BERGHOF B-Fortis CC-Slim Series User manual

USER MANUAL 1.2
B-Fortis CC-Slim series

Copyright © Berghof Automation GmbH
Reproduction and duplication of this document and utilisation and communication of its content are pro-
hibited without with our express permission. All rights reserved.
Infringements will result in compensation for damages.
Disclaimer
The content of this document has been checked for conformity with the hardware and software de-
scribed. It is, however, impossible to rule out all discrepancies. As a result, we cannot be held responsi-
ble if the content is not fully compliant. The information in this document is checked regularly and any
necessary corrections are included in subsequent editions. Suggestions for improvement are always
welcome. Subject to technical modifications.
Trademarks
→CANtrol® and CANtrol®-dialog are registered trademarks of Berghof Automation GmbH.
→Microsoft®, Windows® and the Windows® logo are registered trademarks of Microsoft Corp. in the
USA and other countries.
→EtherCAT® is a registered trademark and a patented technology, licensed by Beckhoff Automa-
tion GmbH, Germany.
→CiA® and CANopen® are registered community trademarks of CAN in Automation e. V.
→ARM ® and Cortex ® are registered trademarks of ARM Limited.
→PROFINET® is a registered trademark of PROFIBUS Nutzerorganisation e.V.
→Modbus® is a registered trademark of the Modbus-IDA organisation.
→i.MX6 is a registered trademark of Freescale.
The rights of all companies and company names mentioned in this document as well as products and
product names belong to the respective companies.
Notes about this handbook
This equipment handbook contains information which is specific to the product and valid at the time of
printing.
This equipment handbook is only complete in conjunction with the product-related hardware and soft-
ware manuals required for the specific application.
You can contact us at:
Berghof Automation GmbH
Arbachtalstrasse 26
72800 Eningen
Germany
T +49.7121.894-0
F +49.7121.894-100
Email: [email protected]om
www.berghof-automation.com
Berghof Automation GmbH is certified to DIN EN ISO 9001:2015.

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
3
Revision log
Version
Date
Description
0.1
06/09/2019
Initial version
0.9
08/05/2020
Conversion to catalogue numbers and adaptation to S-number sys-
tem
1.0
18/06/2020
Formatting revised in the document
1.2
05.03.2021
Dual Core versions added

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
4
Table of contents
1. GENERAL INFORMATION .................................................................................................................7
1.1. Notes about this handbook ...............................................................................................................7
1.2. Symbols and visual depictions .........................................................................................................7
1.3. Hazard categories and indications ...................................................................................................8
1.4. Qualified personnel............................................................................................................................9
1.5. Duty of care.........................................................................................................................................9
1.5.1. General ................................................................................................................................................9
1.6. Intended use .....................................................................................................................................10
1.7. Transport and storage .....................................................................................................................11
Transport and storage ........................................................................................................................11
Operation ...........................................................................................................................................11
Devices with (rechargeable) batteries ................................................................................................11
1.8. Unpacking.........................................................................................................................................11
2. SAFETY.............................................................................................................................................12
Safety-related systems.......................................................................................................................12
2.1. Safety instructions ...........................................................................................................................12
Working on the device........................................................................................................................12
3. PRODUCT DESCRIPTION................................................................................................................13
3.1. Overview of B-Fortis CC-Slim .........................................................................................................14
3.2. Scope of delivery and accessories.................................................................................................15
Scope of delivery................................................................................................................................15
Accessories........................................................................................................................................15
CC-Slim plug kit:.................................................................................................................................15
Extensions for tooling and debugging ................................................................................................15
3.3. Product features...............................................................................................................................15
Assembly............................................................................................................................................15
Processor ...........................................................................................................................................15
Ethernet..............................................................................................................................................15
USB....................................................................................................................................................15
CAN interfaces ...................................................................................................................................16
Serial interfaces..................................................................................................................................16
Onboard analogue inputs/outputs ......................................................................................................16
Additional interfaces...........................................................................................................................16
Real-time clock...................................................................................................................................16
microSD card......................................................................................................................................16
Summary of features..........................................................................................................................16
4. ASSEMBLY .......................................................................................................................................17
5. CONNECTION...................................................................................................................................18
5.1. Power supply ....................................................................................................................................18
5.1.1. Connecting the power supply .............................................................................................................19

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
5
5.2. Data connections .............................................................................................................................20
5.2.1. Block diagram.....................................................................................................................................20
5.2.2. Digital inputs and outputs ...................................................................................................................20
5.2.3. Counting inputs (C) ............................................................................................................................25
5.2.4. Ethernet..............................................................................................................................................27
5.2.5. EtherCAT............................................................................................................................................28
5.2.6. USB....................................................................................................................................................29
5.2.7. Serial interfaces..................................................................................................................................30
5.2.8. CAN bus.............................................................................................................................................32
5.2.9. Analogue inputs..................................................................................................................................33
Basic considerations for connecting analogue inputs.........................................................................33
Data from analogue inputs .................................................................................................................34
Operating modes for the analogue inputs ..........................................................................................35
6. OPERATION......................................................................................................................................40
6.1. Switching on and off ........................................................................................................................40
6.2. Initial start-up of the network ..........................................................................................................41
6.3. Operation ..........................................................................................................................................43
6.3.1. Status indicators.................................................................................................................................43
6.3.2. Start/Stop ...........................................................................................................................................44
6.3.3. Real time clock with battery back-up..................................................................................................44
6.3.4. microSD card......................................................................................................................................45
6.4. Troubleshooting ...............................................................................................................................46
6.4.1. No network connection.......................................................................................................................46
6.4.2. In error stop mode..............................................................................................................................46
6.4.3. Unknown IP address ..........................................................................................................................46
7. SERVICING / MAINTENANCE..........................................................................................................47
7.1. Maintenance......................................................................................................................................47
8. DISASSEMBLY .................................................................................................................................48
9. DISPOSAL.........................................................................................................................................49
10. TECHNICAL DATA............................................................................................................................50
10.1. Type plate..........................................................................................................................................53
10.2. Device variants and identification ..................................................................................................54
10.3. Options and extensions...................................................................................................................54
Extensions for tooling and debugging ................................................................................................54
11. STANDARDS AND CERTIFICATES.................................................................................................55
11.1. Standards..........................................................................................................................................55
11.2. Declaration of conformity................................................................................................................55
12. CUSTOMER SERVICES / ADDRESSES ..........................................................................................56
12.1. Customer services ...........................................................................................................................56
12.2. Addresses.........................................................................................................................................56

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
6
13. APPENDIX.........................................................................................................................................57
13.1. Notes on copyright and the software licence ................................................................................57
13.2. List of figures....................................................................................................................................57

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
7
1. General information
This user handbook is intended for use by qualified personnel and contains information on the assem-
bly, installation, start-up and maintenance of the device.
1.1. Notes about this handbook
This user handbook is a component of the product and applies to the following devices:
→B-Fortis CC-Slim
It contains information on the following topics:
→Areas of application
→Safety
→Mechanical design
→Electrical design
→Connections
→Start-up
→Servicing and maintenance
→Decommissioning
→Disposal
Keep this user handbook available alongside the product at all times.
1.2. Symbols and visual depictions
The following symbols and visual depictions are used in this user handbook:
Symbol
Meaning
→…
List entry
…
Individual instruction or list of instructions which can be carried out in
any order.
1. …
2. …
List of instructions which must be carried out in the order given.
Additional product information

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
8
Structure of the warnings:
WARNING
Optional:
More
symbols
Type and source of the danger
Brief description and consequences
Preventive measures
1.3. Hazard categories and indications
The following indications are used for warning messages that must be observed to ensure your per-
sonal safety and avoid any damage to property.
The indications have the following meanings:
DANGER
Serious injury or death
Failure to observe the safety measures will result in death or serious injury.
Take preventive measures.
WARNING
Possible serious injury or death
Failure to observe the safety measures may result in death or serious injury.
Take preventive measures.
CAUTION
Possible minor injuries
Failure to observe the safety measures may result in minor injuries.
Take preventive measures.
NOTICE
Possible damage to property
Failure to observe the safety measures may result in damage to property.
Take preventive measures.

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
9
1.4. Qualified personnel
The installation, start-up and maintenance of the machine must be carried out by qualified personnel.
For the purposes of this documentation and the safety instructions contained therein, “qualified person-
nel” means trained staff with the authorisation to assemble, install, start up, earth and identify devices,
systems and electrical circuits in accordance with the standards set in safety engineering and who are
familiar with safety concepts in automation engineering.
1.5. Duty of care
1.5.1. General
The user or processor (OEM) must ensure the following:
→The device must only be used for its intended purpose.
→The device must only be used in a perfect, fully functional condition.
→The user handbook must always be kept legible and fully available.
→Only sufficiently qualified and authorised personnel carry out assembly, installation, start-up and
maintenance of the device.
→This authorised personnel must receive regular training in all relevant questions of occupational
health and safety and environmental protection and must be familiar with the contents of this
user handbook, particularly the sections containing safety instructions.
→Any markings or identification labels and safety and warning signs on the device must not be re-
moved and must be kept legible at all times.
→The national and international regulations regarding the operation of machinery and installations
where the device is being used must be observed.
→The user must always be kept abreast of any current relevant information regarding the device
and its use or operation.
→The user is responsible for coordinating the use of the safety-related control components with the
responsible authority and for adhering to its specifications.

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
10
1.6. Intended use
The devices are components of the CANtrol modular automation system based on CAN bus for indus-
trial control applications in the medium to high performance range. It extends the communication op-
tions with EtherCAT, Profinet or Modbus for example.
The automation system is designed for use in overvoltage category I (IEC 364-4-443) for the control
and regulation of machinery and industrial processes in low-voltage installations in accordance with the
following basic conditions:
→Maximum rated supply voltage of 1,000 V AC (50/60 Hz) or 1,500 V DC
→For use in an environment with max. category 2 level of pollution (EN 60950)
→For use in a maximum altitude of 2,000 m a.s.l.
→For indoor use in areas not exposed to direct UV radiation
→Max. ambient temperature inside and outside the control cabinet according to the technical spec-
ifications (see “Technical data”).
→Not for use in residential areas (270011500 only)
The B-Fortis CC-Slim is not designed for use in residential areas and is unable to guarantee ade-
quate protection of radio reception in such environments.
Correct and safe operation of the automation system requires qualified project planning, proper
transport, storage, installation and use as well as careful maintenance.
The automation system may only be used within the scope of the information and applications speci-
fied in this documentation and associated user handbooks.
The automation system must only be used as follows:
As intended
In technically perfect condition
Without unauthorised modifications
By qualified users only
Observe the rules of the employers' liability insurance association, the German Technical Inspec-
tion Association (TÜV), the Association of German Electrical Engineers (VDE) or relevant na-
tional regulations.
The device is intended for installation in a suitable installation cut-out in industrial machines and sys-
tems in indoor areas.
During installation, make sure that the existing seal profiles are undamaged.
For operation, refer to the applicable ambient conditions (see “Technical data”).

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
11
1.7. Transport and storage
The device is susceptible to impacts, heavy vibrations, moisture and extreme temperatures.
Transport and storage
Protect the device from heavy mechanical stresses during transport.
Always transport the device in its original packaging.
For storage, refer to the applicable ambient conditions (see “Addresses”).
Protect the device from condensation and moisture.
Operation
If the device has been stored or transported in cold weather or under conditions of large fluctua-
tions in temperature, do not start to operate it until it has acclimatised to room temperature for the
place in which it is used.
Wait at least 12 hours after it has reached room temperature before operating the device.
Devices with (rechargeable) batteries
Lithium metal batteries are a hazardous material. According to the manufacturers, they fall under UN
3091 (contained in the device).
Special provision 188 of the ADR can be applied tor transport.
1.8. Unpacking
Upon receipt of the device, make sure that it is undamaged and complete.
Check the packaging for external damage.
If the packaging is seriously damaged or if damage to the contents is evident: do not proceed fur-
ther with opening the packaging; instead immediately inform the transport company and your
supplier.
Remove the packaging and keep it safe for subsequent transport.
Check the contents for evidence of damage in transport.
Check the contents for completeness against the order documentation and keep all delivery doc-
umentation for future reference. The delivery documentation contains important information
about the device and is part of the product.
If you notice any damage in transport or the contents do not match the order: inform the suppliers
immediately.

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
12
2. Safety
Safety-related systems
The use of PLC controls in safety-related systems requires specific measures. If a PLC controller is to
be used in a safety-related system, the user must be given comprehensive advice by the PLC manu-
facturer in addition to any available standards or guidelines regarding safety installations.
Before starting work on the devices, switch off all power supplies, including those of connected
peripherals.
Keep all ventilation openings unobstructed.
The failure of certain components in an electronic control system may result in uncontrolled and/or un-
predictable operational behaviour.
All types of failure must be considered at the system level and the associated preventative
measures identified.
If necessary, request information from your automation system provider.
2.1. Safety instructions
The device may only be operated in a flawless condition. Exposed sharp edges pose a risk of injury.
If you detect damage to the front glass of the device, stop operating the device and immediately
disconnect it from the power supply.
Working on the device
Do not start work on the device until all necessary safety precautions have been taken. Take precau-
tions to avoid unforeseeable functional events and movements of the system.
Bring the system into a safe state.
Switch the system and the device off.
Secure the system against being switched on again.
Disconnect the device from the system.
Do not open the device housing.
If it is necessary to work on internal parts of the device, contact the manufacturer (see
“Addresses”).

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
13
3. Product description
This handbook describes B-Fortis CC-Slim series products.
The B-Fortis CC-Slim is a control module without a display for the control and regulation of machinery
and industrial processes in low-voltage installations in real time.
The development environment CODESYS 3.5 (IEC 61131-3) from 3S-Smart Software Solutions is used
for programming.
B-Fortis CC-Slim controllers can be connected via various interfaces and also have their own digital and
analogue inputs and outputs.
The connections are located on the front of the device. Devices from this series are intended for instal-
lation on a mounting rail in the control cabinet. All the connections are of the plug-in type.

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
14
3.1. Overview of B-Fortis CC-Slim
The CC-Slim is installed on a mounting rail.
Fig. 1: Overview of B-Fortis CC-Slim
No.
Designation
No.
Designation
X1
Power supply, digital inputs/outputs
X12
CAN-Bus (CAN1) (S05 only)
X2
Analogue inputs
S1
Function keys (Reset and Run/Stop)
X3
USB 2.0
S2
CAN terminating resistor (120 Ohm)
X4
Ethernet (ETH0)
S3
RS-485 terminating resistor (120
Ohm)
X5
EtherCAT (ETH1)
S11
CAN terminating resistor (120 Ohm)
X6
RS-232 / RS-485
µSD
microSD card connection (optional)
X7
CAN-Bus (CAN0)
LED
LEDs: PWR, Run/Stop, Error
X8
Debug interface

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
15
3.2. Scope of delivery and accessories
Scope of delivery
→B-Fortis CC Slim in the respective version
→
Accessories
The following accessories can be ordered directly or via the following options:
CC-Slim plug kit:
Order option: – H001
Note: the appropriate plug kit for the respective device is supplied
Order number: S-02020105-0100
Plug kit comprising
→12-pin plug-in connector for the digital inputs/outputs and power supply
Weidmüller BLZF 3.50/12/180 (order number: S-02020201-0600)
→6-pin plug-in connector for the analogue inputs
Weidmüller B2CF 3.50/06/180 (order number: --)
Extensions for tooling and debugging
→USB-to-Ethernet adapter order number: S-02040101-0000
→USB to WLAN adapter EasyConnect order number: S-02040102-0000
3.3. Product features
Assembly
The device is designed for installation in a control cabinet on a DIN mounting rail (35 mm) in pollution
degree 2 industrial environments.
Processor
In its basic configuration, the device is equipped with an 800 MHz ARM® CPU with a Cortex™ A9 core.
Customer-specific variants are available, which instead of a single core processor are equipped with a
dual core or quad core processor.
Ethernet
The device has two 10/100 Mbit/s Ethernet interfaces.
The first Ethernet interface is used for standard Ethernet connections. The TCP/IP and UDP protocols
permit flexible connections to visualisation software, upstream control units and to the IT infrastructure.
The second Ethernet interface is used as an EtherCAT master interface.
Other protocols available for the Ethernet interfaces: PROFINET, BACnet and Modbus.
USB
The USB host interface allows a wide range of peripherals to be connected to the device. This allows a
USB thumb drive to be used for updating the application or for downloading data directly.
USB thumb drives with FAT/FAT32 formatting are supported.
If you require support for other USB formats, please contact our Technical Support team.

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
16
CAN interfaces
B-Fortis devices are available in versions with 1 or 2 standard CAN interface which can be used at a
speed of up to 1 Mbit/s.
Serial interfaces
The device can have 2 serial interfaces (1x RS-485; 1x RS-232).
Onboard analogue inputs/outputs
The device incorporates digital inputs/outputs and analogue inputs.
Additional interfaces
There is also a debugging interface located on the device which is accessible via a 3.5-mm jack plug
with a special cable (contact Customer Services if necessary).
Real-time clock
A software interface permits the current time and date to be set and read on a real-time clock with bat-
tery back-up.
microSD card
The standard commercial microSD card interface allows data to be written to or read from memory
cards.
Summary of features
→ARM® CPU with CortexTM-A9 single core (800 MHz; optional dual core or quad core)
→User program and data memory (RAM): 256 MB onboard
→User program memory (flash) 256 MB onboard
→1 USB host interface (USB 2.0)
→Retain memory 100 kB
→2 Ethernet 10/100 Base T interfaces (2nd interface: EtherCAT master interface)
→1 or 2 CAN interfaces
→2 serial interfaces (1x RS-232; 1x RS-485).
→1 µSD card slot
→Onboard I/O (digital and analogue)
→Real-time clock

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
17
4. Assembly
The B-Fortis CC-Slim is intended for installation on mounting rails according to DIN EN 60715:2001, 35
x 7.5 mm.
CAUTION
Danger of burns!
The surface of the device can get hot.
Ensure that there is sufficient convectional cooling.
There must be at least 50 mm clearance above and below the device.
Fig. 2: Installing the device
Prerequisites:
Ensure that there is also a minimum of 10 mm free space to the next adjacent module.
1st Guide the device from the top towards the mounting rail as shown in the image so that the sup-
port is resting on the mounting rail.
2nd Push the device towards the mounting wall until the retaining spring snaps into place.
The device is clamped on the mounting rail.

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
18
5. Connection
WARNING
Uncontrolled and unpredictable operational behaviour!
The failure of certain components in electronic control systems may result in uncontrolled and unpredictable
operational behaviour.
All types of failure and the associated fuse systems are to be taken into account at system level.
Follow the automation system manufacturer’s instructions.
5.1. Power supply
The device is powered by an external 24 V DC power supply.
Before plugging in the device, make sure that the external power supply meets the required
specifications (type K to DIN EN 61131-2).
External power supply (24 V DC)
Supply voltage
+24 V DC SELV (-15% / +20%)
AC voltage component
Max. 5%
The DC voltage level must not fall below 20.4 V.
Power consumption
Total max. 3.2 A at +24 V DC (1.2 A electronics; 2 A AIO)
Power buffering
10 ms
Internal power supply
A power supply for the system electronics for an input voltage of 24 V DC (-15% / +20%) is integrated
into the device. The power supply unit has built-in reverse polarity protection and surge current protec-
tion (1.2 A).
Installation
All connections and cables should be set up in a way that prevents interference and capacitive
interference to the device.
Make sure that the current and voltage resistance of the supply cables are sufficient.

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
19
5.1.1. Connecting the power supply
CAUTION
Live parts!
Before starting any work on the device, switch off all power supplies, including those of connected
peripherals.
Connect the power supply to plug X1 according to the following table.
Fig. 3: Power supply to the CC-Slim plug X1 with power LED
Power supply plug X1
Pin
Des.
Assignment
1-8
I/O
Digital inputs and outputs (see “Digital inputs and outputs
9
L1+
Feed to digital output (max. 2 A) for I/O
10
L+ 24 V
Power supply 24 V DC (-15%/+20%) (PLC internal processing) max.
1.2 A
11
L+ 24 V
Power supply 24 V DC (-15%/+20%) (PLC internal processing) max.
1.2 A
12
GND
–
The following counterparts have been tested for the SL-SMT 3.5 plug-in connector (Weidmüller), and
may be used with the device:
→BLZF 3.50/12/180

USER MANUAL 1.2 | B-FORTIS CC-SLIM SERIES
Berghof Automation GmbH | Arbachtalstrasse 26 | 72800 Eningen | Germany | www.berghof-automation.com
20
5.2. Data connections
5.2.1. Block diagram
Fig. 4: Overview of B-Fortis CC-Slim
CAN interface X12 only with CC-Slim S05
5.2.2. Digital inputs and outputs
The digital outputs are positive switching 24 V outputs with an output current of max. 500 mA. They
have a common reference potential (GND) with the supply voltage.
NOTICE
Damage to the inputs or the device!
Voltages above ±32 V can damage the inputs or the device.
Do not apply a voltage exceeding ±32 V to the inputs.
