Bessey Seaming Tool PS55 User manual

Specialty Clamping Systems
BESSEY
®Clamping - and Cutting Technology
Effective July 1 2008.

Best clamping - and cutting technology
since 1889.
“One, who stops improving himself, has already
ceased to be good” - we behave and work as per
this guiding principle of Max Bessey, the founder
of our company. Again and again, over 110 years
already. Simply go and see for yourself: An over-
view of our entire range of products - and services
is given in the following pages. Be it clamping - or
cutting technology, BESSEY®offers incomparably
innovative solutions with the proven BESSEY®
quality.
Make the most of our innovative edge and ex-
perience why the following still holds true in our
industry:
“BESSEY®. Simply better.”
Innovative ideas
Our company has been setting new benchmarks
in the field of clamping and cutting technology
since its inception in the year 1889. Based on our
expertise in development, we have been work-
ing on new and innovative ideas for continuous
product improvement. We invent and perfect the
patented brands in our plant in Bietigheim, these
often become models for an entire generation of
clamping and cutting tools.
Often copied, but never duplicated: This applies
to the original BESSEY®malleable cast iron-screw
clamps introduced in 1936, or even to the origi-
nal BESSEY®all-steel-screw clamps that were
patented in 1952.
Highest quality
Our fundamental principle: BESSEY®brands have
been manufactured for constant loads, not for
temporary ones against the comparable prod-
ucts of our competitors. We have distinguished
ourselves and earned the respect of customers for
decades owing to our unrivalled quality.
Our brands are manufactured using the high-
est quality materials. Moreover, all components
are personally checked by our experienced
technicians and developers who apply the most
advanced inspection procedures and testing
methods. We do this for you as a customer using
our products in daily, practical use.
We always guarantee you maximum comfort,
safety, user-friendliness and ergonomics. Numer-
ous certificates as well as longstanding partners
and customers in more than 100 countries all over
the world are the best proof. Prove it to yourself
and try one!
Why buy BESSEY®?
Quality
Innovation
Great value
End-user comfort
Superior engineering
BESSEY®. Simply better.
Discount (Multiplier) From List Price in Catalog
Customer
Category VB0001 VB0002 VB0003 VD0001 &
VD0002

Wide range of products and services.
While browsing through this catalogue, you will
observe that BESSEY®strives to offer you the best
solution for your tasks and applications.
In clamping, as well as cutting technology. From
rigid to flexible clamping, from curved to straight
cutting. From heavy duty clamps to light lever
clamps, from delicate Jewellers’ snips to robust
titanium coated cutters.
Personal service
Reliability, confidence and a sense of responsi-
bility are the backbone of our partnership with
our customers. For many years, we have been
working towards manufacturing exclusive and
practical brands that will simplify your life con-
siderably today - as well as tomorrow. Of late, we
have started supporting our trading partners with
comprehensive product training programs in a
personal and informal atmosphere. Directly on-site
in Bietigheim, in our in-house training centre and,
in the field where our distributors and personnel
work, live and play.
Longstanding global
partners and custom-
ers in more than 100
countries have faith in
BESSEY®quality.
Experienced technicians
and developers person-
ally check every BESSEY®
product.

39
Pipe clamps
nTwin vacuum cups for clamping non-porous,
solid surface material such as granite,
marble, corian, plastic or glass
nLevelling toggles ensure smooth surface
joint, reduces grinding, sanding and finishing
nFor laying parquet, plank and laminate
flooring
n13 ft. strap
n“H” shape foot assembly stabilizes clamp in
two dimensions giving dual-axis stability
nExtra high base provides industry leading
clearance from the work surface
nCast jaws for durability, smooth action spindle
nFast-easy adjusting moveable jaw –
simply slide to work piece and place lock pin
in perforated rail
nRugged construction – cast iron jaw,
steel rail
PS55 Seaming Tool
T-bar sash clamps
“H” style pipe clamp fixtures
Standard pipe clamp fixtures
Flooring strap clamps
BESSEY®
Product #
Clampimg
Capacity
Cup
Diameter
Clamping
Force
Approx.
Weight Case
Inches Inches Pounds Pounds qty.
PS55 2 1/85 48 1/23.80 1
BESSEY®
Product #
Throat
Depth
Clamping
Capacity
Clamping
Force
Approx.
Weight Case
Inches Inches Pounds Pounds qty.
BT-36 2 39 3990 18.00 1
BT-96 2 98 3330 32.00 1
BT-120 2 120 2660 40.00 1
BESSEY®
Product # Black Pipe Diameter Approx. Weight Case
Inches Pounds qty.
BPC-H34 3/43.05 4
BPC-H12 1/22.05 4
BESSEY®
Product # Black Pipe Diameter Approx. Weight Case
Inches Pounds qty.
PC34 3/42.40 20
PC12 1/21.65 20
PC34-DR 3/42.15 12
BESSEY®
Product #
Strap
Lenght
Clamp Plate
Width
Clamping
Force
Approx.
Weight Case
Inches Inches Pounds Pounds qty.
SVH400XL 300 4 3/4220 1.80 5
VSA Suction adapter 1.10 1
SVHD Angle adapter 0.85 1
* BPC comes in retail ready full colour clamshell packaging

Bessey Tools North America
1-800-828-1004 · Fax [phone]
www.besseytools.com
Professional Solid Surface Installation Clamp
03-07-100
Eliminates the need for messy
glue blocks & reduces the amount
of joint clean up required ...a great
time saver!
Cat. Nominal Nominal Nominal Nominal
No. Span Width Length Pressure
A B C
PS55 2.1" 5.1" 9.4" - 11.6" 48.5 lb.
Vacuum Cups … instantly secures the
PS55 to any smooth, non-porous material
such as solid surface, SSV laminate,
polished marble and granite to eliminate
the need for glue blocks. Cup made from
rugged high-pressure aluminum alloy with
the highest quality rubber diaphragm.
Vacuum Operating Lever … activates
and locks the vacuum seal on the work
surface. Quick release. Completely
portable.
Leveling Toggles … this unique feature
easily and accurately levels deck joints
during seaming ... reducing the need for
sanding.
Work Hardened Steel Spindle … smoothly
draws deck seams together with just the
right pressure. Galvanized spindle will
hold up to years of wear.
Oversized Wooden Handle … comfortable
for any hand.
Cold Drawn Guide Rods … create a solid,
rigid frame for supporting vacuum cups
and leveling toggles... minimizing panel
lifting.
BESSEY®PS55 Seaming Tool

BESSEY®Tools North America reserves the right to alter technical
specifications. Some product may vary from region to region to meet the
requirements of the international marketplace.
Errors and omissions excepted, BESSEY®believes that to the best of its
knowledge the product illustrations and descriptions provided in this catalog
are accurate. However, such descriptions and illustrations are for the sole
purpose of identification, and do not express or imply any warranty or
condition that the Products are merchantable, or fit for a particular purpose or
that the products will necessarily conform to the illustrations or descriptions.
Customer is solely responsible for reliance on or use of any information,
and for use or application of any product. BESSEY®expressly disclaims any
liability for direct, indirect, consequential or incidental damages in all events
and for all damages, losses and causes of action beyond the purchase price
paid for the products in question.
WARRANTY POLICY
BESSEY®brand clamping products are warranted under a Limited Lifetime
program. We warranty that the products will be free from defects in material
and workmanship for the life of the tool or we will replace, refund or repair
it; provided that this warranty does not cover any damage caused by abuse,
misuse, improper handling, negligence, alteration or normal wear and tear.
Other tools including but not limited to snips, c-clamps, some specialty
clamps, magnets, bearing heaters and pyrometers are guaranteed for 1 year.
For all products, BESSEY®Tools North America reserves the right to refuse
either a repair or a replacement.
BESSEY®Tools North America makes no other warranties, express or implied,
with respect to the tools or their suitability for specific applications. BESSEY®
Tools North America neither assumes, nor authorizes any person to assume
for it, any other warranty, or obligation express or implied. For a more detailed
listing of Terms, Conditions and Warranty please contact BESSEY®Tools
North America direct and toll-free at 1.800.828.1004.
BESSEY®Tools North America will, at its sole discretion, define if a product
submitted for warranty evaluation is eligible for a warranty return and then,
if eligible, offer either to repair, refund or replace any defective product. To
initiate such a claim, please call and request a return authorization number
then, return all parts of the broken tool(s) plus a written warranty evaluation
request (with contact information) in a freight prepaid format to BESSEY®
Tools North America.
This warranty gives you specific legal rights. Please note: you may also have
other rights, which could vary depending upon state, federal and provincial
law.
CAUTION: Clamping Tools
Clamping tools are not suitable for lifting, pulling or transporting. Improper
use may lead to personal injuries or material damages. They should only be
clamped manually without using any auxiliary tools.
CAUTION: Cutting Technology
Always wear appropriate protection including goggles and gloves while
working. Sheared parts may injure the workers and bystanders. Disconnect
the power supply while working on electrical devices to avoid the risk of
electric shock. Always ensure the cutting direction while using snips, knives
and cutters is away from your body. Only use original replacement parts
whenever required. Tools should only be used manually without using any
auxiliary tools. Improper use use may lead to personal injuries or material
damages.
BESSEY®Tools North America
Cambridge, ON N1R 8E1
P.O.Box 399, Leroy, NY 14482
Toll Free: 800.828.1004
Fax: [phone]
General Email: [email protected]
www.besseytools.com
