or damaged during installation or
servicing.
• If the boiler has a door that opens, this should be locked with a door
switch.

5
Bentone BG550/650
General
• Does this product need to be sorted as metal and plastic when being
recycled? Used material must be handled appropriately and in an
environmentally friendly manner. Observe local regulations.
• When in operation the burner’s noise level can exceed 85 dBA. Wear
ear defenders when in the same room.
• It is not permitted to use the burner outside the intended area of use.
• The burner may not be commissioned with safety or protective devices
that are not fit for purpose. Nor are custom design modifications
or the installation of accessories not tested together with the
burner permitted. Commissioning is to be carried out by qualified
professionals only.
• Prior to commissioning, the following points should be checked:
–all fitting and installation work has been completed and approved
–the electrical installation has been carried out properly, the correct
fuses added to circuits and measures to safeguard enclosures on
electrical devices and all wiring have been checked
–flue gas ducts and combustion air ducts are not blocked
–all actuators and control and safety devices are in working order and
set correctly
Service
• Service should be performed after approx. 3,000 working hours, but
no less than once a year.
• Only authorised personnel should perform the service.
• Before servicing, shut off the fuel supply, switch off the installation’s
main switch and ensure accidental reconnection cannot take place.
• Be careful: certain parts exposed after separation of the burner can be
hotter than 60°C.
• Care should be taken by the installer to ensure that no electrical
cables or gas pipelines are crushed or damaged during installation or
servicing.
• Only spare parts recommended by Enertech should be used.

6Bentone BG550/650
General
What to do if you smell gas
• Prevent open flames or sparking, e.g. do not turn lights on or off, do
not use any electrical appliances, do not use mobile phones. Open
windows and doors. Close the gas ball valve. Warn residents; do not
use doorbells. Vacate the building. Notify the company/installer or gas
supplier once the building has been vacated.
• Turn off the equipment and take the boiler out of operation. Open
windows and doors. Notify the company/installer.
• Check that the burner is approved for the intended grade of gas and
connection pressure.
• No safety systems on the burner may be disconnected.
• General advice on how to eliminate a fire
• One or more boilers for solid or liquid fuel whose total rated output
exceeds 60 kW should be installed in a separate boiler room. An
airlock should be the only way a separate boiler room is connected
to evacuation routes from residential buildings in activity class 3, and
offices in activity class 1 that do not constitute an integrated part of an
industrial activity or similar activity. (Swedish building regulations BFS
2011:26).
• The term “separate boiler room” refers to boiler rooms which are
specially designed to provide protection against the starting and
spreading of fire and the production and spreading of combustion gas.
(Swedish building regulations BFS 2011:26).
• Separate boiler rooms and fuel stores immediately next to a separate
boiler room should be designed as individual fire compartments.
(Swedish building regulations BFS 2011:26).
Safety instructions
• Read the manual before installation or commissioning.
• The burner may be installed by authorised personnel only.
• Check that the burner is compatible with the boiler’s output range.
• The power data on the type sign refers to the burner’s min. and max.
power.
• Check that the burner’s dimensions and capacity range are suitable for
the boiler in question.
• The electrical installation must be carried out in accordance with
applicable heavy current regulations and in a professional manner,
avoiding the risk of gas leaks, fire or personal injury.
• If any electrical connection is used other than that recommended by
Enertech, there may be a danger of damage to property and personal
injury.
• Care should be taken by the installer to ensure that no electrical
cables or gas pipelines are crushed or damaged during installation or
servicing.
• The burner must be installed so that it complies with local regulations
on electrical safety and boiler and fuel distribution.

7
Bentone BG550/650
General
• Check that the burner is approved for the intended grade of gas and
connection pressure.
• No safety systems on the burner may be disconnected.
• The installer must ensure that the boiler room has sufficient fresh air
ventilation as per local norms.
• Gas leak checks should be carried out on installation and servicing to
avoid a gas leak and the associated hazards and risks.
• Before servicing, shut off the fuel supply and turn off the power to the
burner.
• The surface temperature of the burner’s components may exceed
60°C.
• Be careful when servicing: there may be a risk of pinching.
• Ensure that the burner is protected against direct spraying of water,
since it is not designed to withstand this.
• Only spare parts recommended by Enertech should be used.
• This burner cannot be used for biogas without first contacting
Enertech.
• If the boiler has a door that opens, this should be locked with a door
switch.
Delivery check
• Make sure everything is delivered and the goods have not been
damaged during transit.
• If something is wrong with the delivery, report it to the supplier.
• Transport damage must be reported to the shipping company.

8Bentone BG550/650
General
(ø210)ø254-280
ø190
M12
1. Technical data
Type designation BG550/BG650
1.1 Dimensions
E
H
I
C
B
E
F
G
D
A
Type Length of
burner tube
Flange
measure A
Burner tube
measure B
Burner tube
measure C
BG 550
Standard 1 256 226
162 162Standard 2 356 326
Standard 3 456 426
BG 650
Standard 1 316 286
185 162Standard 2 416 386
Standard 3 516 486
* Depending on which components that are used, dimensions may vary
D E F G H I
BG 550 660 320 400 *590 *740 340
BG 650 660 320 400 *590 *740 340
K L M
BG 550 M12 Ø 170 (Ø 210) Ø 255-290
BG 650 M12 Ø 190 (Ø 210) Ø 254-280

9
Bentone BG550/650
General
Type Grade
of gas
Capacity
kW
Gas quantity
at min. power
Nm3/h 1)
Gas quantity
at max.
power Nm3/h
1)
Max.
connection
pressure
mbar
Nominal
connection
pressure mbar
BG 550 G20 140–628 14 63
360
40
BG 550 G25 140–608 17 76 40
BG 550 G30 140–628 4 19 30–50
BG 550 G31 140–628 6 25 30–50
BG 650 G20 200–1125 20 113
360
40
BG 650 G25 200–1125 24 141 40
BG 650 G30 200–1125 6 33 30–50
BG 650 G31 200–1125 7 43 30–50
1) A heat value in kWh/Nm3is used for the underlying calculation in normal
ambient conditions: 15°C 1013.25 mbar (as per SS-EN 676)
Calorific value:
G20 Natural gas 10,0 kWh/Nm3
G25 Natural gas 8,0 kWh/Nm3
G31 Propane 26 kWh/Nm3
G30 Butane 34 kWh/Nm3
Gas quantity and capacity vary according to grade of gas and connection
pressure.
1.2 Output range
1.2.1 Burner Specification
Type Motor Ignition
transformer
Fitting Complete
burner
Sound
BG 550 0,75 kW
230/400V 50 Hz
2800 Rpm
3,2/1,8A
Prim. 230 V, 0,25A
50-60Hz 60VA
Sek. 11kV Ampl
50 mA rms
33% ED in 3 min
Naturgas,
Propane,
Butane
1 ½”-2”
0,95 kW
230/400 V
50 Hz
4,0/2,7 A
89 dBA ± 0,5
dBA
BG 650 1,5 kW
230/400V 50 Hz
2800 Rpm
5,7/3,3A
1,7 kW
230/400 V
50 Hz
6,6/4,3 A
91 dBA ± 0,5
dBA

10 Bentone BG550/650
General
Capacity kW
Pressure in fire place
Capacity kW
Pressure in fire place
2
100 200 300 400 500 600 700
-2
0
6
8
10
12
14
4
200 300 400 500 600 700 800
-2
0
6
8
10
12
14
4
2
900 1000 1100 1200
1.3 Working field
BG550
G20,G30 & G31
140-628 kW
G25
140-608 kW
BG650
200-1125 kW
Unbroken line is the approved working
field as per EN 676.

11
Bentone BG550/650
General
S 20/S 50
P1
L1
Mp
N
P1
L1
MP
N
2
1
2.1.1 Electritrical connection MB-DLE403.....B01
2. Skeleton diagrams
2.1 Multi-Bloc MB-DLE403.....B01
!When Bio gas is used, Bentone shall always be contacted.
1
2
pe
3
pa
2
pe
3
pa
4
1 3 2 2 3 1
4
1
1,3,4 G 1/8 screw plug
2 Test nipple, optional

12 Bentone BG550/650
General
V1 V2
AB
C
E
15
14
13
12
11
6
5
4
3
2
1
7
10
8
9
18 19
17
16
p1p2
1. Pressure regulator
2. Microfilter
3. Valve V1
4. Connection flange
5. Closing spring V1
6. Housing
7. Armature V1
8. Regulating spring
9. Solenoid V1
10. Electrical connection
11. Valve V2
12. Closing spring V2
13. Armature V2
14. Solenoid V2
15. Solenoid housing
Setting:
16. - Gas pressure pa
17. - Main volume
18. - Fast stroke
19. Hydraulic brake
MB-DLE403.....B01

13
Bentone BG550/650
General
2.1.2 Functional discription of gas
flow
1. When the valves V1 and V2 are closed, chamber A
is under inlet pressure.
2. A hole D in the filter housing connects min.
pressure switch with chamber A. If the inlet
pressure applied to the pressure switch exceeds
the incoming reference value, it switches through
to the automatic burner control.
3. After release by the automatic burner control,
valves V1 and V2 open. The gas flows through
chambers A, B and C of the GasMultiBloc.
2.1.3 Operating method of valve-
regulator combination on valve
V1
A regulator, compensating for residual pressure is
integrated in valve V1 (pressure regulating part). Armature
7 is not connected to valve plate unit 3. When it opens,
armature 7 pretensions compression spring (V1) 5 and
releases the valve plate unit. When the valve closes, the
armature acts directly on the valve plate unit. The output
pressure upstream of valve 2 is defined by pretensioning
regulating spring 8 (tension spring) via setting screw 16.
The output pressure acts via opening E on the working
diaphragm of regulator part 1. In regulated state, setting
spring inlet pressure and pressure of working diaphragm
are in force equilibrium.
2.1.4 Operating method of valve V2
Armature 13 of valve V2 is connected to valve plate unit
11. When it opens, armature 13 pretensions closing
spring 12. The maximum valve opening can be set
by limiting the armature stroke by means of the main
volume restrictor 17. Min. opening (residual stroke) of
valve (0.5 to 1.0 mm) Main volume restrictor 17 is set by
rotating the adjusting plate or the hydraulic brake 19. The
fast and/or slow opening characteristic is influensed by
setting the fast stroke 18 at the hydraulic brake 19 under
the cover.
2.1.5 Closing function
When the supply voltage to the solenoid coils of valves
V1 and V2 is interrupted, they are closed within < 1 s by
the compression springs.
2.1.6 Closing stroke limitation
(option)
A partial volume setting is possible by means of a closing
stroke limiter. Valve V2 becomes a regulating actuator
without zero shutoff. Partial volume and main volume are
adjustable.
MB-DLE403.....B01

14 Bentone BG550/650
General
3
pe
2
5
pBr
4
pa
V3
04
pa
5
pBr
16
V1 V2
0
2
66
5 3 4 4 5
S 22/S 52
Valves V1, V3
1st stage
Valve V2
2nd stage
P1
L1
P2
L2
Mp
N
N
Mp
L
P
N
Mp
L
P
P2
L2
P1
L1
MP
N
1
2
3
2.2.1 Electritrical connection MBZRD-LE......B07
0 Filter cover
1,3,4,6 G 1/8 screwed sealing plug
2 Test nipple (option)
5 M4 screwed sealing plug
2.2 Multi-bloc MBZRD-LE......B07

15
Bentone BG550/650
General
V2/2
V2/1
V3
V1
A
B
C
D
E
p1p2
15
14
13
12
6
5
4
3
2
1
7
10
11
8
9
18
19
17
16
21
20
24
22
23
28
27
26
25
1. Pressure regulator
2. Microfilter
3. Valve V1
4. Connection flange
5. Closing spring V1
6. Housing
7. Regulating spring
8. Armature V1
9. Solenoid V1
10. Gas pressure switch (optional)
11. Electrical connection
12. Valve V2
13. Closing spring V2
14. Armature V2 (1st stage)
15. Solenoid V2 (1st stage)
16. Armature V2 (2nd stage)
17. Armature V2 (2nd stage)
Setting:
18. - Gas pressure pa
19. - Partial volume, 1st stage
20. - Main volume
21. - Fast stroke
22. Working diaphragm
23. Compensation diaphragm
24. Solenoid V3
25. Armature V3
26. Closing spring V3
27. Valve V3
28. Bypass restrictor
MBZRD-LE......B07

16 Bentone BG550/650
General
2.2.2 Functional description of gas
flow
1. When the valves V1 and V2 are closed, chamber A
is under inlet pressure.
2. A hole D in the filter housing connects min.
pressure switch with chamber A. If the inlet
pressure applied to the pressure switch exceeds
the incoming reference value, it switches through
to the automatic burner control. After release by
the automatic burner control, valves V1 and V3
open.
3. The gas flow through chambers A, B and via
bypass valve V3 in C of the GasMulti-Bloc is
released. The ignition gas volume is adjusted by
using the bypass restrictor. The pressure regulator
controls the pressure upstream of valves V2 and
V3.
4. When valve V2 is released, the gas flows directly
into chamber C, the bypass valve V3 remains
open. On request, the second stage of valve V2
opens.
2.2.3 Operating method of valve-
regulator combination on valve V1
A regulator, compensating for residual pressure is
integrated in valve V1 (pressure regulating part).
Armature V1 is not connected to the valve plate
unit. When it opens, the armature pretensions the
compression spring and releases the valve plate unit.
When the valve closes, the armature acts directly on the
valve plate unit. The output pressure upstream of valves
V2 and V3 is defined by pretensioning the regulating
spring 7 (tension spring) via setting screw 18. The output
pressure acts via opening E on the working diaphragm
of the regulator. In regulated state, setting spring inlet
pressure and pressure of working diaphragm are in force
equilibrium. The compensating diaphragm 23 ensures
the fast closing function of valve V1 and a high regulating
quality.
2.2.4 Operating method of bypass
valve V3
The bypass valve V3 opens at the same time as valve
V1. Ignition gas flow is set by using bypass restrictor 28.
2.2.5 Operating method of valve V2
The armature 14 of valve V2 is connected to the
valve plate unit 12. When it opens, the armature 14
pretensions the compression spring 13. The maximum
valve opening can be set by limiting the armature stroke
by means of the main volume restrictor 20.
2.2.6 Min. opening (residual stroke)
of Valve (0.5 to 1.0 mm)
The main volume restrictor 20 is set by rotating the
adjusting plate or the hydraulic brake. When the second
stage of valve 2 opens, compression spring 13 is
continuously pretensioned. The maximum valve opening
of the second stage can be set by limiting the armature
stroke by means of the main volume restrictor. The main
volume restrictor is set by rotating the adjusting plate
or the hydraulic brake. The fast and/or slowl opening
characteristic is influenced by setting the fast stroke 21
at the hydraulic brake under the cover.
2.2.7 Closing function
When the supply voltage to the main valve solenoid coils
is interrupted, the valves V1, V3 and V2 are closed within
< 1 s by the compression springs.
MBZRD-LE......B07

17
Bentone BG550/650
General
2.3 Multi-bloc MB-VEF 407-412.....B01
1,3,4,6 G 1/8 screwed sealing plug
2 Measuring nozzle (option)
5 M4 screwed sealing plug
7,8,9 G 1/8 female thread for pL,pF,pBr pulse lines
0 Filter cup
1
2
6
5
4
5
4
2
0
0
p , extern
PN1, DN 4
min. 5 x DN
p
p
ap
Br
p
ap
Br
Br
F
pL
7 8
9
3
p
e
3
p
e
V
N
N
V
1
0
7
6
9
8
5
3
4
1
0
7
534
22
2.4 Electritrical connection MB-VEF 407-420
S 10/S 30
P1
L1
Mp
N
P1
L1
MP
N
2
1
2.5 Multi-bloc MB-VEF 415-420.....B01
6 5 7
5
8
657
NN
1
345
5
345
9
9
11
4
34 3
V1 V2
6 7
1, 2, 3, 4, 5 G 1/8 screwed seal plug
9 Test nipple (option)
6, 7, 8 Pulse lines pL,pF,pBr

18 Bentone BG550/650
General
3. Description
3.1 2-Stage/Modulating
Components
1. Flame cone
2. Connection flange
3. Guide bar
4. Fan wheel
5. Fan house
6. Shrouded disc
7. Ignition electrode
8. Nozzle
9. Ionisation electrode
10. Motor
11. Connection gas fittings
12. Ignition transformer
13. Air damper
14. Air damper motor
15. Air pressure switch
16. Fuse holder
17. Indicating lamp Stage 2 /
Change-over switch increase-
decrease
18. Switch I-II / Change-over
switch manually-automatically
19. Indicating lamp Stage I
20. Switch 0-l
21.
22.
23. Contactor with thermal
overload protection
24. Control box

19
Bentone BG550/650
General
4. Mounting of the burner
!For maintenance of the brake plate, nozzles, electrodes etc, when using a long
design of the burner tube, you have to remove the nozzle assembly from the
connecting pipe and move the assembly backwards in the fan housing (from the
boiler).
Fit the burner to the boiler by means of 4 bolts M12. For flange and bolt
dimensions see technical data.
If for some reason you want to separate the burner from the gas flange with
burner head and valve package you can do so.
Do like this:
• Remove the cover of the fan housing.
• Loosen the nut D of the gas assembly package.
• Loosen the electric cables to the valve package.
• Loosen the screws B on both sides.
• Loosen the stop bolt C on the pull rods.
• Loosen the ignition cable and the ionisation cable from the gas
assembly.
• Pull out the burner on the pull rods and put it in a suitable place.
When the burner head and the gas flange have been fitted to the boiler it is
easy to lift up the burner to where it belongs.
4.1 Inspection of gas assembly
If the gas assembly needs to be inspected the pull rods are very useful.
Do like this:
• Remove the cover of the fan housing.
• Loosen the nut D of the gas assembly package.
• Loosen ignition cable and ionisation cable of gas assembly.
• Loosen the screw A on both sides.
• Pull out the burner on the pull rods.
• Loosen the screws B on the gas flange.
• Withdraw the gas assembly.
Ensure that the O-ring between the gas assembly and the gas flange will be
in the correct position when the gas assembly is fitted again

20 Bentone BG550/650
General
Service position
4.2 Adjustment of the position of the
shrouded disc in the blast tube
Sometimes it is necessary to adjust the position of the shrouded disc in the
blast tube. This can be done with the screw E (can be adjusted when the
burner is in operation). If you turn the screw to the left the shrouded disc will
move forward (+), to the right it will move backward.
