Beny Sports V-fit CX9 Manual

Assembly & User Manual
Please ensure that you read this manual carefully
before attempting to assemble or use your new
product and retain for future use
CX9 Motorised Folding Programmable Treadmill with MP3 Link

Contents
Section Page
General Information . . . . . . 4
Before you start . . . . . . . . . 5
Safety . . . . . . . . . . . . . . . . . 6
Exercise Information . . . . . . 8
Assembly . . . . . . . . . . . . . . 11
User Instructions . . . . . . . . . . 16
Page 3
CX9 Motorised Folding Programmable Treadmill with MP3 Link

General Information
Quality
This exercise product has been designed and
manufactured to comply with the latest (BS EN 957)
British and European Safety Standards.
Questions
Should you encounter any difficulty with the assembly,
operation or use of your V-fit exercise product or if you
think that you may have parts missing, please DO NOT
return it to your retailer but contact us first for help and
advice, asking for CUSTOMER SUPPORT, by any of the
following means.
Tel:- 0871 222 0881 or
Fax:- 01535 637722 or
Email:- [email protected]
CUSTOMER SUPPORT is open from 9.00am to 5.00pm
from Monday to Friday
Beny Sports Co. UK Ltd.
Unit 8, Riparian Way,
The Crossings, Cross Hills,
West Yorkshire.
BD20 7BW
Queries
If you do have any queries, please ensure that you have
the following information ready for our Customer Support
Staff:
YOUR NAME
YOUR ADDRESS
YOUR PHONE NUMBER
PRODUCT MAKE OR BRAND
PRODUCT MODEL
PRODUCT SERIAL NUMBER
DATE OF PURCHASE
NAME OF RETAILER
PART NUMBERS REQUIRED
Guarantee
Beny Sports Co. UK Ltd. guarantee's its product range for
DOMESTIC USE ONLY for a period of 1 YEAR from the
original certified date of purchase. During this period we
have the right to: -
a). Provide parts for the purchaser to effect repair.
b). Repair the product, returned to our warehouse
(at the purchaser's cost).
c). Replace the product if it is deemed (by us) to be
economical to do so.
This guarantee does not cover wear and tear on
upholstery or consumables.
This guarantee does not cover abuse, defects caused by
storage or use outside those intended.
If you need to advise us of a defect with your product and
in order for us to service any requirement for replacement
parts or repairs, we may ask for proof of purchase. Failure
to do so may result in any claim for replacement parts or
repairs being refused.
This guarantee, (both given and implied) applies to the
original purchaser only, is not transferable and will be
invalidated if used outside of the above criteria.
This guarantee is valid only in the United Kingdom and Eire.
This does not affect your statutory rights as a consumer.
Customer Support
Tel:- 0871 222 0881 or
Fax:- 01535 637722 or
Email:- [email protected]
CUSTOMER SUPPORT is open from 9.00am to
5.00pm from Monday to Friday
Beny Sports Co. UK Ltd.
Unit 8, Riparian Way,
The Crossings, Cross Hills,
West Yorkshire
BD20 7BW
CX9 Motorised Folding Programmable Treadmill with MP3 Link
Page 4

Before you Start
Tools
If required, most of our products products are supplied with basic tools,
which will enable youto successfully assemble your product. However,
you may find it beneficial to have a soft-headed hammer and perhaps an
adjustable spanner handy as this may help.
Prepare the Work Area
It is important that you assemble your product in a clean, clear,
uncluttered area. This will enable you to move around the product
while you are fitting components and will reduce the possibility of
injury during assembly.
Work with a Friend
You may find it quicker, safer and easier to assemble this product with
the help of a friend as some of the components may be large, heavy
or awkward to handle alone.
Open the Carton.
Carefully open the carton that contains your product, taking note of
the warnings printed on the carton to ensure that the risk of injury is
reduced. Be aware of sharp staples that may be used to fasten the
flaps as these may cause injury. Be sure to open the carton the right
way up, as this will be the easiest and safest way to remove all the
components.
Unpack the Components
Carefully unpack each component, checking against the parts list that
you have all the necessary parts to complete the assembly of your
product.
Please note that some of the parts may be pre-fitted to major
components, so please check carefully before contacting our
CUSTOMER SUPPORT team.
In any event, please do not return the product to your retailer before
contacting us first.
Page 5
CX9 Motorised Folding Programmable Treadmill with MP3 Link

Safety
Before you undertake any programme of exercise that will increase
cardiovascular activity please be sure to consult with your doctor.
Frequent strenuous exercise should be approved by your doctor and
proper use of your product is essential. Please read this manual
carefully before commencing assembly of your product or starting to
exercise.
* Please keep all children away from exercise products when in
use. Do not allow children to climb or play on them when they
are not in use.
* For your own safety, always ensure that there is at least 1 Metre
of free space in all directions around your product while you are
exercising.
* Regularly check to see that all nuts, bolts and fittings are
securely tightened. Periodically checking all moving parts for
obvious signs of wear or damage.
* Clean only with a damp cloth, do not use solvent cleaners. If you
are in any doubt, do not use your product, but contact
CUSTOMER SUPPORT by any of the means listed on the
opposite page.
* Before use, always ensure that your product is positioned
on a solid, flat surface. If necessary, use a rubber mat
underneath to reduce the possibility of slipping in use.
* Always wear appropriate clothing and footwear such as training
shoes when exercising. Do not wear loose clothing that could
become caught or trapped during exercise.
Storage and Use
Your product is intended for use in clean dry conditions. You
should avoid storage in excessively cold or damp places as this may
lead to corrosion and other related problems that are outside our
control.
Weight Limit
Your product is suitable for users weighing:
253LBS / 18 Stones / 115KG or less.
Conformity
This product conforms to:
(BS EN 957) - PARTS 1 and 6 Class (H) - HOME USE - Class (C).
It is NOT suitable for therapeutic purposes.
Page 6 CX9 Motorised Folding Programmable Treadmill with MP3 Link

Safety
Safety-Treadmill Specific
When using an electrical appliance, basic precautions should always be followed,
including the following:
Read all instructions before using the treadmill.
DANGER – To reduce the risk of electric shock:
Always unplug this appliance from the electrical outlet immediately after using
and before cleaning.
WARNING – To reduce the risk of burns, fire, electric shock, or injury to persons:
1. An appliance should never be left unattended when plugged in. Unplug from the
power outlet when not in use, and before putting on or taking off parts.
2. Close supervision is necessary when this appliance is used by, on, or near children,
invalids, or disabled persons.
3. Use this appliance only for its intended use as described in this manual. Do not use
attachments not recommended by the manufacturer.
4. Never operate this appliance if it has a damaged cord or plug, if it is not working
properly, if it has been dropped or damaged, or dropped into water.
Return the appliance to our warehouse for examination and repair.
5. Do not carry this appliance by power supply cord or use cord as a handle.
6. Keep the cord away from heated surfaces.
7. Never operate the appliance with the air openings blocked. Keep the air openings
free of lint, hair, and the like.
8. Never drop or insert any object into any opening.
9. Do not use outdoors.
10. Do not operate where aerosol (spray) products are being used or where
oxygen is being administered.
11. To disconnect, turn all controls to the off position, then remove the plug from the power outlet.
12. Connect this appliance to a properly earthed power outlet only.
13. The appliance is intended for household use only.
SAVE THESE INSTRUCTIONS
14. This product is suitable for users weighting: 253 LBS / 18 Stones / 115 KG or less.
Page 7
CX9 Motorised Folding Programmable Treadmill with MP3 Link

Exercising Information
Warm Up
A successful exercise programme consists
of three parts, Warm Up, Aerobic Exercise
Perform between five and ten minutes of
Aerobic Exercise Session
Those new to exercise should exercise no
more than every other day to start with.
As your fitness level increases, increase
When you are comfortable with your
Exercising in your Target
To ensure that your heart is working in its
unit) you will need to locate the pulse in
your carotid artery. This is situated in the
seconds and then multiply by six to get
your pulse rate. This should be taken
before you start to exercise for easy
reference.
People who have a greater aerobic
and will also be able to exercise with a
higher pulse level.
Target Zone
To determine your target zone, see the
column. If you exercise regularly and have
good aerobic fitness, refer to the right
column.
Beginning
How you begin to exercise will vary
from person to person. If you have
not exercised for a long period of time,
have been inactive for a while, or are
severely over weight you MUST start slowly,
increasing your exercise time gradually,
by perhaps only a few minutes for each
session per week.
Combine a carefully structured nutritious
diet with a simple but effective exercise
routine and this can help make you feel
better, look better and will almost certainly
enable you to enjoy life more.
Aerobic Fitness
Aerobic exercise is simply defined as
any sustained activity that increases
the supply of oxygen to your muscles
via the blood pumped by your heart.
With regular exercise, your cardiovascular
system will become stronger and more
efficient. Your recovery rate i.e. the time
taken for your heart to reach its normal
resting level, will also decrease.
Initially you may only be able to exercise
for a few minutes each day. Do not
hesitate to breathe through your mouth
should you need more oxygen. Use the
"talk test". If you cannot carry on a
conversation while exercising, you are
working too hard! However, aerobic fitness
will be gradually built up with regular
exercise, over the next six to eight weeks.
Do not be discouraged if it takes longer
than this to begin to feel less lethargic,
everyone is different and some will achieve
their targets quicker than others.
Work at your own, comfor table pace and
the results will come. The better your
aerobic fitness the harder you will
have to work to stay in your target zone.
and Cool Down. Never start a training
session without warming up. Never finish
one without cooling down correctly.
stretching before starting your workout to
prevent muscle strains, pulls and cramps.
this to 2 in every 3 days.
routine, exercise for 6 days per week.
Always take at least one day off per week.
Zone
exercise target zone, you need to be able
to take your pulse. If you do not have a
pulse monitor (either from the product
you are using or a proprietary independent
side of the neck and can be felt by using
the index and middle fingers. Simply
count the number of beats you feel in 10
fitness, have a lower resting pulse level
chart opposite. If you are new to exercise
and by definition unfit, refer to the left
Page 8 CX9 Motorised Folding Programmable Treadmill with MP3 Link

Exercising Information
USERS
AGE
(Years)
20-24
25-29
30-34
35-39
40-44
45-49
50-54
55-59
60 and over
UNCONDITIONED
TARGET ZONE - A
(Beats per Minute)
145 - 165
140 - 160
135 - 155
130 - 150
125 - 145
120 - 140
115 - 135
110 - 130
105 - 125
CONDITIONED
TARGET ZONE - B
(Beats per Minute)
155 - 175
150 - 170
145 - 165
140 - 160
135 - 155
130 - 150
125 - 145
120 - 140
115 - 135
Cool Down
To decrease fatigue and muscle soreness, you should also cool down
by walking at a slow relaxed pace for a minute or so, to allow your
heart rate to return to normal.
Warm Up and Cool Down Exercises
Hold each stretch for a minimum of ten seconds and then relax.
Repeat each stretch two or three times. Do this before your Aerobic
Exercise session and also after you have finished.
Head Roll
Rotate your head to the right for one count, feeling a slight pull on the
left side of your neck. Next, rotate your head back for one count,
stretching your chin. Then rotate your head to the left for one count,
feeling a slight pull on the right side of your neck. Lastly, drop your
head to your chest for one count. Repeat 2 to 3 times.
Toe Touch
Slowly bend forward from your waist, letting your back and shoulders
relax as you lower your trunk. Gently stretch down as far as is
comfortable and hold for 10 seconds.
Target Zone (con't)
Page 9
CX9 Motorised Folding Programmable Treadmill with MP3 Link

Exercising Information
Shoulder Lift
Rotate and lift your right shoulder up towards your ear for one count.
Relax then repeat for the left shoulder.
Repeat 3 - 4 times.
Calf / Achilles Stretch
Turn towards the wall and place both hands on it. Support yourself
with one leg while the other is placed behind you with the sole flat on
the floor. Bend the front leg and lean towards the wall, keeping the
rear leg straight so that the calf and Achilles tendon are stretched
hold for 5 seconds. Repeat with the other leg.
Repeat 2 - 3 times.
Side Stretch
Open both arms to the side and gently lift them above your head.
Reach your right arm as high as you can for one count, gently
stretching the muscles of the stomach and lower back. Repeat the
action with your left arm.
Repeat 3 - 4 times.
Inner Thigh Stretch
Sit on the floor and pull your legs toward your groin, the soles of your
feet together. Hold your back straight and lean forward over your feet.
Tighten the thigh muscles and hold for 5 seconds. Release and repeat
3 - 4 times.
Hamstring Stretch
Sit on the floor with your right leg extended and place your left foot
flat against the right inner thigh. Stretch forward toward the right foot
and hold for 10 seconds. Relax and then repeat with the left leg
extended.
Repeat 2 - 3 times.
Page 10 CX9 Motorised Folding Programmable Treadmill with MP3 Link

Assembly
Overview Drawing
Computer
Safety Key /Clip
Upright
Frame
Power Switch
Circuit Breaker
01
Page 11
CX9 Motorised Folding Programmable Treadmill with MP3 Link

Assembly
ITEM Description Qty
A
B
Computer Console 1
1
Frame
Assembly Main Components
A
B
Page 12 CX9 Motorised Folding Programmable Treadmill with MP3 Link

Assembly
ITEM Description Qty
aAllen Bolt M8 x 15mm 6
Assembly Main Components
These are the only accessories needed to complete the assembly
of your Treadmill.
bAllen Bolt M8 x 40mm 4
cAllen Wrench 5mm 1
dSafety Key / Clip 1
eSilicon 1
ab
cde
fh
fPop-Pin Head
gSpring 1
hPin 1
1
g
Page 13
CX9 Motorised Folding Programmable Treadmill with MP3 Link

Assembly
Assembly instruction
b
b
b
b
a
a
1. Pull up the Uprights (L & R) (13 & 14) into position on the front Treadmill Body
Frame (B). Secure with 2 x M8 x 15mm Allen Bolts (Item a) and 2 x M8 x 45mm
Pull up the Handrail (L & R) (75 & 76) into position of the Uprights (L & R) (13 & 14)
Secure with 2 x M8 x 45mm Allen Bolts (Item b).
Allen Bolts (Item b).
Fix the Pin (h) and Spring (g) together and place through the Upright (R) attach the Pop-Pin
Head (f) to the Pin (h) and tighten.
NOTE: - Do not fully tighten the bolts at this stage.
f
hg
Beny Sports Co. UK Ltd
Unit 8, Riparian Way,
The Crossings, Cross Hills,
West Yorkshire.
BD20 7BW
Two persons may be required to finish the assembly steps.
(Caution!! Please follow the assembly steps below to aviod injury.)
Carefully unpack each component, checking against the parts list that
you have all the necessary parts to complete the assembly of your
product.
Please note that some of the parts may be pre-fitted to major
components, so please check carefully before contacting our
CUSTOMER SUPPORT team.
In any event, please do not return the product to your retailer before
contacting us first.
Tel:- 0871 222 0881 or
Fax:- 01535 637722 or
E-mail:- [email protected]
CUSTOMER SUPPORT is open from 9.00am to 5.00pm from Monday
to Friday
Page 14 CX9 Motorised Folding Programmable Treadmill with MP3 Link

Assembly
2.
Place the Computer Console (Item A); onto the Left
and Right Handrail (C & D) as shown
Loosely secure in place using 2 x M8 x 15mm Allen Bolts
(Item a). Take care not to trap any wires.
NOTE: - Now fully tighten all bolts.
3. Connect the Mains Power Lead (41) to a suitable 13
amp earthed power supply and switch the Treadmill on
at the Power Switch (38) which is located at the front
of the Treadmill Body Frame (B).
Assembly instruction
a
C
A
D
a
Take the Computer Console (Item A) and connect the
multi connectors together, feeding them into the Frame
(make sure you match colour for colour and like for like).
Page 15
CX9 Motorised Folding Programmable Treadmill with MP3 Link

User Instructions
TO FOLD YOUR TREADMILL
1. Turn off the Treadmill and unplug the Mains Power Lead (41) from the mains supply.
2. Lift the rear of the Treadmill Body Frame and push carefully into the frame aperture
ensuring that the Pop-Pin (10) locates securely into the hole on the Right of the
Treadmill Body.
3. To lower the Treadmill, support the Treadmill Body and pull out the Pop-Pin (10) to
disengage the lock, gently lower the Treadmill Body to the ground.
WARNING: - THIS TREADMILL IS HEAVY & WHILE THE FRAME IS BALANCED IT SHOULD BE MOVED WITH GREAT CARE
AS POSSIBLE INJURY MAY RESULT FROM INCORRECT MOVEMENT.
TO MOVE THIS TREADMILL WHEN ASSEMBLED, PLEASE ENSURE THAT YOU LIFT (& CONFIRM AS LOCKED) THE RUNNING
DECK INTO AN UPRIGHT POSITION. THE POP-PIN OR FRAME LOCK MUST BE FULLY ENGAGED.
TILT THE RUNNING DECK TOWARDS YOU TO DISENGAGE THE FLOOR FRAME FROM ITS FLAT POSITION ON THE FLOOR & TO
ENSURE THAT THE FRAME TRANSPORTATION WHEELS (69) RUN SMOOTHLY.
CAREFULLY MANOEUVER THE TREADMILL TO ITS DESIRED POSITION.
TO ADJUST THE INCLINE LEVEL ON YOUR TREADMILL
TREADMILL MOVING INSTRUCTIONS
Pop-Pin
Lift the rear of the Treadmill Body and gently pull the Incline Rod (32) away from its
location in the Rear of the Treadmill Body. Move the Rod into any of the 3 preset
positions & release against the spring tension to slot into position.
Page 16CX9 Motorised Folding Programmable Treadmill with MP3 Link

Speed Time
1~4ML One year
4~8ML 6 months
If the Running Belt tends to move off central during operation, step off the belt and stop the Treadmill.
Start the Treadmill in Manual Programme Mode and adjust the speed to 3mph.
Take the 5mm Allen Wrench (C) and adjust the Rear Roller Location Bolts, which are accessible through the Rear Frame Caps.
If the belt is moving towards the RIGHT side of the Treadmill Running
Board, turn the RIGHT Rear Roller Location Bolt 1/4 turn CLOCKWISE
and let the Running Belt find its new position. If it is still moving
towards the RIGHT side of the Treadmill Running Board, turn the Bolt
a further 1/4 turn.
If the belt is moving towards the LEFT side of the Treadmill Running
Board, turn the LEFT Rear Roller Location Bolt 1/4 turn CLOCKWISE
and let the Running Belt find its new position. If it is still moving
towards the LEFT side of the Treadmill Running Board, turn the Bolt
a further 1/4 turn.
Continue this operation until the Running Belt is running centrally.
Please take care to ensure that the Running Belt does not
foul the Side Strips, as this will cause premature wear to both the
Running Belt and the Side Strips.
Dependent upon usage and user weight it will be necessary periodically to lubricate the underside of the Running Belt.
To ensure that this is done successfully, take the 5mm Allen Wrench (C) and adjust the Rear Roller Location Bolts,
which are accessible through the Rear Frame Caps. Rotate each bolt a full 4 turns ANTI-CLOCKWISE
to slacken off the belt.
Lift the sides of the belt and run a small bead of lubricant onto the Running Board and if
possible spread this with a small brush or cloth to ensure even coverage on the
Running Board.
Re-tighten the Running Belt by adjusting the Rear Roller Location Bolts
CLOCKWISE until the belt is running centrally on the Running Board.
Please see table below for suggested lubrication frequency.
ADJUSTING THE RUNNING BELT TRACKING
LUBRICATING THE RUNNING BELT
User Instructions
age 17
CX9 Motorised Folding Programmable Treadmill with MP3 Link

: START/STOP KEY
ENTER: Confirm the modification, display the interchange statement.
3 : SPEED DIRECT KEY, set speed directly to 3.0KPH (2.0 MPH)
6 : SPEED DIRECT KEY, set speed directly to 6.0KPH (4.0 MPH)
9 : SPEED DIRECT KEY, set speed directly to 9.0KPH (6.0 MPH)
12 : SPEED DIRECT KEY, set speed directly to 12.0KPH (8.0 MPH)
: SPEED DECREASE KEY
: SPEED INCREASE KEY
Computer Instruction
A General Operation
1/. Turn on the Power Switch at the front of your P4 Treadmill. This switch is located next to
the Mains Power Cord inlet.
2/. Place the Safety Key into the magnetic recess in the middle front of the Computer Console. The
console will give an audible signal and all console window displays will function with a start display value
of 0.
* Note:- If the Safety Key is not placed correctly or is faulty, the centre Time window will display "-----------".
This means that the treadmill will not operate.
** If the Safety Key falls off during exercise, the console will give an audible signal and all console window
displays will reset to display value 0 and the treadmill will stop.
*** To stop the treadmill in an emergency, simply pull the safety key off its mount in the console front or
simply press the red STOP button in the centre of the console. It is important that you connect the
clothing clip to your shirt or other suitable clothing during exercise to ensure that this safety system can
operate easily.
**** To get a pre-exercise pulse rate, simply hold both Hand Pulse Sensors on either side of the
Handlebar Supports for 10 seconds. The Pulse Range is between 40 ~ 240 Beats per Minute
See chart over page for average target heart / pulse rates.
User Instructions
Insert the 3.5mm jack plug into the
corresponding socket on your generic
MP3 player and either place your MP3
player into the dock above the exercise
monitor to secure in place.
Page 18 CX9 Motorised Folding Programmable Treadmill with MP3 Link

2/. Programme Operation
In this mode the user has a choice of Programme P2 – Programme P7, with all 3 Programmes having 3 different profiles.
2.1 Press the ENTER button followed by the “+” “-“ to choose from P2-P7 then press ENTER again.
2.2 Press “+” “-“ to choose from Level 1, 2 or 3. Press ENTER.
2.3 The Pre-set value for TIME is 32 minutes. Either press START or ENTER to commence exercise or “+” “-“ to set the desired
exercise TIME manually. The TIME range is 5 ~ 99 minutes in 1 minute increments.
2.4 Press START or ENTER and the treadmill will count down 3, 2, 1 and commence operation. The start speed depends on
which Programme you have chosen.
2.5 For all pre-set values, please refer to page 20 & 21 of this manual.
170 OVER
150 166 MIDDLE
120 146 162 LOW
117 143 157
114 137 153
111 135 149
108 131 145
105 128 140
102 124 136
99 120 132
96 116
HEART BEATS/MIN
93
20 25 30 35 40 45 50 55 60 65 （Age）
B Mode Instructions
There are 7 Pre-set Programmes (P2, P3, P4, P5, P6 & P7 with 3 Levels) and 2 Manual (P0 and P1) setting on your
P4 Motorised Treadmill.
1/. Manual Operation
In this mode, (Programme P0 Manual) you can press the START key and the TIME will start counting up and the SPEED will start
from 1.0mph. You can manually adjust the SPEED either pressing “+” or “-“ keys or pressing one of the 4 speed instant keys.
In this mode, (Programme P1 Manual) the user can set their desired EXERCISE TIME.
1.1 Press the ENTER button to enter the MANUAL PROGRAMME P1. This will take you into TIME mode.
1.2 The Pre-set value for TIME is 20 minutes. Either press START/STOP or ENTER to commence exercise or “+” “-“ to set the
desired exercise TIME manually. The TIME Range is 5 ~ 99 minutes in 1 minute increments.
1.3 The Treadmill will start with a pre-set speed of 1.0mph and can be increased/decreased by pressing “+” or “-“ or one of the
4 speed instant keys.
User Instructions
Page 19
CX9 Motorised Folding Programmable Treadmill with MP3 Link

Holding the Pulse Pads on your Treadmill Handlebars will enable your current Heart Rate in Beats per Minute to be displayed on
the Computer Console. The indicated Pulse Range is from 40 – 240 BPM. The display will alternate when on the SCAN function.
Note:- The readings displayed by the computer should not be used for therapeutic purposes as they can vary due to the sensitivity
of the equipment and the available pulse signal put out by individuals palms. To get the best accurate readings keep the hands
placed flat and firm on the PULSE PADS for between 10 and 20 seconds, as this will allow the pulse reading to average and
then settle.
Pulse Function
Programme Starting Speeds
Programme Fitness Level Start Speed
P2
P3
P4
P5
P6
P7
L1
L2
L3
L1
L2
L3
L1
L2
L3
L1
L2
L3
L1
L2
L3
L1
L2
L3
3.0 kph
4.0 kph
5.0 kph
3.0 kph
4.0 kph
5.0 kph
2.0 kph
3.0 kph
4.0 kph
4.0 kph
5.0 kph
6.0 kph
3.0 kph
4.0 kph
5.0 kph
2.0 kph
3.0 kph
4.0 kph
User Instructions
Page 20 CX9 Motorised Folding Programmable Treadmill with MP3 Link
